Integración domótica free@home, gratuita y de código abierto
Control local free@home lights, switched outputs and blinds; use button events in scenes.
Publicado por stefanbauer
- Dispositivos
- Versión 1.1.0
- Requiere Gladys >=5.1.0
- ★ 0
La documentación de esta integración la escribe su autor y, por ahora, solo está disponible en inglés.
An independent integration using ABB/Busch-Jaeger's local REST and WebSocket API, without XMPP or a cloud connection. It implements switched consumers, dimmable lights, blinds/shutters and wall/panel button actions for Gladys scenes.
Setup
The integration runs in its own Linux Docker container supervised by Gladys.
Gladys manages startup, restart, logs and integration credentials. Users need no
macOS, host Node.js, source checkout or .env. Version 1.1.0 is published with
a public AMD64/ARM64 image. Install in Gladys using the GitHub repository URL
https://github.com/stefanbauer/gladys-freeathome. Store discovery is enabled;
catalog visibility depends on the next successful indexing and local cache.
Local builds are covered separately in the development guide.
Use Gladys 5.1.0+ with Docker, a compatible SysAP with its local API enabled, the controller
origin including http:// or https://, the API username shown in free@home next
and its password. Enter both credentials in Gladys' Configuration secret fields, separate from this
integration's own Gladys token. Never share credentials or raw configuration.
Save settings and check connection status. The test button checks REST access only; the ongoing status also confirms the WebSocket connection. Discovery lists supported channels. Create the ones you need and assign rooms yourself. One physical multichannel actuator can have several entries. The integration does not create or delete user devices automatically.
Equally named channels on one device get an API channel suffix in discovery,
such as Double button [ch0000] and [ch0003]. This does not mean upper/lower:
REST supplies no physical mapping, and a rocker may send multiple actions on one
channel. Existing devices keep their user-owned names; rename them in Gladys if
needed.
Controls and button events
Since 1.1.0: impulse actuators (FID_TRIGGER, 0x0045)
appear as a separate writable Press feature (button/push). Create the
actuator channel in Discovery; a same-named text sensor remains read-only.
Press on the dashboard, or set the device value to 1 in a scene. Each press
sends one trigger; free@home retains its configured impulse duration. No extra
off command or software timer is added, and no contact/door state is inferred.
Do not change the free@home function or delete existing sensor devices/scenes.
After updating in Gladys, scan and create the actuator channel. Commands have
synthetic test coverage; real-controller discovery passed, but physical
actuation is unverified.
Opening and slat opening are 0% closed, 100% open. Slats appear only with matching datapoints, as a separate percentage slider, not calibrated degrees. Up/down/stop use actuator feedback; some actuators report position only when movement finishes. Stop first reads movement: idle is a no-op and unknown movement is rejected. ABB's stop also steps an idle blind, so an actuator stopping between that read and write remains a non-atomic protocol race. Zero brightness uses the separate binary off command.
Create a button channel first, then choose Integrations → free@home → Button action in the scene editor. Select the button; an empty action filter matches any of its actions. Depending on button configuration, actions include on/off, dim up/down/stop, open/close and stop/step up/down. Equal live telegrams remain separate events. The last-action display is a state, not a press trigger. Telegram semantics are not a universal raw press/release or double-click API. Snapshots and initial synchronization never trigger scenes. Events during disconnection/resync are lost, not replayed; there is no reliable replay marker for an exactly-once guarantee.
Security and development status
Prefer HTTPS with a trusted certificate. A private CA can be supplied using
NODE_EXTRA_CA_CERTS; never disable TLS checks. Basic auth over HTTP is not
encrypted. Never expose the controller API to the Internet. Commands are never
automatically retried, including after reconnect: a lost acknowledgement does
not prove that a command failed to execute.
Alongside synthetic tests, explicitly authorized firmware 3.5.3 hardware checks
verified a switched light, blind positioning, up/stop, repeated identical button
scene events and restart/reconnection. A subsequent manual test confirmed dimming
at 31% and 73% with matching feedback and off at 0%. Slats, the other button side and
the separate down command have not been checked on real hardware. Groups,
virtual devices, free@home scenes, HVAC and other sensors are outside this scope.
Anonymous image downloads, full metadata/image validation and GitHub-URL
installation with controller discovery and restart have passed for 1.0.0.
Device behavior and the hardware verification limits are unchanged from 0.1.0.
Operation and updates
Use Gladys' supervision controls for start/stop, restart, logs and updates. The Gladys/Docker host must be running; a developer's computer is not required. Use update, not uninstall/reinstall, to retain registration, configuration and devices: uninstalling in Gladys deletes them. The image contains no personal credentials. Runtime config comes from Gladys; no persistent local files are required.
Parámetros de configuración
Estos son los parámetros que free@home te pide en su pantalla de configuración en Gladys.
| Parámetro | Tipo | Obligatorio | Descripción |
|---|---|---|---|
| Controller URL | string | Sí | |
| Local API username | secret | Sí | |
| Local API password | secret | Sí |
Cómo instalar free@home en Gladys
- En Gladys, abre Integraciones: free@home aparece en el catálogo junto a las integraciones nativas, con una insignia de comunidad.
- Haz clic en Instalar. Gladys descarga la imagen Docker (
ghcr.io/stefanbauer/gladys-freeathome:1.1.0), la ejecuta en un entorno aislado del núcleo y genera la interfaz de la integración (dispositivos, descubrimiento y configuración). - Abre la pantalla de Configuración de la integración, rellena los parámetros y guarda.
- También puedes instalarla directamente desde la URL de su repositorio: https://github.com/stefanbauer/gladys-freeathome.
free@home requiere Gladys >=5.1.0. El catálogo de Gladys se actualiza cada hora, así que una nueva versión está disponible como máximo una hora después de publicarse.
¿Todavía no usas Gladys? Es gratuito y de código abierto: sigue la guía de instalación para empezar.
Sobre las integraciones externas
free@home es una integración externa: una integración comunitaria empaquetada como contenedor Docker y publicada en GitHub. Gladys la instala con un clic y la ejecuta en un entorno aislado del núcleo. La publica y mantiene stefanbauer, no el equipo principal de Gladys.
