Brings your TP-Link Deco mesh Wi-Fi into Gladys: who is home (phones on the Wi-Fi), the state of each Deco of the mesh, and two commands for your scenes: the guest Wi-Fi and the restart of a Deco. Everything stays on your local network: the integration talks to the main Deco directly, never to the TP-Link cloud.
Not affiliated with TP-Link. Developed without the hardware: feedback welcome — the integration is tested against a fake Deco that speaks the real encrypted protocol, built from published answers of real Decos, not against a real one yet.
Overview
- Presence: every phone, laptop or device connected to the mesh can become a presence sensor, with a departure delay so a phone in sleep mode does not "leave" every few minutes.
- One device per Deco: online, Internet, connected clients, guest clients, role (main Deco or satellite), firmware version and, for a satellite, the link rate of its connection to the mesh.
- Scene triggers: an unknown device connects to the network, a Deco goes offline.
- Commands (off by default): turn the guest Wi-Fi on or off, restart a Deco.
- Dashboard widget: clients, guests, the state of each Deco and who is home, at a glance.
Models: the Deco range that the Deco app manages and that has a local web page (X20, X50, X55, X60, X68, M4, M5, M9 Plus, BE65, BE85…). Gladys 5.1 or later.
Prerequisites
- A Deco mesh set up with the Deco app, and the IP address of the main Deco — the one plugged
into your Internet box. The Deco app shows it: Network → the main Deco → IP address (often
192.168.68.1in router mode). In access-point mode, it is the address your box gave it. - The password of the TP-Link ID that owns the network in the Deco app: the local web API of the
Deco only accepts the owner account, with the username
admin, not a manager account. - The Deco allows one administrator session at a time. The integration logs in for each read and logs out at once, but while it reads, a login elsewhere ends one of the two sessions. TP-Link recommends a second TP-Link ID, added as a manager in the Deco app, for your own use of the app.
Configuration
In Gladys, Integrations → Install from GitHub with the address of this repository, then Integrations → TP-Link Deco → Configuration:
| Field | What to enter |
|---|---|
| Address of the main Deco | Its IP address, e.g. 192.168.68.1. Add https:// only if http does not answer. |
| Deco app password | The password of the owner TP-Link ID. Never shown, never logged. |
| Offer the network clients in Discovery | On by default: the clients online appear in the Discovery tab. |
| Departure delay (minutes) | 5 by default: how long a client must be gone before it is reported away (0 to 120). |
| Refresh interval | 1 minute by default; 30 seconds, 2 or 5 minutes. Each read is one login on the Deco. |
| Allow guest Wi-Fi control | Off by default. Adds the guest Wi-Fi switch to the main Deco. |
| Allow restarts | Off by default. Allows the "Restart a Deco" action and scene action. |
| Language of the feature names | French by default; English, German or Spanish. Names are set when a device is added. |
Then run Test the connection (Configuration screen): it logs in, counts the Decos and the clients, and logs out. The Deco counts wrong passwords and locks the login after several of them: a refused password pauses the reads until you fix it, so the integration never locks your account.
How often the Deco is read: at the chosen interval, by the integration itself (Gladys 5.2 does not poll external devices reliably). One read is one session: the keys, the login, the list of the Decos, one client list per Deco, the guest network when its control is allowed, and the logout — about ten small requests. The Deco has no published quota; every 1 minute is the pace the Home Assistant integration uses (30 seconds there). Opening a dashboard never reads the Deco.
Devices
Go to Integrations → TP-Link Deco → Discovery and add what you want to follow.
A Deco (one device per Deco of the mesh):
| Feature | Value |
|---|---|
| Online | 1 when the Deco is part of the mesh, 0 when it dropped out. |
| Internet | 1 when the Deco reaches the Internet. |
| Connected clients | The clients connected through this Deco (Wi-Fi and wired). |
| Guest clients | Those of them on the guest network. |
| Role | Main Deco or Satellite. |
| Firmware version | As the Deco reports it, e.g. 1.8.0 Build 25102213 Rel. 43970. |
| Link rate | Satellites only: the rate of the link to the mesh, in Mbit/s (Wi-Fi or Ethernet). |
| Guest Wi-Fi | Main Deco only, once "Allow guest Wi-Fi control" is on: a switch, on or off. |
A network client (a phone, a computer…): one Presence feature, 1 when the client is connected to the mesh (or left less than the departure delay ago), 0 otherwise. A client added to Gladys stays in the Discovery list when it is away.
After turning on "Allow guest Wi-Fi control", open the Discovery tab and click Update on the main Deco: the switch is added to it.
Widget
Add the Deco network widget to a dashboard. It shows three tiles (clients connected, guests, Decos online), the clients you added to Gladys with Home or Away, and the state of each Deco: its number of clients, No Internet or Offline. It is built from the latest read of the Deco and costs it nothing.
Scene triggers
| Trigger | When | Variables |
|---|---|---|
| Unknown device connected | A device never seen on the mesh joins it. Filters: connection, guest network. | name, MAC address, IP address, connection, Wi-Fi band, connected to |
| Deco offline | A Deco drops out of the mesh: unplugged, out of reach, restarting. Filter: Deco. | Deco name, model |
The first read only learns the devices already there: installing the integration or restarting it fires
nothing. The devices seen are kept in /data (MAC addresses only).
Commands
Both are off by default: turn on their option in the configuration first.
- Guest Wi-Fi: the switch of the main Deco turns the guest network on or off on every band that has one. The guest network must exist (create it in the Deco app). Use it from a scene like any switch.
- Restart a Deco: an action of the Configuration screen and a scene action, never a switch. The area of that Deco loses the Wi-Fi for a few minutes; restarting the main Deco cuts the whole network, Gladys included if it reaches the Deco through it.
Scene examples
- Welcome: when "Presence" of a phone goes to 1 after 18:00, turn on the hall light.
- Intruder on the network: on "Unknown device connected" with guest network "No", send a message with the name and MAC address of the device.
- Guests: every Saturday at 14:00 turn the guest Wi-Fi on, at 23:00 off.
- Weekly restart: every Monday at 4:00, "Restart a Deco" on a satellite that tends to slow down.
Troubleshooting
- "Password refused": check the password of the owner TP-Link ID (not a manager). The reads are paused: fix the password, or run "Test the connection".
- "Login refused": the Deco locks the login for a while after wrong passwords. Wait a few minutes.
- "The session was taken over by another login": someone logged in on the web page of the Deco during a read. The next read logs in again; close the web page when you are done with it.
- The Deco app logs you out: the owner account of the app and the integration share the same administrator. Use a manager account in the app, as TP-Link recommends.
- "No answer": check the IP address of the main Deco (Deco app) and that Gladys reaches it. Some
firmwares only answer on
https://: the integration follows that redirect by itself. - "Does not answer like the main Deco": the address is not the main Deco, or the firmware uses an older login (Deco S7, some old firmwares) that the integration does not support.
- Logs: Integrations → TP-Link Deco → Logs; set
LOG_LEVEL=debugfor every read.
Limits
- Developed without the hardware: the protocol follows the Home Assistant integration
tplink_deco; report any difference with your model. - The Deco allows one administrator session: the integration and the web page of the Deco interrupt each other while one of them reads.
- The firmwares with the older encrypted login (HTTP 401 on the keys, Deco S7) are not supported.
- The loss of the main Deco itself shows as "Main Deco unreachable" on the integration, not as a "Deco offline" trigger: the satellites are only seen through it.
- Presence depends on the phone staying on the Wi-Fi: phones that randomize their MAC address need a fixed (private address off) address for this network.
- No cloud: the Deco must be reachable on the local network; the TP-Link cloud is never used.
Configuration settings
These are the settings TP-Link Deco asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Main Deco | section | No | The Deco connected to your Internet box. Its local web API allows one administrator session at a time: the integration logs out after each read, and a login on the web page of the Deco interrupts the integration. |
| Address of the main Deco | string | Yes | Its IP address on your network, shown in the Deco app (Network > the main Deco). Add https:// only if http does not answer. |
| Deco app password | secret | Yes | The password of the TP-Link ID that owns the network in the Deco app (the owner, not a manager). The Deco locks the login after several wrong passwords. |
| Presence and refresh | section | No | The clients online appear in the Discovery tab: add the phones to follow, each becomes a presence sensor. |
| Offer the network clients in Discovery | boolean | No | |
| Departure delay (minutes) | number | No | How long a client must be gone before it is reported away (phones in sleep leave the Wi-Fi for a while). |
| Refresh interval | select | No | Each read is one login on the Deco. Every 30 seconds suits a fast presence; every 2 or 5 minutes spares the Deco. |
| Commands (off by default) | section | No | Restarting a Deco cuts the Wi-Fi of its area for a few minutes, the main Deco the whole network: turn on only what your scenes need. The guest Wi-Fi switch appears on the main Deco once allowed (Discovery > Update). |
| Allow guest Wi-Fi control | boolean | No | |
| Allow restarts | boolean | No | |
| Language of the feature names | select | No | Also used for the messages of the integration. Names are set when a device is added. |
How to install TP-Link Deco in Gladys
- In Gladys, open Integrations: TP-Link Deco appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-deco:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-deco.
TP-Link Deco requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
