RFLink integration for Gladys Assistant

RFLink integration for Gladys Assistant

433/868 MHz devices through an RFLink gateway: switches, dimmers, sensors, weather stations.

View on GitHubAll external integrations

This integration connects Gladys to an RFLink gateway and turns the 433 MHz / 868 MHz traffic it hears into Gladys devices: wall plugs, dimmers, weather stations, motion and smoke detectors, energy meters, doorbells.

Gladys runs each external integration in a sandboxed container that has no access to serial ports — the only hardware a manifest can request is a Coral accelerator, a GPU or a video device. So the integration reaches the gateway over the network. There are two supported setups.

A. RFLink32 on ESP8266 / ESP32 (nothing else to install)​

RFLink32 exposes a TCP server natively. Flash your board, connect it to your Wi-Fi, and note the IP address it takes; the default port is 1234.

B. A USB RFLink plugged into a computer (Arduino Mega + transceiver)​

Bridge the serial port to TCP with ser2net, on the machine the RFLink is plugged into (it can be the Gladys host):

sudo apt install ser2net

Add this to /etc/ser2net.yaml, adjusting the device path:

connection: &rflink
  accepter: tcp,1234
  connector: serialdev,/dev/ttyUSB0,57600n81,local
  options:
    kickolduser: true

Then sudo systemctl restart ser2net. 57600 baud is the RFLink rate — the classic symptom of a wrong rate is a log full of unreadable characters.

esp-link and a USR-TCP232 style serial-to-Ethernet module work the same way.

Check the bridge from any machine on the LAN before configuring Gladys:

printf '10;PING;\r\n' | nc 192.168.1.42 1234
## -> 20;01;PONG;

Configuration​

  1. Open the Configuration tab of the integration.
  2. Fill in the gateway address (its IP or hostname) and the TCP port (1234 unless you changed it).
  3. Save, then press Test the gateway: it sends 10;PING; and waits for the PONG. If that button answers, everything downstream will work.
  4. Read the firmware version shows your RFLink firmware, revision and build — the first thing to check when a device is decoded oddly.

Adding your devices​

A 433 MHz device is invisible until it transmits: there is no list to fetch, the integration builds one by listening.

  • A remote, a switch, a doorbell: press one of its buttons. Each button is a separate device in Gladys (RFLink reports it as a distinct SWITCH= unit).
  • A sensor (temperature, weather station...): wait for its next transmission — every 30 to 60 seconds for most, up to a few minutes.

The device then appears in the Discovery tab, named after what the gateway reported (for example NewKaku 000005 (unit 2)). Add it, rename it, and it starts recording its history. You can rename it freely: Gladys tracks it by its radio address, not by its name.

Your receiver also hears your neighbours. Two settings keep that under control:

  • Automatic discovery — turn it off once your own devices are added. Known devices keep working; only the learning of new ones stops.
  • Ignored protocols — a comma-separated list of RFLink protocol names to drop entirely, for the ones that flood your receiver (Oregon TempHygro, Cresta).

The Forget undiscovered devices action empties the Discovery tab of everything you have not created, so you can start the learning over in a clean state. Devices you already added are never touched.

A device you add shows its last known reading straight away — the integration heard it before you added it and hands the value over, timestamped when it was actually measured. No waiting for the next transmission.

Chips like EV1527, PT2262 and HS1527 are bare radio encoders: they transmit an address and four bits of data, and nothing more. The same chip sits in motion detectors, door contacts, smoke alarms, leak probes, doorbell buttons and wall plugs — and all of them produce the exact same frame:

20;2D;EV1527;ID=07a410;SWITCH=01;CMD=ON;

No software can tell them apart, because the information is not transmitted. RFLink reports them all as a switch, so your motion detector arrives as a switch. Use the Set a device type action to say what it really is:

  1. Add the device from the Discovery tab (it appears as a switch).
  2. Run Set a device type: pick the device, then its real type — motion detector, door contact, smoke detector, leak probe, vibration sensor, doorbell, button, siren, light, or a generic read-only sensor.
  3. Go back to the Discovery tab and press Update on that device.

That last step is Gladys refusing to rewrite one of your devices behind your back: changing a type changes the device structure, so it asks you to confirm. Your history is preserved — the feature keeps its identity through the change.

Motion detectors: the reset delay​

A PIR reports a detection but, on most cheap hardware, never reports the end of it. Left alone the feature would stay "on" for ever, no further change would happen, and no scene could ever trigger again. So a detection is automatically reset to off after a delay, which you can set per device in the same action:

TypeDefault reset
Motion, presence, smoke, leak60 s
Vibration30 s
Doorbell, button2 s
Door / window contact, switch, lightnever

A door contact is never reset: it transmits on opening and on closing, so resetting it would erase a door that is genuinely still open. Enter 0 to disable the reset and drive it yourself from a scene.

Somfy RTS roller shutters​

RTS devices are recognised on their own — a frame carrying CMD=UP, CMD=DOWN or CMD=STOP can only be a cover, so no type has to be declared. Press a button on your Somfy remote and the shutter appears in the Discovery tab with an open / stop / close control:

20;1E;RTS;ID=f1e260;SWITCH=01;CMD=DOWN;

Add it and it already works one way: every press on the physical remote is reflected in Gladys. Sending orders needs one more step.

Why you cannot just command the address you see​

RTS is a rolling-code protocol. Each transmission carries a counter that the motor checks and remembers, so a receiver only obeys a remote it has been introduced to, sending the next expected code. RFLink keeps its own counter per address, and that counter is not the one inside your handheld remote — replaying its address f1e260 does not work.

The way RTS is meant to be extended is to declare one more remote. RFLink becomes that extra remote, on an address of your choosing.

  1. Pick a free address you have not used before — six hexadecimal digits, for example 100001. Use a different one per shutter (100002, 100003…) and write them down.

  2. Take the Somfy remote that already drives the shutter and hold its PROG button (on the back, ~2-3 s) until the shutter jogs briefly. It is now waiting for a new remote, for a few seconds.

  3. In Gladys, run the Send a raw command action with:

    10;RTS;100001;0;PAIR;

  4. The shutter jogs again: it has accepted RFLink as a remote.

  5. Test it with 10;RTS;100001;0;DOWN; — the shutter should close.

  6. Send one more command (for example 10;RTS;100001;0;UP;) and the new virtual remote appears in the Discovery tab. Add it, name it after the room, and you have full control.

Repeat per shutter. To undo a pairing, put the motor back in programming mode with the PROG button and send PAIR again on the same address.

Two devices per shutter​

After pairing you have, in the Discovery tab, the address of your physical remote (f1e260, discovered by listening) and the address RFLink owns (100001). They are separate devices:

  • the physical remote's device reports what you do by hand — useful if you want a scene to react to someone pressing the wall remote;
  • RFLink's own address is the one that actually drives the motor.

If you only care about control, add the second one and use Forget undiscovered devices to clear the first.

RTS troubleshooting​

  • The shutter never jogs on PAIR. The motor was not in programming mode any more (the window is short — send the command within a few seconds), or the RFLink transmitter is out of range. RTS is 433.42 MHz, slightly off the usual 433.92: a standard RFLink transceiver works at short range, but a dedicated 433.42 MHz crystal is what gives full range.
  • It worked, then stopped. The rolling code is out of sync. Re-pair the same address, or pair a fresh one.
  • Checking what RFLink stores. 10;RTSSHOW; lists the rolling codes it keeps, 10;RTSCLEAN; wipes them — after which every paired address has to be paired again. Both go through Send a raw command.

The PAIR command and the RTSSHOW / RTSCLEAN helpers come from the RFLink protocol reference rather than from a test on real hardware here. The UP / DOWN / STOP control path is exercised end to end by the test suite.

Controlling a device​

Any device RFLink reports with a command (CMD=ON / CMD=OFF) gets an on/off control in Gladys, and one that reports a dim level also gets a brightness slider.

433 MHz is a one-way medium: the gateway transmits and no device answers. Gladys therefore records the state you asked for, and the physical device may be out of sync if it was out of range or if another remote acted on it. This is a property of the radio protocol, not a limitation of the integration.

Pairing a receiver (NewKaku and friends)​

A receiver has to learn the address it should obey, and that address has never been transmitted, so no discovered device exists yet. Use the Send a raw command action:

  1. Put the receiver in pairing mode (usually by holding its button until it blinks).
  2. Send a command on a free address, for example 10;NewKaku;00c142;1;ON;.
  3. The receiver memorizes it. Send the same command again and it appears in the Discovery tab like any other device.

The action accepts a single RFLink line starting with 10;, and rejects anything else.

Actions​

ActionWhat it does
Test the gatewaySends 10;PING; and waits for the PONG.
Read the firmware versionSends 10;VERSION; and shows firmware, revision and build.
Set a device typeDeclares what an EV1527-style device really is, and its reset delay.
Identify a deviceSwitches the chosen device on, then off, two seconds later.
Send a raw commandTransmits one RFLink 10;...; line (pairing, testing an address).
Forget undiscovered devicesEmpties the Discovery tab, keeping every device you created.

Troubleshooting​

The "Test the gateway" button times out. The bridge is not reachable. Check the address and the port with the nc command above, and make sure the bridge listens on the LAN interface and not only on 127.0.0.1.

The connection status keeps flapping. Something else is already connected to the bridge — RFLink accepts one client at a time. Stop the other consumer (Domoticz, a screen session, a second Gladys), or enable kickolduser in ser2net.

Nothing appears in the Discovery tab. Turn on Log raw frames in the configuration and watch the integration logs: you should see one RFLink <- line per transmission. No line at all means the gateway hears nothing (antenna, distance, wrong band). Lines full of garbage characters mean a wrong baud rate on the bridge.

A sensor changed identity by itself. Many 433 MHz sensors draw a new random ID when their batteries are replaced. The old device stops updating and a new one appears in Discovery; that is the sensor's behaviour, and every 433 MHz controller sees it the same way.

A temperature looks absurd. Report it with the raw frame (from the logs) in an issue: decoding is per-field, and an unusual protocol may need its own handling.

Two readings my sensor sends never show up. HSTATUS (a humidity comfort bucket) and BFORECAST (a crude barometric trend) are deliberately not exposed: both are values the sensor derives from a measurement it already sends, on a scale no Gladys category carries. They would appear as a nameless, iconless line next to the humidity they are computed from. Ask for them in an issue if you have a use for them.

For more detail, set LOG_LEVEL=debug on the integration container: every frame, every command and every reconnection is logged.

Configuration settings​

These are the settings RFLink asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Connect your RFLink gatewaysectionNoThis integration talks to the RFLink gateway over TCP. An RFLink32 board on ESP8266/ESP32 exposes its TCP server natively (port 1234). A USB RFLink plugged into the Gladys host must be bridged to TCP, for example with ser2net, because an integration container has no access to serial ports. See the documentation for the step by step.
Gateway addressstringYesIP address or hostname of the RFLink gateway on your network.
TCP portnumberYes1234 for RFLink32, or the port your serial bridge listens on.
Discovering your devicessectionNoA 433 MHz device is invisible until it transmits: press a remote button, or wait for a sensor to send its measurement, and it appears in the Discovery tab. Your receiver also hears your neighbours, so turn auto-discovery off once your devices are added.
Automatic discoverybooleanNoAdd every new device heard on the air to the Discovery tab. Known devices keep working when this is off.
Ignored protocolsstringNoComma-separated RFLink protocol names to drop entirely, for the ones that flood your receiver.
Log raw framesbooleanNoWrite every line received from the gateway to the logs. Useful while pairing a device, noisy the rest of the time.
  1. In Gladys, open Integrations: RFLink appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/philippema/gladys-rflink:1.0.2), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/PhilippeMA/gladys-RFlink.

RFLink requires Gladys >=4.86.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

RFLink is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by PhilippeMA, not by the Gladys core team.
