Integración domótica Fluidra Pool, gratuita y de código abierto
Fluidra Pool equipment (AstralPool, Zodiac) via the Fluidra cloud: water, pump, heat pump.
Publicado por LM1LC3N7
- Dispositivos
- Versión 0.1.1
- Requiere Gladys >=5.1.0
- ★ 0
La documentación de esta integración la escribe su autor y, por ahora, solo está disponible en inglés.
Unofficial integration, not affiliated with Fluidra. It brings into Gladys the pool equipment linked to the Fluidra Pool app (AstralPool, Zodiac and the other brands of the Fluidra group), through the Fluidra cloud the app uses.
Warning: unofficial API, this integration has never been tested with a real account nor a real device. It was written from the Fluidra-pool Home Assistant integration (foXaCe) and tested against a fake Fluidra cloud only. Fluidra may change its API at any time. Feedback is welcome.
What you get
Fluidra gives no model: every device exposes numbered registers whose meaning changes with the family. The integration only reads the families whose registers were checked by users of the Home Assistant integration. An equipment it does not recognize is counted in the status of the integration but never read: no value is ever shown under a wrong name.
| Equipment | Features |
|---|---|
| tecnoLC2 chlorinators (Energy Connect, Clear Connect, Ei2 iQ, GenSalt OE iQ, iSalt…) | Water temperature, pH, ORP (redox), salinity (g/L), chlorination setpoint (%); free chlorine and real production on a few units |
| domoticS2 chlorinators (Elite Connect, Neolysis…), eXO iQ, eXPERT (tecno2) | Depending on the family: temperature, pH, ORP, salinity, setpoint and production (%) |
| Blue Connect analysers (Silver, Gold) | Temperature, pH, ORP; salinity on the Gold |
| E30iQ filtration pump (and Inari VS, Verdon VS) | Running, automatic mode (schedule), speed (off, low, medium, high, automatic) |
| Victoria Smart Connect VS pump | Running, speed (%), power (W) |
| Z250iQ, Z260iQ, Z350iQ, Z550iQ(+), Z650iQ, Eco Elyo (LG), Gre HPGIC heat pumps | Running, water temperature, air temperature (depending on the model), setpoint, mode (text) |
| LumiPlus Connect lights | Light (on/off) |
An absent probe (no ORP, no free chlorine) creates no feature: it only shows once a real value was read. A pH, ORP or salinity of 0 is taken as "no reading". Free chlorine (mg/L) and the real production (%) of a tecnoLC2 are read only on the units whose owners showed those registers to the Home Assistant integration (Ducere 21 LC24008202, Clear Connect CC24018202, CC24042517, CC24058902; production on the bridged Energy Connect CC24054221 and CC24041107): on the others the same registers may hold nothing, so they are not shown. On a domoticS2, the setpoint shown is the one asked (the register the app writes); its read-back and production registers differ from one unit to another, so they are not shown.
Commands only for a well identified device. The pump speed, the light
and the setpoint can be sent only to a device identified by its serial
number, its Fluidra family id (thingType) or the signature the heat pump
reports, never by its name, its model or its family alone, and never when
what Fluidra says contradicts it (for example a family id of another model).
Such a device is shown with all its features, but its setpoint, speed and
light are read only (no command is sent to it).
The badge of each device shows "cloud", or "unreachable" (with an orange dot) when that device could not be read, or when Fluidra says it is disconnected two reads in a row.
Installation
- Your equipment must work in the Fluidra Pool app.
- In Gladys, install the Fluidra Pool integration, enter the e-mail and the password of the Fluidra Pool app, then save.
- Add the equipment from the Discovery tab.
The two-step sign-in (a code by SMS or e-mail) is not handled: turn it off in the app if it is on.
Commands and safety
Commands are off by default: everything is shown, nothing is changed. Turn Allow commands from Gladys on to allow:
- the speed of the E30iQ pump (a list: off, low, medium, high). Choosing a speed on a stopped pump starts it, then sets the speed. Refused while the pump follows its schedule (automatic mode): that mode is set in the app;
- the LumiPlus light (on, off);
- the heat pump setpoint, within the range of its model and 35 °C at most, by steps of 1 °C (0.5 °C on the Z650iQ).
No chemical dosing command (pH, chlorine, chlorinator production, boost): wrong dosing puts the bathers at risk, and the integration has never been tested on a real device. Those values are only shown.
Before each command, the integration reads the device again in the cloud: the command is refused when that read fails or lacks the value, and nothing is sent when the device is already in the asked state. The permission is checked again right before sending. The commands of one device run one at a time. A command that cannot be sent within 3.5 seconds of its arrival is refused (Gladys shows a failure after 5 seconds). When Fluidra does not answer in time, Gladys shows "The command was sent, without a confirmation from Fluidra": check the device, it is read again within seconds. A command is refused, nothing sent, when the last list of the equipment says the device is not connected.
A success only means that the Fluidra cloud accepted the request, not that the device applied it: the reads after the command (5, 20 and 60 seconds) show its real state. In particular, an account with which the pool is shared (a guest of the owner's account) may be read only on Fluidra's side: Fluidra may answer a command with a success while nothing changes. Use the owner's account for commands.
Once allowed, a scene or a dashboard can send these commands while nobody is there: stopping the filtration, for one, also stops the water flow to the chlorinator and the heat pump.
Password, tokens and privacy
- The password is kept by Gladys in its database, never shown again, and sent only to Fluidra (its AWS Cognito sign-in service, over HTTPS), as the app does.
- Signing in gives tokens: the access token (about one hour) is renewed with
the refresh token, without the password, 5 minutes before it ends (a
tenth of its lifetime when that is shorter). The
tokens are kept in the
/datavolume of the integration (a file readable by the container user only) so a restart does not sign in again. On the Gladys host, that volume is the folder<Gladys base folder>/external-integrations/<selector>, not in the Gladys backups, deleted when the integration is uninstalled. The refresh token gives access to the account while it is valid: protect that host. The e-mail and the password are never written there; another e-mail, or an e-mail or password emptied in the configuration, erases the tokens (a "verification code" stop stays with the account). - Nothing reaches the logs: no password, token, e-mail nor whole serial number (its last 4 characters only).
- Everything goes over HTTPS to
cognito-idp.eu-west-1.amazonaws.com(the sign-in) andapi.fluidra-emea.com(the equipment). The integration says it is "gladys-fluidra-pool": it does not pretend to be the app.
Refresh
The account is read every 60 seconds by default (60 to 900): the list of the pools, the equipment of each pool, then the registers of each recognized equipment (one request each). Three reads follow a command (after 5, 20 and 60 seconds); a new command replaces the reads still due for the previous one.
Errors
- Password refused (or account not confirmed): the integration stops; one new try after 1 h, 6 h, then every 24 h, or at once when you save a changed e-mail or password, or click Test the connection (saving the same e-mail and password again does not try again).
- A verification code, or any other sign-in step (but a new password): not handled. The integration stops and never signs in again by itself (each sign-in could send a code); click Test the connection once the two-step sign-in is off. For a verification code, the stop stays with the account: emptying the configuration, or typing the same e-mail with another password, does not lift it; only the button does.
- Fluidra asks to slow down (429): a pause of at least 1 minute (Retry-After when given, 6 h at most), for every read and command, kept across restarts.
- HTTP 403 on the account despite a fresh token: a 30-minute pause (one renewal of the token per try at most, never a loop). After 3 in a row, the status says that Fluidra may be filtering this client: the integration says who it is ("gladys-fluidra-pool") and never imitates the app nor goes around a block. Check that the account works in the app; if it does, report it (the Fluidra API is unofficial and may refuse other clients).
- One device in error (403, 404, 5xx, timeout): only its badge turns "unreachable", the others are read.
- Fluidra unreachable (network error, 5xx): new try after 1, 2, 5, 10 then every 15 minutes, never faster than the refresh interval. That wait is kept across a restart (15 minutes at most); it holds the reads only, and the Test the connection button tries at once.
Limits
- Never tested with a real account: the registers come from the Home Assistant integration, checked by its users on their devices.
- Not supported yet: generic pumps, PX50, Pro Elyo, Z950iQ heat pumps and the other families with unknown registers, robots, valves, plugs, dosing pumps, Command Connect cabinets, schedules.
- The account must be in the Europe (EMEA) region of Fluidra.
Credits
- Fluidra-pool by foXaCe (MIT): the cloud API, the sign-in, the equipment families and their registers are ported to JavaScript.
- See
THIRD_PARTY_NOTICES.md.
Fluidra, AstralPool and Zodiac are trademarks of their owners; this project is not affiliated with Fluidra.
Parámetros de configuración
Estos son los parámetros que Fluidra Pool te pide en su pantalla de configuración en Gladys.
| Parámetro | Tipo | Obligatorio | Descripción |
|---|---|---|---|
| Your Fluidra account | section | No | Brings the pool equipment of your Fluidra Pool account into Gladys: water temperature, pH, ORP, salinity and chlorine of the chlorinators and water analysers, the chlorine production, the filtration pump (running, speed), the heat pump (water temperature, setpoint, mode) and the pool lights. Read every minute through the Fluidra cloud. Enter the e-mail and the password of the Fluidra Pool app, save, then add the equipment from the Discovery tab. The pump speed, the lights and the heat pump setpoint stay read only until you allow commands below; chemical dosing is never commanded. Unofficial API, never tested with a real account. Not affiliated with Fluidra. |
| Fluidra e-mail | string | Sí | The one you sign in to the Fluidra Pool app with. |
| Fluidra password | secret | Sí | Kept by Gladys in its database, never shown again, sent only to Fluidra (its AWS Cognito sign-in service, over HTTPS). |
| Allow commands from Gladys (pump speed, lights, heat pump setpoint) | boolean | No | Off by default: everything is shown, nothing is changed. On, a scene or a dashboard can stop or start the filtration pump, switch the pool lights and change the heat pump setpoint (35 °C at most) while nobody is there. Chemical dosing (pH, chlorine) is never commanded. |
| Refresh interval (s) | number | No | Seconds between two reads of the account (60 to 900). |
| Language of the names | select | No | Used for the device and feature names of the equipment added from now on, and for the heat pump mode. |
Cómo instalar Fluidra Pool en Gladys
- En Gladys, abre Integraciones: Fluidra Pool aparece en el catálogo junto a las integraciones nativas, con una insignia de comunidad.
- Haz clic en Instalar. Gladys descarga la imagen Docker (
ghcr.io/lm1lc3n7/gladys-fluidra-pool:0.1.1), la ejecuta en un entorno aislado del núcleo y genera la interfaz de la integración (dispositivos, descubrimiento y configuración). - Abre la pantalla de Configuración de la integración, rellena los parámetros y guarda.
- También puedes instalarla directamente desde la URL de su repositorio: https://github.com/LM1LC3N7/gladys-fluidra-pool.
Fluidra Pool requiere Gladys >=5.1.0. El catálogo de Gladys se actualiza cada hora, así que una nueva versión está disponible como máximo una hora después de publicarse.
¿Todavía no usas Gladys? Es gratuito y de código abierto: sigue la guía de instalación para empezar.
Sobre las integraciones externas
Fluidra Pool es una integración externa: una integración comunitaria empaquetada como contenedor Docker y publicada en GitHub. Gladys la instala con un clic y la ejecuta en un entorno aislado del núcleo. La publica y mantiene LM1LC3N7, no el equipo principal de Gladys.
