Integración domótica TickTick, gratuita y de código abierto
Shows your TickTick tasks on the dashboard and lets scenes create tasks or react to due ones.
Publicado por cicoub13
- Dispositivos
- Versión 0.1.1
- Requiere Gladys >=5.1.0
- ★ 0
La documentación de esta integración la escribe su autor y, por ahora, solo está disponible en inglés.
Requires Gladys 5.1 or later. This integration is made of a dashboard widget and scene triggers and actions, which ship with Gladys 5.1; on an earlier version it cannot be installed.
Bring your TickTick tasks into Gladys: a dashboard widget with the tasks due today and the overdue ones, a scene action to create a task (from a button, a voice command, a sensor...), another one to read your tasks out loud or send them in a notification, and a scene trigger that fires when a task reaches its due time.
Requirements
- A TickTick account (free or Premium).
- Internet access from the machine running Gladys: the integration talks to the TickTick cloud API.
Connecting your account
- Open the TickTick developer site, sign in with your TickTick account and click New App. Any name will do, e.g. "Gladys".
- Open the new app and click Edit. In OAuth redirect URL, paste the
redirect URI shown in the Gladys configuration screen, under the
Connect button (usually
https://my.gladysassistant.com/redirect/oauth), and save. Without it, TickTick answers "At least one redirect_uri must be registered with the client". - Copy the app's Client ID and Client secret into the Gladys configuration screen and click Save, at the bottom of the form.
- Only then click Connect: the button does not save the form, and the integration only sees saved values. TickTick asks you to allow access to your tasks. Accept. You are brought back to Gladys, and the status turns to connected.
The access granted lasts several months. When TickTick ends it, the status of the integration says so: click Connect again.
Configuration
| Field | Description |
|---|---|
| Client ID / secret | From your TickTick developer app. |
| TickTick account | The Connect button, once the Client ID and secret are saved. |
| Refresh frequency | How often TickTick is read: 1 minute, 5 minutes (default) or 15 minutes. |
| Hour for all-day tasks | Hour (0-23, default 9) at which the "TickTick task due" trigger fires for a task that has a day but no time. |
Test the connection checks the access and shows how many lists were found. It also resumes the refresh after a refused access was fixed.
Dashboard widget
Add the TickTick tasks widget to a dashboard. It shows:
- two counters: overdue tasks and tasks due today;
- up to 8 tasks, overdue first, with their list, due time and priority. Tap a task to see its notes and a link to open it in TickTick;
- a line saying how many more tasks did not fit.
The Tasks shown setting of each widget chooses between Today and overdue (default), Today, Overdue and Next 7 days and overdue.
Tasks without a date are never shown. Tasks are completed in TickTick, not from the widget.
Scenes
Trigger: TickTick task due
Fires when an undone task reaches its due time: at its time for a task with a
time, at the Hour for all-day tasks for a task with only a day. Optional
filters: the priority, and the list (its exact name, Inbox for the
inbox).
Variables for the next actions: title, list_name, priority (none,
low, medium, high), due_date (YYYY-MM-DD), due_time (HH:MM, empty
for an all-day task), all_day and content (the task notes).
The schedule follows the refresh: a task created or moved less than one refresh period before its due time may be missed. A task already past due when Gladys starts does not fire.
Action: Create a TickTick task
- Title (required, can use scene variables);
- List: name of a TickTick list, case does not matter. Empty or unknown: the inbox;
- Due: no date, today or tomorrow, with an optional Due time (
18:30); without a time the task is for the whole day; - Priority: none, low, medium or high.
Outputs: task_id and list_name (the list the task landed in).
Action: Get TickTick tasks
Reads the tasks of a scope (same choices as the widget) from the last refresh.
Outputs: count, titles (one task per line, with its time when it has one),
and the first task's next_title, next_list, next_due_date and
next_due_time. Example: every morning at 7:30, if count is above 0, send
"Today: {{titles}}" in a notification.
Troubleshooting
| Message | What to do |
|---|---|
| Connect your TickTick account | Nothing is connected yet: follow "Connecting your account". |
| No saved Client ID / No saved Client secret | Fill them in and click Save before clicking Connect. |
| There was an error starting the connection (Gladys) | Gladys does not show the cause: it is in the integration logs ("TickTick connection failed"). Usually the Client ID was not saved. |
| TickTick refused the access | The access was revoked or expired: click Connect again. Refreshing waits until then. |
| The TickTick authorization expired or does not match | More than 15 minutes passed on the TickTick page, or the integration restarted meanwhile: click Connect again. |
| TickTick: At least one redirect_uri must be registered | Your developer app has no OAuth redirect URL: set it to the redirect URI shown in Gladys (step 2). |
| TickTick says the redirect URL is invalid | The OAuth redirect URL of your developer app must be exactly the redirect URI shown in Gladys. |
| TickTick cannot be reached / did not answer in time | Check the Internet connection of the Gladys machine. The integration retries at every refresh. |
| TickTick limits the number of requests | Choose a longer refresh frequency. |
The integration logs (Supervision tab of the integration) give the details of every failure; your token never appears in them.
Parámetros de configuración
Estos son los parámetros que TickTick te pide en su pantalla de configuración en Gladys.
| Parámetro | Tipo | Obligatorio | Descripción |
|---|---|---|---|
| Connect your TickTick account | section | No | 1. On the TickTick developer site, create an app (Manage Apps > New App). 2. In its settings, set the OAuth redirect URL to the redirect URI shown below the Connect button. 3. Copy its Client ID and Client secret here and click Save (bottom of the form). 4. Only then click Connect. |
| Client ID | string | No | |
| Client secret | secret | No | |
| Click Save before Connect | section | No | The Connect button does not save the form: after entering the Client ID and Client secret, first click Save at the bottom of the form, then come back here and click Connect. |
| TickTick account | oauth2 | No | |
| Settings | section | No | How often TickTick is read, and when the "Task due" scene trigger fires for tasks without a time. |
| Refresh frequency | select | No | |
| Hour for all-day tasks | number | No | Hour of the day (0-23) at which the "Task due" trigger fires for an all-day task. |
Cómo instalar TickTick en Gladys
- En Gladys, abre Integraciones: TickTick aparece en el catálogo junto a las integraciones nativas, con una insignia de comunidad.
- Haz clic en Instalar. Gladys descarga la imagen Docker (
ghcr.io/cicoub13/gladys-ticktick:0.1.1), la ejecuta en un entorno aislado del núcleo y genera la interfaz de la integración (dispositivos, descubrimiento y configuración). - Abre la pantalla de Configuración de la integración, rellena los parámetros y guarda.
- También puedes instalarla directamente desde la URL de su repositorio: https://github.com/cicoub13/gladys-ticktick.
TickTick requiere Gladys >=5.1.0. El catálogo de Gladys se actualiza cada hora, así que una nueva versión está disponible como máximo una hora después de publicarse.
¿Todavía no usas Gladys? Es gratuito y de código abierto: sigue la guía de instalación para empezar.
Sobre las integraciones externas
TickTick es una integración externa: una integración comunitaria empaquetada como contenedor Docker y publicada en GitHub. Gladys la instala con un clic y la ejecuta en un entorno aislado del núcleo. La publica y mantiene cicoub13, no el equipo principal de Gladys.
