Integración domótica Tesla Wall Connector, gratuita y de código abierto
Tesla Wall Connector gen 3 leído en su red local: potencia, energía, estado de carga.
Publicado por guim31
- Dispositivos
- Versión 1.3.0
- Requiere Gladys >=5.1.0
- ★ 0
La documentación de esta integración la escribe su autor y, por ahora, solo está disponible en inglés.
Follow your Tesla Wall Connector gen 3 in Gladys: charger and charging state, power, session energy and total energy delivered, voltage, current, handle temperature. The charger is read directly on your home network: no Tesla account, no cloud, no subscription.
Tested on a gen 3 charger on a single-phase supply; three-phase not tested. A user tried it on their charger, with a Tesla and a plug-in hybrid of another make: search, power (checked against the Tesla app and a meter), consumption and cost. Three-phase and the North American split-phase supply have not been checked on a real charger yet. If something looks wrong, say so on the Gladys forum.
This integration is not affiliated with Tesla, Inc.
What you need
- Gladys 5.1 or later.
- A Wall Connector gen 3 (the Wi-Fi model), connected to your Wi-Fi (Tesla One app). The gen 2 and the Universal Wall Connector have no such local API and are not supported.
- Gladys and the charger on the same home network.
Getting started
- Install the integration from the catalog, then open its Configuration tab.
- Tell it where the charger is, either way:
- you know its IP address (in your router's interface): type it in Wall Connector addresses (several chargers: separated by commas), save;
- you do not: press Search for Wall Connectors at the bottom of the page (see Automatic search).
- Open the Discovery tab and add the charger.
- Optional: press Test the Wall Connectors: each address shows the end of the charger's serial number, its firmware and its state, or why it does not answer.
Give the charger a fixed address in your router, so it does not change. The charger is identified by its serial number: if its address changes anyway, type the new one (or search again) and the same device carries on, with its history.
Settings
| Setting | Role |
|---|---|
| Wall Connector addresses | IP address (or host name) of each charger, separated by commas. The search fills it in too. |
| Search range (advanced) | Usually left empty: the search takes the network of Gladys. Otherwise a network (192.168.1.0/24), a range (192.168.1.10-192.168.1.60) or addresses, separated by commas. Private addresses only, 1,024 at most. |
| Temperature unit | Unit of the handle temperature as scenes compare it: automatic (°F on a North American charger, else °C), °C or °F. The dashboard always converts. |
| Device names language | English, French, German or Spanish feature names for new devices. Gladys keeps a feature's name once the device is created. |
Automatic search
The Wall Connector does not announce itself on the network (no mDNS, no SSDP:
Home Assistant finds it through the DHCP server, which Gladys does not offer to
integrations). The Search for Wall Connectors button therefore tries each
address of a range: a quick connection to port 80 of each, then a call to the
charger API (/api/1/version and /api/1/vitals) on the few addresses that
answered, keeping only the answers shaped like a Wall Connector's.
The chargers found are added to the configuration and read at once: they show up in the Discovery tab. A known charger found at a new address replaces its old address. Reload the page before saving the configuration form again, or it would put back the old addresses.
Which range? The integration runs in an isolated container, on a Docker
network of its own: it cannot see directly which network Gladys is on. So it
asks Gladys: Gladys runs an SSDP search on your home network (the only
network capture the integration asks for, shown at install time) and the
devices answering (internet box, TV, speaker…) give the network, such as
10.0.0.0/24. Without a Search range, the search tries, in this order:
- the network of the chargers already configured;
- the network of Gladys, found that way (the search message shows it: "Network of Gladys: 10.0.0.0/24");
- if no device answered Gladys:
192.168.1.0/24and192.168.0.0/24, the most common home networks, and the message says so.
The Search range setting is only needed when the charger is on another
network than Gladys, or the search picks the wrong one. The "Searching the
network" block of the configuration shows the address your browser reaches
Gladys by: if it is 192.168.1.20, the range of that network is
192.168.1.0/24 (addresses 192.168.1.1 to 192.168.1.254).
A search takes a few seconds to a minute. It never leaves the home network: only private addresses are accepted, 1,024 at most. When no charger answers, the result shows in red, with what to check.
What you get
| Feature | Details |
|---|---|
| Connector | Available, occupied (a car is plugged in), unavailable, faulted |
| Charging state | Charging, vehicle connected, paused (car or charger), idle (also as soon as the car is unplugged) |
| Status | The charger's own state in words (see States) |
| Charging power | W |
| Session energy | kWh delivered since the car was plugged in |
| Total energy delivered | Cumulative index in kWh, for the energy monitoring of Gladys |
| Grid voltage, current | V, A |
| Handle temperature | °C or °F (Temperature unit setting) |
Everything is read-only: the charger's local API does not start, stop or limit a charge (do it from the car or the Tesla app).
The charger is read every 15 seconds (the total counter every minute), and only what changes is sent to Gladys. After three missed reads in a row, the charger shows as unreachable (badge on the device).
History. Gladys keeps every value it receives. The grid voltage, the current, the handle temperature and the power move a little at every read, so they are sent only when they change significantly since the last value sent:
| Measurement | Sent when it moves by |
|---|---|
| Charging power | 50 W, or 2 % during a charge (150 W at 7.4 kW); and back to 0 W |
| Vehicle current | 0.5 A; and back to 0 A |
| Grid voltage | 2 V |
| Handle temperature | 1 °C (1.8 °F) |
Each one is also sent again once an hour, even if it did not move, so Gladys never sees it as stale. Expect a few dozen values a day for each of them, plus some during a charge, instead of one every 15 seconds (5,760 a day). The widget's power and current tiles show these values; its session tile and total row are read directly from the charger.
The charger reports voltages and currents, not the power: it is computed phase by phase (three-phase in Europe), or as voltage × current on a North American 240 V split-phase supply (recognized by its 60 Hz grid).
Charger states
The charger reports a state number (evse_state). Their meaning comes from
Home Assistant, corrected by what a user read on their single-phase charger
(October 2026):
| State | Status shown | What was seen |
|---|---|---|
| 1 | Vehicle not connected | No car |
| 4 | Ready to charge | Tesla plugged in, not charging |
| 7 | Plugged in, outside charging schedule | Tesla plugged in outside its charging schedule: normal, not a fault |
| 8 | Charging finished | (not seen) |
| 9 | Waiting for the car | Tesla plugged in, schedule open; also after a charge stops |
| 10 | Charging (likely non-Tesla) | The non-Tesla car charging |
| 11 | Charging | The Tesla charging |
| 12 | Plugged in (likely non-Tesla) | The non-Tesla car being plugged in |
| 13 | Session ending (likely non-Tesla) | End of charge and unplugging of the non-Tesla car |
| 21 | Session ending | The Tesla being unplugged |
State 7 shows as an Error (connector "faulted", red in the widget) only
when no car is plugged in or the charger raises an alert (current_alerts).
Tesla or another car? States 10, 12 and 13 were only seen with the car of another make, and 4, 9, 11 and 21 only with the Tesla. That comes from a single test: the status therefore says "likely non-Tesla", no more.
Energy monitoring
The total energy delivered is the charger's own counter. Gladys computes the consumption per half hour and its cost from it, and files it under your main electric meter: the charger is a sub-meter of your main meter, since its energy goes through it too.
In a consumption widget, do not tick both the main meter and the charger if you want a correct total: the charger's energy would be counted twice. Show them in two widgets, or tick the main meter alone for the house total.
Dashboard
The Tesla Wall Connector widget (Gladys 5.1+), set with the charger to show:
- at the top, three tiles side by side: charging power, current, and the energy of This session while a car is plugged in, Last session otherwise (the charger keeps the energy of the finished session), in kWh with one decimal;
- below, the Total delivered, in whole kWh (in MWh from 100,000 kWh; the feature keeps the exact value);
- the state of the charger and of the car and, with a car plugged in, Plugged in for (counted by the charger from the plug-in) and Charging time (followed by the integration: the time the charger actually delivered power during this plug-in, reset when the car is unplugged).
The total is a row under the tiles, not a fourth tile: Gladys 5.1.4 puts all the tiles of a widget in a single row that wraps after three of them, and has no setting for the number of columns, so four tiles would show as three plus one.
No button: the local API is read-only.
Scenes
Triggers, each one can be limited to one charger, with the session energy in kWh:
- Wall Connector: car plugged in (outside the charging schedule too)
- Wall Connector: car unplugged
- Wall Connector started charging
- Wall Connector charging finished: the charge stops while the car stays plugged in (charge complete, schedule closed…) or ends with the unplugging (states 13 and 21)
They only fire on an observed change: a restart of the integration neither replays nor loses an event. Every feature above also works in scenes the usual way ("when the charging power goes above 7,000 W"…).
Were you using the charger in the Tesla/Teslemetry integration?
The charger had been added to the Tesla integration (version 1.1.0), which is mostly for cars and Powerwall through the Teslemetry service. It now has its own integration, this one, as in Home Assistant. The reading code is the same, and so are the features, the trigger names and the widget.
Gladys ties each device to its integration: the charger of this integration is therefore a new device, and the history of the old one is not carried over. To move from one to the other:
- Install this integration, type the charger address (the same as in the Tesla integration) or press Search for Wall Connectors, then add the charger from the Discovery tab.
- Update your scenes, widgets and energy monitoring: pick the triggers of this integration (same names), the Tesla Wall Connector widget of this integration, and the new charger in the consumption widgets.
- Remove the old charger: in the Tesla integration, empty the Wall Connector addresses field and save, then delete the old Wall Connector device. Deleting the device deletes its history too: keep it as long as you need it.
Both integrations can read the charger at the same time without trouble for it, but the energy would then be counted twice in the energy monitoring, and the triggers would fire twice: keep the charger on one side only. If you only used the Tesla integration for the charger, you can uninstall it.
Troubleshooting
- "No Wall Connector answers": check the IP address in your router and that the charger is on the Wi-Fi (Tesla One app), then press Test the Wall Connectors.
- The search finds nothing: look at the network it searched (in its message); if it is not the charger's, give it in Search range (see above). A charger on another network (a separate "IoT" Wi-Fi, a VLAN) is searched with that network's range, if Gladys can reach it. A strict firewall on the Gladys machine (ufw) can also block the integrations' traffic to the home network.
- The charger answers slowly: common with this firmware; the integration waits up to 10 seconds and only flags it unreachable after three failures in a row.
- The integration logs what it does (searches, charger answers): open its logs from the integration's tab in Gladys.
Parámetros de configuración
Estos son los parámetros que Tesla Wall Connector te pide en su pantalla de configuración en Gladys.
| Parámetro | Tipo | Obligatorio | Descripción |
|---|---|---|---|
| Antes de empezar | section | No | Para el Tesla Wall Connector gen 3 (el modelo wifi). Se lee directamente en su red local: sin cuenta Tesla, sin nube, sin suscripción. El cargador debe estar conectado a su wifi (aplicación Tesla One). Introduzca su dirección IP más abajo o pulse «Buscar Wall Connectors» al final de esta página. Asígnele una dirección fija en su router para que conserve siempre la misma. |
| Direcciones de los Wall Connectors | string | No | Dirección IP (o nombre de host) de cada Wall Connector, separadas por comas. La búsqueda también la rellena. |
| Búsqueda en la red (avanzado) | section | No | El cargador no se anuncia en la red, así que la búsqueda prueba cada dirección de la red en la que está Gladys: Gladys pide a los dispositivos de su red local (router, televisor…) que respondan a una búsqueda SSDP y deduce la red a partir de sus direcciones. También prueba la red de los cargadores ya configurados. Solo si su cargador está en otra red, indique el rango más abajo. Su navegador accede a Gladys en {{gladys_host}}: si es una dirección como 192.168.1.20, el rango de esa red es 192.168.1.0/24 (todas las direcciones de 192.168.1.1 a 192.168.1.254). |
| Rango de búsqueda (avanzado) | string | No | Déjelo vacío para buscar en la red de Gladys. Si no, una red (192.168.1.0/24), un rango (192.168.1.10-192.168.1.60) o direcciones, separadas por comas. Solo direcciones privadas, 1024 como máximo. |
| Unidad de temperatura | select | No | Unidad de la temperatura de la empuñadura, tal como la comparan las escenas. El panel siempre convierte según la preferencia de cada usuario. |
| Idioma de los nombres de dispositivos | select | No | Idioma de los nombres de las funciones de los dispositivos nuevos (Gladys conserva un nombre una vez creado el dispositivo). |
Cómo instalar Tesla Wall Connector en Gladys
- En Gladys, abre Integraciones: Tesla Wall Connector aparece en el catálogo junto a las integraciones nativas, con una insignia de comunidad.
- Haz clic en Instalar. Gladys descarga la imagen Docker (
ghcr.io/guim31/gladys-tesla-wall-connector:1.3.0), la ejecuta en un entorno aislado del núcleo y genera la interfaz de la integración (dispositivos, descubrimiento y configuración). - Abre la pantalla de Configuración de la integración, rellena los parámetros y guarda.
- También puedes instalarla directamente desde la URL de su repositorio: https://github.com/guim31/gladys-tesla-wall-connector.
Tesla Wall Connector requiere Gladys >=5.1.0. El catálogo de Gladys se actualiza cada hora, así que una nueva versión está disponible como máximo una hora después de publicarse.
¿Todavía no usas Gladys? Es gratuito y de código abierto: sigue la guía de instalación para empezar.
