Twilio smart home integration, free and open source

Twilio integration for Gladys Assistant

SMS and voice calls from your Gladys scenes through your Twilio account, with a cost guard.

View on GitHubAll integrations

Send SMS and place voice calls from your Gladys scenes through your own Twilio account: a text message to the family when the water leak sensor goes off, a phone call that reads the alarm out loud when nobody looks at their phone, a call to a neighbour when an elderly relative does not answer. Useful where an app notification is not enough, or where there is no mobile Internet.

This integration is not affiliated with Twilio. Twilio bills every SMS and every call to your account: a cost guard caps what Gladys may send per hour and per day.

Developed without the hardware: feedback welcome. This integration was built against the documented Twilio API, without a real Twilio account. If something does not work as described, please say so on the Gladys forum or in the issues.

What you need​

  • Gladys Assistant 5.1.0 or later.
  • A Twilio account with some balance, and a Twilio phone number able to send SMS and place calls to the countries you need. A trial account works, with its limits: it only reaches the numbers you verified in Twilio, and its messages start with a Twilio notice.
  • The Account SID (on the home page of the Twilio console, AC…).
  • Preferably an API key: in the Twilio console, Account → API keys & tokens → Create API key, type Standard. Note its SID (SK…) and its secret, shown only once. Without an API key, the Auth Token of the account works too, but it gives full access to the account.
  • In the Twilio console, the geographic permissions of SMS and voice must allow the countries of your recipients.

Configuration​

  1. Install the integration from the Gladys catalog.
  2. In Configuration, fill in the Account SID, the API key SID and API key secret (or the Auth Token), and the Sender: your Twilio number in international format, e.g. +33612345678.
  3. Default recipients: the numbers used when an action names none, separated by commas, the most important first. Always in international format (+ and the country code): 06 12 34 56 78 is refused, because the country cannot be guessed.
  4. Set the cost guard (see below), the Voice and Ring time of the calls, and the Language (French by default).
  5. Save, then click Test the connection: the message under the button names the account, its type, its balance, whether the sender belongs to the account, and today's usage.
  6. Click Send a test SMS (to the default recipients, or to the number you type) to check the whole path.
  7. Open the Discover tab and add the Twilio account device.

The sender can also be a Messaging Service SID (MG…) or an alphanumeric sender name (Gladys, up to 11 characters, where the destination country allows it). Both work for SMS only: a call always needs a Twilio phone number.

Cost guard​

Four limits: Most SMS per hour, Most SMS per day, Most calls per hour, Most calls per day (10, 30, 5 and 10 by default). The hour is a rolling hour, the day is the calendar day in the time zone of Gladys. Each recipient counts as one SMS. Past a limit, nothing more is sent until the window frees up: the first recipients of a list go first, the others are held back. A limit of 0 blocks that kind of send. The counters are kept under /data and survive a restart. Only the sends Twilio accepted count: a refused request is not billed.

The "Twilio account" device​

FeatureWhat it shows
BalanceThe balance of the account, in its currency, read every 15 minutes.
SMS sent todaySMS accepted by Twilio since midnight.
Calls placed todayCalls accepted by Twilio since midnight.
Last failureDate, SMS or call, masked number and reason of the last failure, or No failure.

Euros, dollars and pounds get their unit; another currency shows the amount alone. The balance only appears once Twilio let it be read: a restricted API key may not see it, which does not prevent sending.

Dashboard widget​

The Twilio widget shows the balance, the SMS and calls of the day against the daily limits (in orange once reached), the state of the account and the last failure, with a link to the Twilio console to top the balance up. It sends nothing itself.

Scenes​

Actions​

Send an SMS: one SMS to each recipient (up to 10). Recipients: numbers separated by commas, empty for the default recipients. Message: up to 1600 characters, with the variables of the scene (type {{ to insert one). Results for the next steps: SMS sent, Held back by the cost guard, Refused by Twilio.

Make a call: calls one number (empty: the first default recipient) and reads the Message read out (up to 1000 characters) with a text-to-speech voice. The Language (English, French, German or Spanish) and the Voice (female or male) default to those of the configuration; the message is read 1 to 3 times. With Wait for the answer ticked (the default), the scene waits until the call is answered or not, at most the ring time plus 20 seconds. Results: Answered (yes or no), Call outcome and Call SID. The outcome is one of:

  • answered: someone (or a voicemail) picked up;
  • no-answer, busy, failed, canceled: the call did not get through;
  • refused: Twilio refused the call (see Last failure);
  • blocked: held back by the cost guard;
  • pending: not known yet (not waited for, or still ringing at the deadline).

A failure on Twilio's side never stops the scene: test the results with a Condition on variables. Only an action that cannot run at all fails (no configuration, no recipient, empty message, a number not in international format).

Triggers​

SMS or call failed: an SMS or a call did not reach its recipient. Filters: SMS or call, Outcome (refused by Twilio, failed, SMS not delivered, no answer, line busy, canceled), Recipient. Variables: SMS or call (sms or call), Recipient, Outcome, Reason (in the configured language), Twilio error code. Twilio confirms delivery after the fact: an SMS is read back after 1, 5 and 20 minutes, a call after its ring time.

Cost guard limit reached: SMS or calls were held back by a limit. Filters: SMS or call, Limit (per hour or per day). Variables: the kind, the limit (hour or day), its value and the number held back. Fired once per episode, not at each attempt, so it can alert you through another channel without flooding it.

Scene ideas​

  • Water leak: on the leak sensor, Send an SMS "Water leak in the cellar!" to the family, then Make a call to the first default recipient.
  • Nobody answers: Make a call to a relative with Wait for the answer, then a Condition on variables: Answered is false, then Make a call to a neighbour.
  • Something loops: on Cost guard limit reached, send a message through the Gladys app or another channel to check which scene sends so much.

Costs and Twilio limits​

  • Twilio bills each SMS per segment: 160 characters, or 70 as soon as the text holds a character outside the GSM alphabet (ê, ç, œ, an emoji). A 1600-character text can be 23 SMS. Calls are billed per started minute; a call is cut after 3 minutes.
  • The voices are standard Amazon Polly voices provided by Twilio; see the Twilio pricing for text-to-speech.
  • Requests to api.twilio.com: the account and its balance every 15 minutes (two reads), one request per SMS or call, then a few reads to follow its outcome (every 3 seconds while a call is waited for). Far below the Twilio API limits; a 429 answer is reported as "too many requests".
  • Twilio sends at most about one call per second per account and queues the SMS at the pace of the sender: a list of 10 recipients takes a few seconds.
  • Twilio's Acceptable Use Policy and the country guidelines apply: only text people who agreed; a recipient who replied STOP is blocked by Twilio.

Troubleshooting​

  • "credentials refused by Twilio": check the Account SID and the API key secret (or the Auth Token). An API key must belong to the same account.
  • "trial account: verify this number in Twilio first": add the recipient to the verified numbers of the Twilio console, or upgrade the account.
  • "country not allowed in the Twilio geographic permissions": enable the country in the Twilio console, for SMS and for voice.
  • "the sender is not a number of your Twilio account": copy the number from Phone Numbers → Active numbers, in international format.
  • "not delivered (Twilio 30003)" and other 30xxx codes: the operator could not deliver the SMS (phone off, filtered as spam, landline). The code is explained on https://www.twilio.com/docs/api/errors/<code>.
  • Nothing is sent and the widget shows a counter in orange: the cost guard holds; raise the limit or wait for the window to free up.
  • Detailed logs: set LOG_LEVEL=debug on the integration. Phone numbers are always masked in the logs, secrets never written.

Limitations​

  • No incoming SMS. Twilio delivers incoming messages by calling a public URL; Gladys is not exposed to the Internet, and the Gladys Plus webhook relay does not pass the X-Twilio-Signature header, so the sender of a message could not be authenticated. Incoming SMS are therefore not supported.
  • A voicemail that picks up counts as answered: set a shorter Ring time to hang up before it does.
  • No MMS (pictures) and no WhatsApp: SMS and voice only.
  • The feature names are set when the device is added, in the language of the configuration at that time.
  • Developed without a Twilio account: the API answers come from the Twilio documentation, not from a real account.

Configuration settings​

These are the settings Twilio asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your Twilio accountsectionNoTwilio bills every SMS and every call to your account: set the cost guard below. The Account SID is on the home page of the Twilio console; an API key is safer than the Auth Token.
Account SIDstringYesStarts with AC, then 32 characters.
API key SID (recommended)stringNoA Standard API key, starting with SK. Leave empty to use the Auth Token.
API key secretsecretNoShown once by Twilio when the key is created.
Auth TokensecretNoOnly without an API key. It gives full access to the account.
SenderstringYesYour Twilio number in international format. A sender name or a Messaging Service SID (MG…) works for SMS only.
Default recipientsstringNoInternational numbers separated by commas, the most important first. Used when an action names none.
Cost guardsectionNoPast these limits nothing is sent until the window frees up: a scene that loops cannot empty your account. Each recipient counts as one SMS. 0 blocks.
Most SMS per hournumberNo
Most SMS per daynumberNo
Most calls per hournumberNo
Most calls per daynumberNo
Calls and textssectionNoA call reads the message out with a text-to-speech voice, in the language chosen in the action or below.
VoiceselectNo
Ring timeselectNoHang up sooner to avoid the voicemail, which counts as answered.
LanguageselectNoOf the calls, the test SMS, the device names and the failure texts.

How to install Twilio in Gladys​

  1. In Gladys, open Integrations: Twilio appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-twilio:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-twilio.

Twilio requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Twilio is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
