Segway Navimow smart home integration, free and open source
Unofficial connector: Segway Navimow mowers, state, battery, start, pause, dock and errors.
Published by LM1LC3N7
- Devices
- Version 0.1.1
- Requires Gladys >=5.1.0
- ★ 0
Unofficial connector, not affiliated with Segway or Navimow. It brings your Segway Navimow robotic mowers (the models without a perimeter wire) into Gladys through the Navimow cloud, the one of the Navimow app, with the same sign-in Segway offers to Home Assistant. Navimow and Segway are trademarks of their owners.
Development version (0.1). Built from Segway's own documentation and integrations, and tested against simulated answers: it has not run with a real mower yet. Feedback is welcome in the GitHub issues.
What you get
| Surface | Content |
|---|---|
| One device per mower | operational state, battery, activity, error code and error text, online, mowing progress (%) and area mowed in the session (m²), a mow / pause select and a return to the station button |
| Live updates | the state, battery and progress arrive within seconds while the mower works (MQTT over a secure WebSocket); the state is also read every 5 minutes |
| Scene triggers | error, activity changed, mowing finished (complete, interrupted or unknown), back in its station |
| Scene actions | start mowing, pause, resume, back to the station, for one mower or every mower |
| Dashboard widget | Robotic mower: battery, progress, activity, error, online, live updates, and Start / Pause / Resume / Station buttons |
| Configuration screen | a Test Navimow button listing your mowers |
Setup
- Install the integration from the Gladys store, then open its Configuration screen.
- Next to Navimow account, click Connect. Segway's sign-in page opens: sign in with the e-mail and password of the Navimow app (it may ask for a captcha). The browser then comes back to Gladys by itself, and the connection status turns green.
- Open Discovery and add your mowers.
- Put the Robotic mower widget on a dashboard.
Your password stays with Segway: Gladys only receives a session token, which the integration renews by itself (about every hour). If Segway ends the session, the status says so: click Connect again.
If Connect does not come back to Gladys
Sign in by hand instead, the way the ioBroker adapter does:
- Open the Navimow sign-in page link of the Configuration screen (in the "Connect does not come back to Gladys?" block) and sign in.
- The browser then shows an error page whose address starts with
http://localhost:1/callback?code=: this is expected. - Copy that whole address into the Sign in with the copied address action at the bottom of the Configuration screen, and run it within a few minutes (a code works once, for a short time).
The device
Gladys has no robotic mower category yet: like the Husqvarna Automower integration, the state and the two commands use the robot vacuum category, the only one describing a robot that runs, docks and charges. The device card therefore shows:
- State: Running (mowing or mapping), Paused, Returning to Dock, Charging, Docked, Error (lifted or an error), Stopped (idle, updating, self-check, offline);
- Mowing (idle: pause): a select whose Mow choice ("Clean") starts mowing (or resumes a paused mowing) and Pause ("Idle") pauses the mower;
- Return to the station: the "Return to Dock" button.
The other features are the battery (%), the activity (text in the language chosen in the configuration), the error code (0: none, -1: an error without a numeric code) and its text, online, the mowing progress (%) and the area mowed in the current session (m²). The progress and the area come with the mower's position messages: Segway only sends them while the mower mows a whole lawn (a zone task reports none).
Start runs the task set in the Navimow app; the public API offers no "end the task": pause stops the mower where it is, back to the station sends it home.
Scenes
- Navimow error: once per error (lifted, stuck, a motor or sensor error...). Variables: the code, the text in English and in French, the activity, the battery.
- Navimow activity changed: optionally for one activity (mowing, mapping, paused, returning, in the station, charging, idle, lifted, error, software update, self-check, offline). Variables: the new and the previous activity, the battery.
- Navimow mowing finished: a session (it starts when the mower mows) ended in the station or idle. Its outcome can filter the trigger: complete (the progress reached 100 %), interrupted (below 100 %: a stop, or a charging break before it goes on) or unknown (no progress was reported, e.g. a zone task). Variables: the outcome, where it ended, the session length in minutes (empty when the session began before Gladys saw it), the progress, the area, the battery, the end time.
- Navimow back in its station: the mower arrived in its station, whatever the reason (end of mowing, charging break, sent back). A mower the cloud sees again (offline before) does not count.
The actions start mowing, pause, resume and back to the
station act on the chosen mower, or on every mower when the field is empty.
They give mower_name and count to the following actions of the scene,
which find them in their variable list (written {{<step>.<action>.<key>}},
for instance {{0.0.count}} when this action is the first of the scene).
How often Navimow is called
At start: the list of mowers and their state (one call for all). While the mower works, the live updates bring the changes. The state is read again every 5 minutes (option Status refresh interval, 1 to 60), every 2 minutes while the live updates are down, and 10 seconds after a command; the list of mowers every 12 hours and on a Discovery scan. A docked mower sends nothing live, so its battery follows the 5-minute reading.
Troubleshooting
- "Not connected": click Connect (setup, step 2).
- "The Navimow session expired or was refused": Segway ended the session (password changed, account signed out): click Connect again.
- The sign-in page does not come back to Gladys: use the manual sign-in above.
- "Live updates down": the integration keeps reading the state every 2 minutes and reconnects by itself; the logs say why.
- The state lags a minute behind the app: the cloud status the integration reads is a cache; the live updates, when on, are immediate.
- Logs: the integration's log level is set with the
LOG_LEVELvariable (debugalso logs the event and attribute messages of the mowers).
Privacy
The integration uses the state of your mowers only: the positions Segway sends with the progress are dropped at once, never stored nor shown. The session token goes to Segway only and never appears in a log, a status or a scene.
Configuration settings
These are the settings Segway Navimow asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Segway Navimow in Gladys | section | No | Unofficial connector, not affiliated with Segway or Navimow. It reads your Navimow robotic mowers (no perimeter wire) through the Navimow cloud, with the account of the Navimow app: one device per mower (state, battery, activity, error, online, mowing progress and area, a mow / pause select and a return to station button), live updates while the mower works, scene triggers on errors, activity changes, the end of mowing and the return to the station, scene actions to start, pause, resume and send it back, and a dashboard widget. Navimow and Segway are trademarks of their owners. |
| Navimow account | oauth2 | No | Click Connect, then sign in with the e-mail and password of the Navimow app (Segway's page may ask for a captcha). The browser comes back to Gladys by itself. The password stays with Segway: Gladys only keeps a session token. |
| Connect does not come back to Gladys? | section | No | Sign in by hand instead: open the sign-in page below and sign in. The browser then shows an error page (address starting with http://localhost:1/callback?code=): this is expected. Copy that whole address into the "Sign in with the copied address" action at the bottom of this screen, within a few minutes. |
| Status refresh interval (minutes) | number | No | The live updates carry the changes while the mower works; the state and the battery are also read at this pace (every 2 minutes at most while the live updates are down). |
| Language of the names and texts (activity, error) | select | No |
How to install Segway Navimow in Gladys
- In Gladys, open Integrations: Segway Navimow appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/lm1lc3n7/gladys-navimow:0.1.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/LM1LC3N7/gladys-navimow.
Segway Navimow requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
Segway Navimow is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by LM1LC3N7, not by the Gladys core team.
- Browse all integrations, native and community
- Build and publish your own external integration
- Source code on GitHub — source of this documentation
