QNAP smart home integration, free and open source

QNAP integration for Gladys Assistant

Monitor a QNAP NAS (QTS, QuTS hero): CPU, memory, temperatures, fans, volumes, disks, UPS.

View on GitHubAll integrations

Follow a QNAP NAS running QTS or QuTS hero from Gladys: CPU, memory, temperatures, fans, network, volumes, disks and the UPS it shares, with scenes when a volume or a disk needs attention or a firmware update is out, and a dashboard widget.

The integration reads. The only thing it can do on the NAS is restart it or shut it down from a scene, and only once you allowed it in the configuration (off by default).

Developed without the hardware: feedback welcome. The integration reads the same web API as the Home Assistant integration and the qnapstats library, checked against real answers of nine QNAP models (QTS 4.2 to 4.5). If something is missing or wrong on yours, please open an issue: https://github.com/guim31/gladys-qnap/issues.

Not affiliated with QNAP. Not endorsed or sponsored by QNAP Systems, Inc. QNAP, QTS and QuTS hero are trademarks of their owners.

What you get​

After the configuration, the Discover tab proposes the following devices. Add the ones you want to follow: nothing is created on your behalf.

The NAS​

  • Online: 1 while the NAS answers, 0 once it stopped answering.
  • CPU and Memory: use, in %.
  • CPU temperature and System temperature, in °C (when the model gives them: some ARM models have no CPU sensor).
  • Fan 1 (rpm), Fan 2 (rpm)…: the speed of each system fan. Gladys has no "rpm" unit: the value is a plain number, the name says the unit.
  • Download and Upload of each network interface (Download LAN 1, Upload LAN 1…), in Mbit/s.
  • Uptime, in days.
  • Firmware version, e.g. 5.2.1.3000 build 20261001.
  • Update available: 1 when the NAS offers a newer firmware (checked every 6 hours; needs an administrator account, see below).

Volumes​

One device per volume (DataVol1…):

  • Space used, in %;
  • Capacity and Free space, in GB;
  • State: Ready, Rebuilding (a RAID rebuild, resynchronization or migration in progress), Degraded or abnormal;
  • Alert: 1 when the state needs attention, 0 otherwise — handy in scenes and in the history.

QTS gives a state code for each volume, and only the code of a ready volume is known for sure. Any other code shows as Degraded or abnormal and raises the alert: missing a degraded RAID is worse than a false alarm. The code is written in the logs: please report it with what QTS shows.

Disks​

One device per disk, its model as the model of the device:

  • Temperature, in °C;
  • State: the SMART summary of QTS — Good, Warning or Error;
  • Alert: 1 for Warning or Error.

The disks are read every 5 minutes at most, whatever the refresh interval.

The UPS​

When the NAS shares its UPS (see below), one more device:

  • Battery, in %;
  • Runtime, in minutes;
  • Load, in %;
  • On battery: 1 on battery, 0 on mains;
  • Low battery: 1 when the UPS says its battery is low.

Before you start​

A dedicated account​

Create an account on the NAS for Gladys (Control Panel → Privilege → Users), with no access to the shared folders and no application.

  • To read: on recent QTS and QuTS hero (with Delegated Administration), give that account the System Monitoring role. On older firmwares without delegated administration, the account has to be in the administrators group: QTS has no other read-only access to this information.
  • To check the firmware updates, restart or shut down: QTS only allows an administrator. With a System Monitoring account, everything else works; Update available stays without value and the scene actions are refused.

Log in once to the QTS web interface with that account and accept any agreement or wizard QTS shows first: until then, QTS may refuse it.

2-step verification​

The integration cannot type a 2-step verification code: use an account without 2-step verification. If your security policy forces it for every account, keep the NAS off the Internet, give the Gladys account a long random password and no other right, and limit the addresses allowed to reach the NAS (Control Panel → Security → Allow/Deny List) to your local network.

HTTP or HTTPS​

  • HTTP (port 8080 by default): QTS receives the password encoded in base64, which is not encryption. Fine on a home network you trust.
  • HTTPS (port 443 by default): the password is encrypted. The certificate QTS generates is self-signed: tick Accept a self-signed certificate, or install a certificate Gladys trusts (Let's Encrypt) on the NAS.

Sharing the UPS​

QTS has no documented way to read its UPS page. The integration reads the UPS the way other QNAP NAS do: with Network UPS Tools (NUT), port 3493.

  1. On the NAS: Control Panel → External Device → UPS, tick Enable network UPS support (network UPS master).
  2. Add the IP address of the machine that runs Gladys to the allowed IP addresses.

Nothing else is needed: reading the UPS needs no password. Without it, the integration simply finds no UPS.

Configuration​

  1. Open the Configuration tab of the integration.
  2. NAS address: its IP address on your network, e.g. 192.168.1.50: HTTP on port 8080. https://192.168.1.50 uses HTTPS on port 443; add a port when you changed it (https://192.168.1.50:5001).
  3. User name and Password of the account above. The password is never written in the logs.
  4. Accept a self-signed certificate: HTTPS only, see above.
  5. Refresh interval: every minute (default), 2 or 5 minutes.
  6. Read the UPS of the NAS: on by default; turn it off if the NAS has no UPS.
  7. Allow scenes to restart or shut down the NAS: off by default. Leave it off unless a scene really needs it.
  8. Language of the names and states: French by default. Gladys does not tell the integration your language: the feature names, the states and the scene variables use this one.
  9. Save, then use Test the connection: it reads the NAS and its UPS now and tells what it found, e.g. "NAS: connected, TS-464, QTS 5.2.1.3000 build 20261001, 1 volume(s), 4 disk(s), UPS read". Then add the devices from the Discover tab.

Dashboard widget​

Add the QNAP NAS widget to a dashboard: two gauges (CPU, memory), the temperature, then a list where what needs attention comes first (a volume, a disk, a fan in alert, the UPS on battery, a firmware update), then each volume with its use and free space, the UPS and the uptime. The Refresh button reads the NAS again. A NAS that does not answer is said in words.

Scene triggers​

  • Volume degraded: a volume goes Rebuilding, Degraded or abnormal; again if it gets worse. Filter: one volume, or every volume (empty). Variables: the NAS, the volume, its state.
  • Disk alert: QTS rates a disk Warning or Error; again if it goes from Warning to Error. Filter: one disk, or every disk. Variables: the NAS, the disk, its model, its state, its temperature.
  • Firmware update available: the NAS offers a newer QTS or QuTS hero; once per version. Variables: the NAS, the installed version, the new one.

These triggers work for every volume and disk, added to Gladys or not, and are not repeated after a restart of Gladys or of the integration. The state found at the very first read is recorded without any event.

Scene actions​

  • Restart the QNAP NAS and Shut down the QNAP NAS: refused unless Allow scenes to restart or shut down the NAS is ticked, and unless the account is an administrator. A NAS shut down must be turned back on by hand, or by Wake-on-LAN if you enabled it on the NAS.

Scene ideas​

  • A degraded RAID: trigger Volume degraded → send a message "{{triggerEvent.data.volume_name}} is {{triggerEvent.data.state}}" to the whole house, and turn a lamp red.
  • A disk getting tired: trigger Disk alert → message with the disk, its model and temperature, to order a spare before it fails.
  • Power cut: trigger "device state" on On battery = 1 → message; then, if Battery falls under 30 %, the action Shut down the QNAP NAS (with the option ticked). QTS can also shut itself down on its own UPS setting: prefer it when it fits.
  • Updates: trigger Firmware update available → message on Sunday morning with {{triggerEvent.data.new_version}}.
  • A NAS too hot: trigger "device state" on System temperature above 50 °C → message.

How often the NAS is read​

At every refresh, three requests to the web API of the NAS (system, volumes, network); the disks every 5 minutes; the firmware check every 6 hours; the UPS at every refresh (every 10 minutes while the NAS shares none). Only the values that changed are sent to Gladys, every value at least every 6 hours.

The integration keeps its session open between two reads and across restarts (stored under /data, never in the logs): it does not fill the connection log of the NAS with a login per minute. A refused password is never tried again on its own: QTS blocks an address after a few failed logins. Fix it, then save, or use Test the connection.

Troubleshooting​

  • "user name or password refused": check them by logging in to the QTS web interface. Too many failed logins may have blocked the address of Gladys: Control Panel → Security → IP Access Protection.
  • "this account uses 2-step verification": use an account without it.
  • "this account may not read the system": give it the System Monitoring role, or put it in the administrators group.
  • "HTTPS certificate refused": tick Accept a self-signed certificate.
  • "no QTS interface at this address": check the port (Control Panel → General Settings → System Port; HTTPS port under Web Server/Security).
  • "does not answer": is the NAS on, on the same network, and the address right?
  • No UPS: check the network UPS support of the NAS and that the address of the machine running Gladys is allowed. Test the connection says "UPS refused (allowed IP addresses?)" when the NAS refuses Gladys.
  • More detail: set LOG_LEVEL=debug on the integration to see every read in its logs.

Limits​

  • One NAS per installation of the integration.
  • Developed without the hardware: the volume state codes other than "ready" are not documented by QNAP. QuTS hero is expected to answer like QTS but was not tested.
  • The read-only role (System Monitoring) does not reach the firmware check; restart and shutdown need an administrator.
  • No control of applications, shared folders, snapshots, Container Station or virtual machines.
  • The disks without SMART (some USB enclosures) and the expansion units may be missing or partial.
  • Gladys has no "rpm" unit: the fan speeds are plain numbers.

Configuration settings​

These are the settings QNAP asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your QNAP NASsectionNoGladys reads the NAS on your local network through the QTS web interface. Create a dedicated account without 2-step verification, enter it below, then add the NAS, volumes and disks from the Discover tab. Not affiliated with QNAP.
NAS addressstringYesIP address or name of the NAS: 192.168.1.50 (HTTP, port 8080 added), https://192.168.1.50 (HTTPS, port 443), or with another port.
User namestringYesA dedicated account with the System Monitoring role (delegated administration), or an administrator to restart or shut down.
PasswordsecretYesNever written in the logs. Prefer HTTPS: over HTTP, QTS receives it only base64-encoded.
Accept a self-signed certificatebooleanNoHTTPS only: the certificate QTS generates is self-signed. Tick only for a NAS on your local network.
Refresh intervalselectNo
Read the UPS of the NASbooleanNoWhen the NAS shares its UPS (network UPS support, port 3493) and lists the address of Gladys among the allowed IPs.
Allow scenes to restart or shut down the NASbooleanNoOff by default. Needs an administrator account. A shutdown NAS must be turned back on by hand (or Wake-on-LAN).
Language of the names and statesselectNoGladys does not tell the integration your language: the feature names, the states and the scene variables use this one.

How to install QNAP in Gladys​

  1. In Gladys, open Integrations: QNAP appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-qnap:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-qnap.

QNAP requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

QNAP is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
