Snapcast smart home integration, free and open source

Snapcast integration for Gladys Assistant

Multiroom audio with Snapcast: volume and mute per room, streams, groups, scenes.

View on GitHubAll integrations

Snapcast plays the same audio in sync in every room: a snapserver receives the streams (Spotify through librespot, AirPlay, MPD, a radio, a pipe...) and sends them to snapclients, one per room. This integration brings the server into Gladys: the volume and mute of each room, which stream each room plays, the groups of rooms, and scenes when a speaker goes offline or a stream starts.

It does not play music itself: the music comes from the sources of your Snapcast server (MPD, Spotify...). Tested against snapserver and snapclient 0.31 in Docker, without speakers: feedback welcome.

Requirements​

  • A Snapcast server (snapserver 0.26 or later; 0.31 tested) that Gladys can reach on the local network.
  • Its JSON-RPC control port over TCP, 1705 by default, enabled (it is, unless the [tcp] section of snapserver.conf says enabled = false).
  • Gladys 5.3 or later (Music player; version 1.0 of the integration stays for Gladys 5.1 and 5.2).

Configuration​

  1. In Gladys, open Integrations, find Snapcast and install it.
  2. Server address: the IP address or host name of the machine that runs snapserver, for example 192.168.1.20. Add :port, or fill in Control port, if it is not 1705 (not the HTTP port 1780 of Snapweb).
  3. Language: the language of the feature names and of the texts the integration creates. Feature names are set when a device is added: choose it before adding the devices.
  4. Save. The integration connects, then shows each client and each stream in the Discovery tab of the integration: add the ones you want.

The integration keeps one connection open to the server and follows every change live: a volume changed in Snapweb or another app shows up in Gladys at once. It reads the whole state again every minute and after each reconnection.

Devices​

Clients (rooms)​

Each snapclient is a device, named after the name you gave it in Snapweb (or else its host name).

FeatureWhat it does
Volume0 to 100, in both directions
MuteOn = sound off, in both directions (the mute of the Music player)
ConnectedWhether the snapclient is connected to the server
StreamThe stream the room plays; choosing another one switches its whole group
Playback statePlaying (1), paused (0) or stopped (2), from the stream of the room; commands work when the stream has a control script
Now playingArtist and title when the stream reports them, else the stream name and state
Play, PauseAct on the stream of the room, when a control script drives it (see Streams)
Previous, NextSame
Title, Artist, Album, ArtworkWhat the stream of the room plays (see Music player)
Duration, PositionOf the current track; the position can be set when the stream can seek
Shuffle, RepeatWhen a stream of the server reports them; act on the stream of the room

A client is a player for the Gladys Music box: add the box to a dashboard and choose the room (see Gladys 5.3 Music player).

Streams​

Each stream of the server is a device too: its playback state (1 playing, 0 paused, 2 stopped) and what it plays (now playing). A stream driven by a control script (librespot, MPD through meta_mpd.py, AirPlay, Plexamp... see the Snapcast documentation) also has Play, Pause, Previous and Next buttons. A plain pipe has no buttons: Snapcast cannot pause what it does not control.

There is no device per group: Snapcast deletes a group when it is emptied and gives a new one a new identity, which would leave orphan devices in Gladys. Groups are handled through their clients (stream choice, actions below).

Gladys 5.3 Music player​

Since Gladys 5.3, the dashboard Music box is a real player. Choose a room (a client): it shows what the stream of its group plays (artwork, title, artist, album, progress bar), with play / pause, previous / next, shuffle, repeat, and the volume and mute of the room.

  • Title, artist, album, duration, position and artwork come from the control script of the stream (librespot, Mopidy through meta_mopidy.py, MPD through meta_mpd.py, AirPlay...). A plain pipe reports none: the box shows the stream name as the title, live, without a progress bar.
  • Playback, position, shuffle and repeat commands act on the stream the room plays, so on every room of its group; volume and mute stay those of the room.
  • What can be controlled depends on your streams: play, pause and stop when the stream of the room has a control script, the position when it can seek; shuffle and repeat appear as soon as a stream of the server reports them. A command the stream of the room cannot carry out is refused with a message.
  • The artwork is the address given by the script, or the image sent within the stream (AirPlay). A heavy image is made smaller; the SVG logo librespot sends is not shown (a format Gladys refuses).
  • No library, search or queue: Snapcast has none. Pick the music in the app of your source.

Devices already added: in the Discovery tab of the integration, click Update for each room and each stream. The room gets the new features, and its Mute becomes the mute of the Music player (same feature: scenes that set or watch it keep working; a scene that toggled it with the "turn on / off a switch" action must be redone with "control a device"). The offer comes back when a stream reports shuffle or repeat. The playback state is now 2 when nothing plays, instead of 0: a scene on "playback state = 0" now only runs on a pause. Now playing stays available.

Dashboard widget​

Snapcast rooms:

  • without a room chosen: every client with what it plays and its volume (or "Muted", "Offline"), and a Mute all / Unmute all button;
  • with a room chosen: its state and volume, the buttons Volume −, Volume +, Mute / Unmute, and Play / Pause when its stream can be controlled, else Next stream.

Scene triggers​

TriggerWhenVariables
Client disconnectedA snapclient leaves the server (speaker off, network lost)client name
Client connectedA snapclient joins the server againclient name
Stream startedAudio starts flowing on a stream (someone casts to Spotify…)stream, title, artist
Stream stoppedA stream stops playing (paused, no more audio)stream, title, artist

Each trigger can be limited to one client or one stream. Nothing fires for what happens while the server itself is unreachable.

Scene actions​

ActionWhat it does
Set the volume of a roomVolume of a client, 0 to 100
Mute or unmute every roomEvery client of the server; returns how many changed
Play another stream in a roomThe client's group switches to the chosen stream
Control a streamPlay, pause, play/pause, next, previous, on a stream or on what a room hears
Group two roomsThe first client joins the group of the second, in sync
Ungroup a roomThe client gets a group of its own, same stream

The volume, the mute and the stream of a room can also be set with the standard "Set device value" action of Gladys.

Scene examples​

  • Quiet night: at 11 pm, "Mute or unmute every room" → Mute. At 7 am, Unmute.
  • Morning radio: at 7 am on weekdays, "Play another stream in a room" → Kitchen, stream Radio, then "Set the volume of a room" → Kitchen, 30.
  • Music follows you: when "Stream started" on Spotify, "Group two rooms" → Living room joins Kitchen.
  • Speaker unplugged: when "Client disconnected" on Bathroom, send a message.

Troubleshooting​

  • "The Snapcast server does not answer": check the address, that snapserver runs, and that the port is the TCP control port (1705 by default), not the stream port 1704 nor the HTTP port 1780. A firewall must let Gladys reach it.
  • A room shows "Offline": its snapclient is not connected to the server (machine off, wrong server address on the client).
  • "This stream cannot be controlled": the stream has no control script. Use a source that reports its player (librespot, MPD with meta_mpd.py…) or control the player itself.
  • A stream shows "Idle" while its player says playing: no audio reaches snapserver; Snapcast reports what it receives.
  • More detail: set the LOG_LEVEL of the integration to debug.

Limits​

  • One Snapcast server per integration.
  • No authentication: snapserver's control port has none by default. A server that requires one (optional in recent versions) is not supported.
  • No device per group (see Streams); the latency of a client and the names are changed in Snapweb.
  • A room device gains shuffle and repeat when a stream of the server reports them (see Music player): Gladys then offers to Update it.
  • The structure of a stream device depends on its control script: if a stream becomes controllable later, Gladys offers to Update it in the Discovery tab.
  • Tested against snapserver and snapclient 0.31 in Docker, with a pipe stream and a scripted player, without speakers. Feedback welcome on the forum.

Configuration settings​

These are the settings Snapcast asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Connect your Snapcast serversectionNoType the address of the machine that runs snapserver. The integration uses its JSON-RPC control port (TCP 1705, on by default) and follows every change live. Each snapclient becomes a device (a room), each stream too.
Server addressstringYesIP address or host name of snapserver. Add :port if its control port is not 1705.
Control portnumberNoTCP port of the JSON-RPC control (tcp section of snapserver.conf). Not the HTTP port 1780.
OptionssectionNoLanguage of the names and texts the integration creates (feature names are set when a device is added).
LanguageselectNo

How to install Snapcast in Gladys​

  1. In Gladys, open Integrations: Snapcast appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-snapcast:1.1.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-snapcast.

Snapcast requires Gladys >=5.3.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Snapcast is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
