Xbox smart home integration, free and open source
Turn your Xbox consoles on and off, control them and see the game being played.
Published by prohand
- Devices
- Version 1.1.0
- Requires Gladys >=5.1.0
- ★ 0
Control your Xbox consoles (Xbox One, Xbox Series X|S) from Gladys: turn them on and off, see whether they are on and which game is being played, use them in scenes and on the dashboard.
Two channels
| Channel | Needs | What it does |
|---|---|---|
| Local (your network) | nothing | finds the consoles, sees whether they are on, turns them on |
| Cloud (Xbox Live) | a Microsoft account | everything above, plus: turn off, volume, mute, media keys, controller buttons, launch a game, game played |
You can use the local channel alone, the cloud channel alone, or both. With both, the Prefer the local (LAN) connection when available switch of the configuration picks the one asked first; the other one takes over when the first does not answer. The badge of each console says which channel served it last (orange dot: the cloud serves a console the local search did not find).
Prepare the console
- Power mode: Settings → General → Power options → Sleep (Xbox Series) or Instant-on (Xbox One). In "Shut down (energy saving)" mode the console cannot be turned on from the network, by any channel.
- Remote features (cloud channel): Settings → Devices & connections → Remote features → tick Enable remote features.
- In the same screen, under Xbox app preferences, choose Allow connections from any device: it helps the local channel.
Local channel
Nothing to fill in: open the integration, click Test the connection and search for consoles, then create your consoles in the Discover tab.
The search asks Gladys to send a SmartGlass discovery on UDP port 5050 of your network (Gladys shows this permission when you install the integration). A console on another subnet, or behind a router that filters broadcasts, is not found that way: type its IP address in Console IP addresses (several addresses separated by commas). Give the console a fixed address in your router so it does not change.
Cloud channel
The cloud channel signs in to Xbox Live with your Microsoft account, through an application you register at Microsoft (free). Gladys never sees your password.
- Open the Azure portal → App registrations →
New registration.
- Name:
Gladys Xbox(anything). - Supported account types: Personal Microsoft accounts only (or "any organizational directory and personal Microsoft accounts").
- Redirect URI: platform Web, address: the one of the Gladys Connect button (see below).
- Name:
- In the application, copy the Application (client) ID.
- Certificates & secrets → New client secret → copy its Value (not its ID: the value is only shown once).
- In Gladys, paste the two values in Application (client) ID and Client secret, save, then click Connect next to Microsoft account and sign in.
Which redirect URI? The integration writes it in its logs when you click
Connect (Redirect URI to register in Azure: …), and Microsoft shows it in the
error page if it is not registered yet. Microsoft only accepts an https
address (or http://localhost): open Gladys through its https address (Gladys
Plus, your reverse proxy) when you click Connect.
The link lasts: the integration renews its access by itself. If the configuration shows "The Microsoft account link expired", click Connect again.
The console in Gladys
Each console is a television-type device:
- Power: on/off. On: local packet or cloud, by preference. Off: cloud only.
- Mute, Volume up / down, Play, Pause, Previous, Next, the arrows, A (select), B (back), Menu, View, Xbox button (guide): cloud only.
- Game being played: the name of the game or app in the foreground,
-on the home screen or when the console is off (cloud only).
The console is read every 60 seconds by default (Refresh interval, 30 seconds minimum), and again within 30 seconds after a command.
Scenes
Triggers:
- A game starts on an Xbox: filter on the console and on the exact game
name. Variables:
title_name,title_id. - A game stops on an Xbox: same filters. Variables:
title_name,title_id,played_minutes.
Use them in the next actions as {{triggerEvent.data.title_name}}, e.g. send
"Lucas played 95 minutes of Minecraft" by message.
Actions:
- Turn on an Xbox and wait: turns the console on, then waits until it
answers (up to 100 s). Output
awake(true / false) to gate the next actions. - Launch a game on an Xbox: by its Microsoft Store product ID, the 12
characters at the end of the game page address on xbox.com, e.g.
xbox.com/…/games/store/<name>/9NBLGGH2JHXJ. Outputlaunched. - Press a controller button: A, B, X, Y, arrows, Xbox button, View, Menu.
Output
pressed.
The power, mute and keys are also available in the standard "Set device value" action, and the power state in the standard "Device state change" trigger.
The game being played comes from the presence of your Xbox Live account, not from one console: with several consoles on at the same time, they all show the game of the linked account.
Dashboard widget
In Dashboard → Edit → New widget, add the Xbox console widget and pick a console (the first one by default): power, game being played, connection, account, and quick buttons — turn on, and with the cloud channel: home, play/pause, turn off.
Troubleshooting
- No console found: is it on, or in Sleep / Instant-on mode? Is Gladys on the same network? Try typing its IP address.
- The console does not turn on: check the power mode (Sleep / Instant-on). On the local channel, the console must have answered at least once so its Live ID is known.
- "needs the cloud channel": turning off and the keys need the Microsoft account.
- The commands do nothing: enable the remote features on the console.
- Logs: Gladys → Integrations → Xbox → Logs tab. They never contain your tokens nor your secret.
Configuration settings
These are the settings Xbox asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Getting started | section | No | Local channel, no account needed: the integration finds the consoles of your network, sees whether they are on and turns them on. Set the console power mode to Sleep (instant-on). Cloud channel, optional: with your Microsoft account it also turns them off, controls the volume, the media and the controller buttons, launches games and shows the game being played. |
| Console IP addresses | string | No | Optional. The consoles are found automatically on the network; list here the ones that are not (another subnet, a router that filters broadcasts), separated by commas. |
| Cloud channel (optional) | section | No | Register an application in the Microsoft Azure portal (personal Microsoft accounts, Web platform), with the redirect URI shown by the Connect button. Copy its application (client) ID and a client secret below, save, then click Connect. On the console, enable Settings > Devices & connections > Remote features. |
| Application (client) ID | string | No | The application ID of your Azure app registration. |
| Client secret | secret | No | The value of a client secret of the same application (Certificates & secrets). Leave it empty for a public client application. |
| Microsoft account | oauth2 | No | Links the Microsoft account that owns the consoles. Only a refresh token is kept, never your password. |
| Refresh interval (s) | number | No | How often each console is read, in seconds (30 seconds minimum). |
How to install Xbox in Gladys
- In Gladys, open Integrations: Xbox appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/prohand/gladys-xbox:1.1.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/prohand/gladys-xbox.
Xbox requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
Xbox is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by prohand, not by the Gladys core team.
