Tvheadend smart home integration, free and open source
Your Tvheadend recorder in Gladys: recordings, free space, viewers, and scenes on each recording.
Published by guim31
- Devices
- Version 1.0.0
- Requires Gladys >=5.1.0
- ★ 0
Tvheadend is the free TV server and recorder of many homes: it reads DVB tuners (DTT, satellite, cable) and IPTV lists, streams the channels to Kodi, a browser or a TV app, and records programmes. This integration brings your recorder into Gladys: what records now, what comes next, the failed recordings, the free space, who watches what, and scenes that react to a recording that starts, finishes or fails, to someone who starts watching, or to a disk that fills up.
Looking for the TV guide? See the Programme Télé integration: this one does not repeat it.
Tested against a real Tvheadend 4.3 in Docker (image
lscr.io/linuxserver/tvheadend), with an IPTV network reading a test stream
served by ffmpeg: recordings scheduled, running, completed, failed, a stream
cut, a viewer, an admin account and a recorder-only one. Developed without a
DVB tuner: feedback welcome on
the issues.
What you need
- Gladys Assistant 5.1.0 or later.
- Tvheadend 4.2 or later, reachable from Gladys (port 9981 by default).
- A Tvheadend user with a password, and an access entry with the Web interface and Video recorder rights (basic, all DVR, failed DVR). With the Admin right, the integration also shows the viewers and the tuners in use.
Getting started
1. Create a user for Gladys
In Tvheadend, Configuration → Users:
- Access entries → Add: user name
gladys, rights Web interface and Video recorder (tick "All DVR" and "Failed DVR" too), and Admin if you want the viewers and the tuners. - Passwords → Add: the same user name and a password.
2. Configure the integration
In Gladys, open the integration and fill in:
- Tvheadend address:
http://192.168.1.2:9981(an address without port gets 9981; a URL copied from the browser works too). - User name and Password: the user created above. Digest and Basic authentication both work.
- Refresh interval: 30 seconds by default.
- Language of the names: the language of the feature names, of the dates and of the scene results.
Then use Test the connection: it reads Tvheadend and sums up what records, what comes next and the free space.
3. Add the device
Open the Discover tab: the server is a device, named Tvheadend. Add it.
The devices
| Feature | What it says |
|---|---|
| Reachable | Yes while Tvheadend answers |
| Recordings in progress | Recordings running now |
| Scheduled recordings | Recordings to come (enabled) |
| Failed recordings (24 h) | Recordings ended in error in the last 24 hours |
| Now recording | "Title (Channel)" of what records ("—" when nothing) |
| Next recording | "Title · Channel · Fri 20:30" ("—" when nothing is planned) |
| Free space | Free space of the recording directory, in GB |
| Free space (%) | The same, in percent |
| Viewers | People watching a channel (Kodi, browser…), admin account |
| Tuners in use | Tuners (inputs) busy, admin account |
There is no device per tuner: Tvheadend lists only the tuners in use.
Dashboard
The Tvheadend recordings widget shows what records now (title, channel and end), or the next recording; tiles for the scheduled recordings, the free space and (admin account) the viewers; then one row per recording running and per recording to come.
Scenes
Triggers
The recording triggers can be limited to one channel: type its name as Tvheadend shows it (empty: any channel).
- A recording starts: Tvheadend starts recording, with the title, the channel, the end time and the planned duration.
- A recording finishes: a recording ended and its file is on the disk, with the title, the channel, the duration and the number of stream errors.
- A recording fails: a recording ended in error (no signal, no tuner free, file not created, time missed…), with Tvheadend's reason, in English.
- Someone starts watching: a client starts watching a channel, with the channel, the Tvheadend user and the client. Can be limited to a channel or a user. Needs an admin account.
- Free space falls below a threshold: choose 5, 10, 15, 20 or 25 %; fires once, and again only after the free space went back above it.
The integration keeps what it saw: a restart of Gladys does not announce a recording twice, and a recording that ended meanwhile is announced once.
Actions
- Record a channel now: records a channel (its name or number, as Tvheadend shows it) from now, for 1 to 720 minutes, with an optional title. Gives the title, the channel, the start and end times.
- Recordings summary: reads Tvheadend for the next actions: recordings in progress and scheduled, what records, the next recording (title, channel, time), the free space, and a ready-made sentence ("1 recording(s) in progress (News), next: Film · TF1 · Fri 20:30, 120 GB free (24 %)").
Scene ideas
- Failed recording alert: "A recording fails" sends you a message with the title and the reason, so you can record it again.
- Nobody home at 20:55: when the alarm is on, "Record a channel now" records the news for 40 minutes.
- Disk almost full: "Free space falls below a threshold" (10 %) sends a notification; a morning scene says the sentence of "Recordings summary".
- Cinema mode: "Someone starts watching" on the living room account dims the lights.
Troubleshooting
- Tvheadend does not answer: check the address and the port 9981 from the machine running Gladys.
- User name or password refused (or no web interface right): Tvheadend answers the same to a wrong password and to an account without the Web interface right; check both.
- The account has no video recorder right: tick Video recorder in the access entry of the user.
- No viewers nor tuners: the account is not an administrator (the test of the connection says so); the rest works.
- A recording cut in the middle "finishes": Tvheadend itself reports a stream lost during a recording as "Completed OK"; only a stream absent at the start fails.
Limits
- One Tvheadend server per integration.
- Tvheadend is read at the interval chosen (30 seconds by default), not in real time: a viewer shorter than the interval may be missed.
- The failure reason is Tvheadend's, in English.
- No per-tuner device, no signal or SNR: Tvheadend lists only the tuners in use.
- The scene action schedules a recording; it neither cancels nor deletes one.
- "Someone starts watching" fires once per client (address, user, application): changing channel does not fire it again.
- A recording whose file is later moved or deleted stays a finished recording.
- Not affiliated with the Tvheadend project.
Configuration settings
These are the settings Tvheadend asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Your Tvheadend server | section | No | Enter the address of Tvheadend (port 9981) and an account with the video recorder and web interface rights. An admin account also shows the viewers and the tuners in use. The server appears in the Discover tab. |
| Tvheadend address | string | Yes | Address of the web interface of Tvheadend (port 9981 by default). |
| User name | string | Yes | A Tvheadend user (Configuration → Users → Access entries). |
| Password | secret | Yes | |
| Options | section | No | |
| Refresh interval | select | No | How often Tvheadend is read: a few light requests each time. |
| Language of the names | select | No | Language of the feature names (set when the device is added), of the dates and of the scene results. |
How to install Tvheadend in Gladys
- In Gladys, open Integrations: Tvheadend appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-tvheadend:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-tvheadend.
Tvheadend requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
