Roth Touchline integration for Gladys Assistant

Roth Touchline underfloor heating (Ethernet controller): temperatures, setpoints, modes per room.

View on GitHubAll integrations

This integration shows the rooms (room thermostats) of your Roth Touchline underfloor heating in Gladys, through the Touchline Ethernet controller on your local network. It talks to the controller directly, without any account or password, through the two CGI scripts the controller exposes (reading and writing values).

This is not Touchline SL: Touchline SL is the newer Roth range, driven by a cloud service with a Roth account; it has its own integration ("Roth Touchline SL"). If your Roth app asks for an account, you have Touchline SL.

Never tested with a real device: it follows the pytouchline_extended library (the one of the Home Assistant touchline integration), without having been tried on a real installation. Tell us on the forum whether it works for you. Not affiliated with Roth.

What it does​

For each room the controller knows, a device "Room name (Touchline)" with:

  • the room temperature (read only);
  • the setpoint (thermostat);
  • the mode: normal, night or holiday (a list);
  • the week program: none, 1, 2 or 3 (a list).

When a program is active, it decides the mode through the day; "none" lets the chosen mode apply all the time.

Setup​

  1. Install the integration from the Gladys store.
  2. Enter the IP address of the Touchline controller (the one of its web interface), then save.
  3. Open the Discovery tab and add the rooms you want.

The Test the connection button reads the controller once, when the refresh interval allows it, and shows its status.

Devices are identified by the two numbers the controller gives each thermostat (the controller's and the thermostat's), not by their position in the list: removing a thermostat does not mix up the others. A thermostat whose numbers cannot be read is not offered.

Commands (off by default)​

By default, Gladys only reads. Two separate options:

  • Allow setpoint commands: the dashboard, the scenes and the voice assistants may change the setpoint of a room.
  • Allow mode and program commands: the "Mode" and "Week program" lists may be changed from Gladys.

Safety bounds:

  • a setpoint goes from 5 °C to the setpoint ceiling, 24 °C by default, adjustable from 16 to 30 °C; the limits of the controller itself (the minimum and maximum set for the room) apply too, and are never changed by Gladys;
  • the ceiling, the option and the limits are checked again right before the request leaves: if one of them changed during the command, nothing is sent;
  • no command goes through a switch: a "turn everything off" of a voice assistant does not reach the heating. The Touchline controller has no command to stop the heating: lowering the setpoint or choosing the holiday mode are commands like the others, behind the same options.

Each command reads the room again right before acting, checks that the thermostat answering at that position is the one targeted, and decides on that read; it leaves within 3.5 s or is refused without sending anything. The controller echoes the value written, then the room is read back: the command succeeds only when the value read back is the one asked. When the echo comes too late to read back within the Gladys delay, Gladys shows "sent and echoed by the controller: checked by a read in a few seconds"; with no echo in time, "sent, without confirmation". Either way the room is read again 5 s and 20 s later (these reads wait their turn, they are never skipped). When a read back contradicts the echo, the command is told "without effect" in the status of the integration, the log and the badge of the room, until the next read. A read made before a write is never published after it.

Commands wait their turn in a queue (8 at most), one write at a time, 0.5 s after the answer of the previous one; each keeps its 3.5 s from its arrival. A scene setting several rooms one after the other sets them all; a scene setting them at the same time sets a few in a row (6 at most with a fast controller, fewer with a slow one): beyond, or when a room answers "not sent in time", leave about 4 s between two rooms.

A command is refused, with nothing sent, in these cases: configuration of the integration not loaded yet; option off; value out of bounds, not a tenth of a degree, or unknown mode/program; 8 commands already waiting; reads of the controller paused after failures; room unknown; no thermostat or another thermostat at its position; current state unreadable (fresh read failed or invalid answer); setpoint limits unreadable or inconsistent, or the minimum of the room above the ceiling; address or option changed during the command; controller too slow, a read in progress too long, or too many commands before it to leave in time; connection refused before sending ("command not sent" and the reason). A write that left may also come back "the controller refused the command" (a 4xx answer).

Limits and safety​

  • A read every 60 s (30 s to 10 min), every room in turn, one request at a time; a room that does not answer leaves the others read; when all fail, the read failed (pause below). A read starts no new room past 45 s (and never past the interval minus 10 s); the next one starts at the first room left unread, so none is forgotten; a room not read again yet keeps its last values and stays commandable, its badge turns degraded after two reads without it. The controller rests at least half an interval between two reads. Never two reads within an interval, even across a restart (the time of the last attempt is kept in /data at each read).
  • Configuration of Gladys unreadable at start: new tries after 5 s, 15 s, 1 min, then every 5 min, with a status saying so.
  • A room added or changed in Gladys gets its last values at once only when they are fresh (otherwise at the next read).
  • Controller unreachable: a pause of 1, 2, 5, 10 then 15 min (never under the interval), kept in /data, for the reads, the button and the commands.
  • /data holds neither the address of the controller nor any secret (there is none): only the time of the last attempt, the pause and the time of the last write, tied to a fingerprint of the address.
  • The controller gives its web interface password (CD.upass) to whoever asks: the integration never asks.
  • The read request identifies itself as "gladys-roth-touchline", not as the Roth software. If your controller does not answer it, tell us on the forum.
  • 32 rooms at most per controller.

Credits​

The protocol of the controller and the shape of its answers come from pytouchline_extended (brondum, after pytouchline by abondoe, MIT), the library of the Home Assistant touchline integration. See THIRD_PARTY_NOTICES.md.

Configuration settings​

These are the settings Roth Touchline asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your Touchline controllersectionNoBrings the room thermostats of a Roth Touchline underfloor heating into Gladys through its Ethernet controller, on your local network (no account, no password): the temperature, the setpoint, the mode and the week program of each room. Setpoints, modes and programs can be changed from Gladys only once allowed below, bounded by the limits of the controller and a ceiling. Not Touchline SL (a cloud service, another integration). Never tested with a real device. Not affiliated with Roth.
IP address of the controllerstringYesThe address of the Touchline controller on your local network (":port" when it is not 80), without path.
Commands (off by default)sectionNoWithout these options, Gladys only reads. Each command is decided on a fresh read of the device, within the setpoint limits of the controller and the ceiling below. No command goes through a switch: a "turn everything off" never reaches the heating. The controller has no off command.
Allow setpoint commandsbooleanNoThe dashboard, the scenes and the voice assistants may change the setpoint of a room.
Allow mode and program commandsbooleanNoThe mode (normal, night, holiday) and the week program (none, 1, 2, 3) of a room may be changed from Gladys.
Setpoint ceiling (°C)numberNoA setpoint above this value is refused (16 to 30 °C). The limits of the controller itself apply too and are never changed.
Refresh interval (s)numberNoSeconds between two reads of all the rooms (30 to 600). The controller is slow: a read of many rooms takes several seconds.
Language of the namesselectNoUsed for the names of the devices, features and options added from now on.

How to install Roth Touchline in Gladys​

  1. In Gladys, open Integrations: Roth Touchline appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/lm1lc3n7/gladys-roth-touchline:0.1.2), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/LM1LC3N7/gladys-roth-touchline.

Roth Touchline requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Roth Touchline is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by LM1LC3N7, not by the Gladys core team.
