Tisséo smart home integration, free and open source
Next Tisséo departures in Toulouse, traffic alerts and VélôToulouse bikes, from open data.
Published by guim31
- Devices
- Version 1.0.0
- Requires Gladys >=5.1.0
- ★ 0
The public transport of Toulouse in Gladys: the next departures at your stops (metro, tram, Téléo, Linéo, buses), the traffic alerts of their lines, and the VélôToulouse bikes of your stations. Everything comes from open data: no account, no API key.
Data: Tisséo and Toulouse Métropole, under the Open Database License (ODbL), published on transport.data.gouv.fr. This integration is a community project, not affiliated with Tisséo, Toulouse Métropole or JCDecaux.
What you get
- One device per stop you watch: for each line and direction, the minutes before the next departure and before the following one; the three soonest departures as text; the traffic info of its lines.
- One device per VélôToulouse station you watch: bikes available, mechanical bikes, electric bikes, free docks.
- Dashboard widget "Next departures": the board of a stop, the times tracked in real time in green, the timetable times marked "≈".
- Dashboard widget "VélôToulouse": your stations at a glance.
- Scene triggers: "Tisséo disruption", "Bikes running out at a station", "Bikes back at a station".
- Scene actions: "Read the next Tisséo departures" and "Read a VélôToulouse station", with a sentence ready to send ("Metro A towards Basso Cambo at Jean Jaurès: in 3 and 7 min").
Real time or timetable? Tisséo publishes the live position of its buses, tram and Téléo cabins: their departures are corrected (delays, cancellations, skipped stops). The metro is not in the realtime feed: its times are the timetable ones (a train every 1 to 4 minutes at rush hour), marked "≈" or "scheduled".
Requirements
- Gladys 5.1 or later, with Internet access.
- To list the stops around your home: the position of your house in
Gladys (Settings → Houses). The integration asks for it on install
(
location): it reads the coordinates of your houses, nothing else, and only to sort the stops by distance. Without it, search by name. - About 20 MB of disk under
/data(the timetable archive, refreshed once a day).
Installation
- In Gladys, go to Integrations → Install from GitHub and enter
https://github.com/guim31/gladys-tisseo. - Open the Configuration tab of the integration and pick the language of the texts (French by default).
- Add your stops and stations with the actions of the same screen (below), then create their devices in the Discover tab.
Configuration
Settings
- Language of the texts: feature names, traffic info, scene sentences. Feature names are set when the device is created: change the language first, then create the devices.
- Refresh interval: 30 seconds, 1 minute (default), 2 or 5 minutes. Both the departures and the bike stations follow it.
- Real time: on by default. Off, the integration only uses the timetable and no longer downloads the realtime feed.
Adding a stop
- Find a stop: type a name ("jean jaures" finds "Jean Jaurès", accents
and case do not matter), or leave it empty to list the 10 stops closest to
your home. Each result shows its lines, its distance and its identifier,
for example
• Jean Jaurès [SA_1707] — A, B, L1, L9, L14, 15, 23 — 550 m. - Add a stop: its name, or its identifier when several stops share the name (there are three "Jean Jaurès" in the metropolis). Lines is optional: "A, L1" keeps only these two lines; empty keeps every line.
- Open the Discover tab and create the device.
Adding a stop already watched changes its lines: Gladys then offers to update the device in the Discover tab.
The first search downloads the Tisséo timetable (15 MB) and reads it: up to a minute on a small machine. The actions wait for it.
Adding a bike station
- Find a bike station: a name, or empty for the 10 stations closest to
your home. Each result shows its number, for example
• Poids de l'Huile [1] — 570 m. - Add a bike station: its number or its name.
- Create its device in the Discover tab.
Removing a stop or a station, checking the feeds
- Remove a stop or a station: its name or identifier. The device stays in Gladys until you delete it.
- Show what is watched: the stops and stations, the date of the timetable, the age of the realtime data and of the bike data, and the last error if any.
At most 20 stops and 20 stations.
Devices
Stop
For each line and direction served (or the lines you chose):
| Feature | Type | Value |
|---|---|---|
| Metro A → Basso Cambo | duration (min) | minutes before the next departure |
| Metro A → Basso Cambo (next) | duration (min) | minutes before the following one |
Plus two texts for the whole stop:
- Next departures: the three soonest, e.g.
L1 → Gare Matabiau 2 min · A → Basso Cambo ≈4 min("≈" = timetable). - Traffic info: the titles of the current alerts on its lines, or "No disruption".
0 means the vehicle is at the stop or arriving (less than a minute);
1440 means no departure in the next 24 hours (night, a line that does not
run that day). These values keep no history: a countdown re-read every minute
would fill the database for nothing.
Bike station
| Feature | Type |
|---|---|
| Bikes available | counter |
| Mechanical bikes | counter |
| Electric bikes | counter |
| Free docks | counter |
These ones keep their history: the chart shows when your station empties.
Dashboard widgets
- Next departures: choose a stop. One row per line and direction (ten at most, the lines with a departure first): "3 · 7 min" in green when tracked in real time, "≈ 3 · 7 min" in blue for the timetable. The caption lists the disruptions of its lines (⚠), or reminds the legend.
- VélôToulouse: choose your stations (empty: all of them, ten at most). One station shows four live tiles; several show a row each ("3 mech. · 2 elec. · 12 docks"), red when no bike is left, orange at two or fewer.
Scene triggers
- Tisséo disruption: a new traffic alert appears on a line of your watched stops (a line filter of a stop narrows it), or on the whole network (strike, closures). Filters: scope (a followed line, the whole network, or empty for both) and line (as written by Tisséo: A, T1, L9, 15). Variables: line, title, details (plain text), link to tisseo.fr. An alert is announced once; the alerts already there when you add a stop are not.
- Bikes running out at a station: the bikes of a type (any, mechanical, electric) at a watched station drop to the chosen number or below (0, 1, 2, 3 or 5). Fires once when the threshold is crossed, not at every refresh.
- Bikes back at a station: the same bikes rise above the chosen number again.
For "the next bus is in less than 5 minutes", use the built-in "Device state change" trigger on the countdown feature of the stop: it already compares values.
Scene actions
- Read the next Tisséo departures: a watched stop and, optionally, a line. Outputs: sentence (up to four lines and directions, soonest first), stop, line and direction of the next departure, minutes to wait, minutes to the following one, real time (1) or timetable (0), number of lines with a departure.
- Read a VélôToulouse station: outputs a sentence, bikes available, mechanical, electric, free docks, in service (1 or 0).
The sentences follow the language of the configuration.
Scene examples
- Time to go: at 7:45 on weekdays, "Read the next Tisséo departures" at
your stop for line L1, then send
{{sentence}}by Telegram or announce it on a speaker. - Strike morning: trigger "Tisséo disruption" with the scope "whole network", then send the title and the link to your phone.
- The last electric bike: trigger "Bikes running out at a station", your station, electric bikes, at most 0: send "No more electric bikes at the station, take the metro".
- Leave when the bus comes: "Device state change" trigger, countdown of your bus lower than 4, condition "someone at home" and before 8:30: blink the hall light.
Data, refresh and bandwidth
| Data | Source | When |
|---|---|---|
| Timetable (GTFS, 15 MB) | Tisséo, via data.gouv.fr | once a day at most, kept in /data |
| Real time (GTFS-RT, 1.7 MB) | Tisséo (api.tisseo.fr) | at each refresh, every 15 min when nothing runs |
| Bike stations (GBFS) | VélôToulouse (JCDecaux), via data.gouv.fr | station list once a day, status at each refresh |
The realtime feed is the heavy one: about 100 MB per hour at one refresh per minute while departures are scheduled. At night, with no departure within 90 minutes at your stops, it is read every 15 minutes only. Choose 2 or 5 minutes, or turn real time off, on a metered connection. The open data comes without quota; Tisséo rebuilds the realtime feed about every 20 seconds.
Troubleshooting
- "The Tisséo timetable is still loading": the first download takes a minute; try again.
- "Several matches": add the stop by its identifier (
SA_…), shown by "Find a stop". - All the times of a stop are marked ≈: the metro always is; for a bus, the vehicle is not tracked right now, or the realtime feed is down ("Show what is watched" gives the last error). The timetable keeps working.
- A line shows 1440: no departure within 24 hours (night service, a line that does not run that day, a deviation).
- No device in the Discover tab: add a stop or a station first; the timetable must be downloaded for stops.
- A new line at my stop: Gladys offers to update the device in the Discover tab.
- Logs: in Gladys, the integration's logs say which feed failed and why.
Limits
- Toulouse only (the Tisséo network and VélôToulouse).
- The metro is timetable only: Tisséo does not publish it in real time.
- No park-and-ride occupancy: the open data of Toulouse Métropole only gives the capacity of the park-and-ride facilities, not the free spaces.
- The traffic alerts are those Tisséo publishes in its realtime feed; their text is in French.
- The official Tisséo API (api.tisseo.fr, with a key) is not used: the open feeds give the same departures without any account.
- A countdown is accurate to the refresh interval.
- Developed and tested with the real Tisséo and VélôToulouse data, without a Gladys instance: feedback welcome on the forum.
Credits
- Data: Tisséo, Toulouse Métropole, VélôToulouse (JCDecaux), under the ODbL.
- Inspired by the TCL integration of prohand (Lyon) and by the GTFS integrations of Home Assistant.
- Code under the Apache 2.0 license.
Configuration settings
These are the settings Tisséo asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| How it works | section | No | Find your stops and VélôToulouse stations with the actions below (by name, or around your home), add them, then create their devices in the Discover tab. Everything comes from Tisséo and VélôToulouse open data: no account, no key. |
| Language of the texts | select | No | Language of the feature names, of the traffic info and of the sentences sent to your scenes. Feature names are set when a device is created. |
| Refresh interval | select | No | How often the departures and the bike stations are refreshed. The realtime feed weighs about 1.7 MB: once a minute is about 2.4 GB a day while departures are scheduled. |
| Real time | boolean | No | Correct the timetable with the vehicles tracked live (buses, tram, Téléo) and read the traffic alerts. Off: timetable only, no download every minute. |
How to install Tisséo in Gladys
- In Gladys, open Integrations: Tisséo appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-tisseo:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-tisseo.
Tisséo requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
