Twitch smart home integration, free and open source

Follow Twitch channels: live status, viewers, category, scenes and a dashboard widget.

• Published by prohand
• Devices
• Version 0.1.1
• Requires Gladys >=5.1.0
• ★ 0

View on GitHubAll integrations

Follow Twitch channels in Gladys: know who is live, in which category and for how many viewers, start scenes when a stream begins or ends, and show the channels on a dashboard.

The integration only reads public data. No Twitch account is linked: it uses the identifiers of a free Twitch application you create once.

1. Create a Twitch application

1. Go to the Twitch developer console and sign in with any Twitch account (two-factor authentication must be on).
2. Fill in the form:
   • Name: anything unique, e.g. Gladys my-home;
   • OAuth Redirect URLs: http://localhost (not used, but required);
   • Category: Other;
   • Client Type: Confidential.
3. Click Create, then Manage on the new application.
4. Copy the Client ID, then click New Secret and copy the Client Secret (it is only shown once).

2. Configure the integration

1. Open the Configuration tab of the integration in Gladys.
2. Paste the Client ID and the Client Secret.
3. In Channels, list the channels to watch, separated by commas. Names (twitchdev), @names and links (https://www.twitch.tv/twitchdev) are all accepted, up to 100 channels.
4. Optionally change the Refresh interval: Twitch is read every 60 seconds by default (30 seconds to one hour).
5. Save, then click Test the connection: the answer says how many channels were found, how many are live, and which names do not exist on Twitch.
6. Open the Discovery tab and add the channels you want as devices.

What you get

One device per channel, named Twitch <channel>, with:

Feature	Value
Live	1 when the channel is streaming, 0 otherwise
Viewers	Current number of viewers
Uptime	Minutes since the stream started
Title	Title of the stream (the last one when offline)
Category	Game or category played (the last one when offline)

The device is tied to the Twitch user id of the channel: a streamer who renames their channel keeps the same device, history and scenes.

Scenes

The integration adds its own cards to the scene editor (Gladys 5.1 or later).

Triggers:

• Twitch stream started — a watched channel goes live. Optionally pick the channel and a category (exact name, e.g. Just Chatting). Variables: {{triggerEvent.data.channel_name}}, title, game and url.
• Twitch stream ended — a watched channel stops streaming. Variable: duration_minutes, how long the stream lasted.
• Twitch category changed — a live channel switches to another game. Variables: game, previous_game, title.

Actions:

• Check a Twitch channel — is any public channel (watched or not) live right now? Returns is_live, channel_name, viewer_count, title, game and uptime_minutes, which the following actions can use.
• Refresh Twitch channels — reads the watched channels now, without waiting for the next refresh, and returns live_count.

You can also use the standard device state trigger and condition on the Live or Viewers features ("when more than 100 viewers…").

Example: when a stream starts on my favourite channel, send me a message "{{triggerEvent.data.channel_name}} is live: {{triggerEvent.data.title}} {{triggerEvent.data.url}}".

Dashboard

Add the Twitch channels widget to a dashboard. It shows how many channels are live, then one row per channel: avatar, live badge, category and viewers. Tap a row for the stream title and a link to the channel. The Refresh button reads Twitch at once.

Widget settings: pick the channels to show (all when empty) and/or show only the live ones.

Good to know

• A stream is declared ended only after it is missing from two Twitch answers in a row: Twitch sometimes forgets a live stream for one request, and scenes would otherwise announce a stream end and a new start a minute later.
• A channel added to the list while it is already live does not fire Twitch stream started: it did not just start.
• The integration remembers the last state of each channel in its data volume: after a restart, a stream that was already running is not announced again, and a stream that started meanwhile is.

Troubleshooting

• "Twitch refused the Client ID or Client Secret": copy them again from the developer console. A new secret invalidates the previous one.
• A channel is "unknown on Twitch": check its spelling in the channel URL.
• The device badge shows cloud when Twitch answers, unreachable when it does not. Check the integration logs from the Gladys interface for details.

Configuration settings

These are the settings Twitch asks for in its configuration screen in Gladys.

Setting	Type	Required	Description
Twitch application	section	No	Register a free application on the Twitch developer console (OAuth Redirect URL: http://localhost, category: Other, client type: Confidential), then paste its Client ID and a new Client Secret below. No Twitch account is linked: the integration only reads public data.
Client ID	string	Yes
Client Secret	secret	Yes
Channels	string	No	Twitch channels to watch, separated by commas (names or twitch.tv links, 100 at most).
Refresh interval (s)	number	No	How often Twitch is read, in seconds (30 to 3600).

How to install Twitch in Gladys

1. In Gladys, open Integrations: Twitch appears in the catalog, next to the native integrations, with a community badge.
2. Click Install. Gladys pulls the Docker image (ghcr.io/prohand/gladys-twitch:0.1.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
3. Open the Configuration screen of the integration, fill in the settings, and save.
4. You can also install it directly from its repository URL: https://github.com/prohand/gladys-twitch.

Twitch requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations

Twitch is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by prohand, not by the Gladys core team.

• Browse all integrations, native and community
• Build and publish your own external integration
• Source code on GitHub — source of this documentation
