TBM smart home integration, free and open source
Real-time departures of the TBM trams, buses and boats (Bordeaux), by direction.
Published by daviddu26
- Devices
- Version 0.1.1
- Requires Gladys >=5.1.0
- ★ 0
This integration brings the real-time departures of the trams, buses and boats of the TBM network (Bordeaux Métropole) into Gladys, direction by direction: for each line followed at a station, you know in how many minutes the next vehicle of each direction leaves, and where it goes.
It also plans your journeys from the house to the addresses you choose (work, school, station…): when to leave, which lines, when you arrive — in real time, with the night lines and the disruptions.
No account, no key: the TBM real time is open data, and the journeys are planned by Transitous, a free community service.
Community integration, not affiliated with TBM, Keolis Bordeaux Métropole Mobilités nor Bordeaux Métropole.
Beta version. Departures and journeys work, but the integration is young: report any issue or idea on GitHub, with a screenshot if you can.
Getting started
- Give your house an address in Gladys: Settings → Houses. The integration uses it to find the stations nearby.
- Open the Configuration page of the integration and press Save (the defaults suit).
- Open the Discover tab: the lines of the 3 closest stations (within 600 m) are proposed there, e.g. "TBM – Hôtel de Ville – Tram A". Press Add on the ones you want.
The next departures arrive within a minute.
With several houses in Gladys, the integration looks around the first house that has an address, in alphabetical order.
What you get
One device per line at a station. For each direction of the line:
| Feature | Value |
|---|---|
| Direction 1 → … · next departure | minutes before the next departure (999: none) |
| Direction 1 → … · destination | where that vehicle goes, e.g. "La Gardette" |
| Direction 1 → … · following departure | minutes before the one after |
| Direction 1 → … · next departures | "La Gardette 3 min · Cenon Gare 11 min (incl. 2 minutes delay)" |
The name of each feature says where the direction goes. The destination is the vehicle's own: on a branching line (tram A after Buttinière), direction 2 leaves for La Gardette one time and for Cenon Gare the next.
In the texts: ~11 min is a timetable time (the vehicle is not tracked yet); (incl. 2 minutes delay) a delay already counted in the minutes shown ("11 min (incl. 2 minutes delay)": it leaves in 11 minutes instead of 9, nothing to add); (last) the last departure of the direction before a break of more than two hours, that is usually the last of the evening, flagged up to two hours ahead; now less than a minute. Values keep no history.
Set Language of the values to English for English feature names and texts.
Following another station
- At the bottom of the Configuration page, press Find a station and type part of the name ("Quinconces"). The answer gives the code of each station and its lines. The tram and the bus stopping at the same place are two stations (tram codes start with T, bus codes with B).
- Paste the code in Stations. To keep only some lines, add
@and their numbers separated by|:THDVA(every line of Hôtel de Ville),THDVA@A(tram A only),BQUIOR@2|N6. Several stations: separate them with commas. - Save, then add the devices from the Discover tab.
Journeys from the house
In the Configuration page, section Journeys from the house, type up to 5 destinations in
Journeys, separated by semicolons, each as "Name: address":
Work: 1 place Pey Berland, Bordeaux; Station: Gare Saint-Jean. The name is optional. Add the town
when an address is ambiguous: one found more than 60 km from the house is ignored. Save, then add
the "TBM – Journey → Work" devices from the Discover tab.
Journeys start from the address of the house and count the walk to the first stop and from the last. Transitous plans them with the TBM real time: a cancelled trip, a delay, a moved stop, or the end of the tram service (the night buses take over) change the journey.
Features: leave in (minutes before leaving the house, 999: none), duration, arrival ("18:47"), route ("Tram A 18:12, change at Porte de Bourgogne: Tram F 18:19"), next departures ("18:05 → 18:47 · 18:15 → 18:55"), status ("Normal", "4 min late", "Disrupted: …", "Timetable"; or why the journey cannot be planned, and what to do).
Transitous is a volunteer service asking for a light use. The integration therefore makes a full calculation of the journeys only at first, then each time the first journey proposed has left. In between, it updates the real time of the journeys already found (delays, cancellations) every 2 minutes (Journeys update), which costs Transitous almost nothing. "Leave in" counts down every minute.
Settings
| Setting | Role | Default |
|---|---|---|
| Stations near my home | how many close stations are proposed (0: none) | 3 |
| Search radius (m) | the farthest a proposed station may be from the house | 600 |
| Include the school buses | also propose the SCODI school lines | no |
| Stations | stations typed by hand | empty |
| Refresh interval (s) | how often the departures are read | 60 |
| Departures in the summary | departures per direction in the "next departures" text | 3 |
| Journeys | destinations of the journeys from the house | empty |
| Journeys update (s) | how often the real time of the journeys is updated, 120 at least | 120 |
| Language of the values | language of the feature names and texts | French |
Replacement buses during works ("Navette Tram", "Bus Relais") are not proposed automatically: add them by number in Stations if needed.
Dashboard
The TBM departures widget shows a line at a station like a stop sign: one tile per direction with the next departure, then the following departures (the next one, already in its tile, is not repeated) — green when tracked in real time, grey ("~") for a timetable time, orange from 5 minutes late or for the last departure of the evening, also announced under the title ("Last at 00:24 → Le Haillan Rostand").
In its settings, choose the line at a station, the direction ("Both directions", "Direction 1" or "Direction 2", numbered as in the feature names of the device; with one direction, where it goes is shown under the title) and the departures shown per direction, the tile included: "Next only" keeps the tiles alone, "3 departures" is the tile and the 2 following. Left empty: both directions, 5 departures. Add two widgets for the same line to follow each direction on its own.
The TBM journey widget shows a journey: a tile with in how many minutes to leave, the lines and the arrival ("Lianes 4 › TER → 22:00"), the detail with the time of each line above it ("Lianes 4 21:45, change at Gare Saint-Jean: TER ~21:53", and what disrupts the journey, if anything), and the next options below, never repeating the tile's. Journeys are ranked by arrival: the tile shows the one getting you there first, even if it leaves later than another; a change that needs a walk to another stop says so. A "~" marks a timetable time: that vehicle is not tracked in real time (often a TER, whose real time Transitous lacks). Settings: the journey and the journeys shown ("Best only" to 5, the best included; empty: 5).
Scenes
- Trigger TBM departure approaching: a vehicle of a followed line gets under the chosen number of minutes (1, 2, 3, 5, 10 or 15), counted on its real-time departure. Filters: the line, the direction, the minutes. Once per vehicle and per mark. Variables include a ready-made sentence: "Hôtel de Ville: Tram A to La Gardette leaves in 5 min (17:58, incl. 2 minutes delay)."
- Action Read the next TBM departure: the next departure of a line (one direction or both), as outputs for the following actions of the scene.
Buttons of the configuration page
- Find a station — finds the code of a station by its name.
- Test the connection — reads TBM now and shows what it found.
Data
Real time and network directory: TBM / Bordeaux Métropole, Réseau urbain et scolaire TBM, under the Licence Ouverte. The directory is read once a day; the departures once a minute per station, however many of its lines are followed.
Journeys: Transitous (free community service, OpenStreetMap data and the networks' timetables). The integration names itself to it, keeps the addresses found in the container, and plans a journey again only at the configured interval.
Configuration settings
These are the settings TBM asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Get started in 2 minutes | section | No | 1. Check that your house has an address in Gladys (Settings → Houses). 2. Save this page. 3. Open the “Discover” tab of this integration and press “Add” on the lines near your home. That's it: the next departures arrive within a minute. No account, no key: the TBM real time is open data. |
| Near my home | section | No | The lines of the closest stations are proposed in the “Discover” tab, one device per line, both directions in it. |
| Stations near my home | number | No | How many of the closest stations are proposed. 0 turns the suggestion off. |
| Search radius (m) | number | No | Only the stations within this distance of the house, in meters. |
| Include the school buses | boolean | No | Also propose the SCODI school lines calling at these stations. |
| Other stations (optional) | section | No | To follow a station that is not near your home (work, school…): find its code with the “Find a station” button at the bottom of this page, and paste it here. |
| Stations | string | No | Station codes, separated by commas. After @, the lines to keep (separated by |), otherwise all of them: "THDVA, BQUIOR@2|5". |
| Journeys from the house | section | No | The best journeys from your house to the destinations of your choice, in real time. Takes the night timetables and the disruptions into account. Planned by Transitous, a free community service. |
| Journeys | string | No | Up to 5 destinations separated by semicolons, each as "Name: address". One device per journey appears in the Discover tab. |
| Advanced | section | No | The defaults suit almost everyone. One request serves every line of a station. |
| Refresh interval (s) | number | No | How often the departures are read, in seconds (one minute minimum). |
| Journeys update (s) | number | No | How often the real time of the journeys is updated, in seconds (2 minutes minimum). A full new calculation only happens when the first journey proposed leaves, as Transitous asks. |
| Departures in the summary | number | No | How many departures per direction the “next departures” text lists. |
| Language of the values | select | No | Language of the feature names and of the texts published. |
How to install TBM in Gladys
- In Gladys, open Integrations: TBM appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/daviddu26/gladys-tbm:0.1.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/daviddu26/gladys-tbm.
TBM requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
TBM is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by daviddu26, not by the Gladys core team.
