Uptime Kuma smart home integration, free and open source

Uptime Kuma integration for Gladys Assistant

See your self-hosted services in Gladys, and react when one goes down.

View on GitHubAll external integrations

Uptime Kuma watches your websites and services (HTTP, TCP port, ping, DNS, Docker containers…). This integration brings its monitors into Gladys: each one becomes a device showing whether the service is up, its response time and, for an HTTPS site, the days left before its certificate expires. Scenes can react when any service goes down or comes back, without one scene per device, and a dashboard widget sums it all up.

Tested against real Uptime Kuma 1.23.17 and 2.5.6 servers (Docker); not yet on every setup: feedback welcome on the issues.

What you need​

  • Gladys Assistant 5.1.0 or later.
  • Uptime Kuma 1.23 or 2.x, reachable from the Gladys machine (on the local network, or on the Internet in HTTPS).
  • An API key of Uptime Kuma (or its authentication disabled).

The integration only reads: pausing or resuming a monitor stays in Uptime Kuma (it would need your administrator password, which Gladys does not ask for).

Getting started​

1. Create an API key​

In Uptime Kuma, open Settings → API Keys, click Add API Key, give it a name (for example Gladys) and no expiry date, then Generate. Copy the key (it starts with uk): Uptime Kuma shows it only once.

Once a key exists, Uptime Kuma asks for a key on /metrics instead of your password: tools that read it with the password (Prometheus…) need a key too.

2. Configure the integration​

In Gladys, Integrations → Uptime Kuma → Configuration:

  • Uptime Kuma address: the address you open Uptime Kuma with, port included, for example http://192.168.1.2:3001 or https://status.example.com. A URL copied from the browser (…/dashboard/3) works too.
  • API key: the key of step 1.
  • Name (optional): shown in messages and in the widget instead of the address.
  • A second Uptime Kuma can be added, for example one on a rented server watching your home from the outside.
  • Refresh interval: 30 seconds by default (15 seconds to 5 minutes).
  • Certificate warning: the days left at which "Certificate expires soon" fires (14 by default).
  • Accept self-signed certificates: only for an https:// address whose certificate your browser does not trust either.
  • Language of the names: the language of the feature names and of the scene results (French by default).

Save, then click Test the connection: each Uptime Kuma answers with its version and its number of monitors.

3. Add the monitors​

Open the Discover tab: every monitor of Uptime Kuma is proposed. Add the ones you want to see in Gladys; nothing is added on your behalf. A monitor added later in Uptime Kuma appears there at the next read.

The device of each monitor​

FeatureValue
UpOn when the service is up, Off when it is down
Response timeThe last check, in milliseconds (not on group monitors)
Days until certificate expiryFor the monitors of an https:// site; negative once expired

While Uptime Kuma retries a failed check ("pending") or the monitor is in maintenance, the last value stays: only up and down count. While a monitor is down, its response time keeps its last value. A paused monitor sends nothing.

A response time changes at every check: it is sent to Gladys at most once a minute per monitor, so a hundred monitors stay far below the 300 values per minute Gladys accepts.

Dashboard​

Add the Uptime Kuma widget to a dashboard. It shows:

  • the number of services down (red when there is one) and up;
  • the certificate that expires first, in days (orange from the warning threshold);
  • one row per monitor, the problems first: down, pending, maintenance, paused, then the response time of the services up — ten rows at most, then the count of the others;
  • an instance of Uptime Kuma that does not answer;
  • a Refresh button that reads Uptime Kuma again.

By default the widget shows every monitor except the groups (they repeat their members). In its settings, Monitors narrows it to the devices you choose (only devices added to Gladys can be chosen, groups included).

Scenes​

Triggers​

They fire for every monitor, added to Gladys or not. Leave Monitors empty to react to any of them, or choose some.

  • A service goes down: a monitor goes from up (or maintenance) to down, once Uptime Kuma spent its retries. Variables: monitor name, monitor type, URL or host, Uptime Kuma name.
  • A service is back up: a monitor that was down is up again. Variables: the same, plus the outage length in minutes and the response time.
  • Certificate expires soon: the certificate of a monitor reaches the number of days left chosen in the configuration. Once per certificate; again after a renewal. Variables: monitor name, type, URL, days left, Uptime Kuma name.
  • Uptime Kuma no longer answers: Uptime Kuma itself stopped answering (two reads in a row), so nothing is watched any more. Variables: Uptime Kuma name, error.

A transition that happens while Gladys or the integration restarts is still announced, once. A monitor already down when the integration starts for the first time announces nothing.

A group monitor goes down with its members: choose the monitors in the filter to avoid two messages for one outage.

Actions​

  • State of a service: reads a monitor for the next actions of the scene: up (yes/no), the state in words ("Up", "Down", "Pending", "Maintenance", "Paused"), the monitor name, the response time and the days until certificate expiry.
  • Count the services down: the number of services down, up and in total (groups left out), and the names of the ones down, for a message.

Both read Uptime Kuma again when the last read is older than 15 seconds.

Scene ideas​

  • Alert on any outage: trigger "A service goes down" (Monitors empty) → send a message "⚠️ … is down", inserting the variables "Monitor name" and "URL or host". A second scene on "A service is back up" sends "✅ … is back after … min" with "Outage length (minutes)".
  • Morning report: every day at 8:00 → "Count the services down" → send a message "… service(s) down: …" with "Services down" and "Names of the services down".
  • Renew in time: trigger "Certificate expires soon" → send a message with "Monitor name" and "Days left".
  • The internet box is down: trigger "A service goes down" on the monitor of your router → turn on a red light.

Troubleshooting​

  • "API key refused": check the key (it starts with uk) and that it is active in Settings → API Keys. Uptime Kuma also refuses with the same error beyond 60 API requests per minute, shared by every tool that reads its metrics: lengthen the refresh interval if another tool reads it too.
  • "An API key is needed": Uptime Kuma has authentication on and no key is configured.
  • "Does not answer": check the address and the port (3001 by default) from the Gladys machine. localhost is the integration container itself: use the IP address of the machine running Uptime Kuma.
  • "Certificate refused": the HTTPS certificate is self-signed or expired; tick "Accept self-signed certificates", or use the http:// address on the local network.
  • "No Uptime Kuma at this address": the address points at another service, or Uptime Kuma 2 is still waiting for its database setup.
  • A monitor is missing in the Discover tab: it is paused in Uptime Kuma.
  • A device was proposed again after the upgrade to Uptime Kuma 2: devices added under 1.x keep their identity; a monitor renamed during the upgrade cannot be recognised and is proposed as a new device.

Limits​

  • Read only: monitors are paused, resumed and edited in Uptime Kuma.
  • Uptime Kuma is read at the refresh interval: an outage shorter than it may go unseen, and the outage length is known to that precision.
  • Under Uptime Kuma 1.x, monitors have no identifier in the metrics: a monitor renamed in Uptime Kuma 1.x becomes a new device. Under 2.x, renaming is harmless.
  • The tags of Uptime Kuma, the uptime percentages and the status pages are not used.
  • Uptime Kuma answers at most 60 API requests per minute; two instances read every 15 seconds use 8 of them.

Configuration settings​

These are the settings Uptime Kuma asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your Uptime KumasectionNoIn Uptime Kuma, open Settings → API Keys, create a key and paste it below with the address of Uptime Kuma. Then add the monitors to follow from the Discover tab: the scene triggers work for every monitor, added or not.
Uptime Kuma addressstringNoThe address you open Uptime Kuma with, port included (3001 by default).
API keysecretNoStarts with "uk". Leave empty only if the authentication of Uptime Kuma is disabled.
Name (optional)stringNoShown in the messages and the widget instead of the address.
Second Uptime Kuma (optional)sectionNoFor example an instance on a rented server, watching your home from the outside.
Second Uptime Kuma addressstringNo
Second API keysecretNo
Second name (optional)stringNo
OptionssectionNoUptime Kuma answers at most 60 API requests per minute, shared by every tool that reads its metrics.
Refresh intervalselectNoHow often Uptime Kuma is read. A shorter outage may go unseen.
Certificate warningselectNoDays left at which "Certificate expires soon" fires, once per certificate.
Accept self-signed certificatesbooleanNoOnly for an https:// address whose certificate your browser does not trust either.
Language of the namesselectNoLanguage of the feature names (set when a device is added) and of the scene results.

How to install Uptime Kuma in Gladys​

  1. In Gladys, open Integrations: Uptime Kuma appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-uptime-kuma:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-uptime-kuma.

Uptime Kuma requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Uptime Kuma is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
