PrusaLink smart home integration, free and open source

PrusaLink integration for Gladys Assistant

Follow your Prusa 3D printers locally with PrusaLink: progress, temperatures, alerts.

View on GitHubAll integrations

Follow your Prusa 3D printers from Gladys through PrusaLink, the local web interface built into the firmware of the recent Prusa printers (and installed on a Raspberry Pi for the MK3S+). Everything stays on your local network: Gladys talks to the printer directly, no Prusa Connect account is needed.

Developed without the hardware: feedback welcome. The integration was built from the PrusaLink API description, the Home Assistant integration and its recorded answers, and tested against a simulator that authenticates like the printer firmware. It has not been tried on a real printer yet: tell us on the Gladys forum how it goes on yours.

Requirements​

  • Gladys Assistant 5.1 or later.
  • A Prusa printer with PrusaLink: MK4, MK4S, MK3.9, MK3.5, Core One, XL or MINI+ with a firmware 5.0 or later (6.x recommended), connected to your network by Wi-Fi or Ethernet; or an MK3S+ with PrusaLink on a Raspberry Pi.
  • PrusaLink enabled on the printer: Settings → Network → PrusaLink. The same screen shows the password (user maker).
  • The printer reachable from the Gladys machine (same network, or routed).

Configuration​

  1. On the printer, open Settings → Network: note its IP address, enable PrusaLink and note its password. A fixed IP address (a DHCP reservation in your router) avoids losing the printer later.
  2. In Gladys, open the Configuration tab of the integration.
  3. In Printer address, enter the IP address, for instance 192.168.1.60 (a port is allowed: 192.168.1.60:8080). Prefer an IP address: prusa-mk4.local names do not resolve inside the integration container.
  4. Leave User empty (the printer user is always maker). Only PrusaLink on a Raspberry Pi lets you choose another one in its setup wizard.
  5. In PrusaLink password, paste the password shown by the printer. Very old firmwares use an API key instead: paste it in the same field, the integration tries both.
  6. Save. The status of the Configuration screen turns to connected after the first answer of the printer.
  7. A second or third printer: fill Printer 2 and Printer 3 the same way.
  8. Language sets the language of the feature names and texts the integration creates (French by default). Feature names are set when the device is added to Gladys.

Then add the printer from the Discover tab.

The printer device​

One device per printer, named after the printer name set in PrusaLink, or its host name. The integration reads the printer every 10 seconds during a print and every 30 seconds otherwise (Home Assistant reads it every 30 seconds): the printer is a small web server, it is not read more often.

FeatureWhat it shows
StateIdle, Ready, Busy, Printing, Paused, Attention required, Finished, Stopped, Error, Printer unreachable, Password missing or refused
FileThe file being printed (its full name, benchy.bgcode), or "No file"
ProgressPercentage of the print (0 without a job)
Elapsed timeIn minutes
Time leftEstimated by the printer, in minutes (0 when no print runs)
Nozzle, BedTemperatures, in whole degrees
… (target)Setpoints, read only
Print speedThe speed factor set on the printer, in percent (100 % = normal)
FilamentThe filament type loaded (PLA, PETG…), when the printer tells it
Pause, ResumePush buttons
CameraThe camera image, only for PrusaLink on a Raspberry Pi with a camera (the Core One and MK4 cameras send their images to Prusa Connect only, PrusaLink has no access)

There is deliberately no cancel button on the device: one tap without confirmation would ruin a print. Cancelling is offered by the widget (with a confirmation) and by the scenes. The temperatures and setpoints are read only, and the integration sends no heating command at all: a printer heater can never be turned on from Gladys, nor through HomeKit, Alexa or Google. They are "device temperatures" for Gladys, so they never count in the temperature of the room.

When the printer starts telling its filament type, or a camera appears, Gladys offers to update the device in the Discover tab.

Dashboard widget​

Add the 3D printer widget to a dashboard and pick the printer in its settings. It shows:

  • the progress gauge, the time left, the nozzle and bed temperatures (live);
  • the camera image if there is one, otherwise the thumbnail of the file being printed;
  • the state, the message of the printer when something is wrong, the file, the elapsed time, the time the print should end, the active setpoints, the speed and the filament;
  • the buttons that fit the moment: Pause or Resume and Cancel (asks for confirmation) during a print. When the printer requires attention, only Cancel: the answer is given on the printer.

Scene triggers​

Under the Integrations category of the scene editor. Each can be limited to one printer.

  • Print started — variables: printer name, file.
  • Print finished — variables: printer name, file, print time (text, like 1 h 05 min, and in minutes).
  • Print failed or cancelled — can be limited to a reason (cancelled, error). Variables: printer name, file, print time, reason, printer message.
  • Print paused — from the printer, PrusaLink, Prusa Connect or Gladys. Variables: printer name, file, elapsed time.
  • Attention required — the printer waits for someone: filament runout, a question on its screen. Variables: printer name, file, elapsed time, printer message.
  • Printer error — the printer entered its error state, during a print or not (an error during a print also fires Print failed). Variables: printer name, file, elapsed time, printer message.

The variables are read in the following actions with, for instance, {{triggerEvent.data.file}} and {{triggerEvent.data.duration}}.

Scene actions​

  • Pause, resume or cancel a print — returns Applied: false when there was nothing to pause, resume or cancel (the scene goes on). Cancelling cannot be undone: choose it on purpose.
  • Read the printer state — returns a ready-made Sentence to send or say ("Prusa MK4: Printing, benchy.bgcode, 37 %, 1 h 05 min left."), and the values to test in the following actions: state (printing, paused, finished…), state as shown, file, progress, time left in minutes.

Scene examples​

  • Print finished → notification: trigger Print finished, action "Send a message": {{triggerEvent.data.file}} done in {{triggerEvent.data.duration}}.
  • Filament runout → call someone: trigger Attention required, action "Send a message": The printer needs you: {{triggerEvent.data.message}}.
  • Smoke detected → stop the print: trigger on the smoke detector, action Pause, resume or cancel a print (cancel), then turn the printer's smart plug off.
  • Where is my print?: a "Read the printer state" action, then "Send a message" with its sentence, on a button or every hour during a print.

Troubleshooting​

  • PrusaLink does not answer: check that PrusaLink is enabled on the printer, and the address from the Gladys machine (curl http://192.168.1.60/api/version answers 401 without password: the printer is reachable). Use an IP address rather than a .local name.
  • User or password refused: copy the password again from Settings → Network → PrusaLink (it changes if you regenerate it on the printer). Leave User empty unless PrusaLink runs on a Raspberry Pi.
  • The values move slowly: the printer is read every 10 seconds during a print, every 30 seconds otherwise. A print shorter than that may be seen only when it ends.
  • No filament type: older firmwares do not tell it; the feature then does not exist.
  • No camera image: only PrusaLink on a Raspberry Pi gives a camera image; it must be a JPEG or PNG of about 110 KB at most (a Gladys limit).
  • Logs: in the integration page of Gladys, or docker logs on the host. LOG_LEVEL=debug shows the detail. The password never appears in the logs.

Limits​

  • Up to three printers.
  • No file upload, no print start from Gladys, no temperature or G-code command, no time-lapse, no Prusa Connect (cloud).
  • A print that goes back to Idle or Ready without showing Finished or Stopped (screen cleared while the printer was unreachable) fires no end trigger.
  • The printer is read, not pushed: an event lasting less than 10 seconds may be missed.
  • The XL reports a single nozzle temperature.
  • Developed without the hardware: feedback welcome.
  • Not affiliated with Prusa Research. Prusa, Original Prusa and PrusaLink are trademarks of Prusa Research a.s.

Configuration settings​

These are the settings PrusaLink asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Connect your Prusa printerssectionNoEnable PrusaLink on the printer (Settings > Network > PrusaLink), then enter its IP address and the password it shows. Works with the MK4, MK4S, MK3.9, MK3.5, Core One, XL and MINI+ (firmware 5 or later), and the MK3S+ with PrusaLink on a Raspberry Pi. Up to three printers. Everything stays on your network.
Printer addressstringYesThe IP address shown on the printer (Settings > Network). A port is allowed (192.168.1.60:8080).
UserstringNoLeave empty for maker, the user of every printer with PrusaLink built in.
PrusaLink passwordsecretNoOn the printer: Settings > Network > PrusaLink. Older firmwares: the API key.
Printer 2 (optional)sectionNo
Printer addressstringNoThe IP address shown on the printer (Settings > Network). A port is allowed (192.168.1.60:8080).
UserstringNoLeave empty for maker, the user of every printer with PrusaLink built in.
PrusaLink passwordsecretNoOn the printer: Settings > Network > PrusaLink. Older firmwares: the API key.
Printer 3 (optional)sectionNo
Printer addressstringNoThe IP address shown on the printer (Settings > Network). A port is allowed (192.168.1.60:8080).
UserstringNoLeave empty for maker, the user of every printer with PrusaLink built in.
PrusaLink passwordsecretNoOn the printer: Settings > Network > PrusaLink. Older firmwares: the API key.
OptionssectionNoLanguage of the names and texts the integration creates (feature names are set when a device is added).
LanguageselectNo
  1. In Gladys, open Integrations: PrusaLink appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/guim31/gladys-prusalink:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/guim31/gladys-prusalink.

PrusaLink requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

PrusaLink is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
