Integración domótica sonnenBatterie, gratuita y de código abierto
Unofficial: sonnenBatterie on your network: charge, powers, solar, grid, read-only.
Publicado por LM1LC3N7
- Dispositivos
- Versión 0.1.2
- Requiere Gladys >=5.2.0
- ★ 0
La documentación de esta integración la escribe su autor y, por ahora, solo está disponible en inglés.
Unofficial integration, not affiliated with sonnen. It reads your sonnenBatterie (eco, 10, hybrid...) on your local network, through its local API v2 (HTTP), with a read token, without any cloud.
Never tested with a real device: the integration was written from the
sonnen-api-v2 library and the API
documentation the battery serves at /api/doc.html, without a sonnenBatterie
at hand. Your feedback is welcome.
Read-only
The integration only reads (GET requests of the read API). It never changes the operating mode, never forces a charge or a discharge and changes no setting. A read token is enough.
What you get
One "sonnenBatterie" device (one battery per integration: the one whose token is entered; the read API gives no serial number):
- usable state of charge (USOC, %, the one of the sonnen app), relative state of charge (RSOC), usable energy remaining (kWh);
- charge and discharge power (W), battery power (W, positive when discharging), state (0 = idle, 1 = charging, 2 = discharging);
- solar power (W) and the solar production index of the production meter of the battery, for the Gladys energy monitoring (with its 30-minute production, computed by Gladys);
- house consumption (W, average, and a counter in kWh);
- grid exchange (W, positive when the home imports, negative when it exports), grid state (0 = on grid, 1 = off grid, backup), voltage and frequency;
- backup buffer (%), operating mode (1 = manual, 2 = self-consumption, 6 = module extension, 10 = time of use), discharge not allowed (0/1);
- cycles, minimum and maximum cell temperatures, DC voltage, full charge capacity and installed capacity.
No double count
The consumption meter of the battery measures the house consumption, which the main meter of the home (Linky...) already counts in Gladys. It is therefore published as a plain sensor, never as a consumption index: nothing is billed twice. The integration sends no daily consumption. Only the solar production index feeds the energy monitoring.
Solar production and inverter: a sonnenBatterie eco is AC-coupled, with a separate solar inverter (SMA, Fronius, SolarEdge, Kostal...), and its production meter measures that inverter. If your inverter already sends its production to Gladys, keep only one source: choose Sensor only in "Solar production" before creating the device. The production is then a plain sensor (kWh, never counted) and the index gets nothing. Changing this choice after the creation: a created device keeps all its features (none is removed), only the feature of the current choice gets values; for a clean device, delete it and create it again. Coming back from "Sensor only" to the energy monitoring, the first value of the index is held as a jump (the production of the period, already counted by the inverter, is never counted at once): accept it with the two clicks only if it should be.
Requirements
- Gladys 5.2.0 or later.
- The battery on the same network as Gladys, its API reachable over HTTP (port 80).
- A read token: in the local web interface of the battery
(
http://<battery-address>), menu Software-Integration, JSON API, turn on Read API and copy the token.
Configuration
- Install the integration from the Gladys store.
- Battery IP address: its address on your network (with
:portonly if it is not 80). Preferably give it a fixed address in your router. - Read token: kept by Gladys in its database, never shown again, sent only to the battery (in the header of its requests), never logged.
- Reading interval: 30 s by default, 30 to 300 s (five small requests a read).
- After the first read, create the device from the Discover tab.
The Test the connection button reads the battery once if the interval has passed; otherwise it shows the last read and when the next one can be.
Pace of the reads
Nothing reads the battery faster than the interval: not the test button, not
the Discover tab, not a reconnection to Gladys, not a save of an unchanged
configuration, not a restart of the container (the time of the last read is
kept in /data, written at most once a minute: after a restart, the first
read waits the interval plus a minute). A new address or a new token is tried
at once.
Held index
Gladys counts every rise of an index in full. So that no fictive energy is ever counted, the solar production index goes through a guard:
- a value of 0 is never sent;
- a drop, or a rise faster than 30 kW on average, is held back: the last accepted value is sent again, and the status of the integration shows it. Neither time nor repetition confirms it;
- if it is right, click Accept the held index twice: the first click lists what is held and accepts nothing, the second, 3 seconds to 5 minutes later, accepts exactly what was listed (a jump is then counted at once, a drop counts nothing). Saving the configuration accepts nothing.
Errors
- Token refused (HTTP 401/403): the reads stop, the status says so.
Without a change, a new try comes after 15 minutes, then 30, up to 6 hours;
this stop is kept in
/dataacross a restart. A new token saved is tried at once. To recognise a refused token after a restart,/datakeeps a salted fingerprint of that refused token only (never of the right one), erased by the first successful read. - An HTTP 429 or 5xx of the configuration pauses the battery from 1 minute to
6 hours, kept in
/data. An error of another endpoint only leaves its values out: the others are published. - An unreachable battery is tried again after 1 minute, then 2, up to 15 minutes, never faster than the interval.
- Only a refusal of the configuration is a refused token. If another part of the API (meters, modules...) refuses the token while the configuration takes it, only its values are missing, the status says so, the reads go on.
- Every read starts with the configuration, with the token: another battery taking the address (DHCP) refuses that token and gives nothing. Once per start, the integration also asks for the configuration without a token: if the battery answers anyway, the status advises a fixed address (only the address identifies it then).
Privacy
Nothing leaves your network: the integration only talks to the battery, over local HTTP, and follows no redirect. The token travels in clear on your local network, as for the app of the battery.
Parámetros de configuración
Estos son los parámetros que sonnenBatterie te pide en su pantalla de configuración en Gladys.
| Parámetro | Tipo | Obligatorio | Descripción |
|---|---|---|---|
| sonnenBatterie | section | No | Unofficial connector, not affiliated with sonnen. It reads your sonnenBatterie through its local API v2 (HTTP on your network, no cloud), with a read token created in the web interface of the battery, every 30 seconds: state of charge, charge and discharge power, solar power, house consumption, grid exchange, backup state, temperatures, and the solar production index for the Gladys energy monitoring. Read-only: it never changes the operating mode and never forces a charge or a discharge. Never tested with a real sonnenBatterie. |
| Battery IP address | string | Sí | The address of the sonnenBatterie on your network, with :port only if it is not 80. Preferably give it a fixed address in your router. |
| Read token | secret | Sí | Created in the web interface of the battery (Software-Integration, JSON API, Read API): a read token is enough, the integration never writes. Kept by Gladys in its database, never shown again; sent only to the battery, in the header of its read requests, never logged. |
| Solar production | select | No | Energy monitoring: the production meter of the battery is the solar production index of Gladys. Sensor only: a plain sensor, never counted; choose it when your solar inverter (SMA, Fronius, SolarEdge...) already sends its production to Gladys, or it would be counted twice. Chosen before creating the device. |
| Reading interval (s) | number | No | How often the battery is read (five small requests each time): 30 s by default, more if you wish. Nothing reads it faster, not even the test button. |
Cómo instalar sonnenBatterie en Gladys
- En Gladys, abre Integraciones: sonnenBatterie aparece en el catálogo junto a las integraciones nativas, con una insignia de comunidad.
- Haz clic en Instalar. Gladys descarga la imagen Docker (
ghcr.io/lm1lc3n7/gladys-sonnen:0.1.2), la ejecuta en un entorno aislado del núcleo y genera la interfaz de la integración (dispositivos, descubrimiento y configuración). - Abre la pantalla de Configuración de la integración, rellena los parámetros y guarda.
- También puedes instalarla directamente desde la URL de su repositorio: https://github.com/LM1LC3N7/gladys-sonnen.
sonnenBatterie requiere Gladys >=5.2.0. El catálogo de Gladys se actualiza cada hora, así que una nueva versión está disponible como máximo una hora después de publicarse.
¿Todavía no usas Gladys? Es gratuito y de código abierto: sigue la guía de instalación para empezar.
Sobre las integraciones externas
sonnenBatterie es una integración externa: una integración comunitaria empaquetada como contenedor Docker y publicada en GitHub. Gladys la instala con un clic y la ejecuta en un entorno aislado del núcleo. La publica y mantiene LM1LC3N7, no el equipo principal de Gladys.
