VLC smart home integration, free and open source

VLC integration for Gladys Assistant

Control VLC media player: playback, volume, now playing, web radios, announcements, scenes.

View on GitHubAll external integrations

Control VLC media player from Gladys: on a computer, a Raspberry Pi or a server, follow what it plays, drive the playback and the volume, play a web radio or a file from a scene, and make Gladys announcements heard on its speakers.

This integration is not affiliated with VideoLAN. VLC is a trademark of VideoLAN.

Presentation​

The integration talks to VLC through its web interface (the Lua HTTP interface, port 8080), on your local network only: no cloud, no account.

  • One device per VLC (up to three): state, title, artist, album, progress, time left, volume, and the play, pause, stop, previous, next and mute buttons.
  • The core's Music dashboard box works with it (play/pause, previous, next, volume).
  • Announcements: the core's Talk on a speaker scene action plays on VLC, then what was playing comes back.
  • A VLC player dashboard widget, four scene triggers (playback started, paused, resumed, stopped) and two scene actions (play an address, empty the playlist).

Developed and tested against a real VLC 3.0.20 on Linux, without Gladys hardware around it: feedback welcome, especially on Windows and macOS.

Why the web interface and not telnet? VLC has two remote interfaces. The web interface answers JSON with everything at once: state, volume, position, length, and the tags of the current item, including the song of a web radio (now_playing) and its artwork. The telnet interface (the one Home Assistant uses) answers text meant for humans, partly translated into VLC's language, over a connection that must be kept open. Both need a password; both are available on every VLC 3.

Requirements​

  • Gladys Assistant 5.1 or later.
  • VLC 3.0 or later, with its web interface turned on and a password set (VLC refuses to start it without one).
  • The computer running VLC reachable from the Gladys server on the port of the web interface (8080 unless changed): allow VLC in its firewall when the system asks.

Turn on VLC's web interface​

From VLC's window (Windows, Linux):

  1. Tools → Preferences, then at the bottom left Show settings: All.
  2. Interface → Main interfaces: tick Web.
  3. Interface → Main interfaces → Lua: type a password in Lua HTTP → Password.
  4. Save, then quit and restart VLC.

On macOS: VLC → Settings (or Preferences), Show All, then the same three steps: Interface → Main interfaces, tick Web; Main interfaces → Lua, set the password; save and restart VLC.

From the command line (a Raspberry Pi or a server without a screen, or to keep the window too):

## With VLC's window
vlc --extraintf http --http-password 'your-password'
## Without a window (Linux, Raspberry Pi)
cvlc --intf http --http-password 'your-password'
## Another port
cvlc --intf http --http-port 9090 --http-password 'your-password'

On Windows: "C:\Program Files\VideoLAN\VLC\vlc.exe" --extraintf http --http-password your-password. On macOS: /Applications/VLC.app/Contents/MacOS/VLC --extraintf http --http-password your-password.

Check it from a browser on another computer: http://<address>:8080 asks for a password (leave the user name empty) and shows VLC's web remote.

Configuration​

In Integrations → VLC → Configuration:

  • VLC address: the IP address of the computer running VLC, e.g. 192.168.1.20. Add :port if the web interface does not use 8080 (192.168.1.20:9090). A host name works too. Do not type localhost or 127.0.0.1, even when VLC runs on the Gladys server: the integration runs in its own container, give the network address of the computer.
  • Password: the Lua HTTP password set in VLC.
  • VLC 2 and VLC 3: two more VLC, optional, set up the same way.
  • Language: the language of the feature names and of the texts the integration writes (French by default). The feature names are fixed when a device is added.

Click Save, then Test the connection: each VLC answers with its version and what it does. Finally, in the Discover tab, add each VLC: its device is named VLC (<address>), rename it as you like.

Devices​

Each VLC is a device with these features:

FeatureWhat it shows or does
Playing1 while VLC plays, 0 otherwise (paused, stopped, closed)
Playback statePlaying, Paused, Stopped, or Off or unreachable
TitleThe title of the item; for a web radio, the song it announces
ArtistThe artist; for a web radio without one, the name of the station
AlbumThe album (— when unknown)
ProgressThe percentage played (0 for a live stream)
Time leftThe minutes left (0 for a live stream)
VolumeA slider, 0 to 100 %
PlayResumes a paused item, or starts the playlist
PausePauses (nothing happens when nothing plays)
StopStops
Previous, NextMoves in the playlist
MuteMutes, or brings the volume back
NotificationUsed by the core's Talk on a speaker scene action

Volume: VLC's own slider goes up to 125 % (and beyond from the web interface). Gladys shows 100 % for anything above, and the slider sets 0 to 100 %.

Mute: VLC's web interface neither tells nor sets its mute. The Mute button sets the volume to 0 and remembers the one before; pressed again, it brings it back (50 % if it was lost). A VLC at 0 % shows as muted.

Announcements: the Talk on a speaker scene action of the core (text-to-speech, it needs Gladys Plus) sends the address of an MP3 to the Notification feature. VLC plays it at once, at the current volume (the core does not give its volume to integrations: put a Set device value action on the Volume feature before it). When it ends, the integration removes it from the playlist and, if VLC was playing, plays it again: a file where it was, a web radio from now. The scene triggers stay quiet meanwhile. VLC must reach the address of the MP3 (Gladys Plus, or your Gladys server).

Refresh: VLC pushes nothing, the integration reads it. Every 3 seconds while something plays, every 5 seconds when stopped, every minute for a VLC not added to Gladys yet, and every 30 seconds when VLC is closed or unreachable — local requests that VLC answers in a few milliseconds, with no quota. A single missed answer is ignored; after two, VLC is "Off or unreachable".

Dashboard widget​

Add the VLC player widget (an external integration widget) and choose a VLC. It shows:

  • the artwork of the item when VLC has one (the progress gauge otherwise);
  • the title, then the artist, the album and the VLC name;
  • the state, the position (1:23 / 3:20) and the volume;
  • four buttons: play/pause, next, volume down and volume up (5 % steps).

The core's Music box also works with each VLC: play/pause, previous, next and the volume slider.

Scene triggers​

Each trigger can be limited to one VLC (empty: any VLC), and gives the scene the VLC name, the title, the artist and the album.

  • Playback started: VLC starts playing something: a file, a web radio, the next item of the playlist. A web radio announcing its next song is not a new start.
  • Playback paused: what VLC plays is paused.
  • Playback resumed: the paused item plays again.
  • Playback stopped: nothing plays anymore: stopped, end of the playlist, or VLC closed. The title is the one that stopped.

The first read after Gladys or the integration restarts fires nothing.

Scene actions​

  • Play an address in VLC: a web radio, a stream or a file. The address is an http(s), rtsp, rtp, udp, mms, ftp, smb or file URL, or a full path on the computer running VLC (/home/me/Music/song.mp3, C:\Users\me\Music\song.mp3). How: add to the playlist and play now (default), replace the playlist and play, or add at the end of the playlist. Volume: optional, 0 to 100 %. VLC's own commands (vlc://quit), the screen and the capture devices are refused.
  • Empty the VLC playlist: stops the playback and removes every item.

Playing, pausing, the volume and the other buttons are in the core's Set device value action, on the device features.

Scene examples​

  • Wake up with the radio: at 7:00 on weekdays, Play an address in VLC with the address of your radio, volume 20 %; ten minutes later, a Set device value action sets the Volume to 40 %.
  • Movie night: trigger Playback started on the living-room VLC, then dim the lights; Playback paused turns them up a little; Playback stopped turns them back on.
  • Doorbell: when the doorbell rings, Set device value on the Pause button of the VLC, then Talk on a speaker "Someone is at the door"; the music comes back after the announcement.
  • Leaving home: when everyone leaves, Empty the VLC playlist.

Do not start a playback from a Playback started trigger on the same VLC: the scene would start itself again.

Troubleshooting​

  • "No answer (closed, or web interface off)": VLC is closed, its web interface is off, or a firewall blocks the port. Open http://<address>:8080 from another computer to check.
  • "Password refused": retype the Lua HTTP password in both places. The user name stays empty in a browser.
  • "Use the network address of the computer, not localhost": type the IP address of the computer running VLC.
  • "This address does not answer like VLC": another program uses that port (a router, another web server): check the port of VLC's web interface.
  • The title shows a file name: the file has no tags; VLC shows its name.
  • The artwork does not show: VLC only has the artwork the file carries or the one it found itself; a web radio usually has none.
  • Details: set LOG_LEVEL=debug on the integration to see every read.

Limits​

  • No discovery on the network: VLC's web interface announces itself on no protocol Gladys can browse. Type the address.
  • Up to three VLC.
  • No real mute (see Devices), no seek, no shuffle or repeat from Gladys.
  • The state is read every 3 to 5 seconds: a pause and a resume in the same second may go unseen.
  • VLC 4 is not released yet: its web interface may change.
  • Tested on VLC 3.0.20 for Linux (playback of files, of a web radio, of an announcement, artwork, volume, wrong password, VLC closed and back), not on Windows, macOS or Android: feedback welcome.

Configuration settings​

These are the settings VLC asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Connect your VLCsectionNoTurn on VLC's web interface: in VLC, Tools > Preferences, Show settings: All, Interface > Main interfaces, tick Web; then Main interfaces > Lua, set a Lua HTTP password, and restart VLC. Or start it with --extraintf http --http-password <password>. Type below the address of the computer running VLC (port 8080 unless changed) and that password. Up to three VLC.
VLC addressstringNoIP address of the computer running VLC. Add :port if its web interface does not use 8080.
PasswordsecretNoThe Lua HTTP password set in VLC (VLC refuses to start its web interface without one).
VLC 2 (optional)sectionNoAnother VLC, set up the same way.
VLC address 2stringNo
Password 2secretNo
VLC 3 (optional)sectionNoAnother VLC, set up the same way.
VLC address 3stringNo
Password 3secretNo
OptionssectionNoLanguage of the names and texts the integration creates (feature names are set when a device is added).
LanguageselectNo

How to install VLC in Gladys​

  1. In Gladys, open Integrations: VLC appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-vlc:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-vlc.

VLC requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

VLC is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
