ZeroTier smart home integration, free and open source

ZeroTier integration for Gladys Assistant

Who is online on your ZeroTier networks, and who is waiting to be authorized.

View on GitHubAll integrations

Follow the members of your ZeroTier networks in Gladys: one device per member (online or not, authorized or not, last seen, managed IP address, ZeroTier version), one device per network, a dashboard widget, and scene triggers when a member comes online, goes offline, or asks to join — for instance to know that a phone is back on the family network, or that an unknown device is knocking at the door of a private network.

It works with ZeroTier Central (my.zerotier.com, the cloud) or with a self-hosted controller (your own ZeroTier node managing its networks). The self-hosted mode was tested against a real ZeroTier 1.14.2 controller and member in Docker. The Central mode was developed from the official API documentation, without a real Central account: feedback welcome on the Gladys forum or in the issues.

What you need​

  • Gladys Assistant 5.1.0 or later.
  • ZeroTier Central: an API token of the account that owns the networks (my.zerotier.com → Account → API Access Tokens), and Internet access for Gladys.
  • Self-hosted controller: the ZeroTier node that runs the controller, reachable from Gladys on its port 9993, the content of its authtoken.secret file, and the address of Gladys allowed in its local.conf (see below).

Set up​

  1. In Gladys, install the integration, then open its Configuration screen.
  2. Controller: ZeroTier Central (cloud) or Self-hosted controller (local).
  3. API token: the Central token, or the content of authtoken.secret.
  4. Networks to follow: the network IDs (16 characters, as shown by Central or zerotier-cli listnetworks), separated by commas. Empty: every network the token sees.
  5. Refresh interval: 1 minute by default. Each reading costs one request, plus one per network.
  6. Allow authorizing members: off by default (see the devices below).
  7. Language of the names: the language of the feature names and of the dates, French by default.
  8. Save, then press Test the connection: each network is listed with its members. The devices then appear in the Discovery tab of the integration: add the ones you want.

ZeroTier Central​

Create a token in my.zerotier.com → Account → API Access Tokens. It gives access to every network of the account: keep it private. Central limits the number of API requests per account: keep the default interval if other tools use the same token.

Self-hosted controller​

The local API of ZeroTier only answers the node itself by default. Allow the address Gladys calls from in the local.conf file of the controller's ZeroTier folder (/var/lib/zerotier-one on Linux), then restart ZeroTier:

{ "settings": { "allowManagementFrom": ["192.168.1.0/24"] } }

Gladys calls from its host (the integration runs in a Docker container on the default bridge): allow the address of the Gladys machine, or, when the controller runs on the same machine, the Docker range (172.16.0.0/12). As Controller address (self-hosted), give the address of the machine of the controller on your local network, never 127.0.0.1.

The devices​

Each network (ZeroTier followed by its name):

FeatureWhat it shows
Online membersMembers online right now
MembersMembers of the network
Awaiting authorizationMembers that asked to join and are not let in yet

Each member (its name, or its node ID when it has none, followed by (ZeroTier)):

FeatureWhat it shows
OnlineYes when the member was seen a few minutes ago at most
AuthorizedWhether the member is authorized on the network (a switch, read only by default)
Last seenWhen it went offline; while online, when it came online
Managed IP addressThe addresses the network gives it (None when it has none)
ZeroTier versionThe version of ZeroTier the member runs

The same machine in two networks is two devices: its authorization is per network.

Online is read differently in each mode. With Central, a member is online when it checked in with Central less than 5 minutes ago (members check in about every minute). With a self-hosted controller, the controller does not store such a date: the integration reads the node's peers, and a member is online when the controller heard from it less than 3 minutes ago. A member reached through a relay (no direct path) counts as online once the node has listed it for 2 minutes; one that moves from a direct path to a relay is seen offline for about 12 minutes.

Authorized only becomes a command when Allow authorizing members is on: then Gladys, its scenes and voice assistants can let a member in or cut it off. Turning the option on or off changes the device: press Update in the Discovery tab.

Dashboard​

The ZeroTier members widget shows the online members and the members of the networks, then one row per member: the ones awaiting authorization first, then the online ones, then the others with the time they were last seen. Its Network (empty: all) setting shows a single network.

Scenes​

Triggers​

  • ZeroTier member online: a member came online.
  • ZeroTier member offline: a member has not been seen for a few minutes.
  • New member awaiting authorization: a new device asked to join a private network.

Each trigger can be limited to one member (Member (empty: any)) or one network (Network (empty: any)), and gives the variables Member name, Node ID and Network name to the scene's messages. No event is sent at the first reading after a start or a change of configuration: the previous state is unknown. Online and offline only concern authorized members: a stranger coming and going fires nothing, and authorizing a connected member fires ZeroTier member online.

Scene ideas​

  • When a new member awaits authorization, send yourself a message with its Node ID and the Network name, then authorize it in Central or from its device in Gladys.
  • When the laptop of a teenager comes online after 11 pm, send a notification.
  • When the remote NAS that keeps your backups goes offline, send a message.

Troubleshooting​

  • "API token refused": check the token. For a self-hosted controller, it is the whole content of authtoken.secret, without a new line.
  • "ZeroTier does not answer": with Central, check the Internet access of Gladys. With a self-hosted controller, check the address and the port (9993), and that allowManagementFrom allows Gladys (see above).
  • "network not found": the network ID is wrong, or the token does not see that network.
  • "this ZeroTier node is not a network controller": the address is the one of an ordinary ZeroTier node, not of the controller of your networks.
  • "too many requests to ZeroTier Central": the integration already waits longer between readings; choose a longer interval.
  • A member stays online after being switched off: it takes up to 5 minutes, plus one reading, and up to about 9 minutes for a relayed member of a self-hosted controller.

Limits​

  • One controller (or one Central account) per installation of the integration.
  • The integration does not create networks, nor rename or delete members: that stays in Central or on your controller.
  • The last seen date of a self-hosted controller is kept in memory: it is unknown again after a restart of the integration, until the member is seen.
  • Central members that were deleted (hidden by Central) are not shown.
  • Not affiliated with ZeroTier, Inc. ZeroTier is a trademark of ZeroTier, Inc.

Configuration settings​

These are the settings ZeroTier asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your ZeroTier networkssectionNoZeroTier Central (my.zerotier.com): an API token of your account. Self-hosted controller: the address of its node and the content of its authtoken.secret file.
ControllerselectNoWhere your networks are managed.
API tokensecretNoCentral: Account → API Access Tokens. Self-hosted: the content of authtoken.secret (/var/lib/zerotier-one on Linux).
Controller address (self-hosted)stringNoOnly for a self-hosted controller: its IP address, port 9993 by default. Its local.conf must allow the address of Gladys (allowManagementFrom).
Networks to followstringNoNetwork IDs (16 characters), separated by commas. Empty: every network the token sees.
Refresh intervalselectNoHow often ZeroTier is read: one request per network, plus one. A member counts as offline a few minutes after it stops.
Allow authorizing membersbooleanNoOff: the "Authorized" switch is read only. On: Gladys, its scenes and voice assistants can let a member in or cut it off.
Language of the namesselectNoLanguage of the feature names and of the dates, set when a device is added.

How to install ZeroTier in Gladys​

  1. In Gladys, open Integrations: ZeroTier appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-zerotier:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-zerotier.

ZeroTier requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

ZeroTier is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
