Integración domótica JVC Projector, gratuita y de código abierto
JVC D-ILA projectors on the local network: power on, standby, input, picture mode, lamp hours.
Publicado por LM1LC3N7
- Dispositivos
- Versión 0.1.1
- Requiere Gladys >=5.1.0
- ★ 0
La documentación de esta integración la escribe su autor y, por ahora, solo está disponible en inglés.
Control your JVC D-ILA projectors (DLA-NZ, NX, N, X, RS and Z series, 2012 models on) from Gladys, on your local network, without any cloud: power on, standby, input, picture mode, remote keys, signal and lamp / laser hours.
Important. This integration has never been tested with a real projector: it was written from the
pyjvcprojectorlibrary (the one of Home Assistant) and tested against a fake projector only. Your feedback is welcome. Unofficial integration, not affiliated with JVCKENWOOD.
Installation
- Connect the projector to your network (LAN port) and give it a fixed IP address in your router (reserved DHCP lease), or set one in its Network menu.
- To control it in standby, keep its network on in standby: set ECO mode to Off (otherwise it leaves the network in standby, and only the remote can turn it on).
- Recent models (2024 on, and some after a firmware update) require a network password set in the projector's Network menu: type it in the configuration. Older models have none: leave the field empty.
- In Gladys, install the JVC Projector integration, open its
configuration and type the IP addresses, separated by commas (for example
192.168.1.50; port 20554 by default, another one as192.168.1.50:20555). - The projectors appear in the Discovery tab: create them.
The projector must be on, or in standby with its network kept on, the first time: the integration reads its model and its MAC address, which identifies it from then on (its address may change: type the new one).
What you get
| Feature | Gladys type | Note |
|---|---|---|
| Power | binary state (read only) | 1 on or warming up, 0 standby, cooling down, error or not reachable |
| Power status | text (read only) | On, Warming up, Cooling down, Standby, Error, Not reachable |
| Power on | button | sent from standby only |
| Standby | button | sent when on; while warming up, sent as soon as the projector is on |
| Input | list | HDMI 1, HDMI 2 |
| Picture mode | list | the modes of your model (Film, Cinema, Natural, HDR10, User 1…) |
| Remote key | list | Menu, arrows, OK, Back, Info, Lens control, Mode 1 to 10… |
| Signal | binary state (read only) | 1 when the input has a signal |
| Lamp / laser time | duration in hours | read while the projector is on |
On purpose, no switch: an "everything off" or "everything on" from a voice assistant or a scene never turns your projector on or off. Use the two buttons in your scenes.
Input, picture mode and signal are read while the projector is on (the picture mode with a signal only, as Home Assistant does). The picture mode list follows the model the projector reports; a model the integration does not know offers no picture mode.
Commands
The power state is read from the projector just before each command, then its MAC address when it answered it before in that state (another projector at the address: nothing is sent, and the address is forgotten). Every background read checks the MAC too. Only a valid MAC address of another projector counts: a projector that does not answer its MAC in standby, or answers zeros, keeps its address and can still be powered on.
- Power on is only sent in standby. Already on or warming up: nothing to do. While cooling down, the projector refuses it: the command is refused, nothing sent; try again once it is in standby.
- Standby is only sent when on. Already in standby or cooling down: nothing to do. While warming up, the projector ignores it: Gladys gets the answer "warming up: standby will be sent once it is on, nothing sent yet", and the integration sends it as soon as the projector is on (checked every 5 seconds, within 3 minutes, a failed read included); pressing Power on meanwhile cancels it. Standby is never refused because the state could not be read: it is then sent anyway. It goes before the other commands waiting, and never waits behind a background read or the slow confirmation of an input or picture mode change (that connection is closed; the change stays "sent, without confirmation").
- Input, picture mode and remote key are only sent when the projector is on.
Every command is answered within 4 seconds (Gladys waits 5 seconds). A command that left without the projector confirming it in time is reported "sent, without confirmation" (an input change can take up to 10 seconds on the projector); one that could not leave is reported "nothing sent". The state is read again 3 seconds after each command.
Network password
The password is kept by Gladys in its database, never shown again, and sent
only to the projectors, at the start of each connection (padded as the
older models expect it, then in the SHA-256 form of the recent models when
the first one is refused, as pyjvcprojector does). The integration never
writes it to its data folder, nor to its logs, statuses or error messages.
A refused password stops the tries to that projector: the integration status says so, and the password is tried again only when you save the configuration, or 30 minutes later (never in a loop). A projector that closes the connection or stops answering after refusing a password counts as a refusal too. Fix it in the projector's Network menu or in the configuration, then save.
Configuration button
- Check the projectors: reads each projector now (power, lamp hours) and shows the refresh interval.
Refresh, status and limits
- The state of each projector is read every 15 seconds by default (10 to 300), in one short connection (the projector takes one client at a time: close the JVC app or another controller if it says "busy").
- A projector that does not answer shows power 0 and "Not reachable", and is named in the integration status; it is asked again at every refresh, never faster.
- If another projector answers at the address of a created one (address changed), its address is forgotten and it is never commanded there: type its new address.
Data and privacy
The integration keeps in /data/jvc-projector.json the known projectors
(MAC address, address, port, model, picture modes) and the addresses whose
password was refused, with the time of the next try. Nothing leaves your
local network.
Known limits
- HDMI 1 and HDMI 2 only (the inputs
pyjvcprojectormaps). - No lens memory, laser power, installation mode, anamorphic or HDR settings yet.
- One password for all the projectors.
- Never tested with a real projector: real answers may differ.
Parámetros de configuración
Estos son los parámetros que JVC Projector te pide en su pantalla de configuración en Gladys.
| Parámetro | Tipo | Obligatorio | Descripción |
|---|---|---|---|
| Your JVC projectors, on your local network | section | No | Power on, standby, input, picture mode, remote keys, signal and lamp / laser hours of each JVC D-ILA projector (DLA-NZ, NX, N, X, RS, Z series), through the network protocol published by JVC (TCP port 20554), without any cloud. Give each projector a fixed IP address in your router and type it below; the projectors then appear in the Discovery tab. To control a projector in standby, keep its network on in standby (ECO mode off). Power on and standby are buttons, never a switch: an "everything off" never turns a projector on or off. Never tested with a real projector. Unofficial integration, not affiliated with JVCKENWOOD. |
| IP addresses of the projectors | string | No | Separated by commas, for example 192.168.1.50, 192.168.1.51. Port 20554 by default (another one: 192.168.1.50:20555). |
| Network password of the projectors (optional) | secret | No | Only if a network password is set on the projector (Network menu; required by the recent models): the same for every projector. Kept by Gladys in its database, never shown again, sent only to the projectors, at the start of each connection. A refused password stops the tries until the configuration is saved again (or 30 minutes). |
| Refresh interval (s) | number | No | How often the state of each projector is read, in seconds (10 to 300). |
Cómo instalar JVC Projector en Gladys
- En Gladys, abre Integraciones: JVC Projector aparece en el catálogo junto a las integraciones nativas, con una insignia de comunidad.
- Haz clic en Instalar. Gladys descarga la imagen Docker (
ghcr.io/lm1lc3n7/gladys-jvc-projector:0.1.1), la ejecuta en un entorno aislado del núcleo y genera la interfaz de la integración (dispositivos, descubrimiento y configuración). - Abre la pantalla de Configuración de la integración, rellena los parámetros y guarda.
- También puedes instalarla directamente desde la URL de su repositorio: https://github.com/LM1LC3N7/gladys-jvc-projector.
JVC Projector requiere Gladys >=5.1.0. El catálogo de Gladys se actualiza cada hora, así que una nueva versión está disponible como máximo una hora después de publicarse.
¿Todavía no usas Gladys? Es gratuito y de código abierto: sigue la guía de instalación para empezar.
Sobre las integraciones externas
JVC Projector es una integración externa: una integración comunitaria empaquetada como contenedor Docker y publicada en GitHub. Gladys la instala con un clic y la ejecuta en un entorno aislado del núcleo. La publica y mantiene LM1LC3N7, no el equipo principal de Gladys.
