UniFi Access smart home integration, free and open source
UniFi Access doors: lock, door sensor, doorbell, granted or denied accesses and door alarms.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.1.0
- ★ 0
Brings the doors of UniFi Access (Ubiquiti's access control: G2 and G3 readers, Intercom, UA Hub, UA Hub Door Mini, UA Ultra) into Gladys, on your local network: the state of each lock and door, the doorbell, who came in and how, the door alarms. Not affiliated with Ubiquiti.
Developed without the hardware: feedback welcome. The integration was written from the official API, the Home Assistant integration and real captures published by other projects, but never run against a real UniFi Access installation. Tell us what works and what does not on GitHub.
Presentation
- One Gladys device per UniFi Access door, read-only: nothing on the dashboard can open a door.
- Real time: the integration keeps a connection open to the notification WebSocket of UniFi Access, and reads everything again every 5 minutes (every minute if the WebSocket is down).
- Scene triggers: doorbell, access granted, access denied, door alarm, door offline and back.
- Scene actions: keep a door locked, return it to its normal schedule, and — only if you enable it — unlock a door.
- A dashboard widget: the doors and the last accesses.
Prerequisites
- UniFi Access running on a UniFi OS console (UDM, UCG, UNVR, Cloud Key Gen2+…), recent enough to offer the developer API (Settings, General, Advanced, API Token).
- Gladys 5.1 or later, on the same network as the console (port 12445 reachable).
- An API token: in UniFi Access, Settings → General → Advanced → API Token → Create. Give it the Space (doors) and Device permissions, in read and write if you want the scene actions. Copy it: it is shown once.
Configuration
In Gladys: Integrations → UniFi Access → Configuration.
| Field | What to enter |
|---|---|
| Console address | IP address or name of the console, e.g. 192.168.1.1. The API answers on port 12445: add :port only if yours differs. |
| API token | The token created above. It stays in Gladys and is never written in the logs. |
| Accept the self-signed certificate | UniFi consoles serve a self-signed certificate on port 12445: tick it unless you installed a certificate your system trusts. |
| Allow remote unlock from scenes | Off by default. See "Scene actions" below before enabling it. |
| Language of the feature names | Names of the features when a door is added, and texts of the states and scene events (French by default). |
Then Test the connection: it reads the console now and says how many doors and devices it found, and whether the real-time notifications are connected. The doors then appear in the Discovery tab: add the ones you want.
Devices
Each door of UniFi Access becomes one device, named like the door. Its features are all read-only; some only exist if the hardware has them.
| Feature | Gladys type | Values |
|---|---|---|
| Lock | lock / state | locked or unlocked |
| Door position | opening sensor | open or closed — only on a door whose position sensor (DPS) is wired |
| Doorbell | doorbell / ring | rings for a few seconds at each ring — on a door with a reader Pro, an intercom or a hub doorbell input |
| Lock rule | text | Normal, Always locked, Always unlocked, Unlocked for a while until 18:30, Unlock schedule… |
| Last access | text | e.g. Alice Martin · NFC card · Entry, Denied · Unknown · PIN code |
The badge of the device says whether its door is online (its hub answers UniFi Access), and turns orange when the real-time notifications are down.
A door that rings for the first time while it had no doorbell feature gets one: use Update in the Discovery tab to add it to the device.
Widget
UniFi Access doors: one line per door (locked or unlocked, open or closed, alarm, offline) and the last accesses (who, how, granted or denied). Choose a door in the widget settings to show only that one: the widget then offers two buttons, each asking for confirmation:
- Always locked: the door stays locked whatever its schedule (shown with a ✓ while active);
- Normal schedule: ends the temporary rule. Ending "always locked" can unlock the door, so this button only appears for it when the remote unlock is enabled.
There is never an unlock button.
Scene triggers
| Trigger | When | Filters | Variables |
|---|---|---|---|
| Doorbell rang | someone rang at a reader or an intercom | door | door name, doorbell device |
| Access granted | a door was opened with a badge, a code, a face, the app… | door, method, user name | door name, user name, method (nfc, pin, face…), method in words, direction (entry, exit) |
| Access denied | a badge, a code or a face was refused | door, method | same |
| Door alarm | door forced open or held open too long | door, alarm | door name, alarm (forced_open, held_open, other), alarm in words, type sent by UniFi Access |
| Door offline | the hub of a door stopped answering | door | door name |
| Door back online | the hub of a door answers again | door | door name, minutes offline |
UniFi Access reports each access twice (an "insight" and a log line, a few milliseconds apart): the integration fires the trigger once.
Scene actions
| Action | Effect |
|---|---|
| Keep a door locked | The door stays locked whatever its schedule. Always allowed. |
| Return a door to its normal schedule | Ends "always locked" or "always unlocked". Ending "always locked" requires the remote unlock to be enabled. |
| Unlock a door | One remote unlock; the door relocks by itself after its usual delay. Refused unless the remote unlock is enabled. |
Warning — remote unlock. It is off by default. Once enabled, any scene using "Unlock a door" opens the door when it runs: a wrong trigger, a shared dashboard, a compromised Gladys account then means an open door. It never exists as a switch, a voice command or a dashboard button. Each unlock is signed "Gladys" in the UniFi Access system log.
Scene examples
- Someone at the door: trigger "Doorbell rang" on the front door → send a message "Someone is ringing at {{triggerEvent.data.door_name}}", and show the camera of the entrance.
- The children are home: trigger "Access granted" with user "Léa" → send "Léa came home ({{triggerEvent.data.method_label}})".
- Leaving the house: when the alarm system is armed → "Keep a door locked" on every door.
- Break-in: trigger "Door alarm" with alarm "Door forced open" → siren and notification.
- A badge refused three times: trigger "Access denied" → notification with {{triggerEvent.data.door_name}} and {{triggerEvent.data.method_label}}.
Refresh and limits of the API
- Real time through the notification WebSocket of UniFi Access (one outgoing connection from the container to port 12445), reopened after 1 s, 2 s, 4 s… up to 1 minute when it drops.
- A complete read (doors, devices, one lock rule per door) every 5 minutes, every minute while the WebSocket is down; an unchanged state is sent again to Gladys every 6 hours.
- The local API publishes no quota; the integration stays far below anything a console would refuse (a few requests per minute at most). If the console answers "too many requests", the integration says so and simply tries again at the next read.
Troubleshooting
| Message | What to do |
|---|---|
| The console does not answer | Check the address, and that Gladys reaches port 12445 of the console (firewall, VLAN). |
| Certificate not trusted | Tick "Accept the self-signed certificate". |
| API token refused | The token was deleted or mistyped: create a new one in UniFi Access and paste it again. |
| The API token lacks a permission | Edit the token in UniFi Access: give it the Space and Device permissions. |
| This UniFi Access version lacks the developer API | Update UniFi Access. |
| Real-time notifications unavailable | The doors are still read every minute; check that nothing between Gladys and the console blocks WebSockets. |
For more details, set LOG_LEVEL=debug on the integration: every notification and every read
appears in the logs (never the token).
Limitations
- Developed without the hardware: the vocabulary of the alarms (only
force_unlockhas been seen in captures), of the access methods and of some intercoms may differ on your installation. The raw values are kept in the trigger variables. - No visitor, user, PIN or NFC card management; no evacuation or lockdown control.
- The doorbell answers (pick up, open from the intercom) stay in the UniFi apps.
- The history of the widget starts when the integration starts (the 20 last accesses are kept).
- Not affiliated with Ubiquiti. UniFi and UniFi Access are trademarks of Ubiquiti Inc.
Configuration settings
These are the settings UniFi Access asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Your UniFi console | section | No | UniFi Access on a UniFi OS console (UDM, UCG, UNVR, Cloud Key…). In UniFi Access, create an API token: Settings, General, Advanced, API Token, with the Space and Device permissions. |
| Console address | string | Yes | IP address or name of the console. The API answers on port 12445: add :port only if yours differs. |
| API token | secret | Yes | Created in UniFi Access, shown once. Kept in Gladys, never written in the logs. |
| Accept the self-signed certificate | boolean | No | UniFi consoles serve a self-signed certificate on port 12445: tick it unless you installed a trusted one. |
| Remote unlock | section | No | Off by default. Enabled, it allows the scene action "Unlock a door" and ending "always locked" — never a switch nor a dashboard button. A scene that misfires then opens your door: enable it knowingly. |
| Allow remote unlock from scenes | boolean | No | Each unlock is signed "Gladys" in the UniFi Access system log. |
| Language of the feature names | select | No | Names given to the features when a door is added, and texts of the states and scene events. |
How to install UniFi Access in Gladys
- In Gladys, open Integrations: UniFi Access appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-unifi-access:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-unifi-access.
UniFi Access requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
UniFi Access is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
- Browse all integrations, native and community
- Build and publish your own external integration
- Source code on GitHub — source of this documentation
