Proxmox integration for Gladys Assistant

Proxmox VE backups per node (last run, duration, status) and the state of every VM and LXC.

• Published by prohand
• Devices
• Version 1.0.3
• Requires Gladys >=4.86.0
• ★ 0

View on GitHubAll external integrations

Monitor the backups of your Proxmox VE nodes from Gladys — when the last one ran, how long it took and whether it succeeded — the SMART health and temperature of their disks, plus the running state of every virtual machine and LXC container.

This integration is strictly read-only. It performs GET requests on the Proxmox VE API and nothing else — it never starts, stops, migrates, deletes or reconfigures anything.

What you get

After installation, one Gladys device appears per Proxmox node, named Proxmox <node>, carrying three read-only features about its last backup (a Proxmox vzdump task):

Feature	Type	What it holds
Last backup	Text	When the last backup started, in your time zone and in the date format you chose — e.g. 16/08/2026 11:25:04. Holds unknown when the node has no backup.
Backup duration	Integer sensor	How long that backup ran, in seconds. Kept in history, so you can chart it and trigger scenes on it.
Backup status	Text	OK, or failed — followed by what Proxmox said — e.g. failed — command 'lvcreate' failed: exit code 5.

Unless you turn Disk monitoring off, the same device also carries the state of the physical disks of that node:

Feature	Type	What it holds
SMART status	Text	OK (3 disks) when every disk passes, failed — /dev/sdb: FAILED when one does not, unknown when no verdict was readable.
Disk <name> temperature	Temperature sensor	One sensor per disk found when the node was discovered — Disk sda temperature, Disk nvme0n1 temperature — in °C, kept in history.

And one Gladys device per virtual machine and per LXC container, named Proxmox <name> (<vmid>):

Feature	Type	What it holds
Status	Text	The Proxmox state word, as it comes: running, stopped, paused, suspended…

Why text and not on/off sensors? Proxmox answers with a word or with a whole error line, and a binary feature can only say "not on": a paused VM read exactly like a stopped one, and a failed backup told you nothing about why — you had to open the Proxmox task log to find the full datastore. The text features carry the answer itself. A switch is also the shape Gladys draws for an actuator, which these read-only readings never are.

Whether a backup counts as a success is still yours to set: with the default OK only, a run that ended in WARNINGS: 2 publishes failed — WARNINGS: 2; switch What counts as a successful backup to OK and warnings and the same run publishes OK.

A node with no backup inside the observation window publishes unknown on Last backup and on Backup status, and leaves Backup duration unknown rather than showing a 0 s backup that never happened. A drive that reports no temperature is left the same way — no 0 °C that would read like a measurement. Templates never become devices, and a guest that disappears (deleted, or no longer visible to the token) keeps its last known state instead of being shown as stopped.

The natural Gladys usage is a scene triggered on those texts: when "Backup status" on pve1 is not "OK", notify me, or when "Status" of my NAS VM is not "running", notify me. Backup duration is the historized one, so it is the one you can chart.

Several backup jobs

Proxmox is read per node, not per job. However many jobs you schedule (the VMs at 02:00, the containers at 04:00, one job per storage…), the three features always describe the most recent finished vzdump task of that node, whichever job produced it. A job covering guests spread over several nodes runs one task per node, so each node device reports its own share of it — and a job still running is not reported at all until it ends, the previous one staying on screen in the meantime.

What follows from it: a later job overwrites the verdict of an earlier one. If the 02:00 job fails and the 04:00 one succeeds, Backup status reads failed — … for two hours, then OK. That is what a scene triggered on the change of the status catches — the recommended shape here — whereas a value read once a day at noon would see the successful job only. The failed run itself never disappears from the Proxmox task log.

There is no per-job device today: if you need each job followed separately, open an issue saying so.

Two Proxmox servers

The configuration has two identical blocks: fill in the second one and the integration monitors a second, completely independent Proxmox — its own host, its own API token, its own TLS settings and its own node filter. Everything below (permissions, TLS, actions) applies to each of them separately.

Devices of the second server are named after its own label, so nothing collides: a node called pve1 on both servers shows up as Proxmox pve1 and Proxmox 2 pve1, and a VM 101 on each shows up twice as well. Set Name of this Proxmox on either block to name them yourself (Home, Office…).

If you only have one Proxmox, leave the second block empty and nothing changes.

---

Required Proxmox permissions (read-only)

This is the part worth getting right. The integration needs two audit (read) privileges, and nothing else:

Privilege	On path	Why
Sys.Audit	/nodes (or /)	Read the task log of the nodes, their status and their disks.
VM.Audit	/vms (or /)	See the virtual machines and containers, and their state.

Nothing else. No Datastore.*, no Sys.Modify, no VM.PowerMgmt, no Sys.Console, no root access, no shell access.

Which endpoints are called

Endpoint	Method	Privilege required
/api2/json/nodes	GET	none (any authenticated token)
/api2/json/nodes/{node}/tasks	GET	Sys.Audit on /nodes/{node} *
/api2/json/nodes/{node}/status	GET	Sys.Audit on /nodes/{node}
/api2/json/nodes/{node}/disks/list	GET	Sys.Audit on /nodes/{node} †
/api2/json/nodes/{node}/disks/smart	GET	Sys.Audit on /nodes/{node} †
/api2/json/cluster/resources?type=vm	GET	VM.Audit on /vms/{vmid} *

* Important subtlety. Both lists are permission-filtered, not permission-refused. Without Sys.Audit on /nodes/{node}, Proxmox answers 200 OK with only the tasks the token itself started — which, for a token that never starts anything, is an empty list. Without VM.Audit, the guest list comes back empty the same way. So an under-privileged setup does not look broken: the backup features simply stay unknown forever, and no VM appears. That is why the Test the connection button probes /nodes/{node}/status (which does return 403) and tells you exactly which nodes are missing the privilege, and how many guests the token can actually see.

† Only called when Disk monitoring is on. Those two, unlike the lists above, are refused with a 403: a token without Sys.Audit gets unknown on the SMART status, and Test the connection names the nodes it could not read.

Option A — the built-in PVEAuditor role (simplest)

PVEAuditor is Proxmox's own read-only role. It grants Sys.Audit and VM.Audit plus the other audit privileges (Datastore.Audit, Pool.Audit, SDN.Audit, Mapping.Audit, VM.GuestAgent.Audit). It is read-only by construction — it contains no *.Modify, no *.Allocate, no *.PowerMgmt, no Sys.Console — but it is broader than what this integration uses.

In the Proxmox web UI:

1. Datacenter → Permissions → Users → Add
   • User name: gladys, Realm: Proxmox VE authentication server (pve)
   • Set a password (it is never used by the integration, but Proxmox requires one)
2. Datacenter → Permissions → Add → User Permission
   • Path: / — User: gladys@pve — Role: PVEAuditor — Propagate: ✔
3. Datacenter → Permissions → API Tokens → Add
   • User: gladys@pve — Token ID: tasks
   • Privilege Separation: keep it checked (see the note below)
   • Proxmox now shows the secret once — copy it, it is never shown again
4. Datacenter → Permissions → Add → API Token Permission
   • Path: / — API Token: gladys@pve!tasks — Role: PVEAuditor — Propagate: ✔

Or, from a shell on any node:

pveum user add gladys@pve --password "$(openssl rand -base64 24)"
pveum acl modify / --users gladys@pve --roles PVEAuditor

## Prints the secret once — copy it into Gladys.
pveum user token add gladys@pve tasks --privsep 1
pveum acl modify / --tokens 'gladys@pve!tasks' --roles PVEAuditor

Granting on / (rather than on /nodes and /vms separately) is the simplest form and stays read-only: the role itself is what limits the token.

Option B — a minimal custom role (least privilege)

If you would rather grant only what is actually used, create a role holding Sys.Audit and VM.Audit and nothing else:

pveum role add GladysBackupAudit --privs "Sys.Audit,VM.Audit"

pveum user add gladys@pve --password "$(openssl rand -base64 24)"
pveum acl modify /nodes --users gladys@pve --roles GladysBackupAudit
pveum acl modify /vms   --users gladys@pve --roles GladysBackupAudit

pveum user token add gladys@pve tasks --privsep 1
pveum acl modify /nodes --tokens 'gladys@pve!tasks' --roles GladysBackupAudit
pveum acl modify /vms   --tokens 'gladys@pve!tasks' --roles GladysBackupAudit

This is the tightest configuration the integration can run on.

About privilege separation

When a token is created with privilege separation (--privsep 1, the default and the recommended setting), its effective permissions are the intersection of the user's permissions and the token's own ACL. So the pveum acl modify lines above are all needed: some for the user, some for the token.

Creating the token with --privsep 0 makes it inherit the user's permissions directly and skips the token ACLs — but it also means the token can do everything the user can, forever. Prefer privilege separation.

Verifying

Use the Test the connection button in the integration's Configuration tab. It reports, node by node, whether the token can actually read the task log, how many VMs and containers it can see, and names the missing privilege when something is denied.

You can also check by hand:

curl -sS --insecure \
  -H "Authorization: PVEAPIToken=gladys@pve!tasks=YOUR-SECRET" \
  "https://192.168.1.10:8006/api2/json/nodes/pve1/tasks?typefilter=vzdump&limit=5"

curl -sS --insecure \
  -H "Authorization: PVEAPIToken=gladys@pve!tasks=YOUR-SECRET" \
  "https://192.168.1.10:8006/api2/json/cluster/resources?type=vm"

---

Configuration

The first six fields below exist twice: once for the first Proxmox, once for the optional second one. The last six are shared by both.

Field	Required	Default	Notes
Name of this Proxmox	no	Proxmox	Prefixes the name of every device of that server. Second block defaults to Proxmox 2.
Proxmox host	yes	—	IP or hostname of any node — one node answers for the whole cluster. A pasted URL works too, see below.
API port	no	8006	The Proxmox VE API port.
API token ID	yes	—	The full user@realm!tokenname form, e.g. gladys@pve!tasks.
API token secret	yes	—	The value Proxmox shows once. Stored encrypted by Gladys, never sent back to your browser.
TLS certificate fingerprint	no	empty	SHA-256 fingerprint of the node certificate. See below.
Verify the TLS certificate	no	on	Leave on. See below.
Nodes to monitor	no	all	Comma-separated node names, e.g. pve1, pve2. Also scopes the VMs/LXC reported.
How far back to look for a backup	no	7 d	The last backup is searched inside this window.
What counts as a successful backup	no	OK only	Whether a backup that ended with WARNINGS: n still counts as successful.
Time zone	no	host	IANA zone used to render the timestamp, e.g. Europe/Paris.
Date format	no	16/08/2026 11:25:04	How that timestamp is written: day-first, month-first, ISO, or ISO followed by the time zone.
Disk monitoring (SMART)	no	SMART status and temperatures	What is read from the physical disks — see below.
Refresh interval	no	300 s	How often Proxmox is read, between 60 s and one hour.

Proxmox host takes a host name or an IP address, but the address you have in front of you is the one in your browser — so a pasted URL is accepted as well: https://pve.lan:8006/#v1:0:18 is read as the host pve.lan on port 8006. The scheme, the path and any credentials are dropped, and the port written in the address wins over the API port field.

Only the first server's host and token are mandatory: the whole second block is optional. How far back to look for a backup, What counts as a successful backup, Time zone, Date format, Disk monitoring and Refresh interval are configured once and apply to every server.

The time is always shown on a 24-hour clock, and the time zone is not repeated on the tile — you know the one you live in. Pick the last Date format option if you do want it printed, for instance when the Proxmox and the person reading the dashboard are not in the same country.

Disk monitoring

Disk monitoring has three settings:

• SMART status and temperatures (default) — the health verdict of every disk, and one temperature sensor per disk. Reading the verdicts is one request per node; the temperatures cost one more request per disk, each of which runs a smartctl on the Proxmox side.
• SMART status only — the verdicts, and nothing else. One request per node, no smartctl per drive.
• Off — the disks are never read, and the node devices carry their backup features only.

Both reads need Sys.Audit on /nodes, exactly like the backups — Test the connection tells you how many disks the token can read, and names the nodes where it cannot. A disk with no SMART verdict (a controller smartctl knows nothing about, a USB enclosure) is counted apart rather than reported as failing, and a node whose disk list cannot be read at all reports unknown without ever costing that node its backup features.

The temperature sensors are created when the node is discovered. Add or replace a disk, and it gets its own sensor at the next scan (Discovery tab, or a configuration save).

Gladys itself cannot ask for a refresh less often than once a minute, so the integration holds the extra wait: it is called every minute and reads Proxmox only when the interval you set has elapsed. In between, nothing is published and the values already on the dashboard stay as they are.

A device you have just added from the Discovery tab is the exception: it is read right away rather than at the next tick, so it carries its backup — or its status — as soon as it appears, without you pressing Refresh now.

TLS: the self-signed Proxmox certificate

Out of the box, a Proxmox node serves a self-signed certificate, which no container trusts. You have three options, best first:

1. Pin the fingerprint (recommended). Paste the node's SHA-256 fingerprint into the TLS certificate fingerprint field. The connection is then encrypted and authenticated, without any public certificate authority. Find the fingerprint in the UI under Node → System → Certificates → pveproxy-ssl.pem, or from a shell:

   openssl x509 -in /etc/pve/local/pveproxy-ssl.pem -noout -fingerprint -sha256
   # falls back to the node's own certificate when no custom one is installed:
   openssl x509 -in /etc/pve/local/pve-ssl.pem -noout -fingerprint -sha256

   Any format is accepted (AA:BB:CC…, aabbcc…, with or without spaces).

   Note that the fingerprint changes when the certificate is renewed or replaced — update the field then, or switch to option 2.

2. Install a trusted certificate on the node (Let's Encrypt through the Proxmox ACME support, or your own CA installed in the container's trust store). Leave both TLS fields at their defaults.

3. Turn Verify the TLS certificate off. Last resort, on a trusted LAN only: the traffic stays encrypted, but nothing proves the server you reach is really your node — and the API token secret travels on that connection.

What counts as a successful backup

Proxmox records a finished backup with one of these statuses, and Backup status publishes:

Proxmox status	Meaning	"OK only" (default)	"OK and warnings"
OK	success	OK	OK
WARNINGS: 3	finished, with warnings	failed — WARNINGS: 3	OK
anything else	error string	failed — <the error>	failed — <the error>
(empty)	no exit status — worker crashed	failed — no exit status (worker crashed?)	failed — no exit status (worker crashed?)

A backup that completed but skipped a guest ends in WARNINGS: n. Choose OK and warnings if you consider those good enough.

Only finished backups are read (Proxmox's archived task list): a backup still running is not the last backup yet.

Actions

• Test the connection — checks that the host answers, that the API token is accepted, that it can actually read the task log of every monitored node, how many VMs/LXC it can see and how many disks it can read the SMART data of. Run this first whenever something looks wrong.
• Refresh now — reads the backups, the disks and the VM/LXC states immediately, instead of waiting for the next refresh.

Both run on every configured server, and prefix each result with [<name>] when there are two — so a message like [Office] Proxmox refused the API token (401) tells you which one to fix.

Troubleshooting

"Proxmox refused the API token (401)" — the token ID or the secret is wrong. The ID must be the full user@realm!tokenname form (gladys@pve!tasks), not just the token name. If you lost the secret, delete the token and create a new one: Proxmox only shows it once.

"the token cannot read the task log of: …" — the token is missing Sys.Audit on those nodes. Re-read the permissions section above; with privilege separation on, remember that both the user and the token need the ACL.

"No VM or LXC is visible" — the token is missing VM.Audit (on /vms, or on /). The guest list is filtered rather than refused, so an under-privileged token simply sees nothing.

"Last backup" stays unknown while the Proxmox UI shows backups — either the missing Sys.Audit privilege above (run Test the connection), or a window shorter than your backup schedule: a node backed up every two weeks reports nothing with the default 7-day window. Raise How far back to look for a backup.

"Backup status" reads failed — WARNINGS: 2 while the backup looks fine — the backup ended with warnings (a guest was skipped, a hook returned non-zero…). The text after failed — is Proxmox's own words: open that task in the Proxmox UI to see why, or switch What counts as a successful backup to OK and warnings, and such a run will read OK.

A VM I deleted is still listed — the Gladys device stays until you delete it in Gladys; the integration stops publishing states for it, so it simply freezes on its last value.

"Proxmox presents a self-signed certificate" — pin its fingerprint, see the TLS section above.

"Cannot resolve the host name …" — the name in Proxmox host could not be looked up (EAI_AGAIN, ENOTFOUND). Check its spelling, and that the machine running the integration resolves it — a short .local/LAN name often only resolves on the network it comes from, where the IP address always works.

"… refused the connection" — the host answers but nothing listens on that port: check the API port (8006 by default).

"Cannot reach …" — check the host and the port (8006), and that the Gladys container can reach the node on your network. With two servers configured, the message names the one that did not answer; the other keeps being refreshed normally.

Two devices with the same name — both servers use the same label. Set Name of this Proxmox on at least one block. Renaming a server changes the names of the devices it discovers from then on; devices Gladys already created keep the name you see in Gladys and can be renamed there.

The devices of my second server disappeared from the dashboard — emptying the second block stops it from being monitored, but its Gladys devices remain, frozen on their last known value, until you delete them in Gladys.

Timestamps are off by a few hours — set the Time zone field to your IANA zone (Europe/Paris, America/New_York…). Left empty, the integration uses the time zone of the machine Gladys runs on, which is often UTC inside a container. Date format decides how that date is written, and whether the zone is printed next to it.

"SMART status" stays unknown — the token cannot read /nodes/{node}/disks/list (run Test the connection: it names the nodes), or smartctl has no verdict for those drives — a RAID controller hiding its members, a USB enclosure. Disks behind a hardware RAID controller are not visible to Proxmox at all.

A disk has no temperature sensor — it was added after the node was discovered: run a new scan from the Discovery tab, or save the configuration. A drive that reports no temperature at all (some SAS and USB drives) publishes nothing rather than a fake 0 °C.

The integration logs everything it does: check the integration logs from the Gladys UI (or docker logs on the host), with LOG_LEVEL=debug for the full detail. The API token secret is never logged.

Privacy and security

• Read-only by construction. The client only implements GET; there is no code path in this integration that writes to Proxmox.
• The API token secret is stored encrypted by Gladys, is never returned to the browser (it is a secret config field), and is never written to the logs.
• The integration talks to nothing but your Proxmox host: no cloud service, no telemetry, no outbound call of any kind.

Configuration settings

These are the settings Proxmox asks for in its configuration screen in Gladys.

Setting	Type	Required	Description
First Proxmox server — read-only API token	section	No	This integration only READS Proxmox: the backup task log of the nodes, and the state of the VMs/LXC. Create a dedicated user, give it the built-in PVEAuditor role on / (Sys.Audit on /nodes and VM.Audit on /vms), then add an API token to that user. With privilege separation enabled, the token needs the same ACL as its user. Full step-by-step in the Documentation link below.
Name of this Proxmox	string	No	Prefixes the name of every device of this server, e.g. "Proxmox pve1". Leave empty to use "Proxmox". Renaming it here does not rename the devices Gladys already created.
Proxmox host	string	Yes	IP address or hostname of a Proxmox VE node (any node of the cluster answers for all of them).
API port	number	No	HTTPS port of the Proxmox VE API. The default Proxmox port is 8006.
API token ID	string	Yes	Full token id, in the user@realm!tokenname form, as shown by Proxmox when the token is created.
API token secret	secret	Yes	The secret value Proxmox shows ONCE when the token is created. Stored encrypted by Gladys and never sent back to the browser.
TLS certificate fingerprint	string	No	Recommended with the default self-signed Proxmox certificate: pin its SHA-256 fingerprint (Datacenter > Certificates > pveproxy-ssl.pem). Leave empty when the node serves a certificate signed by a public CA.
Verify the TLS certificate	boolean	No	Turn OFF only as a last resort, on a trusted LAN: the connection stays encrypted but nothing proves the server is the real one. Pinning the fingerprint above is the safe way to accept a self-signed certificate.
Nodes to monitor	string	No	Comma-separated node names. Leave empty to monitor every node the token can see. VMs and LXC are filtered the same way: only the guests running on those nodes are reported.
Second Proxmox server (optional)	section	No	Leave this block empty if you only have one Proxmox. Filled in, it monitors a second, fully independent server: its own host, its own API token and its own TLS settings, read the same way and needing the same PVEAuditor privileges. Its nodes and its VMs/LXC show up as their own Gladys devices, so a node called pve on both servers stays two distinct devices.
Name of this Proxmox	string	No	Prefixes the name of every device of this server, e.g. "Proxmox 2 pve1". Leave empty to use "Proxmox 2". Renaming it here does not rename the devices Gladys already created.
Proxmox host	string	No	IP address or hostname of a node of the SECOND Proxmox VE installation. Leave empty if you only have one.
API port	number	No	HTTPS port of the Proxmox VE API. The default Proxmox port is 8006.
API token ID	string	No	Full token id of the second server, in the user@realm!tokenname form.
API token secret	secret	No	The secret value the second Proxmox shows ONCE when the token is created. Stored encrypted by Gladys and never sent back to the browser.
TLS certificate fingerprint	string	No	Recommended with the default self-signed Proxmox certificate: pin its SHA-256 fingerprint (Datacenter > Certificates > pveproxy-ssl.pem). Leave empty when the node serves a certificate signed by a public CA.
Verify the TLS certificate	boolean	No	Turn OFF only as a last resort, on a trusted LAN: the connection stays encrypted but nothing proves the server is the real one. Pinning the fingerprint above is the safe way to accept a self-signed certificate.
Nodes to monitor	string	No	Comma-separated node names. Leave empty to monitor every node the token can see. VMs and LXC are filtered the same way: only the guests running on those nodes are reported.
Backups and display	section	No	These settings apply to every configured Proxmox server.
How far back to look for a backup (days)	number	No	The last backup is looked for inside this window. A node with no backup in it reads "unknown" on "Last backup" and "Backup status", and publishes no duration at all. Raise it if your backup jobs run less often than that.
What counts as a successful backup	select	No	Proxmox marks a finished backup OK, WARNINGS: n (it completed but skipped something), or with an error string. Choose whether a backup that ended with warnings still reads "OK" on the "Backup status" feature, or "failed — WARNINGS: n".
Time zone	string	No	IANA time zone used to render the "Last backup" timestamp (Europe/Paris, America/New_York...). Leave empty to use the time zone of the Gladys host.
Date format	select	No	How the "Last backup" timestamp is written. The time is always shown on a 24-hour clock, in the time zone above — which is only printed on the tile if you pick the last option.
Disk monitoring (SMART)	select	No	Adds a "SMART status" feature to every node, and one temperature sensor per physical disk. Reading the health costs one request per node; the temperatures cost one more per disk, each running a smartctl on the Proxmox side. Needs Sys.Audit on /nodes, like the backups. Add or replace a disk? Re-run a scan so its sensor appears.
Refresh interval (s)	number	No	How often Proxmox is read, in seconds.

How to install Proxmox in Gladys

1. In Gladys, open Integrations: Proxmox appears in the catalog, next to the native integrations, with a community badge.
2. Click Install. Gladys pulls the Docker image (ghcr.io/prohand/gladys-proxmox:1.0.3), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
3. Open the Configuration screen of the integration, fill in the settings, and save.
4. You can also install it directly from its repository URL: https://github.com/prohand/gladys-proxmox.

Proxmox requires Gladys >=4.86.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations

Proxmox is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by prohand, not by the Gladys core team.

• Browse all external integrations
• Discover the native integrations built into Gladys
• Build and publish your own external integration
• Source code on GitHub — source of this documentation

Subscribe to the Gladys Assistant newsletter

A few emails per month about new releases and project news. Sent by Pierre-Gilles Leymarie, founder of the project. Unsubscribe anytime 🙂
