Seafile smart home integration, free and open source

Seafile integration for Gladys Assistant

Your Seafile account in Gladys: space, quota, libraries, and a scene when a library changes.

View on GitHubAll integrations

Seafile is a self-hosted file storage and sync service: your libraries live on your own server and the desktop and mobile apps keep them in sync. This integration brings a Seafile account into Gladys: the space used and the quota, the libraries, the linked devices, and a scene trigger when a library is modified (a file added, changed or deleted), with who modified it. It also warns when the quota goes above a threshold, and a dashboard widget shows the quota and the libraries modified last. For an administrator, a second device follows the whole server.

Tested against a real Seafile Server CE 12.0 (Docker image seafileltd/seafile-mc with MariaDB and memcached): a regular account with a quota, an administrator, libraries of its own, shared and of a group, files uploaded, the quota changed, a linked desktop client, a wrong password. Not yet tested on a real Gladys: feedback welcome on the issues.

What you need​

  • Gladys Assistant 5.1.0 or later.
  • Seafile Server (Community or Professional edition, version 11 or later), reachable from the Gladys machine at the address of its web interface.
  • A Seafile account: its email (or username) and password, or an API token if the account uses two-factor authentication. An administrator account adds the server device; a regular account is enough for the rest.

The integration reads Seafile every minute by default: four light requests on your own network (account, libraries, linked devices, and the server figures for an administrator).

Getting started​

1. Configure the integration​

In Gladys, open Integrations → Seafile → Configuration and fill in:

  • Seafile address: the address of the web interface, as in your browser, e.g. http://192.168.1.2:8000 or https://cloud.example.com. A link copied from a library page works too.
  • Email or username and Password of the account.
  • API token (optional): instead of the password, needed when two-factor authentication is on. To get one, run on any computer curl -d username=EMAIL -d password=PASSWORD -H "X-SEAFILE-OTP: CODE" https://cloud.example.com/api2/auth-token/ (CODE is the current code of your authenticator app) and copy the token it answers.
  • Refresh interval: 30 seconds to 15 minutes. It is also the delay of the "A library is modified" trigger.
  • Quota alert threshold: 70 to 95 %.
  • Language of the names: the language of the feature names and of the texts sent by the integration.

Then click Test the connection: it answers with the version of Seafile, the account, the space used and the number of libraries.

2. Add the devices​

Open the Discover tab: the account is listed, and the server too for an administrator. Add the ones you want to follow.

The devices​

The account (Seafile <name>):

FeatureMeaning
Online1 while Seafile answers, 0 otherwise
Quota usedpercentage of the quota used (0 without a quota)
Space usedspace used by the account, in MB
Quotathe quota of the account, in MB (nothing without a quota)
My librarieslibraries the account owns
Shared librarieslibraries shared with the account, or of its groups
Linked devicesdesktop and mobile apps linked to the account
Last library modifiedname of the library modified last
Last modificationits day and time

The server (Seafile server, administrator accounts only):

  • Users
  • Active users
  • Libraries
  • Files
  • Groups
  • Linked devices
  • Connected devices
  • Storage used

Storage used is in MB, for every library of the server.

The integration reads Seafile on its own timer, and only publishes what changed (plus an unchanged value every 12 hours, so Gladys never shows "no recent value").

Dashboard​

The Seafile storage widget shows the quota used as a gauge (green, orange 10 points before the threshold, red above it), the space used, the number of libraries, then the six libraries modified last with their size and time. The Refresh button reads Seafile again. It works even before the account is added to Gladys.

Scenes​

Triggers​

  • A library is modified: a file is added, changed, deleted or renamed in a library the account sees. Filters: the library (its exact name) and who modified it (the name shown by Seafile), empty for any. Variables: library, modified by, owner, size, size in bytes, and whether the library is shared with the account. One event per library at each reading; a library created is not announced, its next modification is.
  • The quota goes above the threshold: the account goes above the threshold of the configuration. Once, until the usage goes back 5 points below it. Variables: quota used (%), threshold, space used, quota. A quota already above the threshold at the first reading, or when the threshold changes, is not announced.

A modification made while the integration or Gladys was stopped is announced at the next reading, once. Nothing is announced at the very first reading.

Actions​

  • State of the account: reads the account (again if the last reading is older than 15 seconds) and gives the space used, the quota, the quota used (-1 without a quota), the libraries, the linked devices, the last library modified with its time, and a ready-made sentence such as "Seafile: 4.2 GB of 10.0 GB used (42 %), 3 libraries, last modified: Photos on 22/10 08:12."

Scene ideas​

  • When the library "Scans" is modified, send yourself a message "New scan in Seafile".
  • When the quota goes above the threshold, send a message with the space used and the quota.
  • Every Sunday evening, run "State of the account" and send its sentence.
  • When "Online" of the account goes to 0, send a message: Seafile is down.

Troubleshooting​

  • "Seafile does not answer": check the address from the Gladys machine (the web interface must open there), and the firewall.
  • "username, password or token refused by Seafile": check them in the web interface; an API token is deleted when the password changes or when you log out of all devices. A refused password is not tried again by itself (Seafile could lock the account): fix it, then save the configuration or click Test the connection.
  • "two-factor authentication is on: use an API token": create a token as shown above.
  • "no Seafile API at this address": the address is not the web interface of Seafile (the file server port 8082 is not enough).
  • "the address redirects": enter the https:// address.
  • "certificate refused": the container only trusts valid certificates; use a valid one, or the http:// address on your network.
  • "Seafile limits the requests": choose a longer refresh interval.
  • No server device: the account is not an administrator. A promotion is noticed within the hour.
  • The logs of the integration (Integrations → Seafile) say more, without any password or token.

Limits​

  • One account per integration. The libraries are those the account sees.
  • "A library is modified" tells which library and who, not which file.
  • A library with many modifications between two readings fires one event; at most 20 libraries are announced per reading.
  • Sizes are in decimal units (1 MB = 1,000,000 bytes), as Seafile shows them.
  • The password stays in the configuration of Gladys; only the token Seafile gives in exchange is kept, in memory. Nothing secret is written under /data.
  • Developed and tested with a real Seafile in Docker, not yet on every setup: feedback welcome. Not affiliated with Seafile Ltd.

Configuration settings​

These are the settings Seafile asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your Seafile accountsectionNoEnter the address of the Seafile web interface and the username and password of your account, or an API token if two-factor authentication is on. Then add the account (and the server, for an administrator) from the Discover tab.
Seafile addressstringYesThe address of the web interface, as in your browser.
Email or usernamestringNoThe one you log in to Seafile with.
PasswordsecretNo
API tokensecretNoOptional, instead of the password: needed with two-factor authentication. See the setup guide.
Refresh intervalselectNoAlso the delay of the scene on a library modified.
Quota alert thresholdselectNoThe scene trigger fires when the account goes above it.
Language of the namesselectNoFeature names and texts sent by the integration.

How to install Seafile in Gladys​

  1. In Gladys, open Integrations: Seafile appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-seafile:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-seafile.

Seafile requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Seafile is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
