Prometheus smart home integration, free and open source
Your PromQL queries as Gladys sensors, and scenes when a Prometheus alert fires or resolves.
Published by guim31
- Devices
- Version 1.0.0
- Requires Gladys >=5.1.0
- ★ 0
Bring your Prometheus monitoring into Gladys: the PromQL queries you choose become sensors (a temperature, a disk usage, the power of a rack, targets up or down), a "Prometheus alerts" device counts the firing alerts by severity, and your scenes react when an alert fires or is resolved — a red light for a critical alert, a message for a full disk. With Alertmanager, a scene can also silence an alert for a while, and a dashboard widget lists the alerts in progress.
The integration reads the HTTP API of Prometheus (and of Alertmanager) on your local network. Nothing goes through a cloud.
Tested against a real Prometheus 3.15 and Alertmanager 0.34 (official Docker images, node-exporter, alerting rules, a silence created then expired). Feedback welcome: github.com/guim31/gladys-prometheus/issues.
What you need
- Gladys Assistant 5.1.0 or later.
- Prometheus 2.x or 3.x, reachable from the Gladys machine (port 9090 by default). Servers with the same query API (Thanos Query, VictoriaMetrics) should work too, untested.
- Optionally Alertmanager (API v2, port 9093 by default): it gives the silences, and the "Silence an alert" scene action. Without it, the alerts are read from the alerting rules of Prometheus.
- No account: Prometheus and Alertmanager have no authentication of their own. Behind a reverse proxy, a user and password (Basic) or a Bearer token.
Getting started
1. Configure the integration
In Gladys, open the configuration of the integration:
- Prometheus address: the address you open Prometheus with, e.g.
http://192.168.1.2:9090. A bare192.168.1.2gets port 9090; the URL of a page (…/graph?g0.expr=…) or a path prefix (https://example.com/prometheus) works too. - Alertmanager address (optional): e.g.
http://192.168.1.2:9093. - User (Basic), Password (Basic), Bearer token: only when a reverse proxy asks for them. The same credentials go to both servers; the token wins over the user and password.
- Refresh interval: 30 seconds by default, from 15 seconds to 5 minutes.
- Allow silencing from scenes: untick to turn off the silence action.
- Accept self-signed certificates: only for an
https://address whose certificate your browser does not trust either. - Language of the names: the language of the feature names and of the scene results.
Click Test the connection: it answers with the version of Prometheus, the queries and the firing alerts, or with what goes wrong.
2. Add your queries
Still in the configuration, the Add a query action asks for:
- Name: the name of the device, e.g.
NAS temperature. Adding a query with the same name again replaces it (same device). - PromQL expression: an instant query whose result is a number per series,
e.g.
node_hwmon_temp_celsius{chip="platform_coretemp_0"}, or100 - 100 * node_filesystem_avail_bytes{mountpoint="/"} / node_filesystem_size_bytes{mountpoint="/"}. A range vector (up[5m]) or a text is refused: wrap it inrate()oravg_over_time(). - Type: what Gladys shows. Number (no unit), Temperature (°C),
Percentage (%), Power (W), Energy (kWh), Data rate (bytes/s), Size (bytes),
Duration (seconds), or On/off (0 or 1) — the last one turns any non-zero
value into 1. Convert in PromQL when needed (
/ 1000for kWh from Wh). - Label naming the series (optional): when the query returns several
series, each one becomes a feature named after this label (e.g.
instance). Empty: the labels that differ from one series to the other.
The query is checked against Prometheus first: a PromQL error is answered with the message of Prometheus, and nothing is saved. Remove a query takes a name.
3. Add the devices
Open the Discover tab of the integration and add the devices to follow. The scene triggers work even if the alerts device is not added.
The devices
One device per query, with one feature per series, 20 at most. The name of a feature is set when the series is first seen, and Gladys keeps it once the device is added. A series seen later adds a feature: Gladys then proposes Update in the Discover tab. A series that disappears keeps its feature, without new values.
Prometheus alerts, from Alertmanager when its address is set, from the alerting rules of Prometheus otherwise (firing alerts only, not pending ones):
- Firing alerts: the alerts that fire and are not silenced nor inhibited;
- Critical alerts, Warning alerts, Info alerts: the same, by severity;
- Silenced alerts: the alerts silenced or inhibited in Alertmanager.
The severity comes from the severity label of the alert: critical,
error, page, high count as critical; warning, warn, average as
warning; info, none, low as info. Any other value counts in the total
only.
A device is marked unreachable while its server does not answer, and keeps its last values.
Dashboard
The Prometheus alerts widget shows the firing, critical and silenced alerts, then one row per firing alert, the most severe first, with its instance (or its summary). The Refresh button reads the servers again.
Scenes
Triggers
- An alert fires: a new firing alert. Filters: the alert name, and the severities (empty: any). A silenced alert is announced when its silence ends, if it still fires.
- An alert is resolved: an alert announced by the first trigger stops firing. Same filters, plus its duration in minutes.
Both give the scene: the alert name, the severity (in the language of the
names), the severity key (critical, warning, info, other), the
severity label as in Prometheus, the summary, the instance, all the labels
as text, and the fingerprint of the alert.
The alerts already firing when the integration starts the first time are not announced. An alert that fires or resolves while Gladys or the integration restarts is announced once it is back.
Actions
- Silence an alert (Alertmanager): creates a silence for an alert name,
and other labels if given (
instance=nas:9100, job=node), for 15 minutes to a week (1 hour by default). Results: the silence id, and the firing alerts it silenced. Give the other labels one by one (instance=…), not the variable holding all the labels. It can be turned off in the configuration. - Read the alerts: counts and lists the firing alerts, all or of one
severity. Results: firing, critical and warning alerts, highest severity,
and the alerts as text (
TargetDown (nas:9100), DiskFull). - Read a PromQL value: runs an expression once, without creating a device. Results: the value of the first series (0 when there is none), the number of series, and the values as text.
Scene ideas
- An alert fires, severity Critical → turn the hall light red and send "Alert: {alert name} on {instance}" to your phone.
- An alert is resolved → send "{alert name} resolved after {duration} minutes".
- A dashboard button "I'm on it" → Silence an alert with the name of the last alert, for 2 hours.
- Every morning → Read a PromQL value
sum(increase(node_network_receive_bytes_total[24h])) / 1e9and send "Yesterday: {value} GB downloaded".
Troubleshooting
- "does not answer": check the address and the port from the Gladys
machine (
curl http://192.168.1.2:9090/api/v1/status/buildinfo). Gladys runs the integration in a container on a bridge network:localhostis the container, not the host. - "access refused": the reverse proxy refuses the user, the password or the token.
- "certificate refused": tick Accept self-signed certificates.
- "the address redirects": enter the
https://address, or the one without the login page of a proxy. - "no Prometheus or Alertmanager API at this address": another service answers there; check the port.
- A query shows no value: Test the connection tells which query has no series for now. Try it in the Prometheus web interface (Graph tab).
- Logs: in Gladys, the integration page shows its logs. Add
LOG_LEVEL=debugfor every read.
Limits
- 20 queries, and 20 series per query. A query runs at every refresh: keep heavy queries to recording rules.
- The queries are stored in the data volume of the integration: reinstalling it from scratch loses them (add them again with the same names: same devices).
- Values are rounded to two decimals.
- Silences can be created, not removed: they end on their own, or in the Alertmanager interface.
- The alert filters of the triggers match exact values only: a threshold belongs to a query device and a scene condition.
- Tested with the test tools of the Gladys SDK, not yet in a real Gladys instance: feedback welcome.
Configuration settings
These are the settings Prometheus asks for in its configuration screen in Gladys.
| Setting | Type | Required | Description |
|---|---|---|---|
| Your Prometheus | section | No | Enter the address of Prometheus, and of Alertmanager to silence alerts. Then add your PromQL queries with "Add a query" below, and the devices to follow from the Discover tab. |
| Prometheus address | string | Yes | The address you open Prometheus with (port 9090 by default). |
| Alertmanager address (optional) | string | No | Empty: the alerts are read from Prometheus, without silences. |
| Authentication (optional) | section | No | Only when a reverse proxy protects Prometheus and Alertmanager: the same credentials are sent to both. |
| User (Basic) | string | No | |
| Password (Basic) | secret | No | |
| Bearer token | secret | No | Used instead of the user and password when filled. |
| Options | section | No | |
| Refresh interval | select | No | How often Prometheus is read: one request per query, plus the alerts. |
| Allow silencing from scenes | boolean | No | Untick to turn off the "Silence an alert" scene action. |
| Accept self-signed certificates | boolean | No | Only for an https:// address whose certificate your browser does not trust either. |
| Language of the names | select | No | Language of the feature names (set when a device is added) and of the scene results. |
How to install Prometheus in Gladys
- In Gladys, open Integrations: Prometheus appears in the catalog, next to the native integrations, with a community badge.
- Click Install. Gladys pulls the Docker image (
ghcr.io/guim31/gladys-prometheus:1.0.0), starts it in a sandbox isolated from the core, and generates the integration's interface (devices, discovery and configuration). - Open the Configuration screen of the integration, fill in the settings, and save.
- You can also install it directly from its repository URL: https://github.com/guim31/gladys-prometheus.
Prometheus requires Gladys >=5.1.0. The catalog inside Gladys refreshes every hour, so a new version becomes available at most one hour after its release.
Not running Gladys yet? It is free and open source: follow the installation guide to get started.
About external integrations
Prometheus is an external integration: a community integration packaged as a Docker container and published on GitHub, that Gladys installs in one click and runs in a sandbox isolated from its core. It is published and maintained by guim31, not by the Gladys core team.
