pyLoad smart home integration, free and open source

pyLoad integration for Gladys Assistant

Follow and control pyLoad: speed, queue, free space, pause, failed files, new links.

View on GitHubAll integrations

Follow and control pyLoad from Gladys: the free download manager for direct links and file hosts, often run on a NAS or a home server (Docker, Unraid, Synology…). The integration talks to the local API of pyLoad: the speed, the queue and the free space show on the dashboard, a scene can pause the downloads during a video call, and Gladys can tell you when a download is finished, when a file failed or when the queue is empty.

Tested against real pyLoad 0.5.0b3.dev96 and dev101 installs, not yet in a real Gladys: feedback welcome on GitHub.

Requirements​

  • Gladys 5.1.0 or later.
  • pyLoad 0.5 (the pyload-ng package, or the linuxserver/pyload-ng Docker image), reachable from the Gladys server (same network). The old pyLoad 0.4 is not supported.
  • pyLoad 0.5.0b3.dev101 or later (2025): an API key. Create it in pyLoad: Settings → Users, the menu of your user, Manage API Keys. It starts with pl_.
  • Older pyLoad 0.5 (before dev101): the user name and password of the web interface (pyload / pyload until you change them).
  • The user needs the pyLoad permissions List (read the queue), Status (pause, free space) and, for the scene actions, Modify (restart the failed files) and Add (add links). An administrator has them all.

Configuration​

Up to two servers, each with:

  • Address: the IP address or name, with the port: 192.168.1.10:8000. Without port, 8000 is added. Write https:// for HTTPS, and the path if pyLoad sits behind a reverse proxy (https://nas.example.org/pyload). The address copied from the browser works too.
  • API key, or User name and Password for the older versions.
  • Name: the name of the device in Gladys (empty: pyLoad followed by the address).

Options:

  • Accept self-signed certificates: for an https:// address with a certificate of its own. Tick it for your own servers only.
  • Refresh interval: how often pyLoad is read, 30 seconds by default. It is also the delay of the triggers.
  • Allow adding links: lets the scenes add links to download (off by default: whoever can edit a scene could then start a download).
  • Language of the device texts: the names given to the features when a device is added, and the status texts (French by default).

The Test the connection button reads every server and says what it found: version, state, queue, failed files.

Devices​

One device per server, found in the Discovery tab. Its features:

FeatureWhat it shows
Downloads pausedswitch: on pauses pyLoad until you turn it off, off resumes it.
Automatic reconnectionswitch: the reconnection of pyLoad (new IP address from the router) on or off.
Download speedin MB/s.
Active downloadsthe files downloading now.
Files in the queuethe files of the queue not finished, failed ones included (pyLoad's "queue").
Files in totalevery file of pyLoad, queue and collector (pyLoad's "total").
Failed filesthe files that failed, or whose link is offline.
Free disk spacein GB, of the download folder.
StatusDownloading, Paused, Waiting (files queued, none downloading), Idle, Unreachable.
Last downloadthe name of the last package completed.

Pausing pyLoad starts no new download: the files already downloading finish (it is pyLoad's own pause). Sizes and speeds are binary units, like pyLoad shows them (1 MB = 1024 × 1024 bytes). Only the changes are sent to Gladys, and every value again after 6 hours.

Widget​

The pyLoad downloads widget shows the speed, the queue and the time left of every server (or of the one chosen in its settings), and one line per server: its state (with the end of a timed pause), the files downloading with their percentage, the failed files, the free space and the last download. Four buttons:

  • Pause: pauses pyLoad until you resume it;
  • Pause 30 min: pauses it for 30 minutes;
  • Resume: resumes it;
  • Retry failed: tries the failed files again.

The check mark shows the current state: on Pause when everything is paused, on Resume when everything runs.

Scene triggers​

  • Download completed: every file of a package is downloaded. Filter: the server. Variables: package name, number of files, size in MB, server name.
  • File failed: a file failed to download, or its link is offline (dead link, 404). Filter: the server. Variables: file name, package name, the reason given by pyLoad, server name.
  • Queue empty: nothing is left to download, the last file of the queue finished or failed. Filter: the server. Variable: server name.

Each package and each file fires once (a file restarted that fails again fires again). What happened while the integration was stopped (an update, a restart) fires when it starts again.

There is no "low disk space" trigger: the Free disk space feature is a value, and the device trigger of Gladys already compares it with a threshold ("Free disk space below 20 GB").

Scene actions​

  • Pause downloads: one server or all of them, for a number of minutes (0: until resumed). The integration resumes pyLoad at the end (pyLoad has no timed pause of its own). Outputs: number of servers paused, duration.
  • Resume downloads: one server or all of them.
  • Restart failed files: tries the failed files again, on one server or all of them.
  • Add links to download: http(s) or ftp links, separated by spaces (50 at most), as one package, on the chosen server (empty: the first one). The package name is optional (empty: the name of the first file). Only when Allow adding links is ticked. Output: the package id.

The integration never deletes a file or a package, and never restarts pyLoad.

Scene examples​

  • Video call: when the calendar event "Meeting" starts, Pause downloads for 60 minutes.
  • Night: at 1 am, Resume downloads; at 8 am, Pause downloads until resumed.
  • Notification: on Download completed, send "{{triggerEvent.data.name}} is downloaded" to your phone.
  • Problem: on File failed, send the file name and the reason; then Restart failed files after an hour.
  • Energy: on Queue empty, turn off the NAS plug a few minutes later.

Troubleshooting​

  • "does not answer": check the address and the port (8000), and that the Gladys server can reach pyLoad (firewall, Docker network).
  • "login refused": pyLoad 0.5.0b3.dev101 and later only accept an API key; the older versions a user name and password. Correct, then save. The integration does not try again on its own: each refused login writes an error in the pyLoad log.
  • "the pyLoad user lacks a permission": give the user the permissions listed in Requirements.
  • "no pyLoad 0.5 at this address": wrong port, or a pyLoad 0.4.
  • "certificate refused": tick "Accept self-signed certificates", or use http://.
  • "too many requests": pyLoad answers 100 API calls a minute per address at most; a refresh costs 3 or 4. Choose a longer refresh interval if other tools read pyLoad too.
  • A link added by a scene that fails at once with "Refusing to download from Server-Side host": pyLoad refuses the addresses of your own network (a protection of pyLoad).
  • More details: the integration logs, with LOG_LEVEL=debug for every reading.

Limits​

  • Each refresh reads the whole queue of pyLoad (every file): every 30 seconds by default.
  • The pause of pyLoad lets the files already downloading finish.
  • The Automatic reconnection switch shows the option of pyLoad within its time window: outside the window set in pyLoad, it reads off.
  • A timed pause relies on the integration: if it is stopped at the end of the pause, pyLoad is resumed as soon as it starts again.
  • Not affiliated with the pyLoad team.

Configuration settings​

These are the settings pyLoad asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Your pyLoadsectionNopyLoad (pyload-ng 0.5) on your network: an API key, or a user name and password for the versions before 0.5.0b3.dev101. Up to two servers. Never deletes a file.
AddressstringYesIP address or name, with :port (8000 by default). https:// for HTTPS.
API keysecretNopyLoad 0.5.0b3.dev101 or later: Settings, Users, Manage API Keys (pl_…).
User namestringNoOlder pyLoad (before dev101), without API key: the login of the web interface.
PasswordsecretNoWith the user name only.
NamestringNoName of the device in Gladys. Empty: pyLoad followed by the address.
Second server (optional)sectionNoSame fields, for another pyLoad.
AddressstringNoIP address or name, with :port (8000 by default). https:// for HTTPS.
API keysecretNopyLoad 0.5.0b3.dev101 or later: Settings, Users, Manage API Keys (pl_…).
User namestringNoOlder pyLoad (before dev101), without API key: the login of the web interface.
PasswordsecretNoWith the user name only.
NamestringNoName of the device in Gladys. Empty: pyLoad followed by the address.
OptionssectionNo
Accept self-signed certificatesbooleanNoFor a pyLoad served in HTTPS with its own certificate (common on a NAS).
Refresh intervalselectNoHow often pyLoad is read: also the delay of the triggers.
Allow adding linksbooleanNoLets the scenes add links to download. Off by default: whoever can edit a scene could then start a download.
Language of the feature namesselectNoNames given to the features when a device is added, and the status texts.

How to install pyLoad in Gladys​

  1. In Gladys, open Integrations: pyLoad appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-pyload:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-pyload.

pyLoad requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

pyLoad is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
