Integración domótica Onkyo, gratuita y de código abierto
Control Onkyo, Integra and Pioneer network AV receivers: power, volume, inputs, zones.
Publicado por prohand
- Dispositivos
- Versión 1.0.1
- Requiere Gladys >=5.1.0
- ★ 0
La documentación de esta integración la escribe su autor y, por ahora, solo está disponible en inglés.
This integration drives Onkyo network AV receivers from Gladys, as well as the Integra and recent Pioneer models that speak the same protocol (eISCP).
Everything stays local: Gladys talks to the receiver directly on your network (port 60128). No account, no cloud, no Internet.
Before you start
- The receiver must be on the network (cable or Wi-Fi).
- Turn on Network Standby on the receiver:
Setup→Hardware→Power Management→Network Standby→On(the wording varies a little between models). Without it the receiver drops the network in standby: Gladys loses it and cannot switch it on. - Give it a fixed IP in your router (recommended, not required: if the IP changes, the integration finds the receiver again by its MAC address).
Some older models accept one connection at a time: if the Onkyo Remote app is open, the receiver may refuse Gladys. Close the app and wait a minute.
Adding a receiver
- Install the integration from the Gladys store.
- Open the Discovery tab: Gladys looks for receivers on the network.
- Add the one(s) that show up. One device is created per zone.
The receiver does not show up? It may sit on another subnet or a VLAN: type its IP in Receiver addresses (several separated by commas), save, then run the discovery again.
Settings
| Setting | What it does |
|---|---|
| Receiver addresses | Only for a receiver the discovery does not find. E.g. 192.168.1.40, 192.168.1.41 |
| Zones | Automatic: the zones the receiver declares (the main zone alone on older models). Or force 1, 2 or 3 zones. |
| Volume scale of the receiver | The highest volume value the receiver shows: 80 on most models, 200 on recent ones that step by 0.5. "Test the connection" tells what the receiver declares. |
| Maximum volume (%) | Gladys never sends a volume above it, whatever a slider, a button or a scene asks. 80 % by default. |
| Detailed logs | Logs every message exchanged with the receiver. Turn it on to understand a problem, then off again. |
The volume is a percentage of the scale: 50 % on a scale of 80 shows 40 on the receiver.
What you get
Main zone
- Power (on / standby)
- Volume (slider, in %), Volume up, Volume down, Mute (toggle)
- Input: the list of inputs, with the names you gave them on the receiver (recent models) or the standard names (BD/DVD, CD, NET…)
- Listening mode: Stereo, Direct, Dolby, DTS…
- Tuner preset (1 to 40)
- Play, Pause, Stop, Previous, Next: for the network, USB or Bluetooth player of the receiver
- Now playing: artist and title
Zone 2 and zone 3
Power, volume, mute, volume up/down, input. The "Main zone source" input makes the zone follow the main one.
Every change made on the remote, the front panel or another app shows up in Gladys at once: the receiver reports it, Gladys does not need to poll.
Scenes (Gladys 5.1+)
Triggers
- The input of a receiver changed: someone picked another input (remote,
front panel, app). Filter by zone and by input. Variables:
source(code) andsource_name(name). Gladys' own orders never fire it (no loop). - A new track is playing: the network or USB player moved to another track.
Variables:
title,artist,album. - A receiver went online or offline: the link dropped (unplugged, network standby off) or came back. A restart of Gladys never fires it.
Actions
- Play an input on a receiver: switches the zone on if needed, waits for it, picks the input, then sets the volume (optional). Made for "the radio in the kitchen at 7:00".
- Mute a receiver: mute, unmute or toggle.
- Set the listening mode of the main zone.
- Send an ISCP command: any command of the Onkyo protocol, for what the other actions do not cover. The receiver's answer is available to the next actions.
Example: "when the TV switches on → Play the TV input at 35 %".
Dashboard widget (Gladys 5.1+)
The Onkyo receiver widget shows one zone (picked in its settings, or the first receiver's main zone):
- volume and input;
- status: power, track playing, sound, listening mode, link;
- buttons: on/standby, volume down, volume up, mute.
Configuration buttons
- Test the connection: one line per zone (connected or not, power, input, volume) and the typed addresses that answered nothing.
- Send an ISCP command: try a command before putting it in a scene.
Examples:
PWR01(on),MVL20(volume),SLI23(CD input),LMDQSTN(which listening mode?).
Troubleshooting
| Problem | Hint |
|---|---|
| The receiver is not in Discovery | Network standby on? Same network as Gladys? Otherwise type its IP in "Receiver addresses". |
| "Unreachable" as soon as it is in standby | Turn on network standby (see above). |
| The volume does not match the display | Set "Volume scale of the receiver" (80 or 200 most of the time). |
| An input is missing from the list | Older models do not announce their inputs: the standard list is used. Use "Send an ISCP command" with SLIxx. |
| Play/Pause do nothing | These keys drive the receiver's own network/USB/Bluetooth player, not an HDMI source. |
For a bug report, turn on Detailed logs, reproduce the problem and attach the logs without IP or MAC addresses: https://github.com/prohand/gladys-onkyo/issues
Parámetros de configuración
Estos son los parámetros que Onkyo te pide en su pantalla de configuración en Gladys.
| Parámetro | Tipo | Obligatorio | Descripción |
|---|---|---|---|
| Getting started | section | No | The receivers are found on your network: open the Discovery tab and add them. Everything stays local (eISCP protocol, port 60128), no account, no cloud. On the receiver, turn on Network Standby (Setup > Hardware > Power Management), or Gladys loses it as soon as it goes to standby. |
| Receiver addresses | string | No | Only for a receiver the Discovery tab does not find (another subnet, a VLAN): its IP address, several separated by commas. A fixed IP in your router is recommended. |
| Zones | select | No | One Gladys device per zone. Automatic: the zones the receiver declares (the main zone alone on older models). |
| Volume scale of the receiver | select | No | The highest volume value the receiver shows. 80 on most models, 200 on recent ones that step by 0.5. "Test the connection" tells what the receiver declares. |
| Maximum volume (%) | number | No | Gladys never sends a volume above this, whatever a scene or a slider asks: protects your speakers and your ears. |
| Detailed logs (debug) | boolean | No | Log every message exchanged with the receivers. Turn it on to understand a problem, then off again: it is verbose. |
Cómo instalar Onkyo en Gladys
- En Gladys, abre Integraciones: Onkyo aparece en el catálogo junto a las integraciones nativas, con una insignia de comunidad.
- Haz clic en Instalar. Gladys descarga la imagen Docker (
ghcr.io/prohand/gladys-onkyo:1.0.1), la ejecuta en un entorno aislado del núcleo y genera la interfaz de la integración (dispositivos, descubrimiento y configuración). - Abre la pantalla de Configuración de la integración, rellena los parámetros y guarda.
- También puedes instalarla directamente desde la URL de su repositorio: https://github.com/prohand/gladys-onkyo.
Onkyo requiere Gladys >=5.1.0. El catálogo de Gladys se actualiza cada hora, así que una nueva versión está disponible como máximo una hora después de publicarse.
¿Todavía no usas Gladys? Es gratuito y de código abierto: sigue la guía de instalación para empezar.
Sobre las integraciones externas
Onkyo es una integración externa: una integración comunitaria empaquetada como contenedor Docker y publicada en GitHub. Gladys la instala con un clic y la ejecuta en un entorno aislado del núcleo. La publica y mantiene prohand, no el equipo principal de Gladys.
