SolaX Power smart home integration, free and open source
SolaX inverters over the local Wi-Fi dongle: solar production, grid, battery, energy counters.
Published by guim31
- Devices
- Version 1.0.2
- Requires Gladys >=5.1.0
- ★ 0
Overview
This integration reads your SolaX inverters (X1, X3, X-Hybrid, Boost, Mini, Smart, Hybrid G3/G4, Ultra, MIC PRO, Lite LV, and the Qcells Q.VOLT rebrand) on your local network, through the inverter's Wi-Fi or LAN dongle (Pocket WiFi). Each inverter becomes one Gladys device with its solar production, its energy counters, the grid exchange, the battery of the hybrids and the inverter state. SolaX Cloud is an option for the dongles that do not answer locally.
It is read only: the integration never sends anything to the inverter but a request for its realtime data.
Developed without the hardware: feedback welcome. The decoding follows the real answers published with the
solaxlibrary used by Home Assistant, but it was never run against a real inverter. Report what you see on the Gladys forum or in the GitHub issues.
This integration is not affiliated with SolaX Power.
Requirements
- Gladys Assistant 5.1.0 or later (5.2 for the energy tracking of the production index).
- A SolaX inverter with its Pocket WiFi (V2 or V3) or Pocket LAN dongle, connected to the same network as Gladys. Give the dongle a fixed IP address in your router.
- The dongle's registration number (10 characters, printed on the dongle, also shown in the SolaX Cloud app): recent firmwares use it as the password of the local interface.
- For SolaX Cloud only: an account on solaxcloud.com and its API token (Service → API on the new site, Support → Third-party ecology on the old one).
Configuration
Open Integrations → SolaX Power → Configuration:
| Field | What to enter |
|---|---|
| Dongle IP addresses | One address per inverter, separated by commas (192.0.2.10, 192.0.2.11). A port can be given (192.0.2.10:8080). |
| Dongle passwords | The registration number of each dongle, in the same order. One value applies to every dongle. Empty for the old firmwares. |
| Inverter model | Automatic (recommended): the model is detected from the dongle's answer. Force it only if the readings look wrong. |
| Local refresh | Every 10, 15, 30 (default) or 60 seconds. |
| SolaX Cloud API token | Only for the cloud option. |
| Registration numbers | The registration number of each dongle to read through SolaX Cloud, separated by commas. |
| Cloud refresh | Every 5 (default), 10, 15 or 30 minutes. |
| Language of the texts | Feature names (frozen when the device is added), inverter state, scene texts. French by default. |
Then click Test the connection: for each inverter, it tells the model found, or what went wrong. The inverters found appear in the Discovery tab: add them to Gladys.
SolaX Cloud quota. SolaX allows 10 calls per minute and 10,000 per day per token, and the dongle uploads its data every 5 minutes. The integration therefore reads each cloud inverter every 5 minutes at most, spaces its calls by 6.5 seconds (never more than 10 a minute, whatever the number of inverters), and stretches the period when the inverters would exceed 9,000 calls a day. An inverter configured both locally and in the cloud is read locally only.
What each device shows
One device per inverter, named SolaX <model> <end of the serial number>. The features depend
on what the model reports; a feature never disappears once shown.
| Feature | Gladys type | Notes |
|---|---|---|
| PV power | production power (W) | Sum of the strings. |
| PV string 1, 2, 3 power | production power (W) | When the inverter has several strings. |
| Production today | daily production (kWh) | Reset by the inverter at midnight. |
| Total production | production index (kWh) | The cumulative counter of the energy tracking. Never published lower. |
| AC output power | power (W) | Negative on a hybrid charging its battery from the grid. |
| Grid (import +, export −) | grid power (W) | Needs the SolaX meter (CT). Positive when importing. |
| Grid import index, grid export index | grid indexes (kWh) | The meter's counters. |
| Battery level | battery level (%) | Hybrids. |
| Battery charge power, discharge power | battery storage (W) | One of them is 0 at any time. |
| Battery temperature | device temperature (°C) | When reported. |
| Battery charge index, discharge index | battery storage indexes (kWh) | When reported. |
| Inverter temperature | device temperature (°C) | When reported. |
| Inverter state | text | Normal, Waiting, Fault, Backup (EPS), Standby... When reported. |
| Online | binary | 0 when the dongle does not answer (at night for most inverters). |
The device badge shows local, cloud or unreachable. Values are only sent to Gladys when they change, and at least every 6 hours when they do not.
Widget
Solar overview (dashboard → add a widget → SolaX Power): the PV power, today's production, the grid exchange and the battery as live tiles, the 24-hour curve of production and grid, and a short list: exporting or importing, charging or discharging, inverter state, time of the last reading. Choose the inverter in the widget settings (not needed when there is only one).
Scene trigger
Inverter state changed: fires when the inverter goes to another state (for example from
Normal to Fault, or to Backup (EPS) during a power cut). Filters: the inverter, and the new
states that interest you. Variables: status (code: normal, fault, eps...),
previous_status, status_label (the state in the language of the configuration). Only the
models that report a state can fire it (X3 Hybrid G4, X3 Ultra, X3 MIC PRO G2, and every
inverter read through SolaX Cloud).
Scene action
Get the solar summary: returns the last reading of an inverter without asking the dongle
again: summary (a sentence such as "Solar: 3.1 kW now, 12.4 kWh today. Grid: exporting 830 W.
Battery: 86 %."), online, pv_power, yield_today, grid_power, battery_level.
Scene examples
- Evening report: every day at 21:00 → Get the solar summary → send a message with
{{summary}}. - Inverter fault: Inverter state changed, new state Fault or Permanent fault → send a notification "The inverter is in fault: {{status_label}}".
- Use the surplus: when Grid (import +, export −) goes below −1500 W → switch on the water heater plug; switch it off when it goes above 0 W.
- Power cut: Inverter state changed, new state Backup (EPS) → turn off the non-essential appliances and warn the household.
Supported models
Detected from the type the dongle reports: X-Hybrid (first generation), X1/X3 G3 (Hybrid, Fit,
MIC, Air, Boost, Mini), X1-Boost/Mini (types 4, 18, 22), X1-Smart, X1-Hybrid G4, X3-Hybrid G3 on
firmware 2.034, X3-Hybrid G4 and Q.VOLT HYB-G3-3P, X3-MIC PRO G2, X3-Ultra, X1-Lite LV. The X3-EVC
charging station is not an inverter and is refused.
Troubleshooting
- "No answer": check the address, that Gladys and the dongle are on the same network, and that the dongle is powered: most inverters switch the dongle off at night, the device then shows Offline until morning.
- "Refused: check the password": enter the registration number of the dongle (not the serial number of the inverter).
- "Model not recognized": open an issue with the output of
node scripts/probe.mjs <address> [registration number](read only; the registration number is masked in the output). - Wrong values: force the model in the configuration, and report it.
- Firmware 2.034 and later: some dongles refuse the local network. The integration sends the header these firmwares expect; if it still fails, use SolaX Cloud.
- More details in the logs: set
LOG_LEVEL=debugon the integration.
Limits
- Read only: no setting of the inverter (work mode, charge, export limit) is changed, on purpose.
- Some dongles do not answer locally at all: use SolaX Cloud, refreshed every 5 minutes at best.
- The grid values need the SolaX meter; without it they stay at 0.
- The thirty-minute production of the Gladys energy dashboard is derived by the core from the production index; Gladys 5.2.1 does not link it automatically for external integrations yet.
- The meaning of some registers comes from the community, not from SolaX: a model not seen in the samples may read some values wrong.
Configuration settings
These are the settings SolaX Power asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Local connection | section | No | Gladys reads the inverter through its SolaX Wi-Fi or LAN dongle (Pocket WiFi), on the local network. Give the dongle a fixed IP address in your router. Read only: nothing is ever changed on the inverter. |
| Dongle IP addresses | string | No | One address per inverter, separated by commas. |
| Dongle passwords | secret | No | The registration number printed on each dongle (10 characters), in the same order as the addresses. Leave empty for the old firmwares. |
| Inverter model | select | No | Detected automatically. Force it only if the readings look wrong. |
| Local refresh | select | No | |
| SolaX Cloud (optional) | section | No | Only for the dongles that do not answer locally. The API token is under Service, API on solaxcloud.com. SolaX allows 10 calls a minute and 10,000 a day, and the dongle uploads every 5 minutes: readings are 5 minutes apart at best. |
| SolaX Cloud API token | secret | No | |
| Registration numbers | string | No | The registration number of each dongle to read through SolaX Cloud, separated by commas. |
| Cloud refresh | select | No | |
| Display | section | No | |
| Language of the texts | select | No | Feature names (set when the device is added), inverter state and scene texts. |
How to install SolaX Power in Gladys
- In Gladys, open Integrations: SolaX Power appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-solax:1.0.2), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-solax.
SolaX Power requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
