Integración domótica UptimeRobot, gratuita y de código abierto

Integración UptimeRobot para Gladys Assistant

Your UptimeRobot monitors: online or down, response time, uptime over 24 h, 7 and 30 days.

Ver en GitHubTodas las integraciones
info

La documentación de esta integración la escribe su autor y, por ahora, solo está disponible en inglés.

Your UptimeRobot monitors in Gladys, through the official UptimeRobot API and an API key of your account. Each monitor becomes a Gladys device:

  • Online: 1 up, 0 down (confirmed by UptimeRobot); nothing while the monitor is paused or not checked yet;
  • Status: up, seems_down (looks down, not confirmed yet), down, paused or not_checked;
  • Response time: the latest response time measured, in milliseconds;
  • Uptime 24 h (%), Uptime 7 days (%) and Uptime 30 days (%): the availability of the last 24 hours, 7 and 30 days;
  • the Pause monitoring and Resume monitoring buttons, only when you allow them (see Pause and resume).

The type of the monitor (HTTP(s), Keyword, Ping, Port, Heartbeat) and its target show in the parameters of the device: only the scheme and the host (e.g. https://example.com), never the path, the query nor credentials of the address, and never the secret address of a Heartbeat monitor.

This integration has never been tested with a real UptimeRobot account. This first version was written from the official documentation of the UptimeRobot API, and only tested against a fake UptimeRobot. Tell on the Gladys forum what works and what does not.

Unofficial integration, not affiliated with UptimeRobot.

Gladys only needs to read: use the read-only API key, which can neither change nor delete your monitors.

  1. Sign in on uptimerobot.com.
  2. Open Integrations & API, then the API section.
  3. On the Read-only API key line, click Create (or show the existing key) and copy it.
  4. Paste it in the API key field of the integration and save.

The main API key works too, but it can change anything in the account: give it only if you want pause and resume. A monitor-specific API key reads that monitor only.

The key is kept by Gladys in its database, never shown again, sent only to api.uptimerobot.com, in the body of the requests (never in an address, never in a log, never in the /data volume).

Configuration​

  • API key: see above.
  • Monitors (optional): the ids of the monitors to follow (the digits at the end of the address of a monitor on the dashboard), separated by commas, 50 at most. Empty: every monitor of the account, 200 at most.
  • Refresh: every 5 minutes by default (from every minute to every hour). Each reading makes one request per 50 monitors. The free plan checks your sites every 5 minutes: reading more often only helps on a paid plan.
  • Allow pausing and resuming monitors: off by default.

Then open the Discovery tab and create the monitors to follow.

Scene triggers​

  • Monitor down: UptimeRobot confirmed a monitor down (down) while it was up at the previous reading.
  • Monitor back up: a monitor confirmed down at the previous reading is up again.

Both can target one monitor (empty: any) and give the scene the name and the type of the monitor. They never fire:

  • on the first reading (start, restart, new configuration) nor for a monitor that just appeared;
  • after a long gap: when the previous reading is more than two intervals old (plus a minute), the change only becomes the new reference;
  • on "seems down" (seems_down): UptimeRobot has not confirmed it yet;
  • after a pause or a resume.

The scene starts up to one refresh interval after the change.

Pause and resume​

By default Gladys only reads. Once Allow pausing and resuming monitors is ticked, each monitor gets two buttons, Pause monitoring and Resume monitoring (press Update in Discovery to add them to a device already created). They are never switches: no voice assistant nor "turn everything off" can pause your monitors.

  • It needs the main API key: UptimeRobot refuses a pause with a read-only key, and Gladys says so.
  • A paused monitor no longer alerts you.
  • Unticking the option takes effect at once; the buttons stay on the devices (never breaking the history) but are refused.
  • When the command cannot leave within 3.5 s, nothing is sent. A command sent without an answer in time (or with a server error) fails with "The command was sent but UptimeRobot did not confirm it" (never "nothing was sent"): the next reading shows the result.
  • A "too many requests" refusal (HTTP 429) shows "UptimeRobot refused the command (HTTP 429, too many requests): not done": the command was not done, and every request stops for the pause given.

Usage limits and connection problems​

  • The free plan of UptimeRobot admits 10 requests per minute (API documentation). Gladys sends 8 at most per minute, every request counted (readings and buttons): beyond, a button is refused without sending anything ("Too many requests to UptimeRobot this minute"), and the reading waits a minute (status "Waiting for the request budget of the minute", or a message of its own for Test the connection).
  • Restart: after a successful reading, Gladys reads again at once, but never within a minute of the last request (restarts in a loop never exceed the limit). After a failure, a pause or a spent budget, the planned wait is kept (one interval at most); the status says so ("Restarted: … Reading in N min."). Test the connection reads at once.
  • API v2 retired (HTTP 404 or 410): the status says so ("it may have been retired. Update the integration."); Gladys retries less and less often.
  • Key refused: Gladys does not try again by itself, even after a restart. Paste the key and save, or press Test the connection.
  • UptimeRobot overloaded (HTTP 429) or server error (HTTP 5xx): every request stops, for the chosen interval at least (429: from 1 minute to 6 hours, what UptimeRobot asks for), even after a restart; saving the configuration or pressing Test the connection lifts the pause.
  • UptimeRobot unreachable: retried at the chosen interval, then less and less often up to one hour. The devices show unreachable meanwhile.

Limits​

  • One UptimeRobot account per integration, 200 monitors at most (the monitors already created come first; the connection status says how many are left out).
  • Gladys admits 300 states per minute: with many monitors, the first publication can take a few minutes.
  • The uptimes in % have no unit in Gladys (the core has no "availability" category): 99.95 means 99.95 %.
  • The response time is published only when less than 2 hours old.
  • Status pages, maintenance windows and alert contacts are not followed.

Parámetros de configuración​

Estos son los parámetros que UptimeRobot te pide en su pantalla de configuración en Gladys.

ParámetroTipoObligatorioDescripción
How it workssectionNoGladys reads your UptimeRobot monitors through the official UptimeRobot API, with an API key of your account. Each monitor becomes a Gladys device (Discovery tab): online or down, status, latest response time, uptime of the last 24 hours, 7 and 30 days, and its type and host (never the full URL). Two scene triggers: "Monitor down" and "Monitor back up". Use the read-only API key: on uptimerobot.com, Integrations & API, API, then create the "Read-only API key". Unofficial integration, not affiliated with UptimeRobot.
API keysecretSíThe read-only API key is recommended (it can only read). Pause and resume need the main API key. Kept by Gladys in its database, never shown again, sent only to api.uptimerobot.com, in the body of the requests.
Monitors (optional)stringNoIds of the monitors to follow (the digits at the end of the address of a monitor on the dashboard), separated by commas, 50 at most. Empty: every monitor of the account, 200 at most.
RefreshselectSíHow often Gladys reads UptimeRobot (one request per 50 monitors). The free plan checks every 5 minutes and admits 10 requests per minute: reading more often only helps on a paid plan.
Pause and resumesectionNoBy default Gladys only reads. Once allowed below, each monitor gets two buttons, "Pause monitoring" and "Resume monitoring" (never a switch: no voice assistant nor "turn everything off" can touch them). A paused monitor no longer alerts you: it needs the main API key, a read-only key is refused by UptimeRobot.
Allow pausing and resuming monitorsbooleanNo

Cómo instalar UptimeRobot en Gladys​

  1. En Gladys, abre Integraciones: UptimeRobot aparece en el catálogo junto a las integraciones nativas, con una insignia de comunidad.
  2. Haz clic en Instalar. Gladys descarga la imagen Docker (ghcr.io/lm1lc3n7/gladys-uptimerobot:0.1.1), la ejecuta en un entorno aislado del núcleo y genera la interfaz de la integración (dispositivos, descubrimiento y configuración).
  3. Abre la pantalla de Configuración de la integración, rellena los parámetros y guarda.
  4. También puedes instalarla directamente desde la URL de su repositorio: https://github.com/LM1LC3N7/gladys-uptimerobot.

UptimeRobot requiere Gladys >=5.1.0. El catálogo de Gladys se actualiza cada hora, así que una nueva versión está disponible como máximo una hora después de publicarse.

¿Todavía no usas Gladys? Es gratuito y de código abierto: sigue la guía de instalación para empezar.

Sobre las integraciones externas​

UptimeRobot es una integración externa: una integración comunitaria empaquetada como contenedor Docker y publicada en GitHub. Gladys la instala con un clic y la ejecuta en un entorno aislado del núcleo. La publica y mantiene LM1LC3N7, no el equipo principal de Gladys.
