Schlage smart home integration, free and open source

Schlage integration for Gladys Assistant

Schlage Wi-Fi locks (Encode, Encode Plus, Lever…) via the Schlage cloud: state, battery, door.

View on GitHubAll integrations

Unofficial integration, not affiliated with Schlage or Allegion. It brings the Wi-Fi locks of a Schlage Home account into Gladys (Schlage Encode, Encode Plus and Encode Lever, and, as pyschlage lists them, the Wi-Fi models of the Arrive, Sense Pro and Selene families, Schlage and Gainsborough), through the Schlage cloud (the one the Schlage Home app uses, accounts of the United States and Canada).

Warning: unofficial API. This integration has never been tested with a real account nor a real lock. It was written from the pyschlage library (the one of the Home Assistant integration) and tested against a fake Schlage cloud only. Schlage may change its API at any time. Feedback is welcome.

What you get​

For each lock:

FeatureDetail
LockCommand: 1 locks, 0 unlocks (when allowed). Shows 1 locked, 0 unlocked.
Lock state0 unlocked, 1 locked, 2 a command in progress, 3 jammed.
Jammed1 when the lock reports a jam (bolt or motor), 0 otherwise.
BatteryIn %.
DoorOpening sensor (0 open, 1 closed), only on locks with a door position sensor that reports it.
Last actionText, for example "Unlocked with the keypad (Jean)": how, and by whom when Schlage gives it.
Lock and leave (1-Touch)1 when the one-touch locking setting of the lock is on (read only), on the models that have it.

"By whom" is the name of the access code (keypad), or the name of the Schlage Home user (app, Apple Home); never an e-mail, never a code.

Scene triggers:

  • Schlage lock unlocked: when a read shows unlocked a lock that was locked at the previous read. Variables: lock (its name), method (keypad, app, apple_home, manual for the thumbturn, one_touch, other) and by (code name or user, empty when unknown). An unlock from Gladys counts too (usually app).
  • Schlage lock jammed: when a read shows jammed a lock that was not.

The locks are read every minute: a lock unlocked and locked again between two reads is not seen, and a trigger arrives up to a minute late.

The badge of each lock shows "cloud", "unreachable" (with an orange dot) when Schlage reports the lock offline (its Wi-Fi), and "unreachable" for all when the Schlage cloud does not answer or the account is stopped. An offline lock keeps its last values.

Other models (Schlage Sense behind its Wi-Fi adapter, unknown types) show read only: no command is sent to them.

Setup​

  1. Your locks must work in the Schlage Home app, over Wi-Fi.
  2. In Gladys, install the Schlage integration and enter the e-mail and the password of your Schlage Home account. Save.
  3. If Schlage asks for a verification code (the status says so): click Send the verification code, then type the code you received in Verify the code, within 3 minutes. A code that has just arrived after saving can be typed at once.
  4. Add the locks from the Discovery tab.

Safety​

  • Locking is always possible.
  • Unlocking is off by default: turn on Allow unlocking the locks from Gladys to allow it. Then a scene, a dashboard or a voice assistant connected to Gladys can open your door.
  • Before each command, the integration reads the lock again in the Schlage cloud. The command is refused when that read fails, when Schlage reports the lock offline, jammed, or in an unknown state.
  • The commands of one lock run one at a time.
  • A command that cannot be sent within 3.5 seconds of its arrival is refused: Gladys shows a failure after 5 seconds, and nothing must move after that failure.
  • After a command, any new command of the same lock is refused ("still in progress") until a later read shows the expected state (or a jam), for 45 seconds at most; the lock shows "a command in progress" meanwhile. The answer of the command itself does not count: it may show the requested state before the bolt moved.
  • When Schlage does not answer a command in time, Gladys shows a failure, but the lock may still move: check its state.
  • Commands are refused while the account is stopped (refused password, code awaited) and during a pause asked by Schlage.

Password, tokens and privacy​

  • The password is kept by Gladys in its database, never shown again, and used only to sign in to Schlage. The sign-in is AWS Cognito SRP (as the Schlage Home app does): the password itself never travels, only a proof.
  • The sign-in gives tokens: the access token (about an hour) is renewed with the refresh token, without the password, so the integration does not sign in again at each read. Both tokens are kept in the /data volume of the integration so that a restart neither signs in again nor asks for a new code. On the Gladys host, that volume is the folder <Gladys base folder>/external-integrations/<selector>: readable by root and by the uid 1000 (the user of the container), not in the Gladys backups, deleted when the integration is uninstalled. The refresh token gives control of the locks (unlocking included) for as long as it is valid, without the password: protect that host as you protect your keys. The e-mail and the password are never written there; changing the e-mail, or emptying the e-mail or the password, drops the tokens.
  • Nothing appears in the logs: no password, token, code, e-mail, nor the internal keys (CAT/SAT) and MAC addresses the Schlage answers contain.
  • Everything goes over HTTPS to cognito-idp.us-west-2.amazonaws.com (the sign-in) and api.allegion.yonomi.cloud (the locks).

Refresh​

The locks are read every 60 seconds by default (60 to 900), one request for the whole account, plus a few reads during the 45 seconds after a command.

Errors​

  • Password refused (or account not confirmed, password reset asked): the integration stops; one new try after 1 h, 6 h, then every 24 h, or at once when you save the configuration or click Test the connection.
  • Verification code: the integration never asks for a new code by itself (each sign-in would send one); it waits for the buttons. Once the code is accepted, the session is kept. An account that asked for a code once is remembered: when its refresh token expires or is refused, the integration does not sign in again by itself, it stops and waits for the buttons.
  • New password required: choose it in the Schlage Home app, then enter it here.
  • Session refused right after a new sign-in: new try after 1 h, 6 h, then every 24 h.
  • Schlage asks to slow down (429, or too many sign-ins): a pause of at least 1 minute (Retry-After when given, at most 6 h), for every path (reads, commands, buttons), kept across restarts.
  • HTTP 403: a 30-minute pause.
  • Schlage unreachable: tried again after 1, 2, 5, 10 then every 15 minutes, never faster than the refresh interval.

Limits​

  • Accounts of the United States and Canada only (the only Schlage cloud).
  • Never tested with a real account: the shape of the answers comes from pyschlage.
  • A sign-in step other than the code (SMS, e-mail or authenticator app) is not handled: the status says which one.
  • The locks are polled: no live events (the push channel of Schlage allows one consumer per account, the Schlage Home app being one).
  • Access codes, auto-lock, beeper and alarm settings are not handled.

Credits​

  • pyschlage by David Knowles (Apache-2.0): the cloud API, the sign-in and the meaning of the lock states are ported to JavaScript.
  • pycognito (Apache-2.0): the SRP computation.
  • The Schlage integration of Home Assistant (Apache-2.0).
  • See THIRD_PARTY_NOTICES.md.

Schlage is a trademark of Allegion; this project is not affiliated with Schlage or Allegion.

Configuration settings​

These are the settings Schlage asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your Schlage accountsectionNoBrings the Wi-Fi locks of your Schlage Home account (US, Canada) into Gladys: Encode, Encode Plus, Encode Lever, and the Wi-Fi models of the Arrive, Sense Pro and Selene families. For each: locked or not, jam, battery, door (when the lock has a sensor), last action and by whom, and scene triggers on unlocking and on a jam. Read every minute through the Schlage cloud. Enter the e-mail and the password of the Schlage Home app, save, then add the locks from the Discovery tab. If Schlage asks for a verification code, use the two buttons below. Locking from Gladys is always allowed; unlocking stays off until you allow it below. Unofficial API, never tested with a real account. Not affiliated with Schlage or Allegion.
Schlage e-mailstringYes
Schlage passwordsecretYesKept by Gladys in its database, never shown again, used only to sign in to Schlage (AWS Cognito SRP: the password itself is never sent).
Allow unlocking the locks from GladysbooleanNoOff by default: Gladys can lock, never unlock. On, a scene, a dashboard or a voice assistant connected to Gladys can open your door.
Refresh interval (s)numberNoSeconds between two reads of the locks (60 to 900).
Language of the feature namesselectNoUsed for the feature names of the locks added from now on, and for the last action.

How to install Schlage in Gladys​

  1. In Gladys, open Integrations: Schlage appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/lm1lc3n7/gladys-schlage:0.1.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/LM1LC3N7/gladys-schlage.

Schlage requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Schlage is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by LM1LC3N7, not by the Gladys core team.
