Tractive smart home integration, free and open source
Tractive GPS trackers for dogs and cats: at home or not, distance, battery, activity, buzzer.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.2.0
- ★ 0
Follow your dog's or your cat's Tractive GPS tracker in Gladys: is it at home, how far away, battery, activity of the day, and the buzzer and the light to find it. Unofficial integration, not affiliated with Tractive.
Developed without the hardware: feedback welcome. The integration is built on the API the Tractive app uses, as the open source aiotractive library and the Home Assistant integration read it, and tested against their recorded answers, not against a real tracker. Please report what works and what does not in the issues.
Overview
- One device per pet with a Tractive tracker on your account: battery, charging, distance from home, position accuracy, at home or not, tracker online, power saving, activity and rest of the day, daily activity goal.
- Commands: live tracking, buzzer and light (LED), when the tracker and the subscription allow them.
- Real time: battery, positions and switches arrive as they happen, through the event stream the Tractive app listens to.
- Scene triggers: Pet left home, Pet came home, Tractive battery low.
- Dashboard widget Tractive pet, with buzzer and light buttons.
The position itself (latitude, longitude) is never stored in Gladys, which has no feature for it: Gladys keeps the distance to your house, computed by the integration.
Requirements
- Gladys Assistant 5.2.0 or later.
- A Tractive tracker with an active subscription, and the e-mail address and password of the Tractive account it belongs to. An account created with "Sign in with Apple" or Google has no password: set one in the Tractive app first (account settings).
- For the distance and "at home": a Gladys house with a location (Settings → Houses, place the house on the map).
- Gladys must reach the Internet (
graph.tractive.com,aps-api.tractive.com,channel.tractive.com).
Configuration
- In Gladys, open Integrations → Install from GitHub (or the catalog) and install Tractive. The install screen asks to read the location of your houses: it is used to compute the distance.
- In Configuration, fill in:
- E-mail address and Password of your Tractive account;
- House: the house the distance is measured from (empty: the first house that has a location);
- Home radius (m): inside this distance the pet is at home (100 m by default). It counts as gone once 20 % farther (25 m at least), so GPS jitter at the edge does not make it come and go;
- Low battery threshold (%): 15 % by default;
- Refresh interval (min): the full refresh (15 min by default, 5 to 60);
- Language of the feature names: French by default, also used for the command errors.
- Save, then use Test the connection: it lists the pets found.
- Open the Discovery tab and add your pets.
The integration keeps a session token in its own /data volume, so a restart
does not log in again. The password stays in the Gladys configuration.
What each device does
One device per pet, named after the pet. Features depend on the tracker: a tracker without a light has no light feature, for example.
| Feature | What it shows |
|---|---|
| Battery | Battery level of the tracker (%) |
| Charging | 1 while the tracker charges (trackers that report it) |
| Distance from home | Distance between the last position and the chosen house (m) |
| Position accuracy | Uncertainty of the last position, as given by Tractive (m) |
| At home | 1 inside the home radius, 0 outside |
| Tracker online | 0 when the tracker stopped reporting or was switched off |
| Power saving | 1 while the tracker saves power (asleep on the home Wi-Fi zone) |
| Activity today | Active minutes since midnight |
| Rest today | Calm minutes since midnight (trackers with sleep tracking) |
| Daily activity goal | The goal set in the Tractive app (minutes) |
| Live tracking | Switch: live tracking mode, a position every few seconds |
| Buzzer | Switch: the tracker beeps, to find the pet nearby |
| Light (LED) | Switch: the tracker's light, to see the pet in the dark |
Commands
Live tracking, Buzzer and Light (LED) are sent to the tracker through Tractive. The buzzer and the light stop by themselves after a while on the tracker; Gladys shows them off as soon as Tractive says so. Live tracking drains the battery: turn it off when the pet is found.
A command is refused with a clear message when:
- the tracker sleeps in its power saving zone (home Wi-Fi): it does not take commands there;
- the subscription or the tracker model does not allow the function;
- the integration is not connected to Tractive.
Nothing here opens, unlocks or disarms anything.
Dashboard widget
Add the Tractive pet widget to a dashboard and choose the pet in its settings. It shows:
- the distance from home and the battery (live);
- the activity of the day against the daily goal;
- at home or not, how old the last position is, and the tracker state (online, offline, power saving);
- a buzzer button and a light button (when the tracker has them). A running function shows a check mark: tap again to stop it.
Scene triggers
| Trigger | When | Variables |
|---|---|---|
| Pet left home | The pet goes beyond the home radius plus the margin | pet name, distance from home (m) |
| Pet came home | The pet comes back inside the home radius | pet name, distance from home (m) |
| Tractive battery low | The battery drops below the threshold, once (again only after 5 points above), not while charging | pet name, battery (%) |
Each trigger can be limited to one pet (empty: any pet). They add to the At home and Battery features what a device state cannot say: one event per real crossing, the pet's name for a message, positions less precise than 500 m ignored (a cell-tower fix never makes a sleeping cat "leave"), nothing on the first value after a restart.
Connection test
The Test the connection button logs in to Tractive with the saved configuration and answers with the pets found, whether real-time updates are connected, and whether a located house is missing. It is also how to retry after Tractive refused the password, once it is fixed.
Scene examples
- The dog ran away: trigger Pet left home for the dog → send a message "{{triggerEvent.data.pet_name}} left home, {{triggerEvent.data.distance}} m away" → turn on Live tracking.
- Welcome home: trigger Pet came home → turn off Live tracking and send "{{triggerEvent.data.pet_name}} is home".
- Charge the tracker: trigger Tractive battery low → send a message "Charge {{triggerEvent.data.pet_name}}'s tracker ({{triggerEvent.data.battery}} %)".
- Night check: every evening at 10 pm, if At home is 0 → send a message.
Refresh and API limits
Tractive offers no public API: the integration uses the one of the Tractive app, as Home Assistant does, and takes care not to overload it.
- Real time first: one long-lived connection to the Tractive event stream carries battery, positions and switches. Lost, it reconnects after 10 s, then up to every 5 minutes while it fails.
- Full refresh every 15 minutes (configurable, 5 to 60): tracker, battery, position and activity of the pets added to Gladys only, one request after the other, 2 seconds between two pets. The Gladys scheduler is not relied on: the integration runs its own timer.
- One login per token lifetime: the token is kept in
/dataand renewed an hour before it expires. A refused password is not retried until you change the configuration or press Test the connection. - A "too many requests" answer (429) is retried after 8 seconds, then up to 60 seconds, three times at most.
- Only changed values are sent to Gladys, plus a reminder every 6 hours of the unchanged ones.
Troubleshooting
- "Tractive refused the e-mail address or the password": check them in the Tractive app or on my.tractive.com. A Google or Apple account needs a password set in the Tractive app.
- No pet in Discovery: the pet needs a tracker assigned on your account; a tracker shared with you by another account is not listed. Press Test the connection.
- Distance and "At home" stay empty: give the house a location (Settings → Houses), or choose a located house in the configuration.
- A command fails: see the message; in the home Wi-Fi zone the tracker sleeps and does not take commands.
- Values look old: the tracker reports less often in power saving; check
the tracker in the Tractive app.
LOG_LEVEL=debugon the integration shows every update in its logs.
Limitations
- Developed without the hardware: tested against recorded API answers only.
- The API is the Tractive app's, not a public one: Tractive may change it without notice and break the integration until it is updated.
- No map: Gladys has no feature for a position, only the distance to a house.
- The switch states (buzzer, light, live tracking) are only known once the real-time stream reports them.
- The activity is the one of the day, as Tractive counts it.
- One Tractive account per Gladys.
- Geofences, the Tractive history and the health alerts of the app are not available.
Configuration settings
These are the settings Tractive asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Your Tractive account | section | No | The e-mail address and password you use in the Tractive app. A tracker with an active subscription is needed. Unofficial integration, not affiliated with Tractive. |
| E-mail address | string | Yes | |
| Password | secret | Yes | Kept in the Gladys configuration only; the integration stores a session token in its /data volume, never the password. |
| Home | section | No | The distance and "at home" are computed in Gladys from the location of a Gladys house (Settings, Houses). The position itself is never stored in Gladys. |
| House | select | No | Empty: the first house that has a location. |
| Home radius (m) | number | No | Inside this distance the pet is at home. It counts as gone once 20 % farther (25 m at least), against GPS jitter. |
| Low battery threshold (%) | number | No | Below this level, the "Tractive battery low" scene trigger fires once. |
| Refresh interval (min) | number | No | Positions and battery arrive in real time. This full refresh reads the activity and covers the moments without real time. |
| Language of the feature names | select | No | Used for the devices added from now on, and for the command errors. |
How to install Tractive in Gladys
- In Gladys, open Integrations: Tractive appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-tractive:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-tractive.
Tractive requires Gladys >=5.2.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
