Unraid integration for Gladys Assistant

Unraid server: array, parity, disks, Docker containers, VMs, UPS and alerts in Gladys.

View on GitHubAll external integrations

Unraid is the operating system of many home NAS and servers: an array of disks protected by parity, Docker containers and virtual machines. This integration reads your Unraid server through its official API and brings it into Gladys: the server itself, and the disks, containers, VMs and UPS you choose. Scenes can react when a disk fails or overheats, when a parity check ends, when a container stops or when Unraid posts a notification; they can start, stop or restart a container or a VM. A dashboard widget sums the server up. Everything stays on your local network.

Tested on a real Unraid server by the author, on top of the automated tests against a simulated server. Feedback welcome on the issues.

What you need​

  • Gladys Assistant 5.1.0 or later.
  • Unraid 7.2 or later: its API is built in. Unraid 6.x has no such API and is not supported; Unraid 7.0 and 7.1 may work with the Unraid Connect plugin, untested.
  • The Unraid server reachable from the Gladys machine (its web interface address).

Reading the server never wakes a sleeping disk: the temperatures come from what Unraid already knows, and a disk in standby simply has none.

Getting started​

1. Create an API key​

In the Unraid web interface: Settings → Management Access → API Keys → Create. Give it a name (Gladys) and:

  • the Viewer role, to watch the server (read only);
  • to start, stop and restart containers and VMs from Gladys, also the Docker and VMs permissions with the update action. Without them, every command is refused by Unraid and Gladys says so.

Copy the key: Unraid shows it once.

2. Configure the integration​

In Gladys, Integrations → Unraid → Configuration:

  • Address: the address of the Unraid web interface, as in your browser (192.168.1.10, tower.local, https://192.168.1.10). The integration follows Unraid's own "Use SSL/TLS" redirects: to HTTPS on the same address, or to your myunraid.net address.
  • API key: the key created above.
  • Name (optional): the name of the server in Gladys; empty, the name of the Unraid server.
  • Accept self-signed certificates: tick it when "Use SSL/TLS" is "Yes" in Unraid (its certificate is self-signed).
  • Refresh interval: 15 seconds to 5 minutes (1 minute by default).
  • Language of the names and texts: the names given to the features, the state texts and the texts of the scene events (French by default).

Save, then Test the connection: it reads the server and reports what it finds (Unraid version, disks, containers, VMs, UPS).

3. Add the devices​

Open the Discover tab of the integration: the server, its disks, its containers, its VMs and its UPS are listed. Add the ones you want to follow; the others stay out of Gladys (the scene triggers watch them all the same).

The devices​

The server​

FeatureValue
Online1 while Unraid answers, 0 after two failed reads
CPUCPU usage, %
Memorymemory used (without the cache), %
CPU temperaturethe hottest CPU package, °C
Uptimedays since the last boot
Array started1 started, 0 stopped
Array statetext: "Started", "Stopped", "Started · parity check 45 %"…
Array space used%
Array free spaceterabytes
Parity check progress% while a check, a rebuild or a clear runs, 0 otherwise
Parity errorserrors of the running or last check
Disks needing attentiondisks not "normal", or with read errors
Unread alertsunread Unraid notifications of the alert or warning level
Container updatescontainers with a newer image
Unraid versiontext

A feature the server cannot give (an older API, no CPU sensor) is not created.

Disks​

One device per slot of the array: parity, data disks, pool disks (cache). The device follows the slot (Disk 3), like Unraid: a replaced disk keeps its device and its history.

FeatureValue
Temperature°C, while the disk spins; nothing while it sleeps
Standby1 asleep, 0 spinning (hard disks only)
Space used% (not on parity disks)
Free spacegigabytes (not on parity disks)
Errorsread errors counted by Unraid since the last boot
Statustext: "Normal", "Disabled", "Missing", "Emulated", "Wrong disk"…

Containers​

One device per Docker container, named after the container (its identity: an update recreates the container and keeps the device).

FeatureValue
Runningswitch: on starts the container, off stops it
Update available1 when a newer image exists (Unraid's own check)

The containers of Gladys itself (Gladys and its integrations) are read only: Gladys never stops itself from here. CPU and memory per container are not given by the API without a permanent connection: not supported.

Virtual machines​

FeatureValue
Runningswitch: on starts the VM, off shuts it down cleanly (power button)
Statetext: "Running", "Stopped", "Paused", "Shutting down", "Crashed"…

Turning a VM off asks its operating system to shut down, like the power button: never a forced stop. A VM that ignores it keeps running.

UPS​

When Unraid manages a UPS (Settings → UPS Settings):

FeatureValue
Batterycharge, %
Runtime leftminutes on battery
Load%
On battery1 on battery, 0 on mains
Powerwatts drawn, when the UPS tells it
Input voltagevolts
Statustext given by the UPS ("ONLINE"…)

Dashboard​

The Unraid widget shows the server at a glance: CPU, memory and array space used, then a list with what needs attention first (a disk in trouble, a disk Unraid calls full, a warm disk, a container set to autostart that is not running, a UPS on battery, unread alerts), then the array, the last parity check, the disks, the containers, the VMs, the UPS and the container updates.

In its settings, choose a container or a VM to get its buttons: Start, Stop and Restart (containers only); Stop and Restart ask for a confirmation. Without a choice, a Refresh button reads the server again.

Scenes​

Triggers​

  • Unraid disk in error: a disk of the array becomes disabled, missing or emulated, or its read errors grow. Filter: a disk (empty: any). Information passed on: server name, disk name, disk status, read errors.
  • Unraid disk too hot: a disk reaches the chosen temperature (40 to 70 °C), on two reads in a row; announced again once it cooled 3 °C below, and not twice within 30 minutes. A sleeping disk is never woken to read it. Information passed on: server name, disk name, temperature, threshold.
  • Unraid parity check finished: a parity check, a rebuild or a disk clear ended. Filter: the result (no error, with errors, stopped before the end). Information passed on: server name, result, errors found, duration in minutes, operation. A check that ends while Gladys is stopped is announced at the next read.
  • Unraid container stopped: a container that was running stopped or was removed, on two reads in a row and for a minute at least (an update recreates it within seconds), and not by Gladys. Filter: a container (empty: any). Information passed on: server name, container name, state.
  • Unraid notification: Unraid posted a new notification (SMART warnings, temperatures, array events, updates, a disk almost full…). Filter: the importance (alert, warning, information; empty: any). Information passed on: server name, importance, title, subject, description. The notifications present when the integration starts are not announced.

The disk states and temperatures are also features: for a threshold of your own, use a condition on the feature.

Actions​

  • Control an Unraid container: start, stop or restart a container. Output: the container name.
  • Control an Unraid VM: start a VM, or shut it down cleanly. Output: the VM name.
  • Unraid server status: reads the server for the next actions. Outputs: answers (yes/no), a ready-made summary ("Array: Started. 6 disk(s) OK. 12/14 container(s) running."), array state, disks needing attention, CPU, memory, containers running, unread alerts.

Nothing stops the array or the server from Gladys: too risky for a scene or a voice command. Use the Unraid interface for that.

Scene ideas​

  • Parity check with errors → send yourself a message: "Parity check: {errors} errors in {duration} minutes".
  • Unraid notification, importance alert → a notification on your phone with its subject.
  • Every night at 4:00 → Control an Unraid container: restart the container that needs it (a stuck media server, a VPN).
  • Unraid disk too hot, 50 °C → turn on the fan of the closet.
  • Every morning → Unraid server status, then send its summary.

Troubleshooting​

  • "API key refused": the key was deleted or mistyped. Create a new one in Settings → Management Access → API Keys.
  • "No Unraid API at this address": Unraid older than 7.2 (without the Unraid Connect plugin), or the address of another service.
  • "The Unraid API does not answer": the web interface answers but not the API behind it: Unraid is starting, or the API stopped (unraid-api restart in a terminal).
  • "Certificate refused": "Use SSL/TLS" is "Yes": tick "Accept self-signed certificates".
  • "Your DNS blocks myunraid.net": with "Use SSL/TLS" set to "Strict", Unraid redirects to an myunraid.net address that many routers block (DNS rebinding protection). Enter https:// and the IP of the server, and tick "Accept self-signed certificates"; or allow myunraid.net in your router.
  • A command is refused: give the API key the Docker and VMs permissions.
  • No temperature for a disk: it sleeps; the temperature comes back when it spins.
  • A device shows "Update" in Discover: a feature appeared (a parity check ran for the first time, the API gained a field). Update it to get it.

Limits​

  • One Unraid server per installation.
  • Read every 15 seconds to 5 minutes: a change shows at the next read.
  • No CPU and memory per container (the API only gives them over a permanent connection), no network traffic, no shares.
  • Unraid OS updates are not reported by the API: only container updates are.
  • The integration stores in /data only what the scene triggers compare with (disk states, containers seen running, the parity operation in progress, the notifications already announced) and the features each device had; the API key stays in the Gladys configuration and is never logged.
  • Not affiliated with Lime Technology, Inc. Unraid is a trademark of Lime Technology, Inc.

Configuration settings​

These are the settings Unraid asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your Unraid serversectionNoUnraid 7.2 or later (its API is built in). In Unraid, create an API key: Settings, Management Access, API Keys, role Viewer. To start and stop containers and VMs from Gladys, also give it the Docker and VMs permissions.
AddressstringYesIP address or name of the Unraid server, as in your browser: with https:// for HTTPS and :port if not the default.
API keysecretYesCreated in Unraid: Settings, Management Access, API Keys.
NamestringNoName of the server in Gladys. Empty: the name of the Unraid server.
OptionssectionNo
Accept self-signed certificatesbooleanNoWhen Unraid's "Use SSL/TLS" is "Yes": its certificate is self-signed. Tick only for your own server.
Refresh intervalselectNoHow often the Unraid server is read. Reading never wakes a sleeping disk.
Language of the names and textsselectNoNames given to the features when a device is added, state texts, and texts of the scene events.

How to install Unraid in Gladys​

  1. In Gladys, open Integrations: Unraid appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-unraid:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-unraid.

Unraid requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Unraid is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
