Traefik smart home integration, free and open source

Traefik integration for Gladys Assistant

Your Traefik reverse proxy in Gladys: services up or down, routers in error, alerts in scenes.

View on GitHubAll integrations

Traefik is the reverse proxy in front of many self-hosted services: it routes nextcloud.example.com to the Nextcloud container, renews the certificates, and can check that each backend still answers. This integration brings the state of Traefik into Gladys: a "Traefik" device with its version and the routers, services and middlewares in error, and one device per HTTP service with its servers up. Scenes can react when any service goes down or comes back, when a router turns to error, or when Traefik itself no longer answers; a dashboard widget lists the services down first.

Tested against a real Traefik v3.7 (Docker, file provider, two backends behind a health check, broken routers on purpose). Traefik v2 has the same API and should work, untested: feedback welcome on the issues.

What you need​

  • Gladys Assistant 5.1.0 or later.
  • Traefik v2 or v3 with its API enabled, reachable from the Gladys machine:
    • either api.insecure=true (static configuration): the API answers on the traefik entry point, port 8080, without password. Simple, for a local network only;
    • or a router of yours to the api@internal service, on your domain, usually behind a basicAuth middleware: enter its user and password.
  • To know whether a service is down, a health check on its load balancer. Without one, Traefik reports every server UP: the integration still sees a service in error or gone (a Docker container stopped), not a backend that stopped answering.

The integration sends two light requests per refresh interval (one minute by default) to the API of Traefik, nothing to the internet.

Getting started​

1. Enable the API of Traefik​

With api.insecure, add to the static configuration (command line of the container):

--api.insecure=true

and make port 8080 reachable from Gladys. Through a router, the Traefik documentation shows a router to api@internal with a basicAuth middleware.

2. Configure the integration​

In Gladys, open Integrations → Traefik → Configuration:

  • API address: http://192.168.1.2:8080 with api.insecure, or https://traefik.example.com through a router. A dashboard address copied from the browser works too: /dashboard/… is removed.
  • User (basic auth) and Password (basic auth): only when the router of the API asks for them.
  • Refresh interval: 30 seconds to 5 minutes.
  • Language of the names: language of the feature names and of the scene results.

Save, then Test the connection: the result shows the version of Traefik, the number of HTTP services, and the ones down.

3. Add the devices​

Open the Discover tab: the "Traefik" device and one device per HTTP service (nextcloud@docker, app@file…) are listed. Add the ones you want to follow. The internal services of Traefik (api@internal…) are left out.

The devices​

The Traefik device:

FeatureValue
Reachableyes when the API answers, no after two failed reads
Versione.g. 3.7.15
Routers in errorHTTP, TCP and UDP routers Traefik could not build
Services in errorservices in error
Middlewares in errormiddlewares in error
Warningsrouters, services and middlewares with a warning
Services downHTTP services without any server up (or gone, once added)

Each HTTP service:

FeatureValue
Healthyyes as long as at least one server is up
Servers upservers UP according to the health check
Servers in totalservers declared in the load balancer

A service that disappears from Traefik (its Docker container stopped) counts as down: no server, not healthy, until it comes back.

Dashboard​

Add the Traefik widget to a dashboard: the services down, the routers in error and the services working, then one row per service — down first, then degraded (some servers down), then the others — with its servers up, and the routers in error with their message. Its settings can limit it to some services (devices added to Gladys). Refresh reads Traefik at once.

Scenes​

Triggers​

  • A service goes down: an HTTP service no longer has any server up, or is gone from Traefik (two reads in a row). Optionally limited to some services. Variables: service name, provider, servers up and in total, gone from Traefik.
  • A service is back up: a service that was down has a server up again. Variables: the same, and the length of the outage in minutes.
  • A router is in error: a router turns to error (missing service or middleware, bad rule…), once per router until it is fixed. Variables: router name, provider, protocol, error message.
  • Traefik is unreachable: the API no longer answers, two reads in a row (a quick restart of Traefik does not fire it). Variable: the reason.

Every service fires the triggers, added to Gladys or not. The routers already in error when the integration starts are not announced.

Actions​

  • State of a service: healthy or not, its state in words (OK, Degraded, Down, Missing), servers up and in total, and a ready-made sentence such as "app@docker: Degraded, 1/2 server(s) up."
  • State of Traefik: reachable or not, the number and names of the services down and of the routers in error, the version, and a sentence. When Traefik does not answer, the action does not fail: it says so, and the scene goes on.

Scene ideas​

  • When A service goes down, send a Telegram message "{{service}} is down ({{servers_up}}/{{servers_total}} servers)", and another one on A service is back up with the length of the outage.
  • Every morning at 8:00, State of Traefik and, if a service is down, read its sentence on the speaker.
  • When Traefik is unreachable, switch a light red: every site of the house is down at once.

Troubleshooting​

  • "Traefik does not answer": check the address and the port from the Gladys machine (curl http://192.168.1.2:8080/api/version), and that port 8080 is published by the Traefik container.
  • "no Traefik API at this address": the API is not enabled, or the address points to a router that is not the one to api@internal.
  • "user or password refused": check the basic auth user; a password with a trailing space is kept as typed.
  • "the address redirects": enter the https:// address directly.
  • "certificate refused": use a certificate Gladys trusts (Let's Encrypt), or the http:// address of api.insecure on the local network.
  • A service never goes down: add a health check to its load balancer.
  • More details in the logs of the integration (Integrations → Traefik → Logs), with LOG_LEVEL=debug for every read.

Limits​

  • Read-only: the Traefik API cannot change the configuration, so the integration has no command.
  • HTTP services only as devices; TCP and UDP routers and services are counted on the Traefik device.
  • Without a health check, Traefik reports every server UP.
  • The Prometheus metrics (requests, 5xx errors) are not read.
  • One Traefik per integration.

Configuration settings​

These are the settings Traefik asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your Traefik APIsectionNoEnable the Traefik API: api.insecure=true serves it on port 8080, or a router to api@internal serves it on your domain, often behind basic auth. Then add the services to follow from the Discover tab.
API addressstringNoThe address of the Traefik dashboard or API, without /dashboard.
User (basic auth)stringNoOnly when the router of the API asks for a basic auth. Leave empty otherwise.
Password (basic auth)secretNo
OptionssectionNo
Refresh intervalselectNoHow often Traefik is read: two light API requests each time.
Language of the namesselectNoLanguage of the feature names (set when a device is added) and of the scene results.

How to install Traefik in Gladys​

  1. In Gladys, open Integrations: Traefik appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-traefik:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-traefik.

Traefik requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Traefik is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
