Solarman (Deye, Sofar, Solis) smart home integration, free and open source
Deye, Sofar or Solis inverter with a Solarman Wi-Fi logger, read locally: solar, battery, grid.
Published by guim31
- Devices
- Version 1.0.0
- Requires Gladys >=5.1.0
- ★ 0
Read a solar inverter fitted with a Solarman Wi-Fi logger (the "LSW-3" stick sold with Deye, Sunsynk, Sol-Ark, Sofar, Solis and many other inverters) in Gladys, over your local network: solar production per PV input, house consumption, grid import and export, battery level and power, energies of the day and meter indexes for the energy tab of Gladys, with a dashboard widget, five scene triggers and a scene action. No account and no cloud: Gladys talks to the logger directly with the Solarman V5 protocol (TCP port 8899), the one the Solarman app uses. Read only: nothing is ever written to the inverter.
Developed without the hardware: feedback welcome. This integration was built against the published register maps of these inverters, a real exchange with a Deye logger and a simulated logger, not against a real inverter. If something does not work as described, please say so on the Gladys forum or in the issues.
What you need
- Gladys Assistant 5.1.0 or later.
- An inverter with a Solarman Wi-Fi logger whose serial number starts with
17, 21, 23, 27 or 40 (10 digits, on the logger label), connected to the
same network as Gladys. Supported models:
- Deye hybrid, single-phase (SUN-…K-SG0xLP1, and the Sunsynk and Sol-Ark built on it);
- Deye hybrid, three-phase, low-voltage battery (SG04LP3) or high-voltage battery (SG01HP3);
- Deye microinverter (SUN-M, SUN600/800/2000G3…);
- Sofar G3 (KTLX-G3 three-phase, without battery);
- Solis single-phase (1P…-5G, without battery).
- A fixed IP address for the logger (a DHCP reservation in your router).
Set up
- In Gladys, go to Integrations → Install from GitHub and enter
https://github.com/guim31/gladys-solarman. - In the configuration of the integration, fill in:
- Logger IP address;
- Logger serial number: the 10 digits on the logger label, not the serial number of the inverter;
- Inverter model;
- PV inputs used: the number of panel strings wired to the inverter (one production per input);
- optionally the Reading interval (s) (30 s by default, 15 s minimum), the Export threshold (W) of the export triggers, the Modbus address (1 in almost every case), the Logger TCP port (8899) and the Language of the feature names.
- Run Test the connection in the Configuration tab: it reads the inverter once and answers with what it sees, or with the reason of the failure.
- Open the Discovery tab and add the inverter. Its values arrive right away, then at every reading.
The Gladys device
One device per inverter, named after its brand (for example "Solar inverter Deye"). The features depend on the model: a model without battery has no battery feature, a microinverter has no grid nor house feature.
| Feature | Unit | What it is |
|---|---|---|
| Solar production | W | production of the panels, all inputs together |
| PV1 production, PV2… | W | production of each PV input (when there is more than one) |
| Production today | kWh | energy produced since midnight |
| Total production | kWh | production index of the inverter (energy tab of Gladys) |
| Grid power | W | positive when importing, negative when exporting |
| Grid import today | kWh | energy bought from the grid since midnight |
| Grid export today | kWh | energy sent to the grid since midnight |
| Grid import index | kWh | grid import meter: Gladys turns it into consumption and cost |
| Grid export index | kWh | grid export meter |
| House consumption | W | power used by the house |
| House consumption today | kWh | energy used by the house since midnight |
| Battery level | % | state of charge |
| Battery charge | W | power going into the battery |
| Battery discharge | W | power coming out of the battery |
| Battery charge index | kWh | energy charged since the installation |
| Battery discharge index | kWh | energy discharged since the installation |
| Battery temperature | °C | |
| Inverter temperature | °C | |
| Inverter state | text | Standby, Starting, Normal, Alarm, Fault, or Not answering |
Energy tab. Only the Grid import index is counted by Gladys as consumption (with its cost): it is what your supplier bills. The house consumption is not, since the energy produced by your panels and used at home is free; the production index feeds the production of Gladys. If the house is also read by a smart meter (Linky…), keep that meter as the main one.
At night. The logger of an inverter without battery is powered by the panels: it goes off at night. After three readings without answer, the state becomes "Not answering", the solar production falls to 0 W and the other values stay as they were; everything comes back on its own in the morning. The integration is also shown as disconnected meanwhile.
Dashboard widget
Solar shows at a glance:
- Solar: the production of the panels;
- House: the consumption of the house;
- Grid import or Grid export: the grid exchange, with its direction;
- Battery: the battery level, and Charging or Discharging with the battery power;
- Today: the production of the day;
- the state of the inverter and the time of the last reading.
Add it from the dashboard editor ("Integration widget" box). Before the inverter is added in Gladys, the widget says so.
Scenes
Triggers
- Battery full: the battery reaches 100 % (once; it fires again after dropping to 95 %). Variable: the battery level.
- Battery drops to…: the battery level goes down to the chosen threshold (10 to 50 %) or below. It fires again once the level went 5 points above the threshold. Variable: the battery level.
- Inverter fault: the inverter goes into alarm or fault (choose one or leave empty for both). Variables: the state and its code.
- Grid export started: the house starts sending more than the Export threshold (W) of the configuration to the grid. Variable: the exported power.
- Grid export stopped: the export falls below half of that threshold. Variable: the exported power (negative when importing).
Nothing fires on the first reading after a start: a battery already low is a state, not an event. To react to a level ("production above 2 kW"), use the features of the device in a "Device state" trigger.
Actions
- Read the inverter status: reads the inverter and gives the following actions a Status sentence to send ("Solar 2,340 W, house 1,200 W, battery 85 % (charging 800 W), grid export 340 W; 12.4 kWh produced today; state Normal."), and the solar production, house consumption, grid power, battery level and production of the day as numbers. The sentence is written in the language of the configuration.
Scene ideas
- Use the surplus: when Grid export started, turn on the water heater or the pool pump; when Grid export stopped, turn it off.
- Save the battery: when the Battery drops to… 20 %, send a message and turn off the heaters that can wait.
- Evening report: every day at 9 pm, Read the inverter status and send the status sentence to your phone.
- Watch the inverter: when there is an Inverter fault, send a message with the state.
Troubleshooting
- Test the connection says "cannot connect": check the IP address of the logger and that Gladys is on the same network. The logger must answer on port 8899 (some new "LSE" loggers do not offer it).
- "The logger does not answer": the serial number is wrong (the logger stays silent), or the logger is off (night, inverter without battery).
- "The logger answers, but not the inverter": check the Modbus address (1 by default) and the cable between the logger and the inverter.
- "The inverter refuses the registers read": the chosen model does not match the inverter.
- Values that look wrong (a power 10 times too small, a reversed sign): check the model, especially low or high voltage battery for the Deye three-phase hybrids, and tell us on the forum with a screenshot of the Solarman app.
- More details in the logs of the integration, with
LOG_LEVEL=debug.
Limits
- Read only: no setting of the inverter can be changed (work mode, battery charge, export limit), by choice, for the safety of the battery and the grid.
- One inverter per installation of the integration.
- The logger serves few clients at once: Gladys keeps one connection and reads at most every 15 seconds. Another local tool reading the same logger at the same time may get errors.
- The Solarman cloud is not used and keeps working as before.
- The house consumption total has no meter index in Gladys (only today's value), so that it is never counted a second time in the energy tab.
- Other models (Deye string inverters, Sofar hybrids, Solis hybrids, Afore, KStar, Megarevo…) are not supported yet: ask on the forum.
Register maps after ha-solarman (MIT) and the V5 protocol after pysolarmanv5 (MIT). Not affiliated with Solarman, Deye, Sofar or Solis.
Configuration settings
These are the settings Solarman (Deye, Sofar, Solis) asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Solarman logger | section | No | The inverter is read through its Solarman Wi-Fi logger (LSW-3 stick), on the local network, port 8899. The logger serial number is the 10-digit number on its label (17…, 21…, 23…, 27…, 40…). Read only: nothing is ever written to the inverter. |
| Logger IP address | string | Yes | Give the logger a fixed address in your router. |
| Logger serial number | string | Yes | 10 digits, on the logger label (not the inverter serial). |
| Inverter model | select | Yes | |
| PV inputs used | number | No | Number of panel strings wired to the inverter (one production per input, 1 to 4). |
| Reading interval (s) | number | No | 15 seconds minimum: the logger also sends its data to the Solarman cloud. |
| Export threshold (W) | number | No | Power sent to the grid from which the "Grid export started" trigger fires. |
| Modbus address | number | No | Address of the inverter behind the logger: 1 in almost every case. |
| Logger TCP port | number | No | |
| Language of the feature names | select | No | Used for the names of the inverter features (when it is added) and for the messages of the actions. |
How to install Solarman (Deye, Sofar, Solis) in Gladys
- In Gladys, open Integrations: Solarman (Deye, Sofar, Solis) appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-solarman:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-solarman.
Solarman (Deye, Sofar, Solis) requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
