Wyze integration for Gladys Assistant

Control your Wyze bulbs, light strips, plugs, cameras and Sense sensors.

View on GitHubAll integrations

Control your Wyze devices from Gladys Assistant: bulbs, light strips, plugs, cameras and Wyze Sense sensors, with scene triggers and actions and two dashboard widgets.

Supported devices​

Wyze deviceIn Gladys
White bulb (WLPA19, HL_HWB2)On/off, brightness, color temperature
Color bulb (WLPA19C, BR30) and light strip (HL_LSL)On/off, brightness, color temperature, color — local control on LAN
Plug and outdoor plug (WLPP1, WLPP1CFH, WLPPO)On/off (one device per outlet)
Cameras (Cam v2/v3/v4, Pan, Outdoor, Doorbell...)Latest image, motion, power, siren, motion detection
Floodlight Pro, Battery Cam Pro, Cam OG, Pan v4Latest image and motion (their controls use another Wyze API)
Wyze Sense contact sensor (DWS3U, DWS2U)Open/closed, low battery
Wyze Sense motion sensor (PIR3U, PIR2U)Motion, low battery

Other Wyze devices (locks, thermostat, vacuum, scales...) are ignored.

Before you start: create a Wyze API key​

Wyze only lets third-party applications log in with a personal API key, on top of your email and password. The key also spares you the two-factor code.

  1. Open the Wyze developer console and sign in with your Wyze account.
  2. Create an API key. Copy the KEY ID and the API KEY: the API key is shown only once.
  3. Keep them for the configuration below. You can revoke the key from the same console at any time.

Configuration​

  1. Open the Configuration tab of the integration.
  2. Fill in your Wyze email, password, API key id and API key.
  3. Optionally change the refresh interval (60 seconds by default, 30 at least): how often the states and the camera events are read.
  4. Save, then click Test the connection: it logs in and tells you how many compatible devices it found.
  5. Open the Discovery tab and add the devices you want in Gladys.

Only the devices you add are read at each refresh, which spares the Wyze cloud. Synchronize now forces a refresh.

Local control​

Wyze is a cloud service, with one exception: color bulbs and light strips accept commands on your local network. When Prefer the local connection is on (the default), their commands go straight to the bulb; the states are still read from the cloud.

The badge of each device tells which channel it uses: local, cloud, or unreachable when Wyze reports the device offline. An orange dot means a local command failed and the bulb went through the cloud instead; Gladys tries the local network again after 5 minutes. Gladys must be able to reach the bulb on TCP port 88 (same network, no client isolation on the Wi-Fi).

Cameras​

The Wyze cloud offers no live video: the camera image in Gladys is the latest thumbnail Wyze keeps, usually the one of the last event. It is refreshed at each new event. Gladys only accepts images up to 150 KB; a larger thumbnail is skipped (see the logs).

The Motion feature of a camera goes to 1 for about 30 seconds when the camera records a motion event, then back to 0. The detection depends on your camera settings in the Wyze app (detection zones, sensitivity, notifications). The objects (person, vehicle, pet, package) need a Cam Plus subscription.

Scenes​

The integration adds its own cards to the scene editor (Gladys 5.1 or later).

Triggers:

  • Wyze camera event — a camera recorded an event. Filter on the camera, the event (motion, sound, smoke alarm, CO alarm, doorbell, face, other) and the recognized object (person, vehicle, pet, package, nothing). Empty filters match anything. The following actions can read {{triggerEvent.data.event}} and {{triggerEvent.data.object}}.
  • Wyze device online/offline — a device lost its cloud connection, or got it back. Variable: {{triggerEvent.data.status}} (offline / online).

Actions:

  • Wyze camera siren — start or stop the siren of a camera.
  • Wyze motion detection — enable or disable the motion detection of a camera (for instance when the alarm is armed).
  • Wyze camera image — publish the latest image of a camera, then send it with the Gladys "send a camera image" action.
  • Refresh Wyze devices — read the devices now; returns the number of devices and of devices online.

A camera that cannot run an action (Floodlight Pro...) returns false instead of failing, so the next actions can depend on it.

Dashboard​

Two widgets are available in the dashboard editor:

  • Wyze overview — devices, online and offline, open doors and windows, cloud status, last refresh, last camera event, and a Sync now button.
  • Wyze camera — pick a camera in the widget settings: latest image, live motion, connection, last event, and siren buttons (the siren asks for confirmation).

Troubleshooting​

  • "Wyze refused the login" — check the email, the password, and that the API key id and API key come from the same key. After a refused login, Gladys waits 15 minutes before trying again (Wyze locks accounts that log in too often); saving the configuration retries at once.
  • A device does not update — check it is online in the Wyze app; the states are read at each refresh interval.
  • A color bulb is always on the cloud — check that Gladys can reach the bulb on TCP port 88, or turn off Prefer the local connection.
  • Logs — open the integration logs from Gladys (or docker logs), with LOG_LEVEL=debug for the details. Passwords and tokens are never logged.

Privacy​

Your credentials are stored by Gladys in its configuration. The Wyze session (access and refresh tokens) is kept in the integration's private volume, so a restart does not log in again. The integration only talks to the Wyze cloud, and to your color bulbs on the local network.

This integration is not affiliated with Wyze Labs. It uses the same cloud API as the Wyze app, which Wyze may change without notice.

Configuration settings​

These are the settings Wyze asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Connect your Wyze accountsectionNoWyze requires a personal API key in addition to your email and password. Create it in the Wyze developer console with your Wyze account: copy the key id and the API key below. The API key also avoids the two-factor prompt.
Wyze emailstringYes
Wyze passwordsecretYes
API key idstringYesThe "KEY ID" of the Wyze developer console.
API keysecretYesThe "API KEY" shown once when the key is created.
Refresh interval (s)numberNoHow often the states and the camera events are read from the Wyze cloud, in seconds (30 minimum).

How to install Wyze in Gladys​

  1. In Gladys, open Integrations: Wyze appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/gboulvin/gladys-wyze:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/gboulvin/Gladys-Wyze.

Wyze requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Wyze is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by gboulvin, not by the Gladys core team.
