Integración domótica Robonect, gratuita y de código abierto

Integración Robonect para Gladys Assistant

Robotic mowers with a Robonect module, locally: state, battery, errors; pause, base, start.

Ver en GitHubTodas las integraciones
info

La documentación de esta integración la escribe su autor y, por ahora, solo está disponible en inglés.

This integration shows a robotic mower fitted with a Robonect module (Husqvarna Automower, Gardena, Flymo, McCulloch) in Gladys, through the local JSON API of the module, without any cloud. Never tested with a real device. Not affiliated with Robonect, Husqvarna, Gardena nor Flymo.

This is not the gladys-automower integration. gladys-automower goes through the Husqvarna cloud (Husqvarna account, connected Automower robots). This one talks directly to the Robonect module, a board added inside the mower, on your local network. If your mower has no Robonect module, it is of no use to you.

What you get​

One mower in the Discovery tab, with:

  • Mower state (Gladys' "robot vacuum" card: mowing, paused, returning to the base, charging, docked, error, stopped) and a Return to the base button on that card;
  • Status as text ("Mowing", "Charging", "Mowing (stopped)"...), status code, mode (Auto, Manual, Home, End of day...), stopped (paused);
  • battery, charging;
  • error in progress, error code and text;
  • time in the status, mowing hours, distance from the base, blade quality, Wi-Fi signal (dBm), temperature and humidity inside the mower, next start of the timer, module reachable;
  • three buttons: Pause (stop where it is), Back to the base and Start (lift the stop).

Setup​

  1. Give the Robonect module a fixed IP address in your router.
  2. In Gladys, open the Robonect integration and enter the IP address of the module, its user name and password (those of its web interface). Leave both empty only if the module has no login.
  3. Save, then add the mower from the Discovery tab.

The password is kept by Gladys in its database, never shown again, sent only to the module. It travels in clear (HTTP Basic authentication, over HTTP) on your local network: that is how the module works. It is never written to the logs nor to /data.

The module is read every 60 s (30 s to 1 h), never more often, even after a restart of the integration, a reconnection to Gladys, the "Test the connection" button or a Discovery scan. Only the status command, which does not wake a sleeping module, is sent for these reads.

The commands​

  • Pause (stop where it is, Robonect's stop command) and Back to the base ("Home" mode) are always available: never held back by the option, a start in progress, a pause of the integration (HTTP 429 or 5xx) or refused credentials, and possible right after a restart, before the first read. They cancel a start not sent yet.
  • Start is off by default. Turn on "Allow the start from Gladys" to use it. It lifts the stop of the mower, which then mows according to its mode (Auto: following its timer; Home: it stays at the base). Before sending, the integration reads the mower again and refuses if the module does not answer fast enough, a value is missing, another module answers at this address, the mower is not stopped (nothing to lift: the answer is a failure, nothing is sent), or its status is not one of: parked, mowing (stopped), looking for its base, charging, searching, sleeping, waiting for the garage door. Any other status (error, off, offline, unknown...) refuses. Check that nobody, child or pet, is on the lawn.
  • No command is a switch: a "turn everything on/off" (voice assistants, scenes) can never start the mower.
  • If the module does not answer in time, the answer is "Command sent, without confirmation": check the state a few seconds later. A pause sent while a start could still land is sent again if the mower runs again (twice at most, within two minutes).
  • Back to the base changes the mode; if the mower was paused (stopped), it may stay where it is until the stop is lifted: to be checked on a real module.

Troubleshooting​

  • "No answer": check the address, and that the module is on the Wi-Fi (it may be out of range at the far end of the garden). New tries 1 to 15 minutes apart.
  • "Credentials refused": fix the user name or the password and save. Otherwise, new try after 15 min, 1 h, then every 6 h, even after a restart.
  • The mower does not show up in Discovery ("without a valid id"): the integration identifies the module by the id field of its status answer (":" and "-" removed, for a MAC address for instance), otherwise, by the serial number of cmd=version (tried again after 15 min, 1 h, then every 6 h when unreadable, or with the "Test the connection" button). If that is not enough, open an issue on the GitHub repository with the anonymized answer of http://<module>/json?cmd=status.
  • https:// in the address is refused: this version speaks plain HTTP only (the password travels in clear on the local network); enter the address without https://.
  • "Not read any more": another module answers at this address (IP address given to another device), or the mower was removed.

Limits​

  • One mower per integration; HTTP only (no HTTPS).
  • No timers, mode choice, GPS nor MQTT in this version.
  • Never tested with a real device: the fields come from the aiorobonect library and the Robonect integration for Home Assistant.

Parámetros de configuración​

Estos son los parámetros que Robonect te pide en su pantalla de configuración en Gladys.

ParámetroTipoObligatorioDescripción
Your mower and its Robonect modulesectionNoShows a robotic mower fitted with a Robonect module (Husqvarna Automower, Gardena, Flymo, McCulloch) in Gladys through the local JSON API of the module, without any cloud: state, mode, battery, error, mowing hours, Wi-Fi signal, blades, next timer start. Pause and back to the base are always available; starting the mower from Gladys is off until you allow it below. Enter the IP address of the module (give it a fixed address in your router), its user name and password, save, then add the mower from the Discovery tab. This is not the gladys-automower integration (Husqvarna cloud, no module needed). Never tested with a real device. Not affiliated with Robonect.
IP address of the Robonect modulestringSíAn IPv4 address or a host name, optionally followed by a port (80 by default). Plain HTTP on the local network.
User name of the modulestringNoThe user of the web interface of the Robonect module. Leave it empty, with the password, only if the module has no login.
Password of the modulesecretNoKept by Gladys in its database, never shown again, sent only to the module, in clear (HTTP Basic authentication) on the local network. Refused credentials are tried again after 15 min, 1 h, then every 6 h.
Allow the start from GladysbooleanNoOff by default. On: the "Start" button may lift the stop of the mower, which then mows according to its mode (check that nobody, child or pet, is on the lawn). Off: it refuses every press. Pause and back to the base always work.
Refresh interval (s)numberNoHow often the module is read, in seconds (never more often, even after a restart).
Language of the feature namesselectNoUsed for the feature names of the devices added from now on, for the status texts and for the command errors.

Cómo instalar Robonect en Gladys​

  1. En Gladys, abre Integraciones: Robonect aparece en el catálogo junto a las integraciones nativas, con una insignia de comunidad.
  2. Haz clic en Instalar. Gladys descarga la imagen Docker (ghcr.io/lm1lc3n7/gladys-robonect:0.1.2), la ejecuta en un entorno aislado del núcleo y genera la interfaz de la integración (dispositivos, descubrimiento y configuración).
  3. Abre la pantalla de Configuración de la integración, rellena los parámetros y guarda.
  4. También puedes instalarla directamente desde la URL de su repositorio: https://github.com/LM1LC3N7/gladys-robonect.

Robonect requiere Gladys >=5.1.0. El catálogo de Gladys se actualiza cada hora, así que una nueva versión está disponible como máximo una hora después de publicarse.

¿Todavía no usas Gladys? Es gratuito y de código abierto: sigue la guía de instalación para empezar.

Sobre las integraciones externas​

Robonect es una integración externa: una integración comunitaria empaquetada como contenedor Docker y publicada en GitHub. Gladys la instala con un clic y la ejecuta en un entorno aislado del núcleo. La publica y mantiene LM1LC3N7, no el equipo principal de Gladys.
