Spoolman smart home integration, free and open source
Your 3D printing filament spools from Spoolman: remaining weight, low stock, usage.
Published by guim31
- Devices
- Version 1.0.0
- Requires Gladys >=5.2.0
- ★ 0
Follow your 3D printing filament spools in Gladys through Spoolman, the self-hosted filament inventory: remaining weight and length of each spool, the stock of each material, what a print used, and a consumption you record yourself. Everything stays on your local network: Gladys talks directly to Spoolman.
Spoolman updates Gladys live: as soon as Klipper (Moonraker), OctoPrint or the Spoolman web page changes a spool, its values move in Gladys.
Tested against a real Spoolman 0.27.0 (its official Docker image). Feedback welcome on the Gladys forum.
Prerequisites
- Gladys Assistant 5.2 or later (the widget form needs it).
- A Spoolman server reachable from the Gladys machine, on port 7912 by default, or through a reverse proxy.
- To follow prints automatically: a printer that reports its consumption to
Spoolman, such as Klipper with the
[spoolman]section of Moonraker, or OctoPrint with its Spoolman plugin. Otherwise, record the consumption with the scene action or the widget.
Configuration
- Open the Configuration tab of the integration.
- In Spoolman address, enter the IP address of the server, for example
192.168.1.50: the integration then uses port 7912. Add a port if yours differs (192.168.1.50:8000). Behind a reverse proxy, enter the full address, sub-path included (https://example.org/spoolman). - Spoolman has no login of its own. If your proxy asks for credentials, fill
in Proxy user name and Proxy password (HTTP Basic), or an Extra
HTTP header written
Name: value(a token). - One stock device per material (on by default) adds a device per material (PLA, PETG...) with its total remaining weight.
- Language of names and messages sets the feature names (fixed when the device is added) and the texts. French by default.
- Save, then use Test the connection: it shows the Spoolman version, the number of spools in use and the state of the live updates.
- In the Discovery tab, add the spools and stocks you want to follow.
Devices
A spool (one per spool in use, named after its vendor, filament and
material, with its Spoolman number: Prusament Galaxy Black PLA #1):
| Feature | Value |
|---|---|
| Remaining weight (g) | grams of filament left |
| Remaining | percentage left, of the initial weight |
| Used weight (g) | grams used since the spool was registered |
| Remaining length | metres of filament left |
| Last used | date and time of the last consumption, or "Never" |
| Status | "In use", "Archived" or "Deleted in Spoolman" |
The location, colour and number of the spool are in the device parameters. A spool whose filament has no weight in Spoolman publishes no remaining weight nor percentage: fill in the filament weight in Spoolman.
A stock (Stock PLA): the total remaining weight (g) and the number of
spools in use of a material.
An archived spool leaves the Discovery tab; once added to Gladys, its device stays and shows "Archived". Delete it in Gladys when you no longer need its history.
Dashboard widget
Filament spools: three tiles (total stock in kg, number of spools, number of low spools), the list of the spools that run out first with their remaining weight, location and percentage (green, orange under the threshold, red under half of it), and a Log usage button: it opens a form (spool, amount, grams or metres) and records the consumption in Spoolman.
Settings: a material (PLA) and a Spoolman location to filter the list, and
the percentage under which a spool counts as low (20 % by default).
Scene triggers
- Filament used: a spool lost weight in Spoolman (a print reported by the printer), once the consumption has stopped for 2 minutes, so a whole print gives one event. Optional filter: the spool. Variables: spool name, material, location, grams used, grams left, percentage left. A consumption recorded by the integration itself (scene action, widget) does not fire it.
- Spool archived: a spool was archived in Spoolman (usually: it is empty). Optional filter: the spool. Variables: spool name, material, location.
A threshold ("less than 100 g") needs no special trigger: use the standard Device state change trigger on the remaining weight or percentage of a spool, or on the remaining weight of a stock.
Scene actions
Record a filament use: subtracts an amount (in grams or metres) from a spool in Spoolman, for a printer that does not report it (for instance at the end of a print announced by another integration). Outputs: grams left, percentage left.
Scene examples
- Order filament before it runs out: trigger "Device state change", the
remaining weight of
Stock PETGbelow 500 → send a message "Less than 500 g of PETG left". - Spool almost empty: trigger "Device state change", the remaining weight of a spool below 100 → message "Spool almost empty: order a new one".
- Print report: trigger Filament used → a message built with its variables: grams used, spool name, grams left.
- A printer without Spoolman support: trigger "print finished" of its integration → action Record a filament use on the loaded spool.
Troubleshooting
- "Spoolman does not answer": check the address and the port (7912 with the official Docker image, 8000 inside the container), and that the Gladys machine reaches it.
- "Access refused (401)" or "(403)": your proxy refuses the credentials or the header. Spoolman itself answers 403 only to a request coming from another website (a browser): the integration sends none.
- "Does not answer like Spoolman": the address leads to a login page or another service. With a sub-path, enter it in full.
- A spool has no remaining weight: its filament has no weight in Spoolman.
- More details in the logs of the integration (
LOG_LEVEL=debugfor every update).
Limits
- One Spoolman server.
- Gladys has no gram unit: the weights carry "(g)" in their names.
- The room of a device cannot be set by an integration: assign it in Gladys. The Spoolman location is in the device parameters and filters the widget.
- Spoolman reuses the number of the last spool when it is deleted (SQLite): a new spool may then take over its Gladys device.
- The live updates need the WebSocket to go through your proxy; otherwise the integration reads Spoolman every 5 minutes.
- A filament or vendor change reloads the whole list (Spoolman sends no spool update for it).
Configuration settings
These are the settings Spoolman asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Connect Spoolman | section | No | Enter the address of your Spoolman server: its IP address (port 7912 by default) or the full address behind a reverse proxy, sub-path included. Spoolman has no login of its own: fill in the proxy credentials only if your proxy asks for them. |
| Spoolman address | string | Yes | |
| Proxy user name (optional) | string | No | |
| Proxy password (optional) | secret | No | Sent as HTTP Basic authentication, with the user name above. |
| Extra HTTP header (optional) | secret | No | For a proxy that expects a token, written "Name: value", e.g. "X-Api-Key: abc123". |
| One stock device per material | boolean | No | Total remaining weight and number of spools of each material (PLA, PETG...). |
| Language of names and messages | select | No | Feature names are set when a device is added to Gladys. |
How to install Spoolman in Gladys
- In Gladys, open Integrations: Spoolman appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-spoolman:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-spoolman.
Spoolman requires Gladys >=5.2.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
Spoolman is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
- Browse all integrations, native and community
- Build and publish your own external integration
- Source code on GitHub — source of this documentation
