Integración domótica TRMNL, gratuita y de código abierto

TRMNL e-ink displays: battery, Wi-Fi signal and sleep mode of each display.

• Publicado por LM1LC3N7
• Dispositivos
• Versión 0.1.1
• Requiere Gladys >=5.1.0
• ★ 0

Ver en GitHubTodas las integraciones

info

La documentación de esta integración la escribe su autor y, por ahora, solo está disponible en inglés.

Brings the TRMNL e-ink displays of your account into Gladys, through the official TRMNL account API: battery, Wi-Fi and sleep mode of each display.

Never tested with a real device. This integration was written from the trmnl Python client (the one of the Home Assistant integration) and tested against a simulated TRMNL API only. Unofficial, not affiliated with TRMNL.

What you get

One device per display (Discovery tab), keyed by its TRMNL id:

• Battery (%), and battery voltage (V);
• Wi-Fi strength (0 to 100, as TRMNL rates it) and Wi-Fi signal (dBm);
• Sleep mode (on or off) and sleep hours (for example 22:00-08:00, in the time zone of your TRMNL account);
• as an option, two buttons: "Turn the sleep mode on" and "Turn the sleep mode off" (see below).

What the screen shows (playlists, plugins) stays managed in TRMNL. The API gives no "last contact" time of a display: it is not shown.

Getting started

1. On trmnl.com, open Account and copy the API key of your account (it starts with user_).
2. In Gladys, open this integration, paste the key and save. The key is kept by Gladys in its database, never shown again, and sent only to trmnl.com, in the Authorization header of the requests.
3. Your displays appear in the Discovery tab: create the ones you want.

How often it reads

• One request for all the displays, every refresh interval (15 minutes by default, from 5 minutes to 1 hour). A display reports its battery and signal when it wakes up: reading more often rarely shows more.
• Never faster than the interval: neither Gladys reconnecting, nor a configuration saved unchanged, nor the Discovery button, nor "Test the connection", nor a restart of the container (the time of the last attempt is kept) adds a reading. A new key is tried one minute at most after the last attempt.
• After an error, a new try after the interval, then twice that, up to 1 hour.
• 429 (TRMNL asks to slow down) or 5xx: a pause of what TRMNL asks, else 15 or 5 minutes, between 1 minute and 6 hours, kept across restarts. No reading and no command during the pause.
• Key refused (401): no automatic try any more, restarts included. Paste a new key (generated again on trmnl.com; saving the same key again does nothing), or press "Test the connection" once the interval has passed: the refusal is erased only by a successful reading. A 403 (it may come from the network protecting trmnl.com) is not a refusal of the key: tried again like any other error.
• After a restart that follows a successful reading, the integration shows "connected" at once, until the next reading.

Sleep mode buttons (off by default)

Tick "Allow changing the sleep mode of the displays" in the configuration. Each display then gets two buttons (never a switch: no voice assistant nor "turn everything off" can reach them). Each press:

1. reads the display from TRMNL again (and checks it is the same display: MAC address and friendly id); when it already is in the mode asked, nothing is sent;
2. checks again that the option is still ticked, then changes the sleep mode;
3. reads the display back: the command is said done only when TRMNL shows the new value. Otherwise: "Command sent, without confirmation" (the next reading shows the real mode).

Nothing is sent later than 3.5 seconds after the press (Gladys waits 5 seconds), nor during a 429/5xx pause; 6 commands per minute at most.

Questions to testers

If you own a TRMNL display, tell us (forum, or a GitHub issue): do the battery, voltage and signal match what trmnl.com shows? Do the sleep mode buttons act on the display?

Data and privacy

The integration only talks to trmnl.com. It keeps in its /data volume: a random key, the fingerprint (HMAC) of a refused key (erased at the first success; never a fingerprint of a key that works), the end of a pause, the time of the last attempt, and the list of displays (id, name, friendly id, MAC address). It does not read your profile (name, e-mail).

Parámetros de configuración

Estos son los parámetros que TRMNL te pide en su pantalla de configuración en Gladys.

Parámetro	Tipo	Obligatorio	Descripción
Your TRMNL account	section	No	Brings the TRMNL e-ink displays of your account into Gladys, through the official TRMNL account API (trmnl.com) and the API key of your account: for each display its battery (charge and voltage), its Wi-Fi strength and signal, its sleep mode and sleep hours. Read every refresh interval, never faster. Optional buttons turn the sleep mode on or off (off by default, see below). What the screen shows (playlists, plugins) stays in TRMNL. Never tested with a real device. Unofficial, not affiliated with TRMNL.
API key of your account	secret	Sí	On trmnl.com, Account, the "API key" of your account (it starts with user_). Kept by Gladys in its database, never shown again, sent only to trmnl.com, in the Authorization header of the requests.
Refresh	select	Sí	How often Gladys reads TRMNL (one request for all the displays). A display reports its battery and signal when it wakes up, often every 15 minutes: reading more often rarely shows more.
Language of the names	select	No	Used for the names of the features added from now on.
Sleep mode buttons	section	No	By default Gladys only reads. Once allowed below, each display gets two buttons, "Turn the sleep mode on" and "Turn the sleep mode off" (never a switch: no voice assistant nor "turn everything off" can reach them). Each press reads the display first, changes its sleep mode in your TRMNL account, then reads it back: it is said done only when TRMNL shows the new value.
Allow changing the sleep mode of the displays	boolean	No

Cómo instalar TRMNL en Gladys

1. En Gladys, abre Integraciones: TRMNL aparece en el catálogo junto a las integraciones nativas, con una insignia de comunidad.
2. Haz clic en Instalar. Gladys descarga la imagen Docker (ghcr.io/lm1lc3n7/gladys-trmnl:0.1.1), la ejecuta en un entorno aislado del núcleo y genera la interfaz de la integración (dispositivos, descubrimiento y configuración).
3. Abre la pantalla de Configuración de la integración, rellena los parámetros y guarda.
4. También puedes instalarla directamente desde la URL de su repositorio: https://github.com/LM1LC3N7/gladys-trmnl.

TRMNL requiere Gladys >=5.1.0. El catálogo de Gladys se actualiza cada hora, así que una nueva versión está disponible como máximo una hora después de publicarse.

¿Todavía no usas Gladys? Es gratuito y de código abierto: sigue la guía de instalación para empezar.

Sobre las integraciones externas

TRMNL es una integración externa: una integración comunitaria empaquetada como contenedor Docker y publicada en GitHub. Gladys la instala con un clic y la ejecuta en un entorno aislado del núcleo. La publica y mantiene LM1LC3N7, no el equipo principal de Gladys.

• Explorar todas las integraciones, nativas y de la comunidad
• Crear y publicar tu propia integración externa
• Código fuente en GitHub — fuente de esta documentación
