Z-Wave JS UI integration for Gladys Assistant

Z-Wave JS UI integration for Gladys Assistant

Control your Z-Wave network in Gladys through Z-Wave JS UI and MQTT.

View on GitHubAll external integrations

Control your Z-Wave network from Gladys, through Z-Wave JS UI and an MQTT broker.

This integration does not talk to your Z-Wave stick directly. Z-Wave JS UI owns the radio and the network management (inclusion, exclusion, healing, firmware updates); this integration turns the nodes it publishes into Gladys devices, and Gladys commands into Z-Wave commands.

What you need​

  1. Z-Wave JS UI, running and already paired with your Z-Wave controller.
  2. An MQTT broker (Mosquitto, EMQX…) reachable from both Z-Wave JS UI and Gladys.

Setting up Z-Wave JS UI​

The integration expects MQTT topics named in a specific way. These are not configurable on the Gladys side: Z-Wave JS UI is the one that must match.

In Settings, MQTT section:

  • Name: zwave-js-ui — otherwise the prefix of some topics will be wrong;
  • Prefix: zwave;
  • Host url / Port: your broker, plus the username and password if it requires them.

MQTT section

Then, in the Gateway section, exactly these settings:

  • Topic type: Named topics;
  • Payload type: Entire Z-Wave value Object;
  • Send Z-Wave events: enabled;
  • Include Node info: enabled;
  • Publish node details: enabled;
  • Ignore location and Ignore status updates: disabled.

Gateway section

Without the payload type and the Z-Wave events, no device state ever reaches Gladys.

Configuring the integration​

In Gladys, open the integration's Configuration tab:

  1. MQTT broker URL — for example mqtt://192.168.1.10:1883.
  2. MQTT username / password — leave empty for an anonymous broker.
  3. Save.

Use Test the connection to check the link: it reports the broker it reached and how many Z-Wave nodes it can see.

Adding your devices​

Open the Discovery tab: every non-virtual Z-Wave node appears there, with the features this integration understands. Pick a room, adjust the name, and create the devices you want. Scan asks Z-Wave JS UI for a fresh node list — useful right after including a new device.

A device you create is populated immediately from the last known values, so it is not blank while waiting for a battery sensor to wake up.

Supported devices​

Features are derived from the Z-Wave command classes a node exposes:

Command classWhat you get in Gladys
Binary Switchon/off switch
Multilevel Switch (dimmer)brightness, on/off, "restore previous"
Multilevel Switch (window covering)shutter position, open/close/stop
Binary Sensor / Alarm Sensormotion, smoke, CO, CO₂, leak, opening, temperature
Notificationdoor/window opening, smoke alarm, CO alarm
Multilevel Sensortemperature, illuminance, power
Meterenergy, power, voltage, current
Central Scenebutton clicks (single, double, triple, hold, release)
Batterylevel and low-battery flag
Thermostat Modemode: off, heat, cool, auto
Thermostat Setpointheating, cooling and energy-save setpoints
Thermostat Operating Statewhat it is really doing: idle, heating, cooling

Thermostats​

A Z-Wave thermostat exposes up to three distinct setpoints — heating, cooling and energy save — and each becomes its own temperature feature in Gladys. The mode is what the device is asked to do; the operating state is what it is actually doing: a thermostat set to Heat goes idle once the room is warm enough.

One limitation worth knowing: the Z-Wave "Energy Save Heat" mode has no Gladys equivalent. It is therefore reported as Heating — which is what the device is doing — but selecting Heating from Gladys switches the thermostat from energy-save to plain heating. The energy-save temperature itself stays adjustable through its own setpoint.

The modes offered in the UI are Off, Heat, Cool and Auto. Z-Wave does not reliably advertise which modes a device supports, so a heat-only thermostat still shows Cool and Auto, and ignores them.

A node exposing something else still appears in Discovery — only the features above are created.

Troubleshooting​

Nothing appears in Discovery. Check the Configuration tab status. If it says the broker is unreachable, the URL or the credentials are wrong. If it is connected but no node shows up, go back over "Setting up Z-Wave JS UI": Name must be zwave-js-ui and Prefix zwave, or the integration listens on topics nobody publishes to.

A device stopped updating. Z-Wave JS UI is the source of truth: check the node is alive there first.

"State budget exhausted" in the logs. Gladys accepts 300 states per minute per integration. A very chatty network (energy meters reporting every few seconds) can exceed it: the integration then keeps the first and last value of each feature and drops the intermediate ones. Reducing the report frequency of the noisiest devices in Z-Wave JS UI is the real fix.

Set LOG_LEVEL=debug for verbose logs, readable from the integration's Logs tab.

Migrating from the built-in Z-Wave JS UI integration​

Gladys ships a built-in zwavejs-ui service. This external integration replaces it and produces the same devices, features, categories, units and names, so your history, scenes and dashboards can follow.

  1. Install and configure this integration.

  2. In the Discovery tab, create the devices matching the ones you already have.

  3. Migrate each device, which moves its history and rewrites the references in your scenes and dashboards. Until the built-in integration is flagged as deprecated in Gladys, the migration has no button yet — call the API directly, once per device:

    POST /api/v1/device/<internal-device-selector>/migrate
    {
      "destination_device_selector": "<new-device-selector>",
      "features_mapping": {
        "<source-feature-selector>": "<destination-feature-selector>"
      }
    }

    Both devices expose the same feature list in the same order, so the mapping is one-to-one.

  4. Once every device is migrated, disable the built-in integration.

Migrating deletes the source device: do it once you are satisfied with the new one.

Configuration settings​

These are the settings Z-Wave JS UI asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Before you startsectionNoThis integration does not talk to your Z-Wave controller directly: it connects to a running Z-Wave JS UI through your MQTT broker. Install Z-Wave JS UI first, enable its MQTT gateway, and make sure both are reachable from Gladys.
Configure Z-Wave JS UIsectionNoIn the Z-Wave JS UI settings, MQTT section: set "Name" to zwave-js-ui and leave "Prefix" at zwave — the integration expects those exact values to build its topics. Then, in the Gateway section, set "Topic type" to Named topics and "Payload type" to Entire Z-Wave value Object, and enable Send Z-Wave events, Include Node info and Publish node details. Without these, no device state ever reaches Gladys. The two screenshots below show the expected settings.
MQTT broker URLstringYesAddress of the broker Z-Wave JS UI publishes to, protocol included.
MQTT usernamestringNoLeave empty if your broker accepts anonymous connections.
MQTT passwordsecretNo

How to install Z-Wave JS UI in Gladys​

  1. In Gladys, open Integrations: Z-Wave JS UI appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/sescandell/gladys-zwavejs:1.8.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/sescandell/gladys-zwavejs.

Z-Wave JS UI requires Gladys >=4.85.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Z-Wave JS UI is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by sescandell, not by the Gladys core team.
