Integración domótica Danfoss Air, gratuita y de código abierto
Danfoss Air ventilation over the local CCM: temperatures, humidity, fan, filter; optional commands.
Publicado por LM1LC3N7
- Dispositivos
- Versión 0.1.1
- Requiere Gladys >=5.1.0
- ★ 0
La documentación de esta integración la escribe su autor y, por ahora, solo está disponible en inglés.
Shows a Danfoss Air heat recovery ventilation unit (Air a2, a3, w2… fitted with the CCM, Connection and Control Module) in Gladys, over your local network, without any cloud or account. Unofficial integration, not affiliated with Danfoss. Never tested with a real device: it follows the protocol as the open-source library pydanfossair (used by Home Assistant) speaks it; please report what you see.
Before you start
- The CCM must be on your network (Ethernet) and reachable from Gladys on TCP port 30046. Give it a fixed IP address in your router.
- The CCM has no password and accepts one connection at a time: keep it on a trusted network, and close the Danfoss Air app (or another home automation that reads it) if Gladys cannot connect.
Setup
- Install the integration from the Gladys store.
- Enter the IP address of the CCM (port 30046 unless you add one), save.
- Open the Discovery tab and add the unit.
What you get
One device, Danfoss Air ventilation, with:
| Feature | Notes |
|---|---|
| Outdoor, supply, extract and exhaust air temperatures | °C |
| Room temperature (Air Dial) and calculated room temperature | °C |
| Humidity | % |
| Airflow | %, read only (it may show as a fan in HomeKit, but refuses every command) |
| Supply and extract fan speeds | rpm |
| Filter life remaining | % |
| Air Dial battery | % |
| Boost active, bypass open, automatic bypass, away mode | read only, 1 = on |
| Operation mode | list: demand, program, manual |
| Fan step (manual mode) | list: 1 to 10 |
| Start / stop the boost, open / close the bypass, automatic bypass on / off | buttons |
The unit is read every 60 s (configurable from 30 s to 1 h). The test button, a Discovery scan, a reconnection of Gladys or a restart of the integration never read it sooner than the interval. The one exception: after a command that was not confirmed, the unit is read again 5 s and 20 s later to check its effect.
Commands
All commands except Stop the boost are refused unless Allow the commands is on (off by default). There is no switch: a "turn everything off" of a voice assistant never reaches the ventilation.
- Each command reads the register again just before writing it, writes nothing when it is already so, and is confirmed only when the value read back is the one asked. A command that may have reached the unit without being confirmed answers "sent, without confirmation": check the unit a few seconds later. A command that cannot be written within 3.5 s is refused and nothing is sent.
- The fan step can only be set in manual mode (choose the mode first).
- Stop the boost is always allowed: it is never held back by the option, by another command or by a read in progress, and cancels a command not sent yet. If the CCM refuses the connection for a moment, it tries again every 250 ms until 3.5 s after the press. If it is not confirmed, the reads of the following two minutes send it again (twice at most) while the boost shows on; a "Start the boost" pressed afterwards wins and is never undone.
- Unit stopped from the Air Dial (mode 3, or step read 0): the status says so, the lists do not change, and the mode, fan step and "Start the boost" commands are refused. The bypass commands are sent as they are (they move a damper, they do not start the fans); "Stop the boost" is always allowed. Gladys neither stops nor restarts the ventilation in this version (stopping a heat recovery unit stops the air renewal).
- Opening the bypass stops the heat recovery (fresh air not warmed): use it in summer.
Limits
- The protocol is not documented by Danfoss; only the registers read and written by pydanfossair are used.
- The protocol gives no serial number: the integration shows one unit, the one at the configured address. Changing the address keeps the device and its history; another unit put at the same address would show on the same device and receive its commands too. Reserve the address of the CCM in your router (fixed DHCP lease).
- An answer of the unit must be exactly 63 bytes; an incomplete answer ends the read (nothing is published shifted).
- Gladys holds the connection while it reads (about a second every interval): the Danfoss Air app may have to wait, and conversely.
- The room temperature and battery come from the Air Dial remote; without one they may stay empty.
Privacy
Nothing leaves your network. The integration keeps only the time of its last
read in its /data volume.
Parámetros de configuración
Estos son los parámetros que Danfoss Air te pide en su pantalla de configuración en Gladys.
| Parámetro | Tipo | Obligatorio | Descripción |
|---|---|---|---|
| Your Danfoss Air unit | section | No | Shows your Danfoss Air heat recovery ventilation in Gladys through its CCM module (Connection and Control Module, TCP port 30046) on your local network, without any cloud: temperatures (outdoor, supply, extract, exhaust, room), humidity, airflow, fan speeds, filter, Air Dial battery, boost, bypass and away mode. Enter the IP address of the CCM (give it a fixed address in your router), save, then add the unit from the Discovery tab. The mode, fan step, boost and bypass can be changed from Gladys only if you allow the commands below; stopping the boost always works. The CCM has no password and accepts one connection at a time: keep it on a trusted network. Never tested with a real device. Not affiliated with Danfoss. |
| IP address of the CCM | string | Sí | An IPv4 address or a host name (port 30046 unless you add one, for example 192.168.1.70:30046). |
| Allow the commands | boolean | No | Off by default. On: Gladys may change the operation mode, the manual fan step, start the boost, open or close the bypass and turn the automatic bypass on or off. Off: these commands are refused. Stopping the boost is always allowed. |
| Refresh interval (s) | number | No | How often the unit is read, in seconds. |
| Language of the feature names | select | No | Used for the names of the device and features added from now on, the status and the command errors. |
Cómo instalar Danfoss Air en Gladys
- En Gladys, abre Integraciones: Danfoss Air aparece en el catálogo junto a las integraciones nativas, con una insignia de comunidad.
- Haz clic en Instalar. Gladys descarga la imagen Docker (
ghcr.io/lm1lc3n7/gladys-danfoss-air:0.1.1), la ejecuta en un entorno aislado del núcleo y genera la interfaz de la integración (dispositivos, descubrimiento y configuración). - Abre la pantalla de Configuración de la integración, rellena los parámetros y guarda.
- También puedes instalarla directamente desde la URL de su repositorio: https://github.com/LM1LC3N7/gladys-danfoss-air.
Danfoss Air requiere Gladys >=5.1.0. El catálogo de Gladys se actualiza cada hora, así que una nueva versión está disponible como máximo una hora después de publicarse.
