SABnzbd / NZBGet smart home integration, free and open source
SABnzbd and NZBGet: speed, queue, pause from the dashboard, finished and failed download scenes.
Published by guim31
- Devices
- Version 1.0.1
- Requires Gladys >=5.1.0
- ★ 0
Follow and control your Usenet downloads from Gladys: SABnzbd and NZBGet, the two download clients most home servers run (Docker, Unraid, Synology, Proxmox…). The integration talks to the local API of the client: the download speed, the queue and the time left show on the dashboard, a scene can pause the downloads during a video call and limit the speed in the evening, and Gladys can tell you when a download is finished or failed.
Tested against real SABnzbd (4.2 and 5.1) and NZBGet (21 and 26) installs, not yet in a real Gladys: feedback welcome on GitHub.
Requirements
- Gladys 5.1.0 or later.
- SABnzbd 3 or later, or NZBGet 21 or later, reachable from the Gladys server (same network).
- For SABnzbd: its API key (Config → General → Security → API Key). The NZB key, just below, is not enough: it can only add jobs.
- For NZBGet: the control user name and password (Settings → Security → ControlUsername and
ControlPassword,
nzbget/tegbzn6789until you change them).
Configuration
Up to two clients, each with:
- Software: SABnzbd or NZBGet.
- Address: the IP address or name, with the port:
192.168.1.10:8080(SABnzbd) or192.168.1.10:6789(NZBGet). Without port, the default port of the software is added. Writehttps://for HTTPS, and the path if the client sits behind a reverse proxy (https://nas.example.org/sabnzbd). - API key (SABnzbd), or User name (NZBGet) and Password (NZBGet).
- Name: the name of the device in Gladys (empty: the software followed by the address).
- Line speed (Mbit/s): your download speed, needed to limit the speed in percent with NZBGet, and with SABnzbd when its "Maximum line speed" (Config → General) is not set. 0: unknown.
Options:
- Accept self-signed certificates: for
https://addresses with the certificate SABnzbd generates. Tick it for your own servers only. - Refresh interval: how often the clients are read, 30 seconds by default.
- Language of the feature names: the names given to the features when a device is added, and the status texts (French by default).
The Test the connection button reads every client and says what it found: version, state, queue, recent errors.
Devices
One device per client, found in the Discovery tab. Its features:
| Feature | What it shows |
|---|---|
| Downloads paused | switch: on pauses the downloads until you turn it off, off resumes them. |
| Speed limit | slider, the share of the line in %, 100 = no limit. Moving it limits the speed. |
| Download speed | in MB/s. |
| Jobs in the queue | the jobs waiting or downloading (post-processing excluded). |
| Left to download | in GB. |
| Time left | in minutes at the current speed, 0 when nothing downloads. |
| Free disk space | in GB, of the download folders (the smaller of the temporary and completed folders). |
| Status | Downloading, Paused, Post-processing, Waiting, Idle, or Unreachable. |
| Last download | the name of the last download completed. |
| Errors (24 h) | the errors and warnings the client reported over the last 24 hours. |
Sizes and speeds are binary units, like the clients show them (1 MB = 1024 × 1024 bytes). Only the changes are sent to Gladys, and every value again after 6 hours.
Widget
The Usenet downloads widget shows the speed, the queue and the time left of every client (or of the one chosen in its settings), one line per client (state, end of a timed pause, speed limit, free space, last download, errors), and three buttons:
- Pause: pauses the downloads until you resume them;
- Pause 30 min: pauses them for 30 minutes;
- Resume: resumes them.
The check mark shows the current state: on Pause when everything is paused, on Resume when everything downloads.
Scene triggers
- Download completed: a job finished downloading and post-processing successfully. Filters:
the client, the category (exactly as written in the client,
tv,Movies…). Variables: name, category, size in MB, client name. - Download failed: a job failed (missing articles, repair or unpack impossible). Same filters; variables: name, category, the reason given by the client, client name.
Each job fires once. The jobs finished while the integration was stopped (an update, a restart) fire when it starts again, if they are less than an hour old.
There is no "low disk space" trigger: the Free disk space feature is a value, and the device trigger of Gladys already compares it with a threshold ("Free disk space below 20 GB").
Scene actions
- Pause downloads: one client or all of them, for a number of minutes (0: until resumed). Outputs: number of clients paused, duration.
- Resume downloads: one client or all of them.
- Limit the download speed: a share of the line in %, 100 to remove the limit. Needs the line speed (see Configuration).
Scene examples
- Video call: when the calendar event "Meeting" starts, Pause downloads for 60 minutes.
- Evening: at 7 pm, Limit the download speed to 30 %; at 11 pm, back to 100 %.
- Notification: on Download completed with the category
tv, send "{{triggerEvent.data.name}} is ready to watch" to the family. - Problem: on Download failed, send the name and the reason to the administrator.
- Disk: when Free disk space drops below 20 GB, pause the downloads and send a message.
Troubleshooting
- "does not answer": check the address and the port, and that the Gladys server can reach the client (firewall, Docker network).
- "API key or password refused": correct the key or the password, then save. The integration does not try again on its own: each refused key adds a warning in SABnzbd.
- "certificate refused": tick "Accept self-signed certificates", or use
http://. - "no SABnzbd or NZBGet at this address": wrong software chosen, or wrong port.
- "the address redirects": write the
https://address. - A limit in % refused: enter the Line speed (Mbit/s), or set "Maximum line speed" in SABnzbd.
- More details: the integration logs, with
LOG_LEVEL=debugfor every reading.
Limits
- Each refresh reads the queue: every 30 seconds by default, a few small requests. NZBGet sends its whole history at once: it is only read again when something changed, at most every 15 minutes otherwise.
- NZBGet resumes a timed pause up to about 25 seconds late (it checks its timer periodically).
- No job management: the integration does not add, remove or reorder downloads, and deletes nothing.
- The "Errors (24 h)" of NZBGet count the messages since the integration started reading its log (the last 100 at start).
- Not affiliated with SABnzbd or NZBGet.
Configuration settings
These are the settings SABnzbd / NZBGet asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Your download client | section | No | SABnzbd 3 or later, or NZBGet 21 or later, on your network. SABnzbd needs its API key, NZBGet its control user name and password. Up to two clients. |
| Software | select | No | |
| Address | string | Yes | IP address or name, with :port (SABnzbd 8080, NZBGet 6789 by default) and https:// for HTTPS. |
| API key (SABnzbd) | secret | No | SABnzbd: Config, General, Security, API Key (not the NZB key). |
| User name (NZBGet) | string | No | NZBGet: Settings, Security, ControlUsername (nzbget by default). |
| Password (NZBGet) | secret | No | NZBGet: Settings, Security, ControlPassword. |
| Name | string | No | Name of the device in Gladys. Empty: the software followed by the address. |
| Line speed (Mbit/s) | number | No | Your download speed, for limits in %. Not needed for SABnzbd when its Maximum line speed is set. 0: unknown. |
| Second client (optional) | section | No | Same fields, for another SABnzbd or NZBGet of your network. |
| Software | select | No | |
| Address | string | No | IP address or name, with :port (SABnzbd 8080, NZBGet 6789 by default) and https:// for HTTPS. |
| API key (SABnzbd) | secret | No | SABnzbd: Config, General, Security, API Key (not the NZB key). |
| User name (NZBGet) | string | No | NZBGet: Settings, Security, ControlUsername (nzbget by default). |
| Password (NZBGet) | secret | No | NZBGet: Settings, Security, ControlPassword. |
| Name | string | No | Name of the device in Gladys. Empty: the software followed by the address. |
| Line speed (Mbit/s) | number | No | Your download speed, for limits in %. Not needed for SABnzbd when its Maximum line speed is set. 0: unknown. |
| Options | section | No | |
| Accept self-signed certificates | boolean | No | For https:// addresses: SABnzbd generates a self-signed certificate. Tick only for your own servers. |
| Refresh interval | select | No | How often the clients are read. |
| Language of the feature names | select | No | Names given to the features when a device is added, and the status texts. |
How to install SABnzbd / NZBGet in Gladys
- In Gladys, open Integrations: SABnzbd / NZBGet appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-usenet:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-usenet.
SABnzbd / NZBGet requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
SABnzbd / NZBGet is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
