UniFi Protect integration for Gladys Assistant

UniFi Protect cameras, doorbells, floodlights and sensors, locally: detections, images, rings.

View on GitHubAll external integrations

Brings the cameras, doorbells, floodlights and sensors of a UniFi Protect console (UDM, UCG, UNVR, Cloud Key) into Gladys, locally: motion and smart detections (person, vehicle, animal, package), camera images, doorbell rings, floodlight control, door and window sensors, temperature, humidity, brightness, water leaks, batteries. Everything goes through the official Protect Integration API of your console: no Ubiquiti cloud account, nothing leaves your network.

Developed without the hardware: feedback welcome. This integration was written from the official API specification and real payloads, without a Protect console at hand. If something does not work as described, please open an issue on github.com/guim31/gladys-unifi-protect/issues with the integration logs (LOG_LEVEL=debug).

This integration is not affiliated with Ubiquiti. UniFi and UniFi Protect are trademarks of Ubiquiti Inc.

What you need​

  • A UniFi console running UniFi Protect 6 or later (the Integration API; 7.x recommended): Dream Machine, Cloud Gateway, UNVR, Cloud Key Gen2+…
  • An API key created in the console (see below). A user without administrator rights on Protect may get a key that sees nothing.
  • Gladys 5.1 or later, able to reach the console over HTTPS (port 443 by default) on your network.

Set up​

Create an API key​

  1. Open your UniFi console locally in a browser (for example https://192.168.1.1).
  2. Go to Settings, Control Plane, Integrations.
  3. Create an API key, give it a name (for example "Gladys") and copy it: the console shows it only once.

Settings​

In Gladys, open the integration, then its Configuration tab:

  • Console address: the IP address or name of the console, with :port if it is not 443. A URL copied from the browser works too.
  • API key: the key you just created. It is sent to your console only.
  • Accept the self-signed certificate: UniFi consoles serve a self-signed certificate, which a browser warns about. Tick this box to accept it, unless your console has a certificate your network trusts. The box is off by default: accepting a certificate that cannot be verified must be your choice.
  • Camera images: how often the image of each camera added to Gladys is refreshed (every 5 minutes by default, or only on detection). Detections, rings and the live view always ask for a fresh image.
  • Language of the names: the language of the feature names and of the texts sent to the scenes (French by default). Names are set when a device is added to Gladys.

Save: the status under the integration name turns to connected, and the devices appear in the Discover tab. Add the ones you want.

Configuration actions​

  • Test the connection: reads the console now and shows its Protect version, how many cameras, floodlights and sensors it has, and the SHA-256 fingerprint of the certificate you accepted (compare it with the one your browser shows for the console).
  • Show the video stream address: pick a camera, and the RTSP address of its video stream is shown under the button, ready for the "RTSP camera" integration of Gladys (see Live video).

The devices​

Cameras​

One device per camera, named as in Protect:

  • Image: the camera image, refreshed at the chosen interval, at every detection and ring, and whenever you open it on the dashboard;
  • Online: on while the camera is connected to the console;
  • Motion: on while Protect sees motion;
  • Person, Vehicle, Animal, Package: on while a smart detection of that kind is in progress — only the kinds your camera can detect. A package is reported once by Protect: the feature turns on for 10 seconds.

Doorbells​

A doorbell is a camera with one more feature, Doorbell ring: it turns on for 10 seconds at each ring, and Gladys shows when it last rang. A doorbell the console does not name as such (older firmware) gets this feature at its first ring: click Update on it in the Discover tab.

Floodlights​

  • Light: turning it on forces the light on; turning it off gives it back to its own lighting mode (motion, schedule…) — it may stay lit until the end of its timer. The state shown is the real state of the light, whatever turned it on.
  • Motion: the motion sensor of the floodlight.
  • Online.

Sensors​

UP-Sense sensors get the features their mount allows:

  • Opening: open or closed, for a sensor on a door, a window or a garage door;
  • Temperature (°C), Humidity (%), Brightness (lux), Motion;
  • Water leak, for a sensor on a leak mount;
  • Battery (%);
  • Online.

Dashboard​

The UniFi Protect widget shows at a glance:

  • the cameras online (3/4) and the detections of the last 24 hours;
  • the last detections and rings, newest first, each with the image taken when it happened;
  • the state of each camera, and the floodlights and sensors offline, if any.

In its settings, pick a camera to show only that one. The detections are kept in memory: the list starts empty after a restart of the integration.

Scenes​

Triggers​

  • Object detected by a camera: a smart detection of Protect. Filters: the camera, and what was detected (person, vehicle, animal, package, license plate, face); left empty, any matches. A detection that sees a person, then a vehicle, starts the scene once for each. The actions can use the camera name and the object type (code person, or its name in the language of the integration). When the scene starts, the image of the camera in Gladys is already the one of the detection.
  • Someone rang the doorbell: a doorbell was pressed. Filter: the doorbell. The actions can use its name. The doorbell image in Gladys is already the one of the ring.

The states of the devices (motion, person, opening, temperature…) are also available to the usual "device state" trigger of Gladys.

Actions​

  • Refresh a camera image: takes a fresh image of a camera for Gladys, so that the next action ("send a camera image" in a message) sends what the camera sees now.
  • Show a message on the doorbell: changes the message of the doorbell screen: do not disturb, leave the package at the door, your own text (30 characters at most), or clears it — for a number of minutes, or until changed (0).

There is no action to arm, disarm, silence or stop recording anything: the Protect Integration API does not offer the recording mode nor the notifications, and nothing in Gladys should be able to lower the security of the house by mistake.

Scene ideas​

  • Someone rings: trigger "Someone rang the doorbell", then "send a camera image" of the doorbell to your phone with the message "Someone at the door".
  • Person in the driveway at night: trigger "Object detected by a camera" (camera Driveway, Person), a condition on the time, then turn the garden lights on for 5 minutes.
  • A package was delivered: trigger "Object detected by a camera" (Package), then a message "A package was delivered" with the image.
  • Away from home: when the house becomes empty, "Show a message on the doorbell" (leave the package at the door, duration 0); when you come back, clear it.
  • Water leak: trigger "device state" on the Water leak feature, then an alert on every phone.

Live video​

The Image feature shows still images. For live video, use the "RTSP camera" integration of Gladys:

  1. In Protect, open the camera settings, Advanced, and enable an RTSP stream (high, medium or low quality).
  2. In Gladys, run Show the video stream address with that camera.
  3. Add the camera in the "RTSP camera" integration with this address (rtsp://<console>:7447/…).

The address works as a password of the stream: share it with nobody.

Refresh and limits of the API​

Gladys never polls these devices: the integration follows the console live over two WebSockets of the Integration API (devices and events), and reads the full state again every 5 minutes (every minute while the live link is down). The values are sent to Gladys only when they change, and again every 6 hours when they do not.

Images: at most one image every 6 seconds per camera (Gladys accepts 12 a minute), read one camera after the other. The console limits the API to about 10 requests per second; the integration stays far below.

Troubleshooting​

  • "The console does not answer": check the address, that the console is on, and that Gladys can reach it (same network, firewall).
  • "self-signed certificate": tick Accept the self-signed certificate.
  • "API key refused": the key was deleted or mistyped. Create a new one, paste it again.
  • "No UniFi Protect Integration API at this address": Protect is not installed on this console, or is older than version 6. Update it.
  • "live events are interrupted": the states still follow, every minute; the detections and rings wait for the link to come back. It reconnects by itself.
  • No image: the integration resizes images of up to 4K; a progressive JPEG larger than 1080p cannot be resized in the memory of the container. The logs say so once.
  • A doorbell without its ring feature: ring it once, then click Update on it in the Discover tab.
  • For more detail, set LOG_LEVEL=debug on the integration and read its logs. They never contain your API key.

Limits​

  • Developed without a console: tested against the payloads of the API, not against real devices.
  • No control of recording, notifications, alarm, chimes or sirens: the Integration API does not expose them cleanly, or a mistake would lower the security of the house.
  • Audio detections (smoke alarm sound, glass break…), license plate text and face identities are not used.
  • The list of detections of the widget starts empty at each restart: the Integration API keeps no history of events.
  • Images are resized to 960 pixels wide at most (the limit of Gladys is 150 KB per image).

Configuration settings​

These are the settings UniFi Protect asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your UniFi consolesectionNoUniFi Protect 6 or later. In the console, create an API key: Settings, Control Plane, Integrations. Everything stays on your network.
Console addressstringYesIP address or name of the console (UDM, UCG, UNVR, Cloud Key), with :port if not 443.
API keysecretYesThe key created in the console. It is sent to the console only, never to a cloud.
Accept the self-signed certificatebooleanNoUniFi consoles serve a self-signed certificate: tick this box, unless yours has a certificate your network trusts.
Camera imagesselectNoHow often the image of each camera added to Gladys is refreshed. Detections and rings always send a fresh one.
Language of the namesselectNoLanguage of the feature names and of the texts sent to scenes. Names are set when a device is added.

How to install UniFi Protect in Gladys​

  1. In Gladys, open Integrations: UniFi Protect appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-unifi-protect:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-unifi-protect.

UniFi Protect requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

UniFi Protect is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
