Shlink smart home integration, free and open source
Visits of your Shlink short links in Gladys, with a scene on each new visit.
Published by guim31
- Devices
- Version 1.0.0
- Requires Gladys >=5.1.0
- ★ 0
Shlink is a self-hosted URL shortener, open source (MIT), with a REST API. This integration brings the visits of your short links into Gladys: the Shlink server becomes a device (reachable or not, number of links, visits in all and today, bot visits today), and each short link you choose becomes a device with its visits in all, its visits today and the date of its last visit. Scenes can react to each new visit of a link (with the country and the referring site when Shlink knows them), and to Shlink going down or coming back; a dashboard widget lists the most visited links, and a scene action puts the figures of a link in a message.
Tested against a real self-hosted Shlink 5.1.8 (Docker, SQLite), with real visits; feedback welcome on the issues.
What you need
- Gladys Assistant 5.1.0 or later.
- A Shlink server (version 3.0 or later, for the REST API v3), reachable from the Gladys machine.
- An API key of this server.
At each refresh the integration sends four requests (visit totals, visits of the day with and without bots, the ten most visited links), plus two per link added to Gladys (three when the bots fire scenes), and reads the whole link list every 10 minutes. Gladys accepts 300 states per minute: with the 30-second interval, add 40 links at most to Gladys.
Getting started
1. Create an API key
On the Shlink server, run shlink api-key:generate (with Docker:
docker exec -it <container> shlink api-key:generate) and copy the key. A key
limited to one domain or to the links of its author (Shlink roles) works too:
the integration then sees only those links.
2. Configure the integration
In Gladys, open Integrations → Shlink → Configuration:
- Shlink address: the address of your server, the one your short links
use, for example
http://192.168.1.10:8080orhttps://s.example.org. An address copied with/rest/...is understood. - API key: the key of step 1.
- Refresh interval: from 30 seconds to 5 minutes (1 minute by default).
- Bot visits fire "New visit": off by default. Shlink flags as bots the crawlers and link previews (messaging apps, social networks); the figures never count them.
- Language of the names: the language of the feature names, set when a device is added, and of the scene results.
Test the connection reads Shlink and answers with the version, the number of links and the visits of the day.
3. Add the server and the links
Open the Discover tab of the integration: it lists the Shlink server and your short links, the most visited first (the 200 first ones). Add the server, and the links you want to follow: only the added links are read one by one and fire "New visit".
The devices
The Shlink server:
| Feature | What it shows |
|---|---|
| Reachable | 1 when Shlink answers, 0 after two failed reads in a row |
| Short links | the short links the API key sees |
| Visits | the visits of every link since Shlink counts, bots excluded |
| Visits today | the visits of every link today (from midnight), bots excluded |
| Bot visits today | the visits of today that Shlink flags as bots |
Each added short link:
| Feature | What it shows |
|---|---|
| Visits | the visits of the link, bots excluded |
| Visits today | the visits of the link today (from midnight), bots excluded |
| Last visit | the local date and time of the last visit (bots excluded), - before the first one |
The same short code on two domains makes two different links. "Today" starts at midnight in the time zone of Gladys.
Dashboard
The Shlink links widget shows the visits of today, the visits in all and the number of links, then the ten most visited links with their visits (and the visits of today for the links added to Gladys). The Refresh button reads Shlink again.
Scenes
Triggers
- New visit: a short link added to Gladys is visited. Choose the links (empty: any). Variables: link name, short address, target address, country and country code (empty when Shlink does not locate visits), referring site (its host only, empty when none), visits today, bot (1) or not (0). Bots fire it only with the option of the configuration. Up to 20 new visits per link and refresh are announced: more are counted, not announced.
- Shlink unreachable: Shlink no longer answers, after two failed reads in a row (a refused API key is not an outage). Variable: server address.
- Shlink reachable again: Shlink answers again. Variables: server address, outage in minutes.
Actions
- Read a short link: reads the figures of a link for the next actions: name, short address, target address, visits, visits today, last visit, and a ready-made sentence such as "Newsletter: 12 visit(s) today, 340 in all, last visit 2026-10-26 17:05.".
Scene ideas
- A notification when someone opens the link of your CV or of a listing: trigger New visit on this link, then a message with the country and the referring site.
- Every evening at 9 pm, Read a short link on the link of your newsletter, then send its sentence by Telegram.
- A warning when your link shortener is down: trigger Shlink unreachable, message to the administrator; and Shlink reachable again with the outage duration.
Troubleshooting
- "Shlink does not answer": check the address and that Gladys can reach the server (same network, firewall, port).
- "API key refused": the key was deleted or disabled, or has expired: create
a new one with
shlink api-key:generate. - "no Shlink API at this address": the address points to something else (a web client such as app.shlink.io, a reverse proxy page): use the address of the short links.
- "the address redirects": enter the
https://address directly. - "certificate refused": the HTTPS certificate is self-signed or expired: use
the
http://address on your local network, or a trusted certificate. - No country in "New visit": Shlink locates visits only with a GeoLite2
license key (
GEOLITE_LICENSE_KEY). - The logs never show who visited: no address, no country, no referring site.
Limits
- Shlink only (REST API v3, Shlink 3.0 or later); orphan visits (base URL, invalid links) are not counted.
- Shlink dates visits to the second and gives them no identifier: the
integration announces each new visit once by remembering the newest one seen,
in
/data. After a long stop, only the 20 newest visits of each link are announced. - A link is read one by one only once added to Gladys; the whole list is read again every 10 minutes (a new link appears in Discover within 10 minutes, or at once with a search).
- The integration reads Shlink, it never creates nor changes a link.
Configuration settings
These are the settings Shlink asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Your Shlink server | section | No | The address of your Shlink server (the one of the short links) and an API key: run shlink api-key:generate on the server. Then add the server and the links to follow from the Discover tab. |
| Shlink address | string | Yes | The address of your Shlink server, the one the short links use. |
| API key | secret | Yes | Created by shlink api-key:generate. A key limited to a domain or to its own links sees only those. |
| Options | section | No | |
| Refresh interval | select | No | How often Shlink is read: four API requests, and two per link added to Gladys. |
| Bot visits fire "New visit" | boolean | No | Off: the visits Shlink flags as bots (crawlers, link previews) fire no scene. The figures never count them. |
| Language of the names | select | No | Language of the feature names (set when a device is added) and of the scene results. |
How to install Shlink in Gladys
- In Gladys, open Integrations: Shlink appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-shlink:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-shlink.
Shlink requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
Shlink is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
