Sigenergy smart home integration, free and open source
Sigenergy SigenStor over local Modbus TCP: solar, home, grid, battery and energy tracking.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.1.0
- ★ 0
Reads a Sigenergy system — SigenStor, Sigen Hybrid, their batteries — on the local network, in Modbus TCP, with the registers Sigenergy publishes in its "Sigenergy Modbus Protocol" (V2.9). No cloud, no account, nothing to declare register by register: solar, home, grid and battery appear in Gladys as devices, with the cumulative indexes of energy tracking.
Developed without the hardware: feedback welcome. The integration follows the official protocol document and is tested against a simulated Sigenergy system built from it, not against a real one. Please report what works and what does not in the issues, with the result of the Test the connection button.
This integration is not affiliated with Sigenergy Technology Co., Ltd. Sigenergy, SigenStor and mySigen are trademarks of their owners.
What it does
- One device for the system (the "plant" of the protocol): solar power, home consumption, grid exchange (import and export), battery level, charge and discharge power, energy available, battery health, the cumulative indexes (solar production, home consumption, grid import and export, battery charged and discharged), the operating mode, the state, off-grid operation and the alarms.
- One device per inverter: its power, solar power, battery, phase voltages and currents, the voltage and current of each PV string, its temperatures, its state and its alarms.
- Battery control, off by default: battery mode (automatic, forced charge or discharge, standby) and charge and discharge power limits.
- A dashboard widget: solar, home, grid and battery at a glance.
- Scene triggers (a new alarm, the system stops or starts answering) and scene actions (set the battery mode, set the limits).
Requirements
- Gladys Assistant 5.1 or later (5.2 for energy tracking).
- A Sigenergy system on the same network as Gladys, with a fixed IP address (a DHCP reservation in your router).
- Modbus TCP enabled on the system (see below). The integration speaks plain Modbus TCP on port 502; Modbus over RS-485 is not supported.
Enable Modbus TCP
Modbus TCP is off on a new system. In the mySigen app, open your system, then its settings, and look for the Modbus TCP server option (under the communication settings); turn it on and save. On many accounts this menu is only shown to the installer: ask yours to enable it. The menu names depend on the version of the app.
Find the unit ids
Each device of a Sigenergy system has a Modbus address, its unit id, set in the mySigen app:
- the plant (the whole system) always answers at 247;
- each inverter has its own, from 1 to 246: 1 on most single-inverter systems. An AC charger usually takes 1, and the inverter then has another one (2, for example).
Not sure? Enter the address of the system, save, and press Test the connection: when no configured inverter answers, it looks for them at unit ids 1 to 16.
Configuration
| Field | Description |
|---|---|
| Language | Language of the feature names (French by default). Gladys keeps the names given when a device is added. |
| Address of the system | IP address or host name of the SigenStor, or of the inverter running the Modbus TCP server. |
| Modbus TCP port | 502 unless your installer changed it. |
| Inverter unit ids | The unit id of each inverter, separated by commas (1 by default, 8 at most). |
| Plant unit id | 247 in the protocol: leave it. |
| Refresh interval | 10 s to 5 min (15 s by default). Only the values that change are sent. |
| Allow battery control | Off by default. See Battery control. |
Save, then add the devices from the Discovery tab of the integration.
Devices
The system
| Feature | Unit | Notes |
|---|---|---|
| Solar power | W | Never negative. |
| Home consumption | W | The "total load power" register, or computed on older firmwares. |
| Grid exchange | W | Positive when importing, negative when exporting. |
| Grid import, Grid export | W | The same exchange, split in two positive values. |
| Battery level | % | Battery systems only. |
| Battery charge power, discharge power | W | |
| Battery energy available | kWh | What the battery can still give. |
| Battery health | % | State of health, when the firmware gives it. |
| Solar production (total) | kWh | Cumulative index. |
| Home consumption (total) | kWh | Cumulative index, used by energy tracking. |
| Grid import (total), Grid export (total) | kWh | Cumulative indexes. |
| Battery charged (total), discharged (total) | kWh | Cumulative indexes. |
| Operating mode | text | Maximum self-consumption, AI mode, time of use, full feed-in, remote control, custom. |
| System state | text | Standby, running, fault, shut down, environmental abnormality. |
| Off-grid (backup power) | 0/1 | 1 when the system runs off the grid. |
| Alarm, Active alarms | 0/1, text | Every alarm bit of the protocol, translated ("Battery: over-temperature"). |
A feature whose register the firmware does not implement is left out.
Each inverter
Inverter power, solar power, battery level, charge and discharge power and battery temperature (with a battery), inverter temperature, grid voltage and current (L1, L2, L3 on a three-phase inverter), the voltage and current of each PV string, the inverter state and its alarms. The device is named after the model the inverter gives ("SigenStor EC 6.0 SP").
Energy tracking
With Gladys 5.2, the Home consumption (total) index feeds the energy tracking: Gladys derives the consumption of every half hour, and its cost when a contract is set. The other indexes (grid, battery, solar) are published in their own categories and are not counted as consumers. The cost computed on the home consumption includes the solar energy you consume yourself: when your electricity meter is already in Gladys, keep it as the main meter.
Battery control
Off by default: the integration only reads. Once Allow battery control is on, the system device gets three selects (click Update in the Discovery tab):
- Battery control: Automatic (app mode) gives the control back to the mode chosen in the mySigen app; Maximum self-consumption, Forced charge (grid first), Forced charge (solar first), Forced discharge (solar first), Forced discharge (battery first) and Standby (battery idle) force the remote EMS of the system.
- Charge power limit and Discharge power limit: from 0 to 100 % of the rated power, by steps of 10 %. A limit set elsewhere shows as the nearest step.
Only the registers the protocol documents as writable are written: remote EMS enable (40029), remote EMS control mode (40031), ESS maximum charging limit (40032) and maximum discharging limit (40034). Never start/stop, the grid code or the power dispatch registers. A forced mode stays until you set it back to automatic, even if Gladys stops: use it knowingly. These features are not switches, so voice assistants cannot drive them.
Actions
Test the connection reads the plant and the configured inverters once and says what answers: mode, state, solar and grid power, battery level, model, serial number (the last four characters) and firmware of each inverter, and whether the battery control registers can be read. When no configured inverter answers, it looks for inverters at unit ids 1 to 16.
Dashboard widget
Sigenergy energy shows four live tiles (solar, home, grid, battery level) and a status list: which way the battery goes and at what power, the operating mode, the alarms, and the link when the system does not answer. With battery control on, three buttons (with a confirmation) set the battery to automatic, forced charge from the grid or forced discharge; the current one carries a check mark.
Scene triggers
- A Sigenergy alarm is raised: a new alarm appears. Variables: the device name, the new alarm(s) and every active alarm, as text — ready for a notification. An alarm already active when the integration starts does not fire it.
- The Sigenergy system stops answering: two reads in a row failed. Variable: the error.
- The Sigenergy system answers again.
The battery level, the powers and the off-grid state are device features: use the usual "device value" trigger for them.
Scene actions
- Set the Sigenergy battery mode: one of the modes above. Output: the mode applied.
- Set the Sigenergy battery limits: charge and/or discharge limit in watts, from 0 to the rated power; an empty field is left unchanged.
Both need battery control allowed in the configuration, and fail otherwise.
Scene examples
- Off-peak charging: at 22:00, Set the Sigenergy battery mode to Forced charge (grid first) with Set the Sigenergy battery limits at 3000 W; at 6:00, back to Automatic (app mode).
- Use the surplus: when Grid exchange goes below −2000 W, start the water heater; stop it when it goes above 0.
- Power cut: when Off-grid (backup power) goes to 1, send a message and switch off the big consumers.
- Alarm: on A Sigenergy alarm is raised, send the alarm text ({{triggerEvent.data.alarm}}) to your phone.
Refresh and protocol rules
The integration reads the system itself, at the chosen interval, whatever the polling of the Gladys core. One cycle sends about fifteen requests, one at a time (the protocol asks to wait for each answer, 1 s at most, before the next one), and never reads a range the protocol marks reserved. Gladys accepts 300 states a minute: only the values that change are sent, and every value is sent again at least every 6 hours. A cumulative index is never sent lower than before (a reading glitch would count the whole index as consumed in 30 minutes).
Troubleshooting
- "does not answer": check the address, that Modbus TCP is enabled and saved in the mySigen app, and that nothing else blocks port 502. Some firmwares accept a single Modbus TCP client: stop the other ones (Home Assistant, an energy manager).
- "No inverter answers at unit id(s)": the plant answers but the inverter ids are wrong. Press Test the connection to find them.
- A feature is missing: your firmware does not implement its register. Update the firmware, then press Scan in the Discovery tab and Update the device.
- More details: set
LOG_LEVEL=debugon the integration to see every read.
Limits
- Developed without the hardware: the values follow the protocol document, not a real system.
- One Sigenergy system per integration, up to 8 inverters.
- The AC and DC chargers, the smart loads, the PSS and PID devices of the protocol are not read yet.
- Modbus TCP only (port 502, the system as server); not RS-485, not the "TCP client" mode of 4G systems.
- The battery commands are limited to the mode and the two limits; no scheduling, no power dispatch.
Configuration settings
These are the settings Sigenergy asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Getting started | section | No | The integration reads your Sigenergy system on the local network, in Modbus TCP (port 502). Modbus TCP must be enabled first: in the mySigen app (or by your installer), turn on Modbus TCP server for the system, note its IP address and the Modbus address (unit id) of each inverter. Save, then add the devices from the Discovery tab. |
| Language of the feature names | select | No | Gladys keeps the names given when a device is added. |
| Address of the system | string | Yes | IP address or host name of the SigenStor (or of the inverter running the Modbus TCP server). Give it a fixed IP in your router. |
| Modbus TCP port | number | No | 502 unless your installer changed it. |
| Inverter unit ids | string | No | The Modbus address of each inverter, as set in the mySigen app, separated by commas (1 by default; an AC charger often takes 1, the inverter then 2). Up to 8. |
| Plant unit id | number | No | 247 in the Sigenergy protocol: do not change it unless told so. |
| Refresh interval | select | No | How often the system is read. Only the values that change are sent to Gladys. |
| Battery control | section | No | Off by default: the integration then only reads. When allowed, Gladys can switch the battery mode (automatic, forced charge or discharge) and set its charge and discharge power limits, from the devices, the widget and scenes. These commands override the mode chosen in the mySigen app until set back to automatic: use them knowingly. |
| Allow battery control | boolean | No | Adds the control features to the system device (click Update in the Discovery tab). |
How to install Sigenergy in Gladys
- In Gladys, open Integrations: Sigenergy appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-sigenergy:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-sigenergy.
Sigenergy requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
