Proxmox Backup Server smart home integration, free and open source

Proxmox Backup Server integration for Gladys Assistant

Read-only monitoring of Proxmox Backup Server datastores and maintenance tasks.

View on GitHubAll integrations

This integration only calls PBS API GET routes. It cannot start, alter, prune, or delete backups or jobs.

Exact read-only permissions​

Grant the built-in DatastoreAudit role (Datastore.Audit) on /datastore, and the built-in Audit role (Sys.Audit) on /system so the task history can be read. Do not grant any datastore write, backup, prune, verify, or admin role.

proxmox-backup-manager user create gladys@pbs --password 'A_LONG_UNIQUE_PASSWORD'
proxmox-backup-manager user generate-token gladys@pbs monitoring
proxmox-backup-manager acl update /datastore DatastoreAudit --auth-id gladys@pbs --propagate true
proxmox-backup-manager acl update /datastore DatastoreAudit --auth-id 'gladys@pbs!monitoring' --propagate true
proxmox-backup-manager acl update /system Audit --auth-id gladys@pbs --propagate true
proxmox-backup-manager acl update /system Audit --auth-id 'gladys@pbs!monitoring' --propagate true

PBS API tokens use separate ACL entries by design; generate-token does not accept a --privsep option. Effective token permissions are the intersection of the parent user's permissions and the token's own permissions, hence the matching ACLs. Replace /datastore with /datastore/NAME in both datastore commands to restrict monitoring to one store. Enter the full token ID and the one-time secret in Gladys.

TLS and the self-signed PBS certificate​

Use an https:// URL. An http:// URL is accepted, but the API token then travels in clear text on the network at every refresh: anyone able to read that traffic can reuse it.

PBS ships a self-signed certificate, which the container does not trust. From the best option to the worst:

  1. Pin the fingerprint (recommended). Paste the server's SHA-256 fingerprint into the TLS certificate fingerprint field. Only a server presenting exactly that certificate is accepted, and the fingerprint is checked before the token is sent: a server impersonating PBS never receives it. Find the fingerprint in the PBS web interface (Dashboard → Show Fingerprint) or in a shell on PBS:

    proxmox-backup-manager cert info | grep -i fingerprint

    Separators and case do not matter (AA:BB:… or aabb…). The fingerprint changes when the certificate is renewed or replaced: update the field then. A pinned fingerprint requires an https:// URL and takes precedence over Verify TLS certificate.

  2. A certificate signed by a trusted authority (for example ACME / Let's Encrypt configured on PBS): leave the fingerprint empty and keep Verify TLS certificate on.

  3. Turn Verify TLS certificate off, as a last resort and on a trusted network only: the connection stays encrypted, but nothing proves the server is the real one, and the token is sent to whoever answers.

The refresh interval defaults to 15 minutes. It cannot be set below 5 minutes to limit growth of the Gladys database, and it can be increased up to 24 hours.

The general Date format dropdown controls all task dates. It offers ISO 8601, day/month/year, year-month-day, and month/day/year formats.

The Time zone field sets the zone dates are shown in, as an IANA name such as Europe/Paris (summer and winter time are handled). It defaults to UTC; an empty or unknown value also falls back to UTC. In ISO 8601, a zone other than UTC adds its offset, for example 2026-09-23T23:30:01+02:00.

After changing and saving the date format or the time zone, open the affected PBS device in Gladys and save it again to apply the change.

Exposed features​

Each PBS datastore is exposed as one Gladys device with these read-only features:

The three capacity values (Usage, Total size, and Used space) are mapped to the Gladys data/size capability while retaining their percent or gigabyte unit.

FeatureValueDescription
UsagePercentageUsed datastore capacity, rounded to two decimal places.
Total sizeGigabytesTotal datastore capacity, rounded to two decimal places.
Used spaceGigabytesUsed datastore capacity, rounded to two decimal places.
Snapshot countIntegerNumber of snapshots currently stored, summed over the backup groups.
Last verify statusTextLatest verification status, for example OK.
Last verify dateTextLatest verification date, in the configured format.
Last garbage collection statusTextLatest garbage collection status, for example OK.
Last garbage collection dateTextLatest garbage collection date, in the configured format.
Last prune statusTextLatest prune status, for example OK.
Last prune dateTextLatest prune date, in the configured format.
Backup stale (> 26 h)0 or 11 when no snapshot exists or the newest snapshot is older than 26 hours.

Dashboard widgets, scene triggers, and scene actions (Gladys 5.1)​

These require Gladys 5.1.0 or later. They only read PBS: no button, trigger, or action can start, change, or delete anything on the server.

Dashboard widgets​

Add them from Dashboard → Edit → New widget, under Integration widgets.

WidgetSettingsContent
PBS datastoreOne datastore, show tiles (default: on)Usage gauge, free space, snapshot count, one card per verify/GC/prune task (date and result badge), last backup, used / total space, Refresh button.
PBS backupsNoneUsage of the fullest datastore, stale backups, failed tasks, one status row per datastore (up to 10), Refresh button.

The snapshot tile follows the device state live. The other tiles, the task cards, and the status rows are updated after each refresh. The Refresh button reads PBS again right away. Turn off Show usage, free space and snapshot tiles to hide the three tiles.

Scene triggers​

They show up in the scene editor, in the "Integrations" category. Each filter is optional: leave it empty to match any value.

TriggerFires whenFiltersVariables
PBS maintenance task finishedA verify, garbage collection, or prune task has ended.Datastore, task type, resultdatastore_name, task_type, result, status, date
New PBS backupA newer snapshot appeared on the datastore.Datastoredatastore_name, last_backup, snapshot_count
PBS backup is staleThe newest snapshot just became older than 26 hours.Datastoredatastore_name, last_backup, hours_since_backup
PBS unreachableA datastore refresh failed (once per outage).Datastoredatastore_name, error
PBS reachable againA datastore refresh succeeded after a failure.Datastoredatastore_name

result is ok, warning, or error; status is the raw PBS status, for example OK, WARNINGS: 2, or the error text.

  • Triggers fire once per change, never at every refresh. Example: a backup that stays stale fires PBS backup is stale only once.
  • Changes are detected by the scheduled refresh (the refresh interval). A refresh asked by a widget or a scene action never fires a trigger itself; the next scheduled refresh reports the change.
  • The first refresh after a start or a configuration change fires nothing: it sets the reference point.
  • If several tasks of the same type finish between two refreshes, only the newest is reported.

Scene actions​

ActionFieldsOutputs
Get PBS datastore statusDatastore (required), Read PBS now (default: off)datastore_name, usage_percent, used_gb, total_gb, snapshot_count, backup_stale, last_backup, hours_since_backup, last_verify_status, last_verify_date, last_gc_status, last_gc_date, last_prune_status, last_prune_date
Get PBS backup reportRead PBS now (default: off), report language (en/fr/de/es)datastore_count, stale_count, failed_task_count, unreachable_count, max_usage_percent, all_ok, summary
  • Without Read PBS now, the action answers from the last refresh and costs nothing on PBS.
  • summary is a ready-to-send text, one line per datastore. Example for a daily report: "Scheduled trigger" (every day at 8:00) → "Get PBS backup report" → "Send Message" with the summary output.
  • Example alert: "PBS maintenance task finished" filtered on result error → "Send Message": PBS {{triggerEvent.data.task_type}} failed on {{triggerEvent.data.datastore_name}}: {{triggerEvent.data.status}}.

Behaviour notes​

  • Snapshot count and backup freshness are read from the datastore's backup groups (backup-count and last-backup), so a datastore holding thousands of snapshots costs one small response per refresh. If a PBS release does not expose those counters, the integration falls back to listing the snapshots.
  • The task history is read with one filtered request per task type (verify, garbage collection, prune), so a busy datastore does not push them out of view and back to Never run, and a task type that never ran costs one empty answer. A PBS release that refuses the filter is read page by page instead (up to 2000 tasks).
  • The capacity of every datastore comes from one /status/datastore-usage read, shared by all the datastores refreshed within the same minute.
  • Datastores that are offline or unmounted report no capacity; the integration then publishes nothing for usage, total size, and used space (the last real values stay displayed) rather than a 0 that would look like an emptied datastore. Widgets show the capacity as unavailable.
  • Every request to PBS ends within 15 seconds, including an answer cut or stalled halfway, and answers larger than 8 MB are refused. The connection status names the cause: token refused (HTTP 401), missing role (HTTP 403), certificate, network, or timeout.
  • A refresh that fails (network error, timeout, PBS restart) is retried on the next one-minute Gladys tick instead of waiting a full refresh interval. At startup, the connection is retried four times with an exponential backoff before the integration reports itself as disconnected.
  • A refresh that PBS answered but Gladys could not store (Gladys restarting, for example) is retried on the next tick too; it is not reported as PBS unreachable.
  • A datastore deleted or renamed on PBS is dropped from the monitored list as soon as PBS stops listing it, without a PBS unreachable event, and no longer keeps the connection status red. Its device left in Gladys is looked up again after one refresh interval, then twice as long each time, up to once a day.
  • A device just added from the Discover tab is read right away instead of at the next refresh.

Checking which inventory route is used​

The integration prefers the cheap groups route and falls back to the full snapshot list; the fallback is logged as a warning in the integration's Logs tab (Falling back to the snapshot list for datastore ..., with the PBS error that caused it).

To check it against your server without installing anything in Gladys, run the read-only diagnostic from a clone of this repository:

PBS_URL=https://pbs.example.com:8007 \
PBS_TOKEN_ID='gladys@pbs!monitoring' \
PBS_TOKEN_SECRET='the-token-secret' \
npm run check:pbs

It prints, per datastore, the route actually used, how long each route takes, and the last verify/GC/prune task. It also cross-checks the snapshot count and the newest backup against the full snapshot list, and exits with code 1 if the two disagree. Add PBS_NODE=... for a node other than localhost, and PBS_FINGERPRINT=AA:BB:... for a self-signed certificate (or PBS_VERIFY_TLS=false on a trusted network).

The same routes can be checked by hand:

curl -sSf -H "Authorization: PBSAPIToken=gladys@pbs!monitoring:SECRET" \
  'https://pbs.example.com:8007/api2/json/admin/datastore/NAME/groups' | head -c 400

An HTTP 403 means the ACL is missing Datastore.Audit on that datastore; an HTTP 404 means this PBS release does not serve the route and the snapshot fallback is expected.

Configuration settings​

These are the settings Proxmox Backup Server asks for in its configuration screen in Gladys.

SettingTypeRequiredDescription
Proxmox Backup Server connectionsectionNoCreate a dedicated API token with the read-only DatastoreAudit and Audit roles. See the documentation for the exact commands.
Server URLstringYesFor example: https://pbs.example.com:8007. Avoid http://: it sends the API token in clear text.
API token IDstringYesFull ID, for example gladys@pbs!monitoring
API token secretsecretYes
PBS node namestringNo
Refresh interval (seconds)numberNo
TLS certificate fingerprintstringNoRecommended with the default self-signed PBS certificate: its SHA-256 fingerprint (Dashboard > Show Fingerprint). The token is only sent to a server presenting it. Leave empty for a certificate signed by a trusted CA.
Verify TLS certificatebooleanNoIgnored when a fingerprint is pinned. Turn off only as a last resort, on a trusted network: the connection stays encrypted but nothing proves the server is the real one.
Date formatselectNoSelect how task dates are displayed, in the time zone set below.
Time zonestringNoIANA name used to display dates, for example Europe/Paris. Empty or unknown: UTC.

How to install Proxmox Backup Server in Gladys​

  1. In Gladys, open Integrations: Proxmox Backup Server appears in the catalog, next to the native integrations, with a community badge.
  2. Click Install. Gladys pulls the Docker image (ghcr.io/prohand/gladys-proxmox-backup-server:2.6.1), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration).
  3. Open the Configuration screen of the integration, fill in the settings, and save.
  4. You can also install it directly from its repository URL: https://github.com/prohand/gladys-proxmox-backup-server.

Proxmox Backup Server requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.

Not running Gladys yet? It is free and open source: follow the installation guide to get started.

About external integrations​

Proxmox Backup Server is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by prohand, not by the Gladys core team.
