Qingping integration for Gladys Assistant

Qingping air monitors and thermometers via the Qingping cloud: CO₂, particles, VOC, temperature.

View on GitHubAll integrations

Overview​

This integration brings your Qingping air monitors and thermometers into Gladys, through the official Qingping cloud API — the cloud the Qingping+ app uses. Every device of your Qingping account becomes a Gladys device with what it measures: temperature, humidity, CO₂, PM2.5, PM10, VOC, noise, pressure, battery, and the age of the latest reading.

On top of the values, it gives you a readable air quality level (Good, Moderate, Poor, Very poor) with the pollutant behind it, a dashboard widget, scene triggers when the air quality changes or a device stops reporting, and a scene action to read the air quality in words.

Models it is meant for: Qingping Air Monitor Lite, Air Monitor 2, CO₂ Temp & RH Monitor, the Wi-Fi thermo-hygrometers (with or without probe), the Lee Guitars hygrometer, and the Bluetooth sensors synced through a Qingping gateway or the app. Any device the API returns is supported: the features follow the metrics it reports.

Developed without the hardware: feedback welcome. The integration was written from the Qingping API documentation and the open-source clients of the community, and tested against a simulated cloud. If something looks wrong with your device, please open an issue on github.com/guim31/gladys-qingping/issues.

This integration is not affiliated with Qingping (Qingping Technology / ClearGrass). Qingping is their trademark.

Requirements​

  • Gladys Assistant 5.1.0 or later.
  • Your devices added in the Qingping+ app, in Qingping mode (a device paired in HomeKit mode does not upload to the Qingping cloud).
  • A free developer access on developer.qingping.co, with the same account as the app.
  • Gladys must reach the Internet (oauth.cleargrass.com and apis.cleargrass.com, HTTPS).

Configuration​

Getting the App Key and App Secret​

  1. Add your devices in the Qingping+ app and check that they show values there.
  2. Log in to developer.qingping.co with the account of the app (same region).
  3. Open Access Management (direct link) and copy the App Key and the App Secret. It is free.

Settings​

  • App Key and App Secret: copied from Access Management. The secret is stored by Gladys and never written to the logs.
  • Cloud reading: Automatic (recommended) reads the cloud right after each upload the devices are expected to make, from their report interval. A fixed interval (5 minutes to an hour) can be chosen instead.
  • Language of the device features: the names given to the features when you add a device (they are frozen afterwards), and the language of the texts sent to scenes. French by default.

Click Test the connection: the result lists your devices and the age of their latest reading. Then open the Discovery tab and add the devices you want.

How often the values change. The cloud only knows what the devices uploaded. An air monitor on battery uploads every 15 minutes by default (the report interval of the Qingping+ app); plugged in, it can upload every minute. A Bluetooth thermometer uploads when the app or a gateway syncs it. Reading the cloud more often brings no fresher value, so in automatic mode the integration reads it once per expected upload — never more than every 2 minutes, never less than every hour. One request reads every device of the account.

Quotas. Qingping publishes no request quota for its open API. The integration makes one token request about every 2 hours (the token is kept in /data, so a restart does not ask for a new one) and one request per reading — about 100 a day with a 15-minute report interval. When the cloud answers "too many requests" it waits at least 15 minutes, or longer if the cloud asks.

Devices​

One Gladys device per device of your Qingping account, named as in the Qingping+ app. Its identity is its MAC address: renaming it in the app keeps it in Gladys.

Features​

Each device gets the features of the metrics it reports, all read-only:

FeatureUnitModels
Temperature°Call
Probe temperature°Cthermometers with an external probe
Humidity%all
CO₂ppmair monitors, CO₂ monitor
PM2.5µg/m³air monitors
PM10µg/m³air monitors
VOCppbAir Monitor (first generation)
VOC index1–500Air Monitor 2 (100 = the room's usual air)
NoisedBAir Monitor 2
PressurekPathermometers with a barometer
Battery%battery devices
Reading ageminall: minutes since the device's latest upload

Reading age tells a stable value from a frozen one: if it grows past twice the report interval, the device stopped uploading (battery, Wi-Fi, out of range). The device badge then turns "unreachable".

A metric a device starts to report later (a sensor warming up after a restart) adds its feature: Gladys then offers Update in the Discovery tab. A sensor that reports itself out of order or warming up publishes nothing, rather than a wrong value.

Air quality level​

Each monitor gets an air quality level, the worst of its pollutants:

LevelCO₂ (ppm)PM2.5 (µg/m³)PM10 (µg/m³)VOC (ppb)VOC index
Goodunder 800under 15under 45under 220under 150
Moderate800–99915–3445–99220–659150–249
Poor1000–199935–54100–199660–2199250–399
Very poor2000 and up55 and up200 and up2200 and up400 and up

The thresholds follow the indoor guide values of the German Environment Agency (CO₂, VOC), the WHO 2021 guidelines and the US EPA breakpoints (particles). To avoid flapping, a level only goes back down once the value is 5 % under the threshold it crossed. Temperature, humidity and noise do not count: they are comfort, not air quality. A thermometer has no air quality level.

Dashboard widget​

Qingping air quality: add it to a dashboard and pick a device, or leave the device empty to see all of them.

  • One device: its name, up to six tiles (CO₂, PM2.5, temperature, humidity, PM10, VOC…) colored by level, then the air quality in words with its cause (for example Poor · CO₂), the age of the latest reading, and the battery.
  • All devices: one line per device with its air quality, or its temperature and humidity for a thermometer.

A device that stopped uploading shows No recent reading instead of a frozen level. The widget works even before the devices are added to Gladys.

Scene triggers​

  • Air quality changed: the level of a monitor changed. Filters: the monitor, the new level, the direction (Getting worse or Getting better). Variables: monitor name, level, previous level, main pollutant, direction, CO₂ and PM2.5.
  • Device stopped reporting: no new reading for two report intervals (at least 30 minutes), or the Qingping cloud says the device is offline. Variables: device name, minutes since the last reading, offline for Qingping.
  • Device reporting again: a device that had stopped reporting sent a new reading. Variable: minutes without reading.

To react to a value crossing a threshold (CO₂ above 1200 ppm, temperature below 5 °C), use the usual Gladys trigger on the device feature: it already compares values.

Scene action​

Get the air quality: reads the air quality of a monitor from its latest reading (no request to the cloud) and gives the next actions of the scene: the level (code, number from 1 Good to 4 Very poor, and label), the main pollutant, CO₂, PM2.5, the minutes since the reading and whether the reading is recent. Use it in a message ("Air in the bedroom: {level}") or in a "continue only if" condition.

Configuration actions​

  • Test the connection: reads the cloud now and lists the devices with the age of their reading.
  • Set the report interval: changes how often an air monitor uploads (1 minute to 1 hour). The device applies it at its next upload, and the integration follows the new pace. A short interval drains the battery much faster: keep 15 minutes on battery. The other devices (thermometers) are set in the Qingping+ app.

Scene examples​

  • Ventilate the bedroom: trigger Air quality changed, monitor Bedroom, new level Poor and Very poor, direction Getting worse → send a message "Open the bedroom window: {main pollutant} is high", or turn on the ventilation.
  • Air is good again: trigger Air quality changed, new level Good, direction Getting better → turn the ventilation off.
  • Check the monitor: trigger Device stopped reporting → send a message "{device name} has not reported for {minutes} min: battery or Wi-Fi?".
  • Morning report: every day at 7:00 → Get the air quality of the bedroom → send "Bedroom air: {level}, CO₂ {co2} ppm".

Troubleshooting​

  • "App Key or App Secret refused": copy both again from Access Management, without spaces, then save. Check you logged in to developer.qingping.co with the account of the app.
  • Connected, but no device: the devices must be in the Qingping+ app of the same account, in Qingping mode (not HomeKit). A device only paired in HomeKit does not reach the Qingping cloud.
  • Values do not move: look at Reading age. If it grows, the device does not upload (battery, Wi-Fi, gateway). If it stays low, the values are just stable.
  • A feature is missing: wait for a reading where the sensor reports it (a CO₂ sensor warms up for a few minutes after a restart), then click Update on the device in the Discovery tab.
  • More detail: set LOG_LEVEL=debug on the integration to see every reading in its logs. The App Secret and the token never appear there.

Limits​

  • Cloud only: the integration reads the Qingping cloud, never the devices on your network. Without Internet, the values stop (the devices keep their own history in the cloud).
  • The values are as fresh as the uploads of the devices: 15 minutes by default on battery.
  • Read-only: the only setting the integration changes is the report interval of the air monitors, on demand.
  • A history gap while Gladys was off is not filled back: only the latest reading is read.
  • The devices that the Qingping cloud does not expose (HomeKit mode, some Bluetooth-only sensors without a gateway) cannot appear.
  • Developed without the hardware nor an account: the API answers were reconstructed from the Qingping documentation and community clients. Report anything odd on github.com/guim31/gladys-qingping/issues.

Configuration settings​

These are the settings Qingping asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your Qingping accountsectionNoFree. Log in to developer.qingping.co with your Qingping+ app account, open Access Management and copy the App Key and App Secret. Devices must be bound in the Qingping+ app (Qingping mode, not HomeKit).
App KeystringYesThe App Key shown in Access Management on developer.qingping.co.
App SecretsecretYesThe App Secret next to the App Key. Kept by Gladys, never written to the logs.
Cloud readingselectNoAutomatic: right after each upload the devices are expected to make (their report interval, set in the Qingping+ app). Reading faster brings no fresher value.
Language of the device featuresselectNoNames given to the features when a device is added, and language of the scene texts.

How to install Qingping in Gladys​

  1. In Gladys, open Integrations: Qingping appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-qingping:1.0.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-qingping.

Qingping requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Qingping is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
