Integración domótica Wemo, gratuita y de código abierto
Control Belkin Wemo plugs, switches, dimmers and motion sensors on your local network.
Publicado por prohand
- Dispositivos
- Versión 1.0.1
- Requiere Gladys >=5.1.0
- ★ 0
La documentación de esta integración la escribe su autor y, por ahora, solo está disponible en inglés.
Control your Belkin Wemo devices from Gladys, on your local network: no account, no cloud. Belkin shut its Wemo cloud down on January 31, 2026; local control, the one this integration uses, keeps working.
Supported devices
| Device | In Gladys |
|---|---|
| Wemo Switch, Wemo Mini | On/off switch |
| Wemo Light Switch, 3-Way | On/off light |
| Wemo Dimmer | On/off light + brightness (%) |
| Wemo Insight | On/off + power (W) + energy (kWh) |
| Wemo Motion | Motion sensor |
| Wemo Maker | Relay + input (opening sensor, 1 = closed) |
Not supported: the Wemo Link bridge (and its bulbs) and the Wemo appliances (coffee maker, slow cooker, humidifier…). The most recent models, made for HomeKit only (Thread), do not speak the local Wemo protocol.
Installation
- Install the Wemo integration from the Gladys catalog (Gladys 5.1 or later). The install screen says it asks for an SSDP network search: that is how Gladys finds the Wemo devices for it.
- Open the Discovery tab of the integration: the Wemo devices of your network show up. Add the ones you want.
- That's it: their state shows in Gladys and you can control them.
The Wemo devices must already be on your Wi-Fi (set up earlier with the Wemo
app, or put back on Wi-Fi with a tool such as pywemo).
Configuration
- Wemo addresses — optional. When a Wemo is not found automatically
(another VLAN, a mesh Wi-Fi that filters multicast), type its IP address
here, separated from the others by commas. The port is optional
(
192.168.1.20:49153): without it, the usual Wemo ports (49152 to 49156) are tried. Give these Wemo a fixed IP address (DHCP reservation). - Refresh interval — how often plugs, switches and dimmers are read, in seconds (10 s by default). A change made from the Wemo button shows in Gladys within this delay.
- Motion sensor interval — how often motion sensors are read (2 s by default): the delay before a scene starts on a motion.
- Find a silent Wemo again — when a Wemo stops answering, run a network search to find it again if it changed IP address (at most once every five minutes).
A Wemo often changes port after a reboot: the integration finds it again on its other ports by itself, checking its serial number.
Configuration screen buttons
- Search for Wemo devices — runs the search and lists what was found (and what was not: a silent address, an unsupported device).
- Test the connection — reads every Wemo added to Gladys and tells whether it answers, with its state or the error.
Local / unreachable badge
Each device shows a badge: local when it answers, unreachable after three reads without an answer. The Configuration screen says "No Wemo answers" when none answers any more.
Scenes
In the scene editor (Integrations category):
Triggers
- Wemo motion detected — a Wemo Motion sees a movement (once per
detection). Variable:
{{triggerEvent.data.device_name}}. - Wemo Insight state changed — an Insight switches on, goes to
standby (the plugged appliance has finished: washing machine,
dishwasher…) or switches off. Filter on the new state. Variables:
state(on,standby,off),power(W),device_name. The standby threshold is set in the Wemo app. - Wemo reachable or not — a Wemo stopped answering, or answers again.
Variables:
status(offline,online),device_name.
For a plain on/off, use the standard Gladys "Device state change" trigger.
Actions
- Toggle a Wemo — switches a Wemo off when it is on, on when it is off.
Outputs:
toggled(false when the device has no relay),is_on. - Read a Wemo Insight — outputs:
reachable,state,power(W),today_energy(kWh), to test in the following conditions. - Search for Wemo devices — output:
found(number of Wemo found).
Dashboard
- Wemo devices — every Wemo at a glance: how many answer, what each one does (unreachable ones first), the total power of the Insights, and a Search for Wemo button.
- Wemo Insight — pick an Insight in the widget settings: live power and energy, today's consumption and running time, a 24-hour power curve and an on/off button.
Troubleshooting
- No Wemo found: check they are on the same network as the Gladys machine. Otherwise, type their address in "Wemo addresses".
- "Automatic search unavailable": your Gladys is too old for the network search, or the SSDP permission was refused at install time. Addresses typed by hand still work.
- A Wemo turns unreachable now and then: its Wi-Fi is weak, or it changed address. Reserve it a fixed IP address in your router.
- Logs: from the Gladys interface (or
docker logs), withLOG_LEVEL=debugfor the detail of every read.
Parámetros de configuración
Estos son los parámetros que Wemo te pide en su pantalla de configuración en Gladys.
| Parámetro | Tipo | Obligatorio | Descripción |
|---|---|---|---|
| Getting started | section | No | Wemo devices are controlled on your local network, without any account: the Belkin cloud is no longer needed (it closed in January 2026). Open the Discovery tab to find them, then add the ones you want. A Wemo that is not found automatically can be typed below by its IP address. |
| Wemo addresses | string | No | Optional. IP addresses of Wemo devices the automatic search does not find (another VLAN, mesh Wi-Fi), separated by commas. A port can be added: 192.168.1.20:49153. |
| Refresh interval (s) | number | No | How often plugs, switches and dimmers are read, in seconds. A change made from the Wemo button or app shows in Gladys within this delay. |
| Motion sensor interval (s) | number | No | How often motion sensors are read, in seconds: the delay before a scene starts on a motion. |
| Find a silent Wemo again | boolean | No | When a Wemo stops answering, search the network for it (it may have a new IP address). At most once every five minutes. |
Cómo instalar Wemo en Gladys
- En Gladys, abre Integraciones: Wemo aparece en el catálogo junto a las integraciones nativas, con una insignia de comunidad.
- Haz clic en Instalar. Gladys descarga la imagen Docker (
ghcr.io/prohand/gladys-wemo:1.0.1), la ejecuta en un entorno aislado del núcleo y genera la interfaz de la integración (dispositivos, descubrimiento y configuración). - Abre la pantalla de Configuración de la integración, rellena los parámetros y guarda.
- También puedes instalarla directamente desde la URL de su repositorio: https://github.com/prohand/gladys-wemo.
Wemo requiere Gladys >=5.1.0. El catálogo de Gladys se actualiza cada hora, así que una nueva versión está disponible como máximo una hora después de publicarse.
¿Todavía no usas Gladys? Es gratuito y de código abierto: sigue la guía de instalación para empezar.
Sobre las integraciones externas
Wemo es una integración externa: una integración comunitaria empaquetada como contenedor Docker y publicada en GitHub. Gladys la instala con un clic y la ejecuta en un entorno aislado del núcleo. La publica y mantiene prohand, no el equipo principal de Gladys.
- Explorar todas las integraciones externas
- Descubrir las integraciones nativas incluidas en Gladys
- Crear y publicar tu propia integración externa
- Código fuente en GitHub — fuente de esta documentación
