Starlink smart home integration, free and open source

Starlink integration for Gladys Assistant

Your Starlink dish in Gladys: state, latency, throughput, obstruction, alerts. Local, no account.

View on GitHubAll integrations

Your Starlink dish in Gladys: its state, latency, packet loss, throughput, obstruction, alerts and snow melt mode, read on your local network like the Starlink app does. Scene triggers tell when the connection drops and comes back, and a dashboard widget shows the dish at a glance.

Developed without the hardware: feedback welcome. The integration was written from the protocol published by the community and tested against recorded dish answers, not against a real dish. Please report what works and what does not on the Gladys forum or in the GitHub issues.

This integration is not affiliated with, endorsed by or supported by SpaceX or Starlink.

Overview​

  • One device per dish, named after its hardware (e.g. "Starlink rev3"), identified by the dish's own serial: it survives an address change.
  • Local only: the dish answers on 192.168.100.1:9200 (gRPC, the protocol of the Starlink app), without account, password or cloud.
  • Measures averaged over the refresh interval: latency, packet loss and throughput come from the second-by-second history of the dish, not from a single sample.
  • Self-refreshing: the integration reads the dish on its own timer; it does not depend on Gladys polling the device.
  • Safe by default: rebooting or stowing the dish cuts the Internet, so these commands stay refused until you allow them.

Prerequisites​

  • Gladys Assistant 5.1.0 or later (scene triggers, scene actions and widgets).
  • A Starlink dish (standard, Gen 2 "rectangular", Gen 3, Mini…) powered on.
  • Gladys must reach 192.168.100.1. The integration runs in its own container on a Docker bridge network: its traffic goes out through the Gladys host, so it reaches the dish exactly when the Gladys host does.
    • With the Starlink router, it works as is: the router forwards 192.168.100.1 to the dish.
    • With your own router and the Starlink router in bypass mode (or a Starlink Ethernet adapter plugged into your router), most routers reach the dish address directly. If not, add on your router a static route to 192.168.100.1/32 through its WAN (Internet) interface.
    • Check from the Gladys host: ping 192.168.100.1 must answer. The Test the connection to the dish button of the configuration confirms the integration sees it.

Configuration​

Open Integrations → Starlink → Configuration:

FieldDefaultRole
Dish address192.168.100.1IP address of the dish, optionally with the port (9200 by default).
Refresh interval30 seconds10, 15, 30 s or 1 min. The measures are averaged over this interval.
Language of the device textsFrançaisFeature names (set when the dish is added) and the state text.
Allow the commands that cut the InternetoffReboot, stow and deploy are refused until you enable it. The snow melt mode needs no opt-in.

Then open Integrations → Starlink → Discover and add the dish to Gladys. The buttons of the configuration screen:

  • test_connection — Test the connection to the dish: says what answered (hardware, software, state).
  • reboot_dish — Reboot the dish: the Internet comes back after a few minutes.
  • stow_dish — Stow the dish: it folds flat (before a storm, to move it). No Internet until deployed.
  • unstow_dish — Deploy the dish: it turns back to the sky and reconnects.

The dish device​

FeatureType (Gladys)Meaning
Starlink onlinebinary1 when the dish is connected to the satellites, 0 otherwise (and when unreachable).
StatetextConnected, Searching for satellites, Obstructed, Stowed, Sleeping, Unreachable…
Latencyduration (ms)Mean ping time to the Starlink network over the interval (seconds fully lost excluded).
Packet losspercentageShare of lost pings over the interval.
Download / Uploadrate (Mbit/s)Mean traffic going through the dish over the interval — what you use, not a speed test.
Obstructed skypercentageShare of the sky the dish found obstructed (trees, buildings).
Obstructed right nowbinary1 while something blocks the dish at the moment of the reading.
Uptimeduration (h)Time since the last reboot of the dish.
Power drawpower (W)Mean power consumption over the interval (dishes that report it).
Heating (snow melt)binary1 while the dish heats to melt snow.
Thermal throttlingbinary1 while the dish limits itself because it is too hot.
Overheating shutdownbinary1 when the dish stopped because of overheating.
Update pendingbinary1 when a software update waits for a reboot.
Snow melt modeselectionAutomatic, Always on, Off — can be changed from Gladys.
Software versiontextThe firmware of the dish.

Only the values that change are sent to Gladys; an unchanged value is sent again every 6 hours so the dashboard never says "no recent value".

Snow melt mode​

Automatic heats when the dish detects snow, Always on heats before a snowfall (more power), Off never heats (saves power, but snow may cut the connection). Choose it from the device or with the set_snow_melt_mode scene action.

Widget​

The dish_status widget (Starlink) shows the latency, the download and upload throughput, the obstructed sky, then the state (green when connected, orange during an outage, red when unreachable), the active alerts by name, the snow melt mode and the uptime. Once the dish is added to Gladys the tiles follow its features live. Its optional setting picks the dish.

Scene triggers​

  • connection_lost — Starlink connection lost: the dish has been offline for a whole refresh interval (two readings in a row), or stopped answering at all (cause unreachable: power cut, cable). Short drops are ignored. Filter on the Cause (obstructed, searching, stowed, sleeping, unreachable…). Variables: the cause code and the state text.
  • connection_restored — Starlink connection restored: the dish is back after a reported loss. Variables: the outage duration in seconds and the cause.
  • obstruction_detected — Starlink sky obstructed: something started blocking the dish, at most once every 10 minutes. Variable: the obstructed share of the sky (%).

An outage already under way when Gladys starts is not reported (Gladys cannot tell when it started).

Scene actions​

  • reboot_dish — Reboot the Starlink dish.
  • stow_dish — Stow the Starlink dish.
  • unstow_dish — Deploy the Starlink dish.
  • set_snow_melt_mode — Set the Starlink snow melt mode (automatic, always on, off).

The first three cut the Internet: they fail (and the scene logs it) until Allow the commands that cut the Internet is enabled. Keep in mind that Gladys Plus, remote access and cloud notifications go through that same Internet access.

Scene examples​

  • Warn when Starlink drops: trigger connection_lost with the cause "Dish not answering (power, cable)" → send a message on a local channel (or a notification later, when the connection is back).
  • Log the outages: trigger connection_restored → send the message "Starlink back after outage_seconds s".
  • Snow is forecast: weather condition "snow" in the evening → set_snow_melt_mode "Always on"; the next morning → "Automatic".
  • Watchdog: trigger connection_lost, cause "No network answer" → wait 10 minutes → reboot_dish (with the commands allowed).

Troubleshooting​

  • "The dish does not answer": from the Gladys host, ping 192.168.100.1. No answer: see the prerequisites (bypass mode, static route). An answer but still failing: check the address and the port (9200) in the configuration.
  • No device in Discover: the dish must have answered once; use Test the connection to the dish.
  • Values never change: check that the dish was added to Gladys; then look at the logs with LOG_LEVEL=debug (each reading is logged at debug level).
  • Power draw stays empty: some dishes or firmware do not report it.
  • Feature names in the wrong language: they are fixed when the dish is added; change the language, then delete and re-add the device (its history is lost).

Limits​

  • The dish API is unofficial: SpaceX can change it with a firmware update. The integration ignores what it does not know and keeps working with what it still finds.
  • One dish per installation (the address of the configuration). The Starlink Wi-Fi router is not read.
  • Download and upload are the traffic going through the dish, not the capacity of the link.
  • No obstruction map, no GPS position, no sleep schedule (the Starlink app does it).
  • The fastest refresh interval is 10 seconds: an outage shorter than one interval may not show.
  • Two small requests per interval (status ≈ 1 KB, history ≈ 25 KB), on the local network only: no quota, no Internet traffic.

Configuration settings​

These are the settings Starlink asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Starlink dishsectionNoThe integration reads the dish on your network, like the Starlink app does: no account, no cloud. Gladys must reach the dish address (192.168.100.1 by default): with the Starlink router it works as is; with your own router in bypass mode, see the documentation.
Dish addressstringNoIP address of the dish, optionally followed by the port (9200 by default). Leave 192.168.100.1 unless you changed the network.
Refresh intervalselectNoHow often the dish is read. Latency, packet loss and throughput are averaged over this interval.
Language of the device textsselectNoFeature names (set when the dish is added to Gladys) and the state text.
Commands that cut the InternetsectionNoRebooting or stowing the dish cuts the Internet access for minutes, Gladys Plus and remote access included. They stay refused until you allow them here.
Allow the commands that cut the InternetbooleanNo
  1. In Gladys, open Integrations: Starlink appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-starlink:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-starlink.

Starlink requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Starlink is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
