Yeelight integration for Gladys Assistant
Control your Yeelight Wi-Fi lights locally: on/off, brightness, color.
Published by William-De71
- Devices
- Version 1.2.0
- Requires Gladys >=4.86.0
- ★ 0
This integration lets you control your Yeelight lights (bulbs, LED strips, bedside lamps, ceiling lights) from Gladys Assistant, directly on your local network. No cloud account, no gateway, no middleman: Gladys talks to your lights itself.
Features
The integration adapts to what each light can do — a light advertises its own capabilities, and only the features actually available are created:
| Feature | Lights concerned |
|---|---|
| On / off | All |
| Brightness (1 to 100 %) | All dimmable lights |
| Color (RGB) | Color models (color, strips, bedside lamps) |
| Color temperature | Tunable-white and color models |
| Ambient light | Ceiling lights and light bars with a backlight |
| Night light (moonlight) | Ceiling lights |
States arrive in real time
Your lights push their state changes: the integration keeps a connection open to each light, and Gladys receives the new value the moment it changes — including when you use the Yeelight app, the remote, or the wall switch. There is no polling interval to set.
Requirements
Enable "LAN Control" — mandatory
This is the step not to skip: by default a Yeelight light refuses every local command. Without this option the light is neither discoverable nor controllable.
For each light, in the Yeelight app:
- Open the light.
- Go to Settings (icon in the top right corner).
- Enable LAN Control (also called "Developer mode").
Do this for every light, one by one. It is a setting stored in the light itself.
Network
- Gladys and your lights must be on the same subnet for automatic discovery to work.
- Discovery broadcasts a request on UDP port 1982. A broadcast never crosses a router: if your lights sit on another VLAN or subnet than Gladys, the scan will not find them — that is a network boundary, not a setting to tune. Raising the scan duration changes nothing.
- In that case, add your lights by hand (see below): control itself is direct TCP and works fine across subnets, as long as they are routed.
Configuration
1. Discover your lights
Once "LAN Control" is enabled, open the integration's Discover screen and run a scan. Your lights appear with their name (the one you gave them in the Yeelight app), ready to be added. No IP address to type.
2. Transition duration
Sets the fade applied to every change (switching on, dimming, color). The default of 500 ms gives a smooth, natural transition. Set 0 for an instant change.
3. Lights not found by the scan
Two cases lead here, and the second is the most common:
- "LAN Control" is not enabled on the light (see Requirements);
- your lights sit on another subnet / VLAN than Gladys — the scan structurally cannot reach them, but control works.
Add their address under Lights added by hand, one per line:
192.168.1.42
192.168.1.43:55443
Important: give those lights a fixed IP address in your router. Unlike a light found by the scan — identified by its serial number, stable for life — a light added by hand is identified by its address. If its DHCP lease changes, Gladys will see it as a different light.
4. Discovery duration
How long the scan listens for answers. 5 seconds is plenty in most cases; raise it if your network is busy and some lights are missing.
Available actions
- Test the connection: runs a discovery and reports how many lights answered.
- Reconnect the lights: closes every connection and reopens them. Useful after a power cut or a network change.
Good to know
Setting a color on a light that is off
A Yeelight refuses color, temperature and brightness commands while it is off. The integration turns it on automatically before applying your setting: clicking a color therefore switches the light on in that color, which is what you meant.
Brightness starts at 1 %, not 0 %
A Yeelight has no "0 %" state: zero means off. Setting the brightness to 0 in Gladys therefore switches the light off.
The color shown in white mode
When a light is in white mode (color temperature), it still remembers the last color used. Gladys deliberately does not show it as the active color, so you never see a color the light is not actually displaying.
Ceiling lights have two independent lights
A ceiling light with a backlight (ceiling10, light bars…) exposes two separate lights, and Gladys names them explicitly:
- Main light, Main brightness, Main colour, Main colour temperature;
- Ambient light, Ambient brightness, Ambient colour, Ambient colour temperature.
Each one switches on and off independently of the other. To drive both in one go, create a Gladys scene acting on both switches — that is how Gladys groups several commands.
Ambient colour temperature only appears on models whose backlight can tune its white — the warm/cold slider the Yeelight app shows next to the ring's colour wheel.
On a light without a backlight there is only one light, and the labels stay simple (On/Off, Brightness, Colour, Colour temperature).
If your ceiling light switches its ring on and off together with the main light, that is not Gladys: it is the "Auto on/off with the main light" option in the Yeelight app. Turn it off to drive each light separately.
Colour temperature
The temperature slider follows the Gladys gradient: left is cold, bluish light; right is warm, orange light. The integration converts that value into the Kelvin the light understands, respecting the real range of your model (2700–6500 K on a ceiling light, 1700–6500 K on a colour bulb).
Light limits
Each light accepts 4 simultaneous connections and 60 commands per minute. The integration opens a single connection per light and smooths command bursts automatically, but keep those limits in mind if you also drive your lights from other apps at the same time.
Troubleshooting
| Symptom | Most likely cause |
|---|---|
| No light found | "LAN Control" is not enabled in the Yeelight app |
| Only one light out of several is found | The option is only enabled on that one — it is set per light |
| A light disappears then comes back | Wi-Fi drop or wall switch: the integration reconnects on its own, backing off |
| A hand-added light becomes unknown | Its IP address changed — give it a fixed address in your router |
| Commands stop working after a while | Another piece of software is holding the light's 4 connection slots |
Configuration settings
These are the settings Yeelight asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Getting started | section | No | This integration talks to your Yeelight lights on your local network, with no cloud account involved. One thing to do first: in the Yeelight app, open each light and enable "LAN Control" (Settings → LAN Control). A light without it refuses every local command and will not be found. Then go to the Discover screen and run a scan: your lights appear there, ready to be added. No IP address to type. |
| Transition duration (ms) | number | No | How long a light takes to fade to its new state. Set 0 for an instant change. |
| Lights not found by the scan | section | No | Fill the field below if a light is not found by the network scan. The most common reason: your lights sit on another subnet or VLAN than Gladys — the discovery broadcast does not cross a router, so the scan cannot reach them, while control itself works fine. Raising the discovery duration does not help in that case. |
| Lights added by hand | string | No | One address per light (192.168.1.42, or 192.168.1.42:55443), separated by a comma. Give these lights a fixed address in your router: unlike a light found by the scan, one added by hand is identified by its address, and a new DHCP lease would make Gladys see it as a different light. |
| Discovery duration (s) | number | No | How long the scan listens for lights answering on the network. Only useful on a busy network: it cannot help if your lights are on another subnet. |
How to install Yeelight in Gladys
- In Gladys, open Integrations: Yeelight appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/william-de71/gladys-yeelight:1.2.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/William-De71/gladys-yeelight.
Yeelight requires Gladys >=4.86.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
Yeelight is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by William-De71, not by the Gladys core team.
